HH Cricket User manual

Active transfer: Sit to Stand
The Cricket is designed to enable quick and easy seated transfers and freewheeling around the home, school, community or hospital
care setting for clients who can weight bear for a short period. Transfers using the Cricket typically only requires one carer.
To transfer a client out of the Cricket, reverse the above procedure.
7
Instructions For Transfers
Move the Cricket from in front or behind
to freewheel to desired location.
Tip: Lead with the large castors,
particularly over door thresholds. The
small castors make it much easier to
move on thick carpets.
Guide the client to sit back down in the
seat. Once they are comfortable and
secure, release the brakes.
5
Whilst the client is standing, hook the
the back bars into position behind the
client. Ensure the seat is secure.
4
RX05240 Issue 13
With the client holding on to either the
side or front bars, support the client as
they stand on the footplate.
32
Move the Cricket under the client as far
as possible, placing feet on the footplate.
Apply brakes. Please see separate guide
on height adjustment.
Start with the back bars pointing
outwards and the seat hooked on one
side only.
1
6
The Cricket should be inspected before use in
accordance with the safety check list on page 3.
6
RA0560C - Cricket With Black Vinyl Upholstery
RA0550C - Cricket With Green Panache Upholstery
RA0002 - Cricket II With Black Vinyl Upholstery

The Cricket can be separated into two sections for
more compact storage / ease of transportation.
1. Release both clamping levers
2. If necessary, lift the upper half up until the
spring-buttons are engaged.
Printed on recycled paper
Guarantee
The Helping Hand Company guarantees the Cricket free from
manufacturing defects for 12 months from the date of delivery.
This guarantee does not cover general wear and tear, damage
resulting from misuse, accidental damage, use in vehicles or
fabric shrinkage due to incorrect washing.
The Helping Hand Company recommends the Cricket is serviced
annually to ensure it is in correct and safe working order.
clamp
lever
spring
button
Height Adjustment
Press both spring-buttons in at the same time
and pull the upper half out.
This operation may require two people.
3.
To prevent cross infection the Cricket should be thoroughly cleaned
between users.
The seat can be removed and machine washed at 40º using a
biological detergent.
Wash the frame using a diluted disinfectant.
Ensure that all parts are fully dry before use.
These instructions should be left with the user to consult as required.
Maximum patient weight: 140kg (22 stone)
Maximum patient height: 1.9m (6’3”)
Minimum patient height: 1.5m (4’11”)
Overall Dimensions H: 1020mm W:590mm D: 870mm
Cleaning
Specication
Tel [phone] Fax [phone] www.adlessentials.com
Bromyard Road, Ledbury, Herefordshire HR8 1NS

Black Vinyl Seat SRX052042
Black Vinyl Paediatric Seat SRX052044
The following parts are available to order:
Green Panache Seat SRX052041
Green Panache Paediatric Seat SRX052043
Cricket Cricket II
Spares
 

Back Pad SRX50500
Large Castor SRX05110
Small Castor SRX05080











Black Vinyl Kneepad SRX05440
Green Panache Kneepad SRX05450
Black Vinyl Kneepad RS0004





Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Date of Manufacture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
1
2
2
RX05240 Issue 13
The height of the Cricket should be adjusted to suit
each patient. The client’s kneecaps must be in the
middle of the knee pad.
1. Release both clamping levers.
2. Raise or lower the upper half of the Cricket to the
desired height. This can be at any point from the
bottom to the top stop.
If the spring-buttons are engaged, press both
buttons in at the same time to release. Do not set
the Cricket higher than the maximum position
indicated by the spring-button engagment.
3. Fully apply the levers once desired height is
achieved. Ensure the clamping is secure. If needed,
turn the adjustment knobs clockwise to increase the
clamping force before re-applying the levers.
Note the Cricket is shipped in its lowest position.
Separating The Cricket

Pre-use checklist and safety warning
1: Height adjustment levers tight
2 Castor brakes all function
3: Seat free from cuts, damage or loose stitches
4: Seat correctly tted - see illustration below
5: Seat hook ts securely to the arm of the Cricket
6: Backrest pads secure and undamaged
7: Knee pad secure and tted in the correct position
8: Footplate covering secure and clean
Daily pre-use checks:-
The height of the Cricket should be adjusted to suit
each patient. The client’s kneecaps must be in the
middle of the knee pad.
Note the Cricket is shipped in its lowest position.
1. Release both clamping levers.
2. Raise or lower the upper half of the Cricket to
the desired height.
If the spring-buttons are engaged, press both
buttons in at the same time to release.
Do not raise the Cricket higher than the
maximum position indicated by the
spring-button engagement.
3. Fully apply the levers once desired height
If needed turn the adjustment knobs clockwise
achieved. Ensure the clamping is secure.
to increase the clamping force before re-applying
the levers.
clamp
lever
spring
button
Adjustment
Separating The Cricket
Bromyard Road, Ledbury, Herefordshire, HR8 1NS
Tel: [phone] Fax: [phone]
Web: adlessentials.com
These Instructions should be left with the user to consult as required.
Safety warning
Only use as instructed. Ensure that users are familiar with these instructions with the operation before use.
* Do not use if any part is damaged
* Do not use the Cricket to transfer outdoors or in vehicles
* Only use on at level surfaces
* Ensure that both castor brakes are applied before transferring a patient to or from the Cricket
* Do not raise the height of the Cricket higher than allowed by the top spring button position
* Do not attempt to adjust the height of the Cricket while in use with a patient
Bromyard Road, Ledbury, Herefordshire HR8 1NS Tel [phone] Fax [phone] www.adlessentials.com
Note: The seat hook must
face outwards as illustrated,
with the labels at the back.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RX05240 Issue 13
B
A
C
K
