HIK VISION DS-3WF03C-D User manual

DS-3WF03C-D Outdoor Video Wireless Network
Bridge
User Manual

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
2
User Manual
COPY IGHT ©2016 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of
Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be
“Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced,
changed, translated, or distributed, partially or wholly, by any means, without the prior written
permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties,
guarantees or representations, express or implied, regarding to the Manual.
About this Manual
This Manual is applicable to DS-3WF03C-D outdoor video wireless network bridge, the Manual includes
instructions for using and managing the product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information contained in the Manual is
subject to change, without notice, due to firmware updates or other reasons. Please find the latest
version in the company website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Ackno ledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various
jurisdictions. Other trademarks and logos mentioned below are the properties of their respective
owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PE MITTED BY APPLICABLE LAW, THE P ODUCT DESC IBED, WITH ITS
HA DWA E, SOFTWA E AND FI MWA E, IS P OVIDED “AS IS”, WITH ALL FAULTS AND E O S, AND
HIKVISION MAKES NO WA ANTIES, EXP ESS O IMPLIED, INCLUDING WITHOUT LIMITATION,
ME CHANTABILITY, SATISFACTO Y QUALITY, FITNESS FO A PA TICULA PU POSE, AND NON-
INF INGEMENT OF THI D PA TY. IN NO EVENT WILL HIKVISION, ITS DI ECTO S, OFFICE S, EMPLOYEES,
O AGENTS BE LIABLE TO YOU FO ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, O INDI ECT
DAMAGES, INCLUDING, AMONG OTHE S, DAMAGES FO LOSS OF BUSINESS P OFITS, BUSINESS
INTE UPTION, O LOSS OF DATA O DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS
P ODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
EGA DING TO THE P ODUCT WITH INTE NET ACCESS, THE USE OF P ODUCT SHALL BE WHOLLY AT
YOU OWN ISKS. HIKVISION SHALL NOT TAKE ANY ESPONSIBILITES FO ABNO MAL OPE ATION,
P IVACY LEAKAGE O OTHE DAMAGES ESULTING F OM CYBE ATTACK, HACKE ATTACK, VI US
INSPECTION, O OTHE INTE NET SECU ITY ISKS; HOWEVE , HIKVISION WILL P OVIDE TIMELY
TECHNICAL SUPPO T IF EQUI ED.
SU VEILLANCE LAWS VA Y BY JU ISDICTION. PLEASE CHECK ALL ELEVANT LAWS IN YOU
JU ISDICTION BEFO E USING THIS P ODUCT IN O DE TO ENSU E THAT YOU USE CONFO MS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS P ODUCT IS USED WITH
ILLEGITIMATE PU POSES.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
3
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATE
P EVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC ules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC ules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
Attention that changes or modification not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC ules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this product does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
— eorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the radiator
and your body
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and
comply therefore with the applicable harmonized European standards listed under the EMC
Directive 2014/30/EU, the LVD Directive 2014/35/EU, the oHS Directive 2011/65/EU.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
4
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for
specific battery information. The battery is marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
5
Table of Contents
Cha ter 1 Product Overview .....................................................................................6
13.1 Product Advantages..................................................................................................... 6
13.2 Electrical Specifications................................................................................................ 7
13.3 Features ...................................................................................................................... 9
13.4 Typical Application....................................................................................................... 9
13.5 Applications................................................................................................................10
13.6 Hardware Overview....................................................................................................10
13.7 LED Description ..........................................................................................................11
Cha ter 2 Installation ..............................................................................................12
2.1 Connections and Installation.......................................................................................12
2.2 estore to the Factory Settings ...................................................................................13
Cha ter 3 Quick Configuration ................................................................................14
3.1 Log In .........................................................................................................................14
3.2 Quick Configuration of the Device...............................................................................16
Cha ter 4 TDMA ......................................................................................................20
Cha ter 5 Status....................................................................................................... 21
5.1 Status.........................................................................................................................21
5.2 Monitor......................................................................................................................22
Cha ter 6 Wireless................................................................................................... 24
Cha ter 7 Network ..................................................................................................26
7.1 outer Mode ..............................................................................................................26
7.2 Bridge Mode...............................................................................................................28
7.3 Management..............................................................................................................28
7.4 Firewall.......................................................................................................................28
7.5 IP Aliases ....................................................................................................................29
7.6 Static outes...............................................................................................................29
7.7 Traffic Shaping............................................................................................................29
7.8 VLAN Settings.............................................................................................................30
Cha ter 8 Advanced.................................................................................................32
Cha ter 9 System .....................................................................................................34
Cha ter 10 Tools..................................................................................................... 36
Cha ter 11 AC Management..................................................................................40
Cha ter 12 Logout..................................................................................................41
Cha ter 13 Network Configuration Examples........................................................42
13.1 AP and Station Network..............................................................................................42
Cha ter 14 Appendix-A Troubleshooting...............................................................43

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
6
Cha ter 1 Product Overview
DS-3WF03C-D is a powerful WIFI Bridge/AP/CPE device, which allows WIFI access and
video/audio/data transmission device, enables long-range, fast speed and robust
wireless connections. Integrated with Hikvision’s XTrans technology, DS-3WF03C-D has
the advantages of long-distance, high-throughput, and Strong anti-interference.
XTrans technologies include TDMA, 5M/10M/20M/40MHz bandwidth, intelligent rate
control, Auto ACK Time-Out Adjust and so on. TDMA technology solves the problems of
hidden-node problem in the 802.11 network. 5M/10M/20M/40MHz bandwidth can be
flexibly configured by the uses in different working scenario to achieve the best link
quality. Intelligent rate control algorithm can be adapted to quick channel quality
variations automatically, thus stabilizing the wireless throughput. ACK Time-Out Auto
Adjust can automatically detect the distances of the DS-3WF03C-D devices, and thus
adjust the wireless parameters to achieve the best wireless link quality.
The longest transmission range and max speed of DS-3WF03C-D can be as high as 5Km
and 300Mbps, making it suitable for many applications of WIFI Bridge/CPE, especially
have advantages for point-to-multi-point communication.
13.1 Product Advantages
The DS-3WF03C-D has the industrial leading technology, owing the performance
capability of a wireless base station with only a small form factor, furthermore, it has
very attractive low cost.
DS-3WF03C-D has the following advantages compared to the competitors:
1. Embedded XTrans technology
DS-3WF03C-D devices is embedded with XTrans technology, including TDMA,
5/10/20/40MHz bandwidth, intelligent rate control, Auto ACK Time-out adjust. They
make the device have longer transmission distance, higher throughput and better point-
to-multi-point performance.
2. Longer transmission distance, higher throughput
The longest transmission distance of DS-3WF03C-D can be as far as 5 km, and the max
throughput can be 300Mbps. It can satisfy the needs of most of the applications.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
7
3. Embedded hardware watchdog
DS-3WF03C-D is embedded with hardware watchdog, which is used to monitor the
working status of the device. Once the system is not working properly, the DS-3WF03C-
D device can be rebooted to guarantee the stability of the system.
4. Software Ping watchdog function
DS-3WF03C-D software ping watchdog function enable the device periodically ping
another device associated to, so that it can detect if the system is working well. If the
wireless link is lost or there is any problem, the device is rebooted. This is important
because the devices can be restored to work automatically if there is any problem, and
avoid the extra human labour to maintain the outdoor devices.
5. Outdoor industrial product
DS-3WF03C-D device can work at all kinds of outdoor severe environments, including -
30 to 70 degree temperature, 5% to 95% humidity, while maintain good performance.
13.2 Electrical Specifications
The electrical specifications are shown are the following table:
Table 1-1 Specifications

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
8
Items Specifications
Wireless
Standard IEEE802.11 a/n(2T2 300Mbps)
Operation frequency 5.15 to 5.25GHz
Modulation mode 802.11 a/n: OFDM
Antenna Internal, Gain 15dBi,H:40° V:15°
Output po er
Receive sensitivity -74dBm@65Mbps, -96dBm@6Mbps
Data rate
11n:13.5/15/27/30/40.5/45/54/60/81/90/108/120/121.5/135/150/162/180/2
16/240/270/300Mbps(40MHz)
130/117/104/78/65/58.5/52/39/26/13/6.5Mbps(20MHz)
11a :54/48/36/24/18/12/9/6Mbps(Auto)
Hard are
Po er supply 24V/0.5A PoE
Interface PoE*1+LAN*1
Operation temperature -30℃ to 75℃(-22℉ to 167℉ )
Storage temperature -40℃ to 85℃(-40℉ to 185℉)
Operation humidity 5% to 95% H non-condensing
Dimensions 270x40x88mm(10.6x1.57x3.46inch)
Soft are
Encryption 802.1x/WPA-PSK/WPA2-PSK
Net ork mode outer/Bridge
Operation mode Access Point, Station, WDS Access Point, WDS Station
Security IP/MAC filter, SSID hidden
Net ork protocol TCP/UDP/A P/ICMP/DHCP/HTTP/NTP
TDMA Supported (Avoid 802.11 hidden-node problems, and improve the point-to-
multi-point performance)
Auto ACK timing adjust Supported(It can automatically choose optimized parameter in long distance
transmission, keep the performance always the best)
Management and Logs NTP, Syslog, Telnet, AC
Web based
configuration Supported
Firm are update Support update firmware by Web page
Band idth supported 5M/10M/20M/40MHz
The Max E.I.R.P about 21dBm

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
9
13.3 Features
High performance 802.11n 2×2 MIMO chip
Longest transmission range: 5Km, and max transmission throughput: 300Mbps
Integrated XTrans technology, including TDMA, intelligent rate control, Auto ACK
Time-out adjust
TDMA solves the problems of hidden-node problem in the 802.11 network, thus
having better long-distance and PTMP performance
5 operation mode: Access Point, Station, WDS Access Point, WDS Station, WDS
epeater
Point-to-point, point-to-multipoint connection
Unique F and antenna design enables long-range transmission
Wireless multimedia optimization technology guarantees video/audio transmission
QoS
Web based working scenario selection makes the installation and setting much
easier
eliable PoE power supply
Web-based configuration, easy to use
Waterproof housing and accessory kit protects
13.4 Typical Application
The DS-3WF03C-D usage examples are shown in figure; it can be used as WIFI AP, CPE,
or outdoor PTP, PTMP topology. Therefore, DS-3WF03C-D is suitable for various
applications like wireless video transmission, and wireless signal coverage.

User Manual of
13.5 Applications
DS-3WF03C-D
can be used widely in the following applications:
•
Wireless video surveillance (free
•
Carrier wireless backhaul and rural area internet last
•
Enterprise local area network inter
•
WIFI signal coverage and rural wireless coverage
13.6
Hardware Overview
DS-3WF03C-D
’s hardware information is described in the following
User Manual of
DS-3WF03C-D
Outdoor Video Wireless Network
10
Figure 1-1 Typical Application
can be used widely in the following applications:
Wireless video surveillance (free
-
way, city, police, oil pipeline, forest and etc.)
Carrier wireless backhaul and rural area internet l
ast-
mile wireless solution
Enterprise local area network inter
-connection
WIFI signal coverage and rural wireless coverage
Hardware Overview
’s hardware information is described in the followi
ng t
able:
Outdoor Video Wireless Network
Bridge
way, city, police, oil pipeline, forest and etc.)
mile wireless solution
able:

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
11
Table 1-2 Hardware information
Hardware Specifications
CPU/Baseband
adio
Atheros A
9344
Memory
64
MB D AM, 8MB Flash
Physical Interface
2×10/100M Base
-
TX (Cat. 5/5E, J
-
45) Ports
LED Status
Power, LAN, WLAN, 3×Link Quality
Power supply
POE, Power Adapter 24V/0.5A
13.7 LED Description
The LEDs of DS-3WF03C-D can be divided to 2 groups. One group of LEDs are Indicators,
including the left 3 LEDs of figure, and they are Power, LAN and WAN indicators. The
other group of LEDs are Link Quality, including the right 3 LEDs of figure, shown the
signal strength.
Table 1-3 LED Information
LED
Color
Status
POWE
Green
ON = Device Power on
LAN
Green
ON = Device connected to the network
WLAN Green
OFF = Device radio is OFF
ON = Device radio is ON, but not sending or
receiving date through the wireless LAN.
BLINK= Device radio is ON, and sending or receiving
date through the wireless LAN.
Link Quality
ed
Showing the signal strength between the device
and the network.
Green is ON = good quality
Yellow is ON = medium quality
ed = poor quality or no link
Yellow
Green

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
12
Cha ter 2 Installation
This chapter describes how to install DS-3WF03C-D device in the bridge mode, and the
installation method of router mode can be seen in Chapter 7.
2.1 Connections and Installation
The connection of DS-3WF03C-D device to POE and power supply is shown in figure.
Figure 2-1 Connections at Bridge mode
DS-3WF03C-D has 2 J45 ports, and they are marked with “POE” and “LAN2” separately.
In the bridge mode, please connect the device with the POE power adaptor in the
following way:
1. emove the bottom cover from the DS-3WF03C-D device, and you will see there are
2 J45 ports marked with “POE” and “LAN2”.
2. Using an Ethernet cable to connect the POE power adaptor and the “POE” port of
the DS-3WF03C-D device.
3. Connect the POE adaptor to the normal power supply board.
4. Normally, “LAN2” port of the DS-3WF03C-D can be connected to IP Camera and

User Manual of
other devices, or leave it unconnected
5. Mount the DS-
3WF03C
2.2
estore to the Factory
In some cases, uses can restore the device to the factory settings by the following way in
the figure
. Push the reset button for 5~10 seconds until all LED
will restore to the factory setting. During this process, the
will be connected and disconnected twice.
For default, all the factory settings are shown in the following
Table
Items
IP address
User name
Password
Output power
Encryption
Network mode
User Manual of
DS-3WF03C-D
Outdoor Video Wireless Network
13
other devices, or leave it unconnected
3WF03C
-D
securely to the pole by locking the strap tightly.
estore to the Factory
Settings
In some cases, uses can restore the device to the factory settings by the following way in
. Push the reset button for 5~10 seconds until all LED
s are
on. Th
will restore to the factory setting. During this process, the
DS-3
WF03C
will be connected and disconnected twice.
Figure 2-2 estore to the factory settings
For default, all the factory settings are shown in the following
table.
Table
2-1 Main parameters at the factory settings
Default Settings
192.168.1.35/192.168.1.36
admin
admin
High
WPA->WPA2->CCMP-
>Password:1234567890abc
Bridge
Outdoor Video Wireless Network
Bridge
securely to the pole by locking the strap tightly.
In some cases, uses can restore the device to the factory settings by the following way in
on. Th
en the device
WF03C
-D’s J45 ports
>Password:1234567890abc

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
14
Cha ter 3 Quick Configuration
This chapter describe how to configure the device quickly.
3.1 Log In
To log in the DS-3WF03C-D device, user needs to configure the TCP/IP of your computer
first as the following steps:
1. ight click Local Area Connection icon of your computer and click properties, then
click Continue, the Local Area Connection Properties dialog box appears as figure.
Figure 3-1 Local Area Connection Properties
2. Select Internet Protocol (TCP/IP) and click Properties button, and the following
dialog box appear:

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
15
Figure 3-2 IP settings
3. In the above figure, IP address should be set to 192.168.1.*, here * can be a number
between 1-255 (but not 36) since the DS-3WF03C-D （ T/ ） default IP address is
192.168.1.35/36.
4. When the above IP setting is done, input the default IP 192.168.1.35 into the
address bar of your web browser, and the following log in interface appears as
shown in figure.
5. In figure, input the user name and password (default is admin/12345) and click the
Confirm button, then you can log in to the web configuration menu of the DS-
3WF03C-D device.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
16
Figure 3-3 DS-3WF03C-D Log in interface
3.2 Quick Configuration of the Device
The users will see how to configure the DS-3WF03C-D device quickly in this chapter.
1. The first page shown after log in is the Status page, which indicates the working
status, current setting, software version and other information of the DS-3WF03C-D
device. Users can switch to other pages by clicking the left main menus in figure.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
17
Figure 3-4 Status Page
2. Click Wizard main menu, the users can configure the device quickly, including
Network and Wireless settings and so on. It is Wizard-Network page as shown in
figure, and this page helps to set the basic network parameters. The default mode is
Bridge mode, and the default LAN IP address is 192.168.1.35. If the user wants to
configure the device to outer mode, please click Network in the main menu.
If several DS-3WF03C-D devices are connected in the Point-to-Point or Point-to-
Multi-Point topologies, they must be configured to different IP address to avoid
collisions.
.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
18
Figure 3-5 Wizard Network
3. After finishing the Wizard-Network settings, click next and it goes to Wizard-
Wireless page shown in figure. The most used wireless mode is the Access Point and
the Station.
Station mode: The device acts as a WIFI station, and it can be connected to a
normal home access point or DS-3WF03C-D access point.
Access Point mode: The DS-3WF03C-D device acts as an access point, which allows
normal WIFI stations access. For detail settings of wireless mode, please click
Wireless in the main menu.
If two DS-3WF03C-D devices need to be connected in point-to-point topology, one
of the device need to be configured as Access Point, and the other one need to be
configured as Station, and both of them should have the same Encryption method.
Figure 3-6 Wizard Wireless
4. The last page of Wizard is shown in figure. User can click Change to save all the
settings, and then click Apply the make the setting effective, or click last to modify
the previous settings.

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
19
Figure 3-7 Wizard Finish

User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
20
Cha ter 4 TDMA
Currently, most of the outdoor bridge products are developed based on 802.11
protocols, however, it has the limitations of short-distance, hidden node problems, and
poor point-to-multi-point performance.
XTrans technology is developed and patented by Hikvision, utilizing a series of advanced
technologies such as TDMA, 5M/10M/20M/40MHz bandwidth support, intelligent rate
control, Auto ACK Time-out Adjust, having the advantage of long transmission range,
high date rate and robust transmission.
TDMA technology solves the problems of hidden-node problem in the 802.11 network
infra-structure. 5M/10M/20M/40MHz bandwidth can be flexibly configured by the uses
in different working scenario to achieve the best link quality. Intelligent rate control
algorithm can be adapted to quick channel quality variations, while stabilize the wireless
throughput, thus suitable for long-distance transmission. ACK Time-out Auto Adjust can
automatically detect the distances of the DS-3WF03C-D devices, and adjust the wireless
parameters to achieve the best link quality.
The TDMA setting is shown in the following figure.
Figure 4-1 TDMA Settings
To use the TDMA, the user needs to enable TDMA mode in the AP device, and set a
priority level in the station device. When several stations are connected to one AP,
different stations demand different throughput. If the station demands higher
throughput, its priority level can be set to High, otherwise set to Low. When the stations
demand the same throughput, their priority level can be set to the same level.
When using TDMA mode, the TDMA button need to be enabled at both AP and station
devices in the web-based configuration menu. The devices from other vendors cannot
be connected to DS-3WF03C-D in the TDMA mode.
