HIK VISION XE61 Series User manual

0
Explosion-Proof Dome Network Camera
Quick Start Guide
UD08535B
05050620171218

Network Dome Camera·Quick Start Guide
1
1
Quick Start Guide
COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This manual is applicable to XE61 Series Explosion-Proof Dome
Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and

Network Dome Camera·Quick Start Guide
2
2
logos mentioned below are the properties of their respective
owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL
HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE
LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

Network Dome Camera·Quick Start Guide
3
3
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.

Network Dome Camera·Quick Start Guide
4
4
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the EMC Directive 2014/30/EU, the
RoHS Directive 2011/65/EU, the ATEX Directive 2014/34/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see:www.recyclethis.info
Intended use of the camera
ATEX: II 2 G D Ex db IIC T6 Gb/Ex tb IIIC T80℃Db IP68
IECEx: Ex db IIC T6 Gb/Ex tb IIIC T80℃Db IP68
Hazardous Area Classification: Zone 1, Zone 2, Zone 21, Zone 22.

Network Dome Camera·Quick Start Guide
5
5
IP Degree: IP68 (2m, 2h)
Ex Standards:
IEC 60079-0: 2011
EN 60079-0: 2012/All: 2013
IEC 60079-1: 2014
EN 60079-1: 2014
IEC 60079-31: 2013
EN 60079-31: 2014
Nameplate:
Special Conditions for Safe Use:
1. Ambient Temperature: -40°C to +60°C.
2. DO NOT OPEN WHEN ENERGIZED.
3. POTENTIAL ELECTROSTATIC CHARGING HAZARD –SEE
INSTRUCTIONS.
4. When assembly, operation and maintenance, the operator must
follow the requirements of the IEC 60079-14: latest version
Explosive atmosphere- Part 14: Electrical installation design,
selection and erection, beside of the manufacturer’s operation
instruction or its National equivalent.

Network Dome Camera·Quick Start Guide
6
6
5. Repair and overhaul shall comply with IEC 60079-19: latest version
or its National equivalent.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Warning:
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to
take adequate measures.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these precautions
to prevent potential injury or
material damage.

Network Dome Camera·Quick Start Guide
7
7
Warnings
●Grounding:
The both internal and external earthing shall be connected
reliably.
Ground wire cross-sectional area of not less than the phase
connector cross-sectional area level, at least 4 mm2.
●All the electrical operation should be strictly compliance with
the electrical safety regulations, fire prevention regulations and
other related regulations of the nation and region.
●Make sure that the power has been disconnected before you
wire, install or disassemble the camera. Never wire, install or
disassemble the camera in explosive environment.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●To avoid fire danger caused by electrostatic charge, never touch
or wipe the camera in explosive environment. Perform the
wiping and replacing accessories only under non-explosive
environment with the provided glove.
●When the camera is installed on wall or ceiling, the device shall
be firmly fixed.
●If smoke, odors or noise rise from the camera, turn off the
power at once and unplug the power cable, and then contact
the service center.

Network Dome Camera·Quick Start Guide
8
8
●If the camera does not work properly, contact your dealer or
the nearest service center. Never attempt to disassemble the
speed dome yourself. (We shall not assume any responsibility
for problems caused by unauthorized repair or maintenance.)
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●To ensure explosion-proof performance, do not damage
explosion-proof surface.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-40°C to +60°C), dusty or damp locations,
and do not expose it to high electromagnetic radiation.

Network Dome Camera·Quick Start Guide
9
9
●To avoid heat accumulation, good ventilation is required for
operating environment.
●To prevent accumulation of electrostatic charge, only damp
cloth can be used during the cleaning.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Dome Camera·Quick Start Guide
10
10
Table of Contents
1 Introduction .............................................................................11
1.1 Overview ............................................................................11
1.2 Model Description .............................................................11
2 Appearance Description ............................................................13
2.1 Overview ............................................................................13
2.2 Cable Description .............................................................. 14
3 Installation ...............................................................................15
3.1 Wall Mounting ...................................................................16
3.2 Pendant Mounting............................................................. 19
4 Setting the Network Camera over the LAN .................................21
Wiring.................................................................................21
Activating the Camera ....................................................... 22
Activation via Web Browser ..................................22
Activation via SADP Software................................ 23
Modifying the IP Address ..................................................25
5 Accessing via Web Browser .......................................................28
6 Operating via Hik-Connect App..................................................30
6.1 Enable Hik-Connect Service on Camera...........................30
Enable Hik-Connect Service via SADP Software...30
Enable Hik-Connect Service via Web Browser .....31
6.2 Hik-Connect Setup.............................................................33
6.3 Adding Camera to Hik-Connect ........................................33
6.4 Initializing the Memory Card ............................................ 35

Network Dome Camera·Quick Start Guide
11
11
1Introduction
1.1 Overview
Explosion-proof network camera is a surveillance product capable of
video/audio collecting, smart encoding and network transmitting. It
adopts an embedded system and a high-performed hardware
process platform to achieve good stability and reliability.
You can visit and configure your camera via web browser and client
software.
Explosion-proof network camera adopts a stainless steel enclosure,
receiving an IP68 rating for ingress protection.
Application Scenarios: oil industry, mine fields, chemical industry,
port, grain processing industry, etc..
1.2 Model Description
This manual is applicable to the following models:
Table 1-1 Applicable Model List
Model List
DS-2XE6126FWD-HS
DS-2XE6136F-HS
DS-2XE6146F-HS
DS-2XE6166F-HS
DS-2XE6186F-HS
DS-2XE6127FWD-HS
DS-2XE6147F-HS
DS-2XE6157F-HS
DS-2XE6167F-HS
DS-2XE6126FWD-S
DS-2XE6146F-S
DS-2XE6166F-S
DS-2XE6186F-S

Network Dome Camera·Quick Start Guide
12
12
On-board Storage Logo(F/Blank, nothing to do with explosion-proof properties) F:supports on-board storage,blank:no supports on-board storage
DS-2 X E 6 1 2 6 F -H S
Hikvision Front-end Product Logo
For Specialized Application Logo(XE) XE:professional products
Product Type (6) 6:professional products
Product Shape Logo(1) 1:dome camera
Max.Resolution Logo(0~9/A~Z, nothing to do with explosion-proof properties) 0:WD1, 1: 1.3 MP, 2: 2.0 MP, 3: 3.0 MP, 4: 4.0 MP, 5: 5.0 MP, 6: 6.0 MP, 8: 8.0 MP, 9: 9.0 MP, etc.
Hardware Performance Logo(0-9, nothing to do with explosion-proof properties) 0:hardware version V-0, 1:hardware version V-1, 2:hardware version V-2, 3:hardware version V-3, 4:hardware version V-4, 5:hardware version V-5, 6:hardware version V-6, 7:hardware version V-7,etc.
Interface Logo (S/Blank） S :audio I/O, alarm I/O, RS-485 interface; blank: without Audio I/O, Alarm I/O, RS-485 interface
WD
Wide-dynamic Function Logo(WD/Blank, nothing to do with explosion-proof properties) WD:supports 120dB wide-dynamic ,blank:no supports 120dB wide-dynamic range
Heater Logo(H/Blank) H: have heater; blank: without.
Figure 1-1 Model Explanation

Network Dome Camera·Quick Start Guide
13
13
2Appearance Description
2.1 Overview
Figure 2-1 Explosion-Proof Network Dome Camera Overview

Network Dome Camera·Quick Start Guide
14
14
2.2 Cable Description
1
2
3
4
5
6
Figure 2-2 Overview of Cables
Table 2-1 Description of Cables
No.
Description
No.
Description
1
Video out (CVBS)
4
Audio input and output
2
RS-485
5
Power cord (9 to 16 VDC)
3
Alarm input and output
6
RJ45 Ethernet interface

Network Dome Camera·Quick Start Guide
15
15
3Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 9 to 16 VDC, please make sure
your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.

Network Dome Camera·Quick Start Guide
16
16
3.1 Wall Mounting
Before you start:
There is no wall mounting bracket included in the package. You have
to prepare a wall mounting bracket if you choose this mounting type.
The shown bracket below is only for demonstration.
Ø 110
4-Ø 3.5
77.8
77.8
3-Ø 6.5
Ø 100
Ø 80
Ø 136
353.4
204.3
Figure 3-1 DS-1695ZJ Wall Mount
Steps:
1. Fix the dome camera to wall mount with four screws (SC-PSFM3 ×
8-SUS).

Network Dome Camera·Quick Start Guide
17
17
Figure 3-2 Fix Camera to Wall Mount
2. Mark the 3 screw holes on desired mounting surface according to
the wall mount.
3. Drill screws holes (Ø 10.5 mm, 0.413 inch) for expansion bolts.
4. Secure the wall mount to wall.

Network Dome Camera·Quick Start Guide
18
18
Expansion
Bolt
Nut
Flat Washer
Spring Washer
Figure 3-3 Secure Wall Mount

Network Dome Camera·Quick Start Guide
19
19
3.2 Pendant Mounting
Before you start:
There is no pendant mounting bracket included in the package. You
have to prepare a pendant mounting bracket if you choose this
mounting type. The shown bracket below is only for demonstration.
Ø 100
360
Ø 30
Ø 136±0.2
Ø 80±0.2
4-Ø 6.5
Ø 110±0.2
4-Ø 3.5
Figure 3-4 DS-1694ZJ Pendant Mount
Steps:
1. Fix the dome camera to pendant mount with four screws
(SC-PSFM3 × 8-SUS).
