HIK VISION DS-2CD4025FWD-A User manual

0
Network Box Camera
Quick Start Guide
UD04345B
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

1
Network Box Camera·Quick Start Guide
Quick Start Guide
COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This Manual is applicable to 40xx/60xx Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective
owners.
1
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

2
Network Box Camera·Quick Start Guide
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE
LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
2
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

3
Network Box Camera·Quick Start Guide
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
3
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

4
Network Box Camera·Quick Start Guide
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
4
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

5
Network Box Camera·Quick Start Guide
Warnings Follow these
Cautions Follow these
safeguards to prevent
precautions to prevent
serious injury or death.
potential injury or material
damage.
Warnings
● Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
● In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
● Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
● Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
● Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
5
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

6
Network Box Camera·Quick Start Guide
● If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
● Make sure the power supply voltage is correct before using the
camera.
● Do not drop the camera or subject it to physical shock.
● Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
● Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
● The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
● Do not place the camera in extremely hot, cold (the operating
temperature shall be-30°C ~+60°C , or -40°C ~ +60°C if the
camera model has an “H” in its suffix), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
● To avoid heat accumulation, good ventilation is required for
operating environment.
● Keep the camera away from liquid while in use.
6
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

7
Network Box Camera·Quick Start Guide
● While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
● Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
● Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
● If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
0504051070109
7
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

8
Network Box Camera·Quick Start Guide
Table of Contents
1 Appearance Description ................................................................. 9
2 Installation.................................................................................... 13
2.1 Ceiling Mounting........................................................... 14
2.2 Wall Mounting .............................................................. 16
2.3 Installing the SD Card .................................................... 20
3 Setting the Network Camera over the LAN .................................. 21
3.1 Wiring ........................................................................... 21
3.2 Activating the Camera................................................... 22
3.2.1 Activation via Web Browser................................ 22
3.2.2 Activation via SADP Software ............................. 23
3.3 Modifying the IP Address .............................................. 25
4 Accessing via Web Browser .......................................................... 28
5 Operating via Hik-Connect App .................................................... 30
5.1 Enable Hik-Connect Service on Camera......................... 30
5.1.1 Enable Hik-Connect Service via SADP Software .. 30
5.1.2 Enable Hik-Connect Service via Web Browser .... 31
5.2 Hik-Connect Setup ........................................................ 33
5.3 Adding Camera to Hik-Connect ..................................... 33
5.4 Initializing the Memory Card ......................................... 35
8
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

9
Network Box Camera·Quick Start Guide
1 Appearance Description
The overview of the box camera is shown below:
Figure 1-1 Overview (1)
The overview of the components and the interface are shown below:
4
35
1
2
Figure 1-2 Overview (2)
The interfaces on the rear panel are shown below:
9
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

10
Network Box Camera·Quick Start Guide
8
6
910
7
18
16
11
17
14
13
15
12
Figure 1-3 Overview (3)
Table 1-1 Description
No.
Description
No.
Description
1
Lens Mount
2
MIC
3
¼ -20 UNC Screw Hole
4
Power Indicator
No.
Description
No.
Description
10
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

11
Network Box Camera·Quick Start Guide
5
Auto-iris Interface
6
LAN(PoE)
7
Power Outlet
8
Reset
9
Micro SD Card Slot
10
Video Out
11
Grounding
12
Alarm Out
13
RS-232
14
RS-485
15
Alarm In
16
Audio Out
17
ABF
18
Audio In
To reset the camera default parameters, you need to press and
hold the RESET button and power on the camera. After the
power on of the camera, you must still press and hold the Reset
button for about 20 seconds.
The type of auto-iris interface is shown as below figure:
Figure 1-4 Auto-iris Interface
Table 1-2 Pins
11
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

12
Network Box Camera·Quick Start Guide
No.
DC-driven
1
Damp-
2
Damp+
3
Drive+
4
Drive-
Power, Video and GND pins are used when the auto-iris is driven by
video; Damp+, Damp-, Drive+ and Drive- pins are used when the
auto-iris is driven by DC.
12
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

13
Network Box Camera·Quick Start Guide
2 Installation
Before you start:
● Make sure the device in the package is in good condition and all
the assembly parts are included.
● The standard power supply is 12V DC or 24V AC, please make
sure your power supply matches with your camera.
● Make sure all the related equipment is power-off during the
installation.
● Check the specification of the products for the installation
environment.
● Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
● Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
● Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
● The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.
13
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

14
Network Box Camera·Quick Start Guide
2.1 Ceiling Mounting
Steps:
1. Install the ceiling mount to the ceiling with the supplied expansion
screws.
Adjustable Nut
Figure 2-1 Install the Mount
2. Fit the lens (not supplied) to the camera and rotate it to get it
tightened.
 Install the adapter ring to the lens interface if a C-mount lens is
used.
 A manual-iris lens can be directly installed to the camera without
plugging the power cable of the auto-iris to the auto-iris interface.
14
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

15
Network Box Camera·Quick Start Guide
3. Plug the auto-iris cable to the auto-iris interface.
Figure 2-2 Install the Lens
4. Align the screw hole on the camera with the ceiling mount and
rotate the camera to get it fixed.
5. Adjust the surveillance angle.
1). Loosen the pan nut to adjust the pan angle [0°-360°].
2). Loosen the knob on the ceiling mount to adjust the tilt angle
[0°-90].
6. Adjust the Lens
1). Connect the VIDEO OUT interface of the camera to the
debugging monitor.
2). Adjust the Zoom Lever and Focus Level to obtain a perfect
image on the monitor.
15
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

16
Network Box Camera·Quick Start Guide
Knob
Figure 2-3 Install the Camera to the Mount and Adjust the Angle
2.2 Wall Mounting
Steps:
1. Install the lens (not supplied) to the camera and rotate it to get it
tightened.
2. Plug the auto-iris cable to the auto-iris interface.
16
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

17
Network Box Camera·Quick Start Guide
Figure 2-4 Install the Lens
You need to use the CS adapter ring if C type lens is adopted.
3. Fix the bracket to the wall with the screws.
17
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

18
Pedestal
Tilt Adjust Screw
Network Box Camera·Quick Start Guide
Figure 2-5 Install the Wall Bracket
Pan Adjust Screw
4. Align the camera to the pedestal, and fix the camera with the
supplied screws.
Figure 2-6 Install the Camera to the Bracket
5. Adjust the Lens
1). Connect the VIDEO OUT interface of the camera to the
debugging monitor.
18
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

19
Network Box Camera·Quick Start Guide
2). Adjust the focus level to obtain a perfect image on the
monitor.
Please do not remove the lens cap until you finish the
installation to avoid the scrape and dust during the installation
and wiring.
6. Adjust the camera angle to the optimal surveillance angle.
3). Loosen the tilt adjust screw to adjust the tilt angle [0 °~±45°].
4). Loosen the pan adjust screw to adjust the pan angle [0°~360°].
5). Tighten the screws.
0°~90°
0°~360°
Figure 2-7 Adjust the Surveillance Angle
For the camera equipped with the auto iris, it is suggested you
change the iris mode to manual from the camera menu
(accessed via web browser), and re-change it back to auto iris
after you adjust the focus by the focus lever.
19
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
