HIK VISION DS-7600NI-I2 Series User manual

Network Video Recorder
User Manual

Legal Informaon
About this Document
●This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other informaon hereinaer are for descripon and explanaon only.
●The informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
●This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
●If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without wrien permission.
● and other Hikvision’s trademarks and logos are the properes of Hikvision in
various jurisdicons.
●Other trademarks and logos menoned are the properes of their respecve owners.
● The terms HDMI and HDMI High-Denion Mulmedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Network Video Recorder User Manual
i

LEGAL DISCLAIMER
●TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
Network Video Recorder User Manual
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against
harmful interference in a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instrucons, may
cause harmful interference to radio communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
●Reorient or relocate the receiving antenna.
●Increase the separaon between the equipment and receiver.
●Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
●This device may not cause harmful interference.
●This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked
with "CE" and comply therefore with the applicable harmonized European
standards listed under the EMC Direcve 2014/30/EU, LVD Direcve 2014/
35/EU, the RoHS Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the
Network Video Recorder User Manual
iii

purchase of equivalent new equipment, or dispose of it at designated
collecon points. For more informaon see: hp://www.recyclethis.info .
2006/66/EC (baery direcve): This product contains a baery that cannot
be disposed of as unsorted municipal waste in the European Union. See
the product documentaon for specic baery informaon. The baery is
marked with this symbol, which may include leering to indicate cadmium
(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the baery to
your supplier or to a designated collecon point. For more informaon
see: hp://www.recyclethis.info .
Network Video Recorder User Manual
iv

Applicable Model
This manual is applicable to the following models. But not all the funcons in this manual are
supported for each model.
Table 1-1 Applicable Model
Series Model
DS-7600NI-I2 DS-7608NI-I2
DS-7616NI-I2
DS-7632NI-I2
DS-7600NI-I2/P DS-7608NI-I2/8P
DS-7616NI-I2/16P
DS-7632NI-I2/16P
DS-7700NI-I4 DS-7708NI-I4
DS-7716NI-I4
DS-7732NI-I4
DS-7700NI-I4/P DS-7708NI-I4/8P
DS-7716NI-I4/16P
DS-7732NI-I4/16P
DS-7732NI-I4/24P
DS-7608NI-M2 DS-7608NI-M2
DS-7616NI-M2
DS-7632NI-M2
DS-7600NI-M2/P DS-7608NI-M2/8P
DS-7616NI-M2/16P
DS-7700NI-M4 DS-7716NI-M4
DS-7732NI-M4
DS-7764NI-M4
DS-7700NI-M4/P DS-7708NI-M4/8P
DS-7716NI-M4/16P
DS-7732NI-M4/16P
Network Video Recorder User Manual
v

Series Model
DS-7732NI-M4/24P
DS-9600NI-M8 DS-9616NI-M8
DS-9632NI-M8
DS-9664NI-M8
DS-96128NI-M8
DS-9600NI-M8/R DS-9616NI-M8/R
DS-9632NI-M8/R
DS-9664NI-M8/R
DS-96128NI-M8/R
DS-9600NI-M16 DS-9616NI-M16
DS-9632NI-M16
DS-9664NI-M16
DS-96128NI-M16
DS-9600NI-M16/R DS-9616NI-M16/R
DS-9632NI-M16/R
DS-9664NI-M16/R
DS-96128NI-M16/R
DS-7600NXI-I2/S DS-7608NXI-I2/S
DS-7616NXI-I2/S
DS-7632NXI-I2/S
DS-7600NXI-I2/P/S( DS-7608NXI-I2/8P/S(
DS-7616NXI-I2/16P/S
DS-7632NXI-I2/16P/S
DS-7700NXI-I4/S DS-7716NXI-I4/S
DS-7732NXI-I4/S
DS-7700NXI-I4/P/S DS-7716NXI-I4/16P/S
DS-7732NXI-I4/16P/S
DS-8600NXI-I8/S DS-8616NXI-I8/S
DS-8632NXI-I8/S
Network Video Recorder User Manual
vi

Series Model
DS-8664NXI-I8/S
DS-8600NXI-I8/24P/S DS-8632NXI-I8/24P/S
DS-9600NXI-I8/S DS-9616NXI-I8/S
DS-9632NXI-I8/S
DS-9664NXI-I8/S
iDS-7600NXI-M2/X iDS-7608NXI-M2/X
iDS-7616NXI-M2/X
iDS-7632NXI-M2/X
iDS-7600NXI-M2/P/X iDS-7608NXI-M2/8P/X
iDS-7616NXI-M2/16P/X
iDS-7700NXI-M4/X iDS-7716NXI-M4/X
iDS-7732NXI-M4/X
iDS-7700NXI-M4/16P/X iDS-7716NXI-M4/16P/X
iDS-7732NXI-M4/16P/X
iDS-9632NXI-M8/X iDS-9632NXI-M8/X
iDS-9664NXI-M8/X
iDS-96128NXI-M8/X
iDS-9600NXI-M8R/X iDS-9632NXI-M8R/X
iDS-9664NXI-M8R/X
iDS-96128NXI-M8R/X
iDS-9600NXI-M16/X iDS-9632NXI-M16/X
iDS-9664NXI-M16/X
iDS-9600NXI-M16R/X iDS-9632NXI-M16R/X
iDS-9664NXI-M16R/X
Network Video Recorder User Manual
vii

Safety Instrucon
●Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
●In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●Firmly connect the plug to the power socket. Do not connect several devices to one power
adapter. Power o the device before connecng and disconnecng accessories and peripherals.
●Shock hazard! Disconnect all power sources before maintenance.
●The equipment must be connected to an earthed mains socket-outlet.
●The socket-outlet shall be installed near the device and shall be easily accessible.
●For the device with the sign indicang hazardous live, the external wiring connected to the
terminals requires installaon by an instructed person.
●Never place the device in an unstable locaon. The device may fall, causing serious personal
injury or death.
●Input voltage should meet the SELV (Safety Extra Low Voltage) and the LPS (Limited Power
Source) according to the IEC62368.
●High touch current! Connect to earth before connecng to the power supply.
●If smoke, odor or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●Use the device in conjuncon with an UPS, and use factory recommended HDD if possible.
●This equipment is not suitable for use in locaons where children are likely to be present.
●CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
●Do not ingest baery. Chemical Burn Hazard!
●This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
●Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
●Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●Do not leave the baery in an extremely high temperature surrounding environment, which may
result in an explosion or the leakage of ammable liquid or gas.
●Do not subject the baery to extremely low air pressure, which may result in an explosion or the
leakage of ammable liquid or gas.
●Dispose of used baeries according to the instrucons.
●Keep body parts away from fan blades and motors. Disconnect the power source during
servicing.
●Keep body parts away from motors. Disconnect the power source during servicing.
●Use only power supplies same with the original model, or LPS power supplies with the same
voltage and electric current.
Network Video Recorder User Manual
viii

Prevenve and Cauonary Tips
Before connecng and operang your device, please be advised of the following ps:
●The device is designed for indoor use only. Install it in a well-venlated, dust-free environment
without liquids.
●Ensure recorder is properly secured to a rack or shelf. Major shocks or jolts to the recorder as a
result of dropping it may cause damage to the sensive electronics within the recorder.
●The device shall not be exposed to water dripping or splashing, and no objects lled with liquids,
such as vases, shall be placed on the device.
●No naked ame sources, such as lighted candles, should be placed on the device.
●The venlaon should not be impeded by covering the venlaon openings with items, such as
newspapers, table-cloths, curtains. The openings shall never be blocked by placing the device on
a bed, sofa, rug, or other similar surface.
●For certain models, ensure correct wiring of the terminals for connecon to an AC mains supply.
●For certain models, the equipment has been designed, when required, modied for connecon
to an IT power distribuon system.
● idenes the baery holder itself and idenes the posioning of the cell(s) inside the
baery holder.
●+ idenes the posive terminal(s) of the device which is used with, or generates direct current,
and - idenes the negave terminal(s) of the device which is used with, or generates direct
current.
●Keep a minimum 200 mm (7.87 inch) distance around the equipment for sucient venlaon.
●For certain models, ensure correct wiring of the terminals for connecon to an AC mains supply.
●Do not touch the sharp edges or corners.
●When the device is running above 45 °C (113 °F), or its HDD temperature in S.M.A.R.T. exceeds
the stated value, please ensure the device is running in a cool environment, or replace HDD(s) to
make the HDD temperature in S.M.A.R.T. below the stated value.
●Provide a surge suppressor at the inlet opening of the device under special condions such as
the mountain top, iron tower, and forest.
●Do not touch the bare components (such as the metal contacts of the inlets) and wait for at least
5 minutes, since electricity may sll exist aer the device is powered o.
●The USB port of the equipment is used for connecng to a mouse, keyboard, USB ash drive, or
Wi-Fi dongle only. The current for the connected device shall be not more than 0.1 A.
●The serial port of the device is used for debugging only.
●If the power output port of the device does not comply with Limited Power Source, the
connected device powered by this port shall be equipped with a re enclosure.
●If a power adapter is provided in the device package, use the provided adapter only.
●For the device with scker or , pay aenon to the following cauons: CAUTION: Hot
parts! Do not touch. Burned ngers when handling the parts. Wait one-half hour aer switching
o before handling the parts.
●If the device needs to be installed on the wall or ceiling,
Network Video Recorder User Manual
ix
