HIK VISION DeepinView DS-2XM6425G0/F Series User manual

0
Network Covert Camera
Quick Start Guide

Network Covert Camera·Quick Start Guide
1
Quick Start Guide
COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This Manual is applicable to 64xx Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective
owners.

Network Covert Camera·Quick Start Guide
2
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE
LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

Network Covert Camera·Quick Start Guide
3
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions

Network Covert Camera·Quick Start Guide
4
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info

Network Covert Camera·Quick Start Guide
5
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.

Network Covert Camera·Quick Start Guide
6
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.

Network Covert Camera·Quick Start Guide
7
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-30°C ~+60°C, or -40°C ~ +60°C if the
camera model has an “H” in its suffix), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Covert Camera·Quick Start Guide
8
Table of Contents
1 Appearance Description ............................................................... 10
1.1 General Appearance...................................................... 10
1.1.1 Type I Camera General Appearance.................... 10
1.1.2 Type II Camera General Appearance................... 12
1.1.3 Type III Camera General Appearance.................. 13
1.2 Front Panel.................................................................... 15
1.2.1 Type I Covert Camera Front Panel....................... 15
1.2.2 Type II Covert Camera Front Panel...................... 17
1.2.3 Type III Covert Camera Front Panel..................... 18
1.3 Rear Panel ..................................................................... 19
1.3.1 Type I Covert Camera Rear Panel........................ 19
1.3.2 Type II Covert Camera Rear Panel....................... 20
1.3.3 Type III Covert Camera Rear Panel...................... 21
1.4 Sensor Units.................................................................. 22
2 Installation.................................................................................... 27
2.1 Installing the Main Unit................................................. 27
2.1.1 Installing Type I Covert Camera Unit................... 27
2.1.2 Installing Type II Covert Camera Unit.................. 29
2.1.3 Installing Type III Covert Camera Unit................. 30
2.2 Installing the Block-Shaped Sensor Unit ........................ 32
2.2.1 Concealed Mounting .......................................... 32
2.2.2 Exposed Mounting ............................................. 34
2.2.3 Mounting with Pole-Shaped Bracket .................. 35
Installing the Cylindrical Sensor Unit ............................. 43
Installing the Tube Lens................................................. 45
2.5 Installing the Ball-Shaped Sensor Unit........................... 50
2.5.1 Mounting with the Included Bracket .................. 50

Network Covert Camera·Quick Start Guide
9
2.5.2 Mounting with a Incline Bracket......................... 54
3 Activate and Access Network Camera .......................................... 58

Network Covert Camera·Quick Start Guide
10
1Appearance Description
1.1 General Appearance
There are two covert camera types, the general appearance of the
covert camera is shown below:
1.1.1 Type I Camera General Appearance
1
2
3
4
567
Figure 1-1 Type I Camera General Appearance

Network Covert Camera·Quick Start Guide
11
Table 1-1 Description of the Type I Camera
No.
Description
1
Main unit
2
Mounting rail
3
Rear panel
4
Front panel
5
POWER
Indicator LED
Solid red: Power-on
Unlit: Power-off
6
STATUS
Indicator LED
Solid green: The camera works
properly.
Unlit: The camera does not work
properly.
7
LINK Indicator
LED
Flashing amber: Network properly
connected.
Unlit: Network disconnected.

Network Covert Camera·Quick Start Guide
12
1.1.2 Type II Camera General Appearance
1
43
2
Figure 1-2 Type II Camera General Appearance
Table 1-2 Description of the General Appearance
No.
Description
1
Main unit
2
LINK: network indicator
3
STATUS: status indicator
4
POWER: power indicator

Network Covert Camera·Quick Start Guide
13
1.1.3 Type III Camera General Appearance
1
2 3 4
Figure 1-3 Type III Camera General Appearance
Table 1-3 Description of the General Appearance
No.
Description
1
Main unit
2
POWER
Indicator LED
Solid red: Power-on
Unlit: Power-off
3
STATUS
Indicator LED
Solid green: The camera works
properly.
Unlit: The camera does not work
properly.

Network Covert Camera·Quick Start Guide
14
No.
Description
4
LINK Indicator
LED
Flashing amber: Network properly
connected.
Unlit: Network disconnected.

Network Covert Camera·Quick Start Guide
15
1.2 Front Panel
1.2.1 Type I Covert Camera Front Panel
The Type I covert camera equips with three types of front panel, as
shown in Figure 1-4, Figure 1-5, and Figure 1-6.
AUDIO
IN AUDIO
OUT
VIN1
SD
1234
Figure 1-4 The Type A Front Panel
AUDIO
OUT
AUDIO
IN
VIN1
SD
1234
Figure 1-5 The Type B Front Panel

Network Covert Camera·Quick Start Guide
16
VIN2
AUDIO
IN AUDIO
OUT
VIN1
SD
1234
Figure 1-6 The Type C Front Panel
Table 1-4 Description of the Front Panel
No.
Description
1
Audio input
2
Audio output
3
RJ-12 video input interface(s)
4
MicroSD card slot

Network Covert Camera·Quick Start Guide
17
1.2.2 Type II Covert Camera Front Panel
1 2 3
Figure 1-7 Type II Camera Front Panel
Table 1-5 Description of the Front Panel
No.
Description
1
Power Input: 12 V DC
2
Network interface
3
RS-485: connect RS-485 cable
ALARM: connect OUT and G terminals, connect
IN and G terminals
AUDIO: connect OUT and G terminals, connect IN
and G terminals

Network Covert Camera·Quick Start Guide
18
1.2.3 Type III Covert Camera Front Panel
The front panel of the Type III covert camera is shown in Figure 1-8.
1 2 3
Figure 1-8 The Type B Front Panel
Table 1-6 Description of the Front Panel
No.
Description
1
12 V DC M8 aviation plug
2
LAN interface
3
MicroSD card slot

Network Covert Camera·Quick Start Guide
19
1.3 Rear Panel
1.3.1 Type I Covert Camera Rear Panel
The rear panel of the Type I covert camera is shown in Figure 1-9.
ALARM
RS232
RXD TXD GND IN1 1B 1A
LAN(PoE)
DC 12V
RESET
1 2
34
Figure 1-9 Type I Covert Camera Rear Panel
Table 1-7 Description of the Type I Covert Camera Rear Panel
No.
Description
1
Reset
2
Power input
3
RS-232 and alarm input and output
interfaces
4
Ethernet interface with PoE function
