HIK VISION DS-2TD2628-7/QA/GLT User manual

Thermal & Optical Bi-spectrum Network
Camera

Thermal & Optical Bi-spectrum Network Camera
i
Legal Information
© 2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the Hikvision website
(https://www.hikvision.com/).
Please use this Manual with the guidance and assistance of professionals trained in supporting the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properties of
Hikvision in various jurisdictions.
Other trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

Thermal & Optical Bi-spectrum Network Camera
ii
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATTER PREVAILS.

Thermal & Optical Bi-spectrum Network Camera
iii
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

Thermal & Optical Bi-spectrum Network Camera
iv
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulations
●In the use of the product, you must be in strict compliance with the electrical safety regulations
of the nation and region.
Transportation
●Keep the device in original or similar packaging while transporting it.
●Keep all wrappers after unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportation without the
original wrapper may result in damage on the device and the company shall not take any
responsibilities.
●DO NOT drop the product or subject it to physical shock. Keep the device away from magnetic
interference.
Power Supply
●Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(12 VDC, 24 VAC, or PoE(802.3af)) according to the IEC62368 standard. Please refer to technical
specifications for detailed information.
●Make sure the plug is properly connected to the power socket.
●The socket-outlet shall be installed near the equipment and shall be easily accessible.
●DO NOT connect multiple devices to one power adapter, to avoid over-heating or fire hazards
caused by overload.
●DO NOT touch the bare metal contacts of the inlets after the circuit breaker is turned off.
Electricity still exists.
●+ identifies the positive terminal(s) of equipment which is used with, or generates direct
current. - identifies the negative terminal(s) of equipment which is used with, or generates
direct current.
Battery
●Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions. Il y a risque d'explosion si la batterie est remplacée par une
batterie de type incorrect. Mettre au rebut les batteries usagées conformément aux
instructions.
●The built-in battery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●For long-term storage of the battery, make sure it is fully charged every half year to ensure the
battery quality. Otherwise, damage may occur.
●This equipment is not suitable for use in locations where children are likely to be present.
●Improper replacement of the battery with an incorrect type may defeat a safeguard (for

Thermal & Optical Bi-spectrum Network Camera
v
example, in the case of some lithium battery types).
●DO NOT dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery,
which may result in an explosion.
●DO NOT leave the battery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of flammable liquid or gas.
●DO NOT subject the battery to extremely low air pressure, which may result in an explosion or
the leakage of flammable liquid or gas.
Installation
●Never place the equipment in an unstable location. The equipment may fall, causing serious
personal injury or death.
●This equipment is for use only with corresponding brackets. Use with other (carts, stands, or
carriers) may result in instability causing injury.
System Security
●You acknowledge that the nature of Internet provides for inherent security risks, and our
company shall not take any responsibilities for abnormal operation, privacy leakage or other
damages resulting from cyber attack, hacker attack, however, our company will provide timely
technical support if required.
●Please enforce the protection for the personal information and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Please contact us when the device might exist network security risks.
●Please understand that you have the responsibility to configure all the passwords and other
security settings about the device, and keep your user name and password.
Maintenance
●If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●A few device components (e.g., electrolytic capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary.
●If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the device may be impaired.
●To reduce the risk of fire, replace only with the same type and rating of fuse.
●The serial port of the equipment is used for debugging only.
Using Environment
●Make sure the running environment meets the requirement of the device. The operating
temperature shall be -40°C to 65°C (-40°F to 149°F), and the operating humidity shall be 95% or
less, no condensing.
●DO NOT expose the device to high electromagnetic radiation or dusty environments.
●DO NOT aim the lens at the sun or any other bright light.
●The equipment shall not be exposed to dripping or splashing and that no objects filled with

Thermal & Optical Bi-spectrum Network Camera
vi
liquids, such as vases, shall be placed on the equipment.
●No naked flame sources, such as lighted candles, should be placed on the equipment.
●Provide a surge suppressor at the inlet opening of the equipment under special conditions such
as the mountain top, iron tower, and forest.
●Burned fingers when handling the parts with symbol . Wait one-half hour after switching off
before handling the parts.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the
power cable, and contact the service center.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without limitation, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government authorities for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between different countries.

Thermal & Optical Bi-spectrum Network Camera
vii
Contents
Chapter 1 Overview........................................................................................................................ 1
1.1 Brief Description ...............................................................................................................1
1.2 Function ............................................................................................................................1
Chapter 2 Device Activation and Accessing....................................................................................2
2.1 Activate the Device via SADP............................................................................................ 2
2.2 Activate the Device via Browser ....................................................................................... 2
2.3 Login ................................................................................................................................. 3
2.3.1 Plug-in Installation ................................................................................................. 3
2.3.2 Illegal Login Lock ....................................................................................................4
Chapter 3 Temperature Measurement........................................................................................... 5
3.1 Notice ............................................................................................................................... 5
3.2 Thermography Configuration Flow Chart..........................................................................6
3.3 Automatic Thermography................................................................................................. 8
3.3.1 Set Thermography Parameters .............................................................................. 8
3.3.2 Set Normal Mode ................................................................................................... 9
3.3.3 Set Expert Mode...................................................................................................10
3.3.4 Set Thermography Rule........................................................................................ 11
3.3.5 Point Thermography ............................................................................................ 12
3.3.6 Line Thermography ..............................................................................................12
3.3.7 Area Thermography ............................................................................................. 12
3.3.8 Set Shielded Region.............................................................................................. 13
3.4 Manual Thermography ...................................................................................................13
Chapter 4 Fire Source Detection...................................................................................................14
4.1 Recommended Scene...................................................................................................... 14
4.2 Set Fire Detection Parameters ........................................................................................ 14
Chapter 5 Behavior Analysis......................................................................................................... 16
5.1 Flow Chart of Behavior Analysis ..................................................................................... 16
5.2 Set VCA Parameters........................................................................................................ 17
5.3 Calibration ...................................................................................................................... 17

Thermal & Optical Bi-spectrum Network Camera
viii
5.3.1 Calibrate Automatically........................................................................................ 17
5.3.2 Calibrate Manually............................................................................................... 18
5.3.3 Verify the Calibration Result ................................................................................ 19
5.4 Set Rules .........................................................................................................................19
5.5 Advanced Configuration ................................................................................................. 21
Chapter 6 Event and Alarm........................................................................................................... 23
6.1 Set Alarm Input...............................................................................................................23
6.2 Set Exception Alarm........................................................................................................ 23
6.3 Detect Audio Exception .................................................................................................. 24
6.4 Set Burning-Prevention................................................................................................... 24
Chapter 7 Arming Schedule and Alarm Linkage............................................................................ 26
7.1 Set Arming Schedule....................................................................................................... 26
7.2 Linkage Method Settings ................................................................................................ 26
7.2.1 Trigger Alarm Output ........................................................................................... 26
7.2.2 FTP/NAS/Memory Card Uploading ...................................................................... 27
7.2.3 Send Email............................................................................................................ 28
7.2.4 Notify Surveillance Center....................................................................................29
7.2.5 Trigger Recording ................................................................................................. 29
7.2.6 Set Audible Alarm Output .................................................................................... 29
7.2.7 Set Flashing Alarm Light Output........................................................................... 29
Chapter 8 Live View...................................................................................................................... 31
8.1 Live View Parameters ..................................................................................................... 31
8.1.1 Window Division ..................................................................................................31
8.1.2 Live View Stream Type .........................................................................................31
8.1.3 Enable and Disable Live View............................................................................... 31
8.1.4 Start Digital Zoom ................................................................................................ 31
8.1.5 View Previous/Next Page.....................................................................................32
8.1.6 Full Screen............................................................................................................ 32
8.1.7 Light ..................................................................................................................... 32
8.1.8 Wiper ................................................................................................................... 32
8.1.9 Lens Initialization ................................................................................................. 32

Thermal & Optical Bi-spectrum Network Camera
ix
8.1.10 Auxiliary Focus ...................................................................................................32
8.1.11 Quick Set Live View ............................................................................................ 32
8.1.12 Lens Parameters Adjustment .............................................................................33
8.2 Set Transmission Parameters.......................................................................................... 33
Chapter 9 Video and Audio .......................................................................................................... 35
9.1 Video Settings................................................................................................................. 35
9.1.1 Stream Type .........................................................................................................35
9.1.2 Video Type ...........................................................................................................35
9.1.3 Resolution ............................................................................................................ 36
9.1.4 Bitrate Type and Max. Bitrate .............................................................................. 36
9.1.5 Video Quality ....................................................................................................... 36
9.1.6 Frame Rate........................................................................................................... 36
9.1.7 Video Encoding..................................................................................................... 36
9.1.8 Smoothing............................................................................................................ 37
9.1.9 Display VCA Info................................................................................................... 38
9.1.10 Audio Settings ....................................................................................................38
9.1.11 Two-way Audio .................................................................................................. 39
9.1.12 Set ROI................................................................................................................39
9.2 Display Settings............................................................................................................... 40
9.2.1 Image Adjustment................................................................................................40
9.2.2 Image Adjustment (Thermal Channel) ................................................................. 40
9.2.3 Exposure Settings................................................................................................. 41
9.2.4 Day/Night Switch ................................................................................................. 41
9.2.5 Set Supplement Light ........................................................................................... 42
9.2.6 BLC .......................................................................................................................42
9.2.7 WDR ..................................................................................................................... 42
9.2.8 White Balance ...................................................................................................... 43
9.2.9 DNR ...................................................................................................................... 43
9.2.10 Defog.................................................................................................................. 44
9.2.11 Gray Scale........................................................................................................... 44
9.2.12 Set Palette.......................................................................................................... 44

Thermal & Optical Bi-spectrum Network Camera
x
9.2.13 Set Target Enhancement ....................................................................................45
9.2.14 DDE..................................................................................................................... 45
9.2.15 Brightness Sudden Change ................................................................................. 45
9.2.16 Enhance Regional Image .................................................................................... 46
9.2.17 Mirror................................................................................................................. 46
9.2.18 Video Standard...................................................................................................46
9.2.19 Digital Zoom ....................................................................................................... 46
9.2.20 Scene Mode........................................................................................................46
9.2.21 Local Output....................................................................................................... 46
9.3 OSD ................................................................................................................................. 47
9.4 VCA Rule Display Settings ...............................................................................................47
9.5 Set Privacy Mask.............................................................................................................47
9.6 Overlay Picture ............................................................................................................... 48
9.7 Set Manual DPC (Defective Pixel Correction).................................................................. 48
Chapter 10 Video Recording and Picture Capture ........................................................................49
10.1 Storage Settings ............................................................................................................ 49
10.1.1 Set Memory Card ............................................................................................... 49
10.1.2 Set NAS............................................................................................................... 49
10.1.3 Set FTP................................................................................................................50
10.1.4 Set Cloud Storage............................................................................................... 50
10.2 Video Recording............................................................................................................ 51
10.2.1 Record Automatically......................................................................................... 51
10.2.2 Record Manually ................................................................................................ 53
10.2.3 Playback and Download Video........................................................................... 53
10.3 Capture Configuration ..................................................................................................54
10.3.1 Capture Automatically ....................................................................................... 54
10.3.2 Capture Manually............................................................................................... 54
10.3.3 View and Download Picture...............................................................................55
Chapter 11 Network Settings ....................................................................................................... 56
11.1 Wireless Dial ................................................................................................................. 56
11.1.1 Set Wireless Dial................................................................................................. 56

Thermal & Optical Bi-spectrum Network Camera
xi
11.2 WLAN AP (Access Point)................................................................................................ 57
11.2.1 Access to Device via AP ......................................................................................57
11.3 TCP/IP ...........................................................................................................................57
11.3.1 Multicast Discovery............................................................................................58
11.4 Port ............................................................................................................................... 59
11.5 Port Mapping................................................................................................................60
11.5.1 Set Auto Port Mapping....................................................................................... 60
11.5.2 Set Manual Port Mapping .................................................................................. 60
11.6 Multicast....................................................................................................................... 61
11.7 SNMP ............................................................................................................................ 61
11.8 Access to Device via Domain Name ..............................................................................61
11.9 Access to Device via PPPoE Dial Up Connection............................................................ 62
11.10 Enable Hik-Connect Service on Camera ...................................................................... 63
11.10.1 Enable Hik-Connect Service via Web Browser.................................................. 63
11.10.2 Enable Hik-Connect Service via SADP Software ............................................... 64
11.10.3 Access Camera via Hik-Connect........................................................................64
11.11 Set ISUP....................................................................................................................... 65
11.12 Set Open Network Video Interface .............................................................................65
11.13 Set Alarm Host ............................................................................................................ 65
11.14 Set Alarm Server ......................................................................................................... 66
11.15 Set Network Service....................................................................................................66
11.16 Set SRTP ......................................................................................................................67
Chapter 12 System and Security................................................................................................... 68
12.1 View Device Information .............................................................................................. 68
12.2 Search and Manage Log ................................................................................................68
12.3 Import and Export Configuration File............................................................................ 68
12.4 Export Diagnose Information........................................................................................69
12.5 Reboot .......................................................................................................................... 69
12.6 Restore and Default...................................................................................................... 69
12.7 Upgrade ........................................................................................................................ 69
12.8 View Open Source Software License.............................................................................70

Thermal & Optical Bi-spectrum Network Camera
xii
12.9 Time and Date............................................................................................................... 70
12.9.1 Synchronize Time Manually ............................................................................... 70
12.9.2 Set NTP Server....................................................................................................70
12.9.3 Set DST ............................................................................................................... 71
12.10 Power Consumption Mode .........................................................................................71
12.11 Set RS-232...................................................................................................................72
12.12 Set RS-485...................................................................................................................72
12.13 Set Same Unit.............................................................................................................. 72
12.14 Security ....................................................................................................................... 73
12.14.1 Authentication ................................................................................................. 73
12.14.2 Security Audit Log ............................................................................................73
12.14.3 Set IP Address Filter ......................................................................................... 74
12.14.4 Set SSH ............................................................................................................. 74
12.14.5 Set HTTPS ......................................................................................................... 75
12.14.6 Set QoS............................................................................................................. 76
12.15 User and Account........................................................................................................ 76
12.15.1 Set User Account and Permission.....................................................................76
Chapter 13 Appendix.................................................................................................................... 78
13.1 Common Material Emissivity Reference ....................................................................... 78
13.2 Device Command.......................................................................................................... 78
13.3 Device Communication Matrix......................................................................................79
13.4 FAQ ............................................................................................................................... 79

Thermal & Optical Bi-spectrum Network Camera
1
Chapter 1 Overview
1.1 Brief Description
Thermal & Optical Bi-spectrum network camera equipped with built-in GPU which supports
intelligent behavior analysis algorithm, can realize high-precision VCA detection and real-time
alarm. It is applied to perimeter defense and fire-prevention purposes in critical infrastructures
such as community, villa, construction site, factory, 4S stores, and so on. The pre-alarm system
helps you discover unexpected events immediately and protects your property.
1.2 Function
This section introduces main functions of the device.
Note
Not all models support the configurations below, take the actual product for reference.
Fire Detection
Device can detect the dynamic fire source in the scene and output pre-alarm and alarm to protect
the property.
Temperature Measurement
Device can measure the actual temperature of the spot being monitored. The device alarms when
temperature exceeds the temperature threshold value.
VCA
Device can do behavior analysis. Multiple rules can be configured for different requirements.
Smoking Detection
Device can detect the smoking behavior and alarm.
Power Consumption Mode
Device supports low power consumption mode and sleep schedule to reduce the power
consumption when the device works.

Thermal & Optical Bi-spectrum Network Camera
2
Chapter 2 Device Activation and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to activate the device when access the device via network.
Note
Refer to the user manual of the software client for the detailed information about the client
software activation.
2.1 Activate the Device via SADP
Search and activate the online devices via SADP software.
Before You Start
Access www.hikvision.com to get SADP software to install.
Steps
1. Connect the device to network using the network cable.
2. Run SADP software to search the online devices.
3. Check Device Status from the device list, and select Inactive device.
4. Create and input the new password in the password field, and confirm the password.
Caution
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case letters, lower case letters, numbers, and special characters)
in order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system, resetting the password monthly or weekly can
better protect your product.
5. Click OK.
Device Status changes into Active.
6. Optional: Change the network parameters of the device in Modify Network Parameters.
2.2 Activate the Device via Browser
You can access and activate the device via the browser.
Steps
1. Connect the device to the PC using the network cables.
2. Change the IP address of the PC and device to the same segment.

Thermal & Optical Bi-spectrum Network Camera
3
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3. Input 192.168.1.64 in the browser.
4. Set device activation password.
Caution
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case letters, lower case
letters, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
5. Click OK.
6. Input the activation password to log in to the device.
7. Optional: Go to Configuration → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in Installation
Certain operation systems and web browser may restrict the display and operation of the device
function. You should install plug-in or complete certain settings to ensure normal display and
operation. For detailed restricted function, refer to the actual device.
Operating System
Web Browser
Operation
Windows
Internet Explorer 10+
Follow pop-up prompts to
complete plug-in installation.
Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Go to Configuration →
Network → Advanced
Settings → Network Service
to enable WebSocket or
WebSockets for normal view if

Thermal & Optical Bi-spectrum Network Camera
4
Operating System
Web Browser
Operation
plug-in installation is not
required. Display and
operation of certain functions
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted function, refer to
the actual device.
Mac OS 10.13+
Mac Safari 12+
Plug-in installation is not
required.
Go to Configuration →
Network → Advanced
Settings → Network Service
to enable WebSocket or
WebSockets for normal view.
Display and operation of
certain functions are
restricted. For example,
Playback and Picture are not
available. For detailed
restricted function, refer to
the actual device.
Note
The device only supports Windows and Mac OS system and does not support Linux system.
2.3.2 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Configuration → System → Security → Security Service, and enable Enable Illegal Login
Lock. Illegal Login Attempts and Locking Duration are configurable.
Illegal Login Attempts
When your login attempts with the wrong password reach the set times, the device is locked.
Locking Duration
The device releases the lock after the setting duration.

Thermal & Optical Bi-spectrum Network Camera
5
Chapter 3 Temperature Measurement
When you enable this function, the device measures the actual temperature of the scene. It
alarms when temperature exceeds the temperature threshold value.
3.1 Notice
This part introduces the notices of configuring temperature measurement function.
●The target surface should be as vertical to the optical axis as possible. It is recommended that
the angle of oblique image plane should be less than 45°.
●The target image pixels should be more than 5 × 5.
●Please select line thermography or area thermography for a certain area temperature
measurement. The point thermography is not recommended in case of deviation occurred
during device movement to affect the accuracy of temperature measurement.

Thermal & Optical Bi-spectrum Network Camera
6
3.2 Thermography Configuration Flow Chart
This part introduces the process of configuring temperature measurement.

Thermal & Optical Bi-spectrum Network Camera
7
Figure 3-1 Thermography Configuration Flow Chart
