HH Electronics Tessen TNA-DF1 User manual

Designed and Engineered in the UK since 1968 © 2019 HH Electronics Ltd
ARRAY
TNA-DF1 - PORTABLE SYSTEM WHEELED DOLLY
WWW.HHELECTRONICS.COM
Thank you for purchasing the TNA-DF1 wheeled dolly frame for use with the TNA-1200S.
With its lightweight rugged design, heavy-duty castors (dual locking) the TNA-DF1 provides
effortless transportation of the TNA system.
The TNA-1200S is secured to the
TNA-DF1 using M8 x 20 hex bolts
included.
See TNA-1200S/TNA-2051 user manual for more information.
Brakes are to be engaged on the
rear wheels once the system has
been suitably positioned.
For added safety, it is strongly recommended that the audio connections and mechanical fixing are checked periodically.

Designed and Engineered in the UK since 1968 © 2019 HH Electronics Ltd
ARRAY
TNA-DF1 - PORTABLE SYSTEM WHEELED DOLLY
WWW.HHELECTRONICS.COM
W
D
H
In the interest of continued development, HH reserves the right to amend product specification without prior notification.
Model
TNA-DF1
Mounting Type
Five M8 mounting points hold the frame securely to the cabinet
Castors
100mm heavy duty PU castor. Two fixed, two omni-directional with brakes
Unit dimensions (HWD)
206 x 457 x 453mm, 8.1" x 18" x 17.8"
Unit weight
10.8Kg, 23.8 lbs
Carton dimensions (HWD)
160 x 520 x 520mm, 6.3" x 20.5" x 20.5" , 0.043 M3
Packed weight
12.9Kg, 28.4 lbs
