HIK VISION E-series User manual

E-series HD Camera
User Manual
UD.6L0201D1062A01

E-series High-definition Camera·User Manual
1
1
Thank you for purchasing our product. If there are any questions, or requests,
please do not hesitate to contact the dealer.
This manual applies to
DS-2CE5512P (N)
DS-2CE5582P(N)
DS-2CE5512P (N)-IR
DS-2CE5582P(N)-IR
DS-2CE5582P (N)-IR1 (IR3)
DS-2CE1582P (N)-IR1 (IR3)
DS-2CE5512P (N)-IRP
DS-2CE5582P(N)-IRP
DS-2CE1512P (N)-IR
DS-2CE1582P(N)-IR
This manual may contain several technical incorrect places or printing errors, and
the content is subject to change without notice. The updates will be added to the
new version of this manual. We will readily improve or update the products or
procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or
reliability of the security or signaling aspects of this product. UL has only tested
for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety,
UL60950-1. UL Certification does not cover the performance or reliability of the
security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED
FUNCTIONS OF THIS PRODUCT.”
0100001030527

E-series High-definition Camera·User Manual
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the
limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too
are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under the
Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this
symbol cannot be disposed of as unsorted municipal waste in
the European Union. For proper recycling, return this product
to your local supplier upon the purchase of equivalent new
equipment, or dispose of it at designated collection points.

E-series High-definition Camera·User Manual
3
3
For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery
that cannot be disposed of as unsorted municipal waste in
the European Union. See the product documentation for
specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd),
lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information see:
www.recyclethis.info.

E-series High-definition Camera·User Manual
4
4
Safety Instruction
These instructions are intended to ensure that user can use the product correctly
to avoid danger or property loss.
The precaution measure is divided into Warnings and Cautions.
Warnings: Serious injury or death may occur if any of the warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the cautions are
neglected.
Warnings
Please adopt the power adapter which can meet the safety extra low voltage
(SELV) request. And source with DC 12V or AC 24V (depending on models)
according to the IEC60950-1 and Limited Power Source standard.
If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the camera yourself.
(We shall not assume any responsibility for problems caused by
unauthorized repair or maintenance.)
To reduce the risk of fire or electrical shock, do not expose this product to
rain or moisture.
Warnings Follow these
safeguards to prevent serious
injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.

E-series High-definition Camera·User Manual
5
5
This installation should be made by a qualified service person and should
conform to all local codes.
Please install blackouts equipment into the power supply circuit for
convenient supply interruption.
Please make sure that the ceiling can support more than 50(N) Newton
gravities if the camera is fixed to the ceiling.
Cautions
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a
clean cloth with a bit of ethanol and wipe it gently. If the camera will not be
used for an extended period of time, put on the lens cap to protect the
sensor from dirt.
Do not aim the camera at the sun or extra bright places. A blooming or
smear may occur otherwise (which is not a malfunction however), and
affecting the endurance of sensor at the same time.
The sensor may be burned out by a laser beam, so when any laser
equipment is being used, make sure that the surface of the sensor will not
be exposed to the laser beam.
Do not place the camera in extremely hot or cold temperatures (the
operating temperature should be between -40°C ~ 60°C), dusty or damp
locations, and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for a proper
operating environment.
Do not let water and any liquid flow into the camera.

E-series High-definition Camera·User Manual
6
6
While shipping, the camera should be packed in its original packing, or
packing of the same texture.
Improper use or replacement of the battery may result in hazard of
explosion. Replace with the same or equivalent type only. Dispose of used
batteries according to the instructions provided by the battery
manufacturer.

E-series High-definition Camera·User Manual
7
7
Table of Contents
1 Introduction ........................................................................ 8
1.1 Product Features ........................................................8
1.2 Appearance of Camera..................................................9
2 Installation ....................................................................... 12
2.1 Installation of DS-2CE5512P(N) and DS-2CE5582P(N) Dome Camera
..............................................................................12
2.2 Installation of DS-2CE5512P(N)-IR and DS-2CE5582P(N)-IR Dome
Camera .....................................................................18
2.3 Installation of DS-2CE5512P(N)-IRP and DS-2CE5582P(N)-IRP Dome
Camera .....................................................................21
2.4 Installation of DS-2CE1512P(N)-IR and DS-2CE1582P(N)-IR Bullet
Camera .....................................................................25
2.5 Installation of DS-2CE1582P(N)-IR1(IR3) Bullet Camera ............27
2.6 Installation of DS-2CE5582P(N)-IR1(IR3) Dome Camera ............ 29
2.7 Power Supply ..........................................................32

E-series High-definition Camera·User Manual
8
8
1Introduction
1.1 Product Features
This camera adopts high performance DIS and advanced print circuit board
design technology. It possesses of high resolution, low distortion, and low noise
features, etc. It is extremely suitable for supervisory system and image processing
system.
The main features of the E-series cameras are as follows.
High-resolution for the clear and bright image;
IR cut filter for auto day/night switching (not supported by DS-2CE5512P(N)
and DS-2CE5582P(N));
Easy to get high quality pictures and video with high SNR (Signal to Noise
Ratio) feature;
Auto-electronic shutter control to adapt to various surveillance
environments;
Auto-Gain Control for surveillance in low illumination scenario and
self-adaptive to different lightening environments;
High color rendition with Auto White Balance function;
Bullet camera adopts an advanced product design and the mounts of them
support wiring from inside out;
Bullet camera adopts three-axis (pan/tilt/rotation) adjustment for optimum
surveillance angles and position;
Dome camera adopts patent universal adjustable structure providing
convenient adjustment and high reliability.

E-series High-definition Camera·User Manual
9
9
1.2 Appearance of Camera
Figure 1-1 DS-2CE5512P(N) and DS-2CE5582P(N)
Figure 1-2 DS-2CE5512P(N)-IR and DS-2CE5582P(N)-IR
