HIK VISION DS-3WF03C User manual

DS-3WF03C User Manual
5.8GHz Wireless Bridge
Model: DS-3WF03C
User Manual
Version：1.1

DS-3WF03C User Manual
Page 1
Contents
Versions..................................................................................................................4
References .............................................................................................................4
Purpose..................................................................................................................4
Notes......................................................................................................................4
Definitsons.............................................................................................................4
1Product Overview .................................................................................................6
1.1 Product Advantages .......................................................................................................6
1.2 Electrical Specifications..................................................................................................7
1.3 Features............................................................................................................................9
1.4 Using Example...............................................................................................................10
1.5 Applications...................................................................................................................10
1.6 Hardware Overview......................................................................................................11
2Installation ...........................................................................................................11
2.1 Connections and installation.......................................................................................11
3Quick Configuration...........................................................................................12
3.1 Log in .............................................................................................................................12
3.2 Quick Configuration of the Device.............................................................................15
4XTrans...................................................................................................................19
5Status....................................................................................................................20
5.1 Status..............................................................................................................................21
5.2 Monitor ..........................................................................................................................22
6Wireless................................................................................................................24
7Network ...............................................................................................................26
7.1 Router mode .................................................................................................................26
7.2 Bridge mode..................................................................................................................27
7.3 Firewall...........................................................................................................................27
7.4 Traffic Shaping ............................................................................................................28
7.5 VLAN Settings ..............................................................................................................29

DS-3WF03C User Manual
Page 2
8Advanced.............................................................................................................30
9System..................................................................................................................31
10 Tools .....................................................................................................................33
11 Network Configuration Examples ....................................................................36
11.1AP and Station Network ..............................................................................................36
11.2 Router Mode .................................................................................................................36
Appendix-A Troubleshooting...................................................................................38
FIGURE 1DS-3WF03C USING EXAMPLES ..................................................................................................10
FIGURE 3CONNECTIONS AT BRIDGE MODE.................................................................................................11
FIGURE 4RESTORE TO THE FACTORY SETTINGS................................................................错误!未定义书签。
FIGURE 5LOCAL AREA CONNECTION PROPERTIES .......................................................................................13
FIGURE 6IP SETTINGS ...............................................................................................................................14
FIGURE 7DS-3WF03C LOG IN INTERFACE.................................................................................................15
FIGURE 8STATUS PAGE..............................................................................................................................16
FIGURE 9WIZARD.....................................................................................................................................16
FIGURE 10 WIZARD-NETWORK..................................................................................................................17
FIGURE 11 WIZARD-WIRELESS ..................................................................................................................18
FIGURE 12 WIZARD-WORKING SCENARIOS ................................................................................................18
FIGURE 13 WIZARD-CUSTOM.................................................................................................................... 19
FIGURE 14 LAST PAGE OF WIZARD .............................................................................................................19
FIGURE 15 XTRANS SETTING ......................................................................................................................20
FIGURE 16 STATUS ....................................................................................................................................21
FIGURE 17 THROUGHPUT MONITOR ...........................................................................................................22
FIGURE 18 ROUTER TABLE .........................................................................................................................23
FIGURE 19 STA INFORMATION OF AN AP...................................................................................................23
FIGURE 20 AP INFORMATION OF A STATION ...............................................................................................23
FIGURE 21 WIRELESS.................................................................................................................................24
FIGURE 22 CONNECTION FIGURE OF ROUTER MODE ....................................................................................26
FIGURE 23 NETWORK-ROUTER MODE ........................................................................................................26
FIGURE 24 FIREWALL................................................................................................................................. 27
FIGURE 25 ADVANCED ..............................................................................................................................30
FIGURE 26 SYSTEM PAGE ...........................................................................................................................32
FIGURE 27 SYSTEM-ACCOUNTS PAGE.........................................................................................................32
FIGURE 28 TOOLS .....................................................................................................................................34
FIGURE 29 AP AND STATION NETWORK......................................................................................................36
FIGURE 30 WDS NETWORK .........................................................................................错误!未定义书签。

DS-3WF03C User Manual
Page 3
FIGURE 31 ROUTER MODE .........................................................................................................................37
TABLE 1VERSIONS ......................................................................................................................................4
TABLE 2DEFINITIONS ..................................................................................................................................4
TABLE 3ELECTRICAL SPECIFICATIONS............................................................................................................7
TABLE 4HARDWARE INFORMATION............................................................................................................11
TABLE 6MAIN PARAMETERS AT THE FACTORY SETTINGS...................................................错误!未定义书签。
TABLE 7CONFIGURATIONS SHOWN IN STATUS ...........................................................................................21

DS-3WF03C User Manual
Page 4
Versions
Table 1 Versions
Version
Date
History
Author
1.1
References
Purpose
This document is proposed for the users of DS-3WF03C devices, helping them to
configure the device and list the troubleshootings, so that the devices can be used
successfully quickly.
This document mainly contains the following parts: hardware information, web
configuration menu descriptions, network configuration examples, and
troubleshootings. It can help the customers quickly be familiar with the devices
and use them correctly.
Notes
This document is to characterize the DS-3WF03C series of devices. Please read the
document carefully before setting up device. Any damage which is caused by
inappropriate use will not be covered under the warranty.
Definitsons
Table 2 Definitions
No.
Items
Description
1
DS-3WF03C
Outdoor, long distance Bridge devices
2
Xtrans
XTrans is a series of wireless technologies,
including TDMA, 5M/10M/20M/40MHz bandwidth
support, intelligent rate control, Auto ACK
Time-out adjust, having the advantage of long
transmission range, high date rate and robust
transmission.

DS-3WF03C User Manual
Page 5
No.
Items
Description
3
AP
Access point
4
Station(Client)
WiFi station that can be associated to an access
point.

DS-3WF03C User Manual
Page 6
1Product Overview
DS-3WF03C is a powerful WiFi Bridge/AP device, which allows WiFi access and
video/audio/data transmission device, enables long-range, fast speed and robust
wireless connections.DS-3WF03C has the advantages of long-distance,
high-throughput, and between point-to-multi-point performance.
XTrans technologies include TDMA, 5M/10M/20M/40MHz bandwidth, intelligent
rate control, Auto ACK Time-Out Adjust and so on. TDMA technology solves the
problems of hidden-node problem in the 802.11 network. 5M/10M/20M/40MHz
bandwidth can be flexibly configured by the uses in different working scenario to
achieve the best link quality. Intelligent rate control algorithm can be adapted to
quick channel quality variations automatically, thus stabilizing the wireless
throughput. ACK Time-Out Auto Adjust can automatically detect the distances of
the DS-3WF03C devices, and thus adjust the wireless parameters to achieve the
best wireless link quality.
The Best transmission range and max speed of DS-3WF03C can be 0~3Km and
300Mbps, making it suitable for many applications of WiFi Bridge/AP, especially
have advantages for point-to-multi-point communication.
1.1 Product Advantages
The DS-3WF03C has the industrial leading technology, owing the performance
capability of a wireless base station with only a small form factor, furthermore, it
has very attractive low cost.
DS-3WF03C has the following advantages compared to the competitors:
1. Embedded Xtrans technology
DS-3WF03C devices is embedded with Xtrans technology, including TDMA,
5/10/20/40MHz bandwidth, intelligent rate control, Auto ACK Time-out adjust. It
makes the device have longer transmission distance, higher throughput and better
point-to-multi-point performance.
2. Longer transmission distance, higher throughput
The longest transmission distance of DS-3WF03C can be as far as 10 km, and the
max throughput can be 300Mbps. At 3km and 5km, the throughput can be as high
as 60Mbps and 40Mbps, which satisfy the needs of most of the applications.

DS-3WF03C User Manual
Page 7
3. Embedded hardware watchdog
DS-3WF03C is embedded with hardware watchdog, which is used to monitor the
working status of the device. Once the system is not working properly, the
DS-3WF03C device can be rebooted to guarantee the stability of the system.
4. Software Ping watchdog function
DS-3WF03C software ping watchdog function enable the device periodically ping
another device associated to, so that it can detect if the system is working well. If
the wireless link is lost or there is any problem, the device is rebooted. This is
important because the devices can be restored to work automatically if there is
any problem, and avoid the extra human labour to maintain the outdoor devices.
5. More Non-standard channels availability
Currently most of the WiFi devices are working at standard 802.11 5.8GHz
frequency. However, standard 802.11 5.8GHz only provide limited channels, and
there is serious interference if there are a lot of 5.8G WiFi devices nearby.
DS-3WF03C support more channels near 5.8GHz band, and spread the band to
non-standard frequency part: 5745MHz-5825MHz (4920MHz-6100MHz) 。The
advantage of working at the non-standard band is to avoid the interference in the
standard channels, and the wireless throughput can be improved.
Note: Please confirm whether those non-standard channels are permitted locally
before using them.
6. Outdoor industrial product
DS-3WF03C device can work at all kinds of outdoor severe environments,
including -30 to 75 degree temperature, 5% to 95% humidity, while maintain good
performance.
1.2 Electrical Specifications
The electrical specifications are shown are the following table:
Table 3 Electrical Specifications
Items
Specifications
W
Standard
IEEE802.11 a/n（2T2R 300Mbps）

DS-3WF03C User Manual
Page 8
I
R
E
L
E
S
S
Operation
Frequency
5.745～5.825 GHz ISM band
Extend to 4900 ~ 6100MHZ
Modulation
Mode
802.11 a/n: OFDM
Antenna
Dual Polarity（Horizontal ＋Vertical）V：30º、H：15º
Output power
＋30dBm(@6Mbps,11a)
Receive
Sensitivity
-75dBm @ 65Mbps, -96dBm@1Mpbs
Date rate
11n:13.5/15/27/30/40.5/45/54/60/81/90/108/120/121.5/1
35/150/162/180/216/240/270/300Mbps(40MHz Channel
Width)
11n:130/117/104/78/65/58.5/52/39/26/13/6.5Mbps(20MH
z Channel Width)
11a ：54/48/36/24/18/12/9/6Mbps(adaptive)
Distance
Outdoor open area: <3 km
H
A
R
D
W
A
R
E
Power supply
12~24V POE
Interface
POE
LED
Wi-Fi Status/LAN/Power/Signal strength
Operation
Temperature
-30℃～ +75℃
Storage
Temperature
-40～+85℃
Operation
Humidity
10%～90%RH
Device Size
270×40×88mm
S
O
F
T
W
A
R
E
Encryption
WEP/WPA-PSK/WPA2/CCMP(AES)/TKIP
Network
Router/Bridge
Operation Mode
AP, Station, AP-WDS, Station-WDS
Security
MAC filter, SSID hidden
Network
protocol
TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP
TDMA
Supported (Avoid 802.11 hidden-node problems, and
improve the point-to-multi-point performance)
Auto ACK timing
Adjust
Supported
Management
and Logs
NTP, Syslog，Telnet, AC

DS-3WF03C User Manual
Page 9
Web based
Configuration
Supported
Firmware Update
Supported
Long-distance
Capability
Throughput>[email protected]Km，>30Mbps@5Km(Open
area)
Bandwidth
supported
5M/10M/20M/40MHz
1.3 Features
High performance 802.11n 2×2 MIMO chip
Best transmission range: 0~3Km, and max transmission throughput:
300Mbps
Integrated XTrans technology, including TDMA, intelligent rate control,
Auto ACK Time-out adjust
TDMA solves the problems of hidden-node problem in the 802.11
network, thus having better long-distance and PTMP performance
Support 4 operation mode: AP, Station, AP-WDS, Station-WDS
Support point-to-point, point-to-multipoint connection
Unique RF and antenna design enables long-range transmission
Wireless multimedia optimization technology guarantees video/audio
transmission QoS
Web based working scenario selection makes the installation and setting
much easier
Reliable POE power supply, support 802.3af standard
Web-based configuration, easy to use
Waterproof housing and accessory kit protects

DS-3WF03C User Manual
Page 10
1.4 Using Example
The DS-3WF03C usage example are shown in Figure 1, it can be used as WiFi AP,
or outdoor PTP, PTMP topology. Therefore, DS-3WF03C is suitable for various
applications like wireless video transmission, and wireless signal coverage.
Figure 1 DS-3WF03C using examples
1.5 Applications
DS-3WF03C can be used widely in the following applications:
Wireless video surveillance (free-way, city, police, oil pipeline, forest and
etc.)
Carrier wireless backhaul and rural area internet last-mile wireless solution
Enterprise local area network inter-connection
WiFi signal converage and rural wireless coverage

DS-3WF03C User Manual
Page 11
1.6 Hardware Overview
DS-3WF03C’s hardware information is described in the following Table 4:
Table 4 Hardware information
Hardware Specifications
CPU/Baseband Radio
Atheros AR9344
Memory
64MB DRAM, 8MB Flash
Physical Interface
2×10/100M Base-TX (Cat. 5/5E, RJ-45)
Ports
Power supply
POE, Power Adapter 24V/1A
2Installation
This chapter describes how to install DS-3WF03C device in the bridge mode, and
the installation method of router mode can be seen in Chapter 7.
2.1 Connections and installation
The connection of DS-3WF03C device to POE and power supply is shown in Figure
3.
Figure 2 Connections at Bridge mode

DS-3WF03C User Manual
Page 12
DS-3WF03C has one RJ45 ports, and they are marked with “POE”. In the bridge
mode, please connect the device with the POE power adaptor in the following
way:
1) Remove the bottom cover from the DS-3WF03C device.
2) Using an Ethernet cable to connect the POE power adaptor and the “POE”
port of the DS-3WF03C device.
3) Connect the POE adaptor to the normal power supply board.
4) Mount the DS-3WF03C securely to the pole by locking the strap tightly.
3Quick Configuration
This chapter describe how to configure the device quickly.
3.1 Log in
To log in the DS-3WF03C device, user needs to configure the TCP/IP of your
computer first as the following steps:
1、Right click Local Area Connection icon of your computer and click properties,
then click Continue, the Local Area Connection Properties dialog box appears as
Figure 5.

DS-3WF03C User Manual
Page 13
Figure 3 Local Area Connection Properties
2、Select Internet Protocol (TCP/IP) and click Properties button, and the following
dialog box appears：

DS-3WF03C User Manual
Page 14
Figure 4 IP settings
3、In the above Figure 6, IP address should be set to 192.168.1.*, here * can be a
number between 1-255 (but not 36) since the DS-3WF03C default IP address is
192.168.1.36.
4、When the above IP setting is done, input the default IP 192.168.1.36 into the
address bar of your web browser, and the following log in interface appears as
shown in Figure 7.
5、In Figure 7, input the user name and password (default is admin/admin), the you
can log in to the web configuration menu of the DS-3WF03C device.

DS-3WF03C User Manual
Page 15
Figure 5 DS-3WF03C Log in interface
3.2 Quick Configuration of the Device
The users will see how to configure the DS-3WF03C device quickly in this chapter.
1、The first page shown after log in is the Status page, which indicates the
working status, current setting, software version and other informations of the
DS-3WF03C device. User can switch to other pages by clicking the left main menus
in Figure 8.

DS-3WF03C User Manual
Page 16
Figure 6 Status Page
2、Click Wizard main menu, as shown in Figure 9, the users can configure the
device quickly, including Network and Wireless settings and so on.
Figure 7 Wizard
3、Click “next step”in Figure 9, the page goes to Wizard-Network page as shown
in Figure 10, and this page helps to set the basic network parameters. The default
mode is Bridge mode, and the default LAN IP address is 192.168.1.36. If the user
wants to configure the device to Router mode, please click Network in the main
menu.

DS-3WF03C User Manual
Page 17
Note: If several DS-3WF03C devices are connected in the Point-to-Point or
Point-to-Multi-Point topologies, they must be configured to different IP address
to avoid collisions.
Figure 8 Wizard-Network
4、After finishing the Wizard-Network settings, click next and it goes to
Wizard-Wireless page shown in Figure 11. The most used wireless mode are
Access Point and Station.
Station mode：The device acts as a WiFi station, and it can be connected to a
normal home access point or DS-3WF03C access point.
Access Point mode：The DS-3WF03C device acts as an access point, which allows
normal WiFi stations access. For detail settings of wireless mode, please click
Wireless in the main menu.
Note: If 2 DS-3WF03C devices need to be connected in point-to-point topology,
one of the device need to be configured as Access Point, and the other one need
to be configured as Station, and both of them should have the same Encryption
method.

DS-3WF03C User Manual
Page 18
Figure 9 Wizard-Wireless
5、After the wireless settings are done, click next, it goes to the Wizard-Scenario
page shown in Figure 12. This page helps users to choose the working scenario,
such as short distance, long distance, Line-of-Sight, or None-Line-of-Sight
scenarios. If the user clicks Custom in the Wizard-Scenario page, it goes to
Wizard-Custom page shown in Figure 13.
Figure 10 Wizard-Working Scenarios
6、In Wizard-Custom page, the following settings will affect the device
performance.
Output power: The max output power is 27dBm. The larger the output power, the
longer distance the transmission distance.
Channel Bandwidth: The default is 20/40MHz AUTO.
Auto ACK-Timeout Adjust：It is suggested to enable this function, so that the
distance between 2 DS-3WF03C devices can be detected and all the related
parameters can be optimized to achieve the best link quality.
Distance: The distance can be set manually if the Auto ACK-Timeout Adjust is
disabled, otherwise, the distance is not allowed to be set. It is suggested the
distance is set automatically by enabling Auto ACK-Timeout Adjust function.

DS-3WF03C User Manual
Page 19
Figure 11 Wizard-Custom
7、The last page of Wizard is shown in Figure 14. User can click Save to save all the
settings, and then click Apply the make the setting effective, or click Last to
modify the previous settings.
Figure 12 Last Page of Wizard
4XTrans
Currently, most of the outdoor bridge products are developed based on 802.11
protocols, however, it has the limitations of short-distance, hidden node problems,
and poor point-to-multi-point performance.
XTrans technologies, utilizing a series of advanced technologies such as TDMA,
5M/10M/20M/40MHz bandwidth support, intelligent rate control, Auto ACK
Time-out Adjust, having the advantage of long transmission range, high date rate
and robust transmission.
TDMA technology solves the problems of hidden-node problem in the 802.11
network infra-structure. 5M/10M/20M/40MHz bandwidth can be flexibly
configured by the uses in different working scenario to achieve the best link
quality. Intelligent rate control algorithm can be adapted to quick channel quality
variations, while stabilize the wireless throughtput, thus suitable for long-distance
