HIK VISION DS-2TD2637B-10/P User manual

User Manual
Code: DS-2TD2637B-10/P
IP HYBRID THERMAL IMAGING CAMERA DS-2TD2637B-10/P 9.7 mm - 720p, 4 mm - 4 Mpx
Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-02-14 DS-2TD2637B-10/P 1/4
Warning!
Please read the user manual included in this work as it contains important information related with safety of installation and use of
the device.
Only persons who read the user manual may use the device.
The user manual must be kept because it may be required in the future. The device is to be used exclusively for purposes specified
in this user manual.
The device must be unpacked prior to starting-up. After removing the packaging make sure the device is in working order.
If the product has defects, it should not be used until it is repaired.
The product is intended for use at home and commercial use and may not be used for other than intended use.
The manufacturer is not liable for damages resulting from not adhering to the rules contained in the user manual, therefore, we
recommend to follow the aforementioned safety rules for operation and maintenance of the device. In this way you will ensure
yourself safety and avoid causing damage to the device.
The manufacturer and the supplier are not liable for losses or damages arising out of the product, including financial or intangible
losses, loss of profits, income, data, pleasure from use of the product or other products related with it - indirect, incidental or
consequential loss or damage. The above provisions apply whether the loss or damage concerns:
1. Deterioration of quality or the lack of operation of the products or products related with it due to damage as well as the lack of
access to the product when it is undergoing repair, which results in stoppage the loss of user's time or a break in business activity;
2. Improper results of operation of the product or products related with it;
3. It applies to losses and damages according to any legal category, including negligence and other losses, termination of a
contract, expressed or implied guarantee and strict liability (even if the manufacturer or the supplier was notified about the
possibility of occurrence of such damages).
Safety measures:
Particular attention at designing was directed to quality standards of the device where ensuring safety of operation is the most
important factor.
The device must be secured against contact with caustic, staining and viscous fluids.
The device was designed in such a way that it restarts operation when power supply is restored after a break.
Attention! We recommend using protections to further protect the device from possible overvoltages in installations.
Surge protectors are effective protection against accidental pass to the device voltages higher than the rated. Damages
caused by pass the voltages higher than specified in manual, are not under warranty.
Turn off the device before transporting it.
Prior to connecting the device to a power source check whether the supplied voltage is consistent with rated voltage specified in
the user manual.
Proper product disposal:
A marking of a crossed out waste bin indicates that the product may not be disposed together with other household waste in the
entire EU. To avoid possible damage to the natural environment of health due to uncontrolled waste disposal, therefore, it should be
handed over for recycling, propagating in this way sustainable use of natural resources.
To return a worn-out product, use a collection and disposal system of this type of equipment or contact a seller from whom it was
purchased. He will then be recycled in an environmentally-friendly way.
The DS-2TD2637B-10/P Thermal Imaging Camera is a modern solution that allows to detect the
presence of people, animals and vehicles regardless of prevailing vision conditions. The device is
equipped with sensitive VOx microbolometer that allows to observe the objects in fog, smoke and in
the absence of illumination.
A solution dedicated to measuring temperature. The camera is able to detect increased object
temperature. It can be used for preliminary temperature control in places such as customs,
airports, schools and hospitals.

User Manual
Code: DS-2TD2637B-10/P
IP HYBRID THERMAL IMAGING CAMERA DS-2TD2637B-10/P 9.7 mm - 720p, 4 mm - 4 Mpx
Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-02-14 DS-2TD2637B-10/P 2/4
Sensor: Uncooled VOx microbolometer
Matrix size: 384 x 288 px
Pixel pitch: 17 µm
Thermal sensitivity (NETD): < 35 mK @ F1.0
Spectral range: 8 µm ... 14 µm
Lens: 9.7 mm
View angle: 37.5 °
Resolution:
1280 x 720 - 720p ,
704 x 576
640 x 480
352 x 288
320 x 240
Temperature measurement:
• Spot
• Line
• Area
Temperature measurement range: 30 °C ... 45 °C
Accuracy of temperature measurement: ± 0.5 °C
VIDEO CAMERA:
Sensor: 1/2.7 " Progressive Scan Exmor CMOS
Matrix size: 4 Mpx
Scanning system: Progressive
Lens: 4 mm
View angle: 84 °
Optical zoom:
Min. illumination: 0.0089 Lux (color) @ F1.6
0.0018 Lux @ F1.6
Range of IR illumination: 50 m
Resolution:
2688 x 1520 - 4 Mpx
1920 x 1080 - 1080p
1280 x 720 - 720p
General information:
Standard: TCP/IP
Video output: CVBS - 1 Vpp / 75 Ω
RS-485 interface:
Memory card slot: Micro SD memory cards up to 256GB support (possible local recording)
Image compression method: H.265 / H.264 / MJPEG
Alarm inputs / outputs: 2 / 2
Audio: • External microphone input
• Audio output

User Manual
Code: DS-2TD2637B-10/P
IP HYBRID THERMAL IMAGING CAMERA DS-2TD2637B-10/P 9.7 mm - 720p, 4 mm - 4 Mpx
Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-02-14 DS-2TD2637B-10/P 3/4
Main stream frame rate: 25 fps @ 4 Mpx
Network interface: 10/100 Base-T (RJ-45)
Network protocols: IPv4/IPv6, HTTP, HTTPS, IEEE 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS,
NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
WEB Server: Built-in
Max. number of on-line users: 20
ONVIF: 16.12
Mobile phones support:
Port no.: 8000 or access by a cloud (P2P)
• Android: Free application iVMS-4500 or Hik-Connect
• iOS (iPhone): Free application iVMS-4500 or Hik-Connect
Default IP address: 192.168.1.64
Default admin user / password: admin / -
The administrator password should be set at the first start
Web browser access ports: 80
PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application
Mobile client access ports: 8000
Port ONVIF: 80
RTSP URL:
• Main stream
VIDEO CAMERA : rtsp://user:[email protected]:554/Streaming/Channels/101/
THERMAL IMAGING CAMERA :
rtsp://użytkownik:hasł[email protected]:554/Streaming/Channels/201/
• Sub stream
VIDEO CAMERA : rtsp://user:[email protected]:554/Streaming/Channels/102/
THERMAL IMAGING CAMERA :
rtsp://użytkownik:hasł[email protected]:554/Streaming/Channels/202/
Main features:
• The possibility of overlapping the image from a thermal imaging camera in a classic
• Temperature measurement
• WDR - 120 dB - Wide Dynamic Range
• 3D-DNR - Digital Noise Reduction
• PIP - Picture In Picture
• ICR - Movable InfraRed filter
• AGC - Automatic Gain Control
• Sharpness - sharper image outlines
• Mirror - Mirror image
• Day/Night mode (color/b&w/auto)
• DDE (Digital Detail Enhancement) - the function automatically optimizes the
contrast of the thermal image in high-dynamic scenes - small differences in the
temperature distribution of the examined object are highlighted
• AI detection : A solution dedicated to measuring temperature. The camera is able to
detect increased object temperature
Power supply:
• PoE (802.3af),
• 12 V DC / 750 mA,
• 24 V AC / 380 mA
Power consumption:
≤ 9 W @ 12 V DC
≤ 9 W @ 24 V AC
≤ 9.5 W @ PoE (802.3af)
Housing: Compact - Metal
Color: White

User Manual
Code: DS-2TD2637B-10/P
IP HYBRID THERMAL IMAGING CAMERA DS-2TD2637B-10/P 9.7 mm - 720p, 4 mm - 4 Mpx
Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-02-14 DS-2TD2637B-10/P 4/4
"Index of Protection": IP66
Operation temp: 10 °C ... 35 °C
Weight: 1.82 kg
Dimensions: 376 x 119 x 118 mm
Supported languages:
Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek,
Spanish, Dutch, Lithuanian, Latvian, German, Norwegian, Portuguese, Russian,
Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Italian
Manufacturer / Brand: Hikvision
SAP Code: 305401179
Guarantee: 3 years
Dimensions:
