HIK VISION DS-2CD883F-EW series User manual

Network Box Camera
Installation Manual
V3.0.0
Hangzhou Hikvision Digital Technology Co., Ltd.
http://www.hikvision.com
2010-04

Thank you for purchasing our product. If there are any questions, or
requests, please do not hesitate to contact the dealer.
This manual applies to DS-2CD883F-E(W),DS-2CD863PF(NF)-E(W),
DS-2CD853F-E(W),DS-2CD854F-E(W),DS-2CD893PF(NF)-E(W),
DS-2CD893PFWD(NFWD)-E(W) and DS-2CD833F-E(W) Network
Camera.
This manual may contain several technical incorrect places or printing
errors, and the content is subject to change without notice. The
updates will be added to the new version of this manual. We will readily
improve or update the products or procedures described in the
manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or
reliability of the security or signaling aspects of this product. UL has only
tested for fire, shock or casualty hazards as outlined in UL’s Standard(s)
for Safety, UL60950-1. UL Certification does not cover the performance
or reliability of the security or signaling aspects of this product. UL
MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS
WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY
SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

Installation Manual of Network Box Camera
1
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly
to avoid danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are
neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are
neglected.
Warnings Follow these safeguards
to prevent serious injury or
death.
Cautions Follow these precautions
to prevent potential injury or
material damage.
Warnings:
1. In the use of the product, you must strictly comply with the electrical safety
regulations of the nation and region.
2. Source with DC 12V or AC 24V according to the IEC60950-1 standard. Please
refer to technical specifications for more details.
3. Do not connect several devices to one power adapter as an adapter overload
may cause over-heating and can be a fire hazard. If use the POE as the power
supply, please make sure that the POE Switch have the sufficient power.
4. Please make sure that the plug is firmly inserted into the power socket.
5. When the product is installed on a wall or ceiling, the device should be firmly
fixed.
6. If smoke, odor, or noise rise from the device, turn off the power at once and
unplug the power cable, then contact the service center.
7. If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
2
maintenance.)
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
3
Notice:
1. Make sure the power supply voltage is correct before using the camera.
2. Do not drop the camera or subject it to physical shock.
3. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean
cloth with a bit of ethanol and wipe it gently. If the camera will not be used for
an extended period of time, put on the lens cap to protect the sensor from dirt.
4. Do not aim the camera at the sun or extra bright places. A blooming or smear
may occur otherwise (which is not a malfunction however), and affecting the
endurance of sensor at the same time.
5. The sensor may be burned out by a laser beam, so when any laser equipment is
being used, make sure that the surface of the sensor will not be exposed to the
laser beam.
6. Do not place the camera in extremely hot or cold temperatures (the operating
temperature should be between -10°C ~ 60°C, dusty or damp locations, and do
not expose it to high electromagnetic radiation.
7. To avoid heat accumulation, good ventilation is required for a proper operating
environment.
8. While shipping, the camera should be packed in its original packing, or packing
of the same texture.
9. Regular part replacement: a few parts (e.g. electrolytic capacitor) of the
equipment should be replaced regularly according to their average life time.
The average time varies because of differences between operating
environment and usage history, so regular checking is recommended for all users.
Please contact with your dealer for more details.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
4
Table of Contents
Chapter 1 Introduction .....................................................................................1
1.1 Network camera Functions and Features..........................................1
1.2 Applications ............................................................................................1
Chapter 2 Installation ........................................................................................2
2.1 Camera Description ..............................................................................2
2.1.1 Side Panel Description ..................................................................2
2.1.2 Rear Panel Description .................................................................4
2.1.3 Camera Connection ....................................................................5
2.2 Hardware Installation.............................................................................7
Appendix Product Specification .....................................................................9
DS-2CD883F-E(W)..........................................................................................9
Specification............................................................................................9
Dimensions ............................................................................................ 10
DS-2CD863PF(NF)-E(W) ............................................................................. 11
Specification......................................................................................... 11
Dimensions ............................................................................................ 12
DS-2CD853F-E(W)....................................................................................... 13
Specification......................................................................................... 13
Dimensions ............................................................................................ 14
DS-2CD854F-E(W)....................................................................................... 15
Specification......................................................................................... 15
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©
5
Dimensions ............................................................................................ 16
DS-2CD893PF(NF)-E(W).....................................................................................17
Specification .................................................................................................17
Dimensions .....................................................................................................18
DS-2CD893PFWD(NFWD)-E(W) .......................................................................19
Specification .................................................................................................19
Dimensions .....................................................................................................20
DS-2CD833F-E(W) ...............................................................................................21
Specification .................................................................................................21
Dimensions .....................................................................................................22

Installation Manual of Network Box Camera
1
Chapter 1 Introduction
Network camera is a kind of embedded digital surveillance product that
combines the features of both traditional analog camera and network DVS (Digital
Video Server). Due to the embedded Linux operation system and the latest Davinci
hardware platform of TI, the system operates with high scheduling efficiency.
Furthermore, the firmware is burned in the flash, which makes the product small,
reliable and highly stable.
1.1 Network camera Functions and Features
Functions:
Network Function: Support the TCP/IP protocols and IE browsing.
Heartbeat Function: The server can acquire real time operating performance of
the network camera through the heartbeat function.
Alarm Function: Supports Motion Detection, Video Loss, Network Broken, IP
address conflict, Storage exception.
User Management: Support multilevel right management. The administrator can
create up to 15 separate users with different right levels, which highly improves
the system security.
Compression Functions:
Support 1 channel video signal and standard H.264 encoding compression,
which supports both variable bit rate and variable frame rate; besides, you can
self-define both the video quality and its compressed bit rate.
Remote Control:
The product offers a 10M/100M self-adaptive Ethernet interface.
Support TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP protocols.
Set the parameters, browse real time videos or check the camera performance
by software or IE, and store the compressed bit rate through network.
Support remote upgrades and maintenance.
1.2 Applications
This camera is ideal for remote control network applications. E.g.:
1. Network surveillance for supermarkets and factories.
2. Remote surveillance for homes and offices.
3. Indoor monitoring scenes, such as hotel, corridor, stairway.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
2
Chapter 2 Installation
NOTE:
1. Please check if all the items on the package list have been included with
your camera.
2. Read the following contents carefully before the installation.
3. Make sure that all the related equipment is power-off during the installation.
4. Check the power supply to prevent any damage caused by mismatching
problems.
5. If the product does not operate properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the camera yourself.
Users are responsible for any problem caused by modification or repairing
without authorization.
2.1 Camera Description
2.1.1 Side Panel Description
Side Panel 1:
Side Panel 2:
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
3
Serial NO. Description
1 Lens mount
2 Back Focus Ring
3 SD card slot
4 Auto iris interface
Back Focus Adjustment:
When it still fails to realize precise focusing after having confirmed the correct lens
interface, the back focus adjustment may be required.
Operate the following steps:
Tighten the lens firstly and then loosen the fixed back focus ring; rotate the lens
slowly until the video image turns to be clear, and finally tighten and lock the back
focus ring.
NOTE:
The type of auto-iris interface is square
four-hole type, and the definition of each pin as
shown:
Video DC
1 Power Damp-
2 NC Damp+
3 Video Drive+
4 GND Drive-
Auto iris interface with video driving uses three
pins: Power, Video and GND; Auto iris interface
with DC driving uses four pins: Damp+, Damp-,
Drive+ and Drive-.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
4
2.1.2 Rear Panel Description
Serial NO. Description
1 10M / 100M self-adaptive Ethernet interface
2 Video output interface
3 Audio output interface
4 Power LED indicator, which turns red when power is applied to the unit
5 Power supply
6 Audio input interface
7 D+, D-: RS-485 interface
8 IN, G: Alarm input interface
9 1A, 1B: Alarm output interface
10 Ground
11 RESET: Reset all parameters to factory default settings
NOTE:
When the camera is power up, press the ‘RESET’ button for about 10 seconds, then all
parameters, including user name, password, IP address, port number, etc., will be
reset to the factory default settings.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
5
2.1.3 Camera Connection
Note:
The alarm input is a NO/NC relay. If the input is not a NO/NC relay, follow the
connection diagram below:
To connect to an AC/DC load, use the following diagram:
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
6
The alarm output is an on/off output that requires external power supply on
connection. The external power supply shall be 12V DC/30mA, or use AC with
external relays. Equipment damage or electric shock may cause if without relays.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
7
2.2 Hardware Installation
Box camera can be fixed in both wall and ceiling, customers can choose different
ways to install the camera according to their specific needs. The following section
introduces the ceiling mounting, and the wall mounting follows the same way:
Step 1: Fix the camera mounting bracket to the ceiling.
Fig 2.2.1 Fix camera mounting bracket
NOTE:
If it is wall, you need to fix the expand bolt (note: the mounting hole of the expand
bolt should align with the bracket) before fixing the bracket as ①in Fig 2.2.1 . If the
wall surface is wooden, the part of ①in Fig 2.2.1 can be ignored and you can use
the self-tapping screw to directly fix the bracket. Please note that the wall on which
the camera is fixed should be able to bear at least three times the weight of the
bracket and the camera.
Step 2: Screw the mounting hole to the mounting bracket, and then adjust the
camera to the desired monitoring location and finally tighten the knob on bracket
to secure the camera to the ceiling.
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
8
Fig 2.2.2 Fix the Camera
Step 3: Mount the camera lens: connect the VIDEO OUT interface of the camera to
the debugging monitor, and adjust lens focus until you have obtained the clearest
video images on the monitor, and then lock the lens. If required, loosen the knob on
the mounting bracket and adjust the camera lens to the desired monitoring scene,
and finally tighten the knob on bracket.
Fig 2.2.3 Mount and adjust Lens
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
9
Appendix Product Specification
DS-2CD883F-E(W)
Specification
DS-2CD883F-E(W)
Model
Parameter 5 Megapixel 1/2.5" CMOS ICR Day&Night Network Box Camera
Camera
Image Sensor 1/2.5" Progressive Scan CMOS
Min.
Illumination
Color: 0.6Lux @(F1.2, AGC ON)
B / W: 0.08Lux @(F1.2, AGC ON)
Electronic
Shutter 1/25s ~1/20,000s
Lens Mount C/CS mount
Auto Iris DC Drive
Day&Night IR cut filter with auto switch
Compression Standard
Video
Compression H.264/ MJpeg
Bit rate 32 Kbps~16Mbps
Audio
Compression G.711(G.722.1 optional)
Max. Image
Resolution 2560×1920
Frame Rate
50HZ: 6.25fps (2560×1920), 12.5fps (2048×1536), 25fps (1920 ×
1080), 25fps (1600 × 1200) ,25fps (1280×720)
60HZ: 7.5fps (2560×1920), 15fps (2048×1536) , 30fps (1920 × 1080),
30fps (1600 × 1200), 30fps (1280×720)
Settings
Saturation, Brightness, Contrast adjustable through client
software or web browser
Network
Storage Support SD/SDHC, NAS (ISCSI optional)
Intelligent
Alarm
Motion Detection, Video Loss, Network Broken, IP address
conflict, Storage exception
Protocols TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP
(SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional)
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
10
Basic Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password
Protection, Watermark
Interface
Audio Input 1 channel microphone input, 3.5mm mini-jack
Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω)
Communicati
on Interface
1 RJ45 10M / 100M self-adaptive Ethernet interface and 1 RS-485
interface
Alarm Input 1 channel
Alarm Output 1 channel
Video Output 1Vp-p Composite Output (75Ω/BNC)
General
Operating
Condition -10℃~60 , Humidity℃90% or less(non-condensing)
Power Supply DC12V±10% / PoE (AC24V optional)
Power
Consumption 5W MAX(10W MAX with ICR Working)
Dimensions(m
m) 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”)
Weight 500g (1.1lbs)
*”W” series supports Wi-Fi (802.11g);
Dimensions
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
11
DS-2CD863PF(NF)-E(W)
Specification
DS-2CD863PF(NF)-E(W)Model
Parameter 1.3 Megapixel 1/3" CCD ICR Day&Night Network Box Camera
Camera
Image Sensor 1/3" SONY Progressive Scan CCD
Signal System PAL/NTSC
Min.
Illumination
Color: 0.1Lux @ (F1.2, AGC ON)
B / W: 0.01Lux @ (F1.2, AGC ON)
Electronic
Shutter 1/25(1/30)s ~1/100,000s
Lens Mount C/CS mount
Auto Iris DC Drive
Day&Night IR cut filter with auto switch
Compression Standard
Video
Compression H.264/MJpeg
Bit rate 32 Kbps~16Mbps
Audio
Compression G.711(G.722.1 optional)
Max. Image
Resolution 1280 x 960
Frame Rate 50HZ: 12.5fps(1280×960), 25fps (1280 x 720)
60HZ: 15fps(1280×960), 30fps (1280 x 720)
Settings
Saturation, Brightness, Contrast adjustable through client
software or web browser
Network
Storage Support SD/SDHC, NAS (ISCSI optional)
Intelligent
Alarm
Motion Detection, Video Loss, Network Broken, IP address
conflict, Storage exception
Protocols TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP
(SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional)
Basic Initial Set button, Anti-flicker, Dual Stream, Heartbeat, Password
Protection, watermark
Interface
Audio Input 1 channel microphone input, 3.5mm mini-jack
Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω)
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
12
Communicati
on Interface
1 RJ45 10M / 100M self-adaptive Ethernet interface and 1 RS-485
interface
Alarm Input 1 channel
Alarm Output 1 channel
Video Output 1Vp-p Composite Output (75Ω/BNC)
General
Operating
Condition -10℃~60 , Humidity℃90% or less(non-condensing)
Power Supply DC12V±10% / PoE (AC24V optional)
Power
Consumption 7.5W MAX(12.5W MAX with ICR Working)
Dimensions(m
m) 68 × 57 × 144.8 (2.7” × 2.2” × 5.7”)
Weight 500g (1.1lbs)
*”W” series supports Wi-Fi (802.11g);
Dimensions
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

Installation Manual of Network Box Camera
13
DS-2CD853F-E(W)
Specification
DS-2CD853F-E(W)
Model
Parameter 2 Megapixel 1/3" CMOS ICR Day&Night Network Box Camera
Camera
Image Sensor 1/3" Progressive Scan CMOS
Min.
Illumination
Color: 0.5Lux @(F1.2, AGC ON), 0.1Lux @(F1.2, AGC ON,
Sense-up×5)
B / W: 0.05Lux @(F1.2, AGC ON) , 0.01Lux @(F1.2, AGC ON,
Sense-up×5)
Electronic
Shutter 1/25s ~1/100,000s
Lens Mount C/CS mount
Auto Iris DC Drive
Day&Night IR cut filter with auto switch
Compression Standard
Video
Compression H.264/ MJpeg
Bit rate 32 Kbps~16Mbps
Audio
Compression G.711(G.722.1 optional)
Max. Image
Resolution 1600 x 1200
Frame Rate
50HZ: 12.5fps (1600×1200), 12.5fps (1600×912), 25fps (1280×960),
25fps (1280×720)
60HZ: 15fps (1600×1200), 15fps (1600×912), 25fps (1280×960),
30fps (1280×720)
Settings
Saturation, Brightness, Contrast adjustable through client
software or web browser
Network
Storage Support SD/SDHC, NAS (ISCSI optional)
Intelligent
Alarm
Motion Detection, Video Loss, Network Broken, IP address
conflict, Storage exception
Protocols TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP
(SNMP,HTTPS, FTP,SIP, 802.1x, IPV6 optional)
Basic e-PTZ, Initial Set button, Anti-flicker, Dual Stream, Heartbeat,
Password Protection, watermark
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©
