HIK VISION DS-2CE5582P(N)-VFIR3 User manual

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
1
Color Camera
Technical Manual

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2012 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusi[email protected]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
3
DS-2CE5582P(N)-VFIR3
Key Features
Compact design
Min. illumination: 0.1 Lux @ F1.2 (0 Lux with IR)
IR cut filter with auto switch
Auto white balance, auto gain control, electronic shutter control and backlight compensation
Advanced Engineering Design, High Reliability
Ingress Protection: IP66
Specification
Model
Parameter
DS-2CE5582P(N)- VFIR3
600 TVL DIS IR Dome Camera (ICR & Vari-focal & Weather-proof & Vandal-proof)
Camera
Image Sensor
1/3" DIS
Signal System
PAL/NTSC
Effective Pixels
720(H)×480(V)
Min. Illumination
0.1Lux @ (F1.2,AGC ON),0 Lux with IR
0.14Lux @ (F1.4,AGC ON),0 Lux with IR
Shutter speed
PAL: 1/25 s to 1/15,000 s
NTSC: 1/30 s to 1/15,000 s
Lens
2.8-12mm @ F1.4
Angle of view: 92°-27.2°
Lens Mount
φ14
Angle Adjustment
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°
Day & Night
IR cut filter with auto switch
Horizontal
Resolution
600 TVL

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
4
Synchronization
Internal synchronization
Video Output
1Vp-p composite output (75 Ω/BNC)
S/N Ratio
More than 52 dB
General
Working
Temperature/Humi
dity
-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 V DC ± 10%
Power
Consumption
Max. 4 W(Max. 6.5 W with IR cut filter on)
Ingress Protection
IP66
IR Range
Approx. 30 to 40 meters
Dimensions
134.21 × 123.85 × 91.42mm(5.28” × 4.88” × 3.60”)
Weight
800g (1.76l lbs)
Order Models
DS-2CE5582P-VFIR3
DS-2CE5582N-VFIR3
Dimensions
