HIK VISION DS-2CD2520F User manual

0
Camera
Network Mini Dome Camera
Quick Start Guide
UD.6L0201B1966A01
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Hikvision DS-2CD2520F o cerca il tuo prodotto
tra le migliori offerte di Videosorveglianza

Network Mini Dome Camera·Quick Start Guide
1
1
Quick Start Guide
COPYRIGHT © 2015 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This Manual is applicable to 25xx Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective
owners.

Network Mini Dome Camera·Quick Start Guide
2
2
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE
LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

Network Mini Dome Camera·Quick Start Guide
3
3
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.

Network Mini Dome Camera·Quick Start Guide
4
4
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.

Network Mini Dome Camera·Quick Start Guide
5
5
Warnings
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Network Mini Dome Camera·Quick Start Guide
6
6
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-30°C ~+60°C , or -40°C ~ +60°C if the
camera model has an “H” in its suffix), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.

Network Mini Dome Camera·Quick Start Guide
7
7
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Mini Dome Camera·Quick Start Guide
8
8
Table of Contents
1 Appearance Description ................................................................. 9
1.1 Overview of Type I Mini Dome Camera ........................... 9
1.2 Overview of Type II Mini Dome Camera .......................... 9
1.3 Overview of Type III Mini Dome Camera ....................... 12
2 Installation.................................................................................... 14
2.1 Type II Mini Dome Camera Installation.......................... 15
2.1.1 Ceiling Mounting ................................................ 15
2.1.2 Ceiling Mounting with a Gang Box...................... 19
2.1.3 Pendent Mounting ............................................. 21
2.1.4 Wall Mounting.................................................... 23
2.1.5 Install the Micro SD Card .................................... 25
2.2 Type III Mini Dome Camera Installation......................... 27
2.3 Install the Water-proof Jacket ....................................... 31
3 Setting the Network Camera over the LAN .................................. 32
3.1 Wiring ........................................................................... 32
3.2 Activating the Camera ................................................... 33
3.2.1 Activation via Web Browser................................ 33
3.2.2 Activation via SADP Software ............................. 35
3.3 Modifying the IP Address .............................................. 36
4 Accessing via Web Browser .......................................................... 38

Network Mini Dome Camera·Quick Start Guide
9
9
1Appearance Description
1.1 Overview of Type I Mini Dome Camera
Figure 1-1 Overview of Type I Mini Dome Camera
1.2 Overview of Type II Mini Dome Camera
2
6
9
8
4
1
3
5
Figure 1-2 Overview of Type II Mini Dome Camera (1)
4
2
68
5
3
7

Network Mini Dome Camera·Quick Start Guide
10
10
Overview of Type II Mini Dome Camera (2)Figure 1-3
Description of Type I/ II Mini Dome CameraTable 1-1
No.
Description
1
Front Cover
2
Dome Drive
3
Micro SD Card Slot
4
Lens
5
IR LED
6
Network Cable
7
Auxiliary Video Output (Supported by Type I camera)
8
Power Cable

Network Mini Dome Camera·Quick Start Guide
11
11
No.
Description
9
Audio/Alarm Cables (Supported by Type II camera)
10
Wi-Fi Antenna
11
Hex Screw
12
MIC
13
RESET/WPS Button(Supported by Type II camera)
Press RESET about 10s when the camera is powering on or
rebooting to restore the default settings, including the user
name, password, IP address, port No., etc.
No.9 is the audio/alarm cable interface, of which the “I”mark
connects to the alarm input, the “o”mark connects to the
alarm output, the “GND”mark connects the grounding, and the
“A”mark connects the audio output.
WPS (Wi-Fi Protected Setup, also known as AOSS or QSS) is a
computing standard that attempts to allow easy establishment
of a secure wireless network. Refer to user manual for details.
A wireless router with the WPS function is required to enable
the WPS function of the camera. Refer the steps below.
Steps:
Press the WPS button on the router.1.

Network Mini Dome Camera·Quick Start Guide
12
12
Press the WPS button (about 2s) on the camera within 120s2.
you enable the WPS of the router to join in the wireless
network.
The WPS button works as a reset button only when you
press it when the camera is powering on.
Press the WPS button on the camera, and then press the
WPS button on the router will establish a connection as
well, and the expire time of WPS connection on the
camera is 120s.
The link indicator blinks if the wireless connection is
succeeded.
1.3 Overview of Type III Mini Dome Camera
Figure 1-4 Overview of Type III Mini Dome Camera

Network Mini Dome Camera·Quick Start Guide
13
13
Table 1-3 Description of Type IIIMini Dome Camera
No.
Description
1
Cover
2
Lens
3
Power LED indicator, It turns solid red when power is
connected.
4
Base Plate
5
Set Screw Hole
6
Set Screw of Lens
7
S & L: Network Status Indicator.
When the network is connected, the “S”LED is solid
yellow, while the “L”LED flashes orange.
8
RESET Button
9
Micro SD Card Slot

Network Mini Dome Camera·Quick Start Guide
14
14
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12V DC or 24V AC, please make
sure your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.

Network Mini Dome Camera·Quick Start Guide
15
15
Type I camera shares the similar appearance with the type II camera,
we will take type I camera as the example to explain the installation
steps, please
2.1 Type II Mini Dome Camera Installation
2.1.1 Ceiling Mounting
Steps:
1. Drill the screw holes and the cable hole in the ceiling according
to the supplied drill template.
Drill TemplateFigure 2-1
2. Loosen the set screw on the front cover to disassemble the
camera with the supplied Allen key.
Drill Template
1
1
11
Hole A:for cables routed through the ceiling
Screw hole 1:for Mounting Base
FRONT

Network Mini Dome Camera·Quick Start Guide
16
16
Disassemble the CameraFigure 2-2
3. Hammer the plugs of the expansion screws to the screw holes.
4. Align the adapter plate to the drill template, and fix the adapter
plate.
Figure 2-3 Fix the Adapter Plate

Network Mini Dome Camera·Quick Start Guide
17
17
5. Connect the power cable, network cable, and the audio/alarm
cables.
6. Fix the camera body to the ceiling with the supplied expansion
screws.
Fix the Camera BodyFigure 2-4
7. View the image via the web browser.
8. Slightly loosen the hex screw beside the WPS/RESET button to
adjust the surveillance angle.
9. Use the supplied adjusting tool to adjust the pan [±30°], tilt
[0~80°], and rotation direction [0~360°].

Network Mini Dome Camera·Quick Start Guide
18
18
3-Axis AdjustmentFigure 2-5
10. Tighten the hex screw to fix the well-adjusted surveillance angle.
11. Align the front cover to the dome drive and tighten the set
screws on the front cover.
Install the Front CoverFigure 2-6
12. Tear off the protection film softly to complete the installation.
Adjusting Tool
Rotation
Tilt
Pan

Network Mini Dome Camera·Quick Start Guide
19
19
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your hands.
2.1.2 Ceiling Mounting with a Gang Box
Steps:
1. Fix the adapter plate to the gang box with the supplied PM4X8
screws.
Fix the Adapter PlateFigure 2-7
2. Fix the dome drive to the adapter plate with the supplied PM4X8
screws.
