Hikmicro HIKMICRO SP Series User manual

Contact Us
Handheld Thermography Camera
HIKMICRO SP Series
User Manual
HIKMICRO SP Series

Handheld Thermography Camera User Manual
i
Legal Information
Read all information and instructions in this document carefully before using the device and keep
it for further reference.
For more device information and instructions, please visit our website at
http://www.hikmicrotech.com. You can also refer to other documents (if any) accompanying the
device to get more information.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the HIKMICRO website
(http://www.hikmicrotech.com).
Please use this Manual with the guidance and assistance of professionals trained in supporting the
Product.
© 2023 Hangzhou Microimage Software Co., Ltd. All rights reserved.
Trademarks
and other HIKMICRO's trademarks and logos are the properties of
HIKMICRO in various jurisdictions.
Other trademarks and logos mentioned are the properties of their respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKMICRO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY

Handheld Thermography Camera User Manual
ii
RISKS, AND HIKMICRO SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

Handheld Thermography Camera User Manual
iii
Regulatory Information
These clauses apply only to the products bearing the corresponding mark or
information.
FCC Information
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Note: Due to the device size limit, the above statement may not be disclaimed on the device.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the Directive 2014/30/EU (EMCD), Directive 2014/35/EU (LVD), Directive
2011/65/EU (RoHS).
This product and - if applicable - the supplied accessories too are marked with
"UKCA" and comply therefore with the following directives: Radio Equipment
Regulations 2017, Electromagnetic Compatibility Regulations 2016, Electrical
Equipment (Safety) Regulations 2016, the Restriction of the Use of Certain
Hazardous Substances in Electrical and Electronic Equipment Regulations 2012.
Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, when operating in the 5150
to 5350 MHz frequency range, this device is restricted to indoor use in: Austria
(AT), Belgium (BE), Bulgaria (BG), Croatia (HR), Cyprus (CY), the Czech Republic (CZ),
Denmark (DK), Estonia (EE), Finland (FI), France (FR), Germany (DE), Greece (EL),
Hungary (HU), Iceland (IS), Ireland (IE), Italy (IT), Latvia (LV), Liechtenstein (LI),
Lithuania (LT), Luxembourg (LU), Malta (MT), Netherlands (NL), Northern Ireland

Handheld Thermography Camera User Manual
iv
(UK(NI)), Norway (NO), Poland (PL), Portugal (PT), Romania (RO), Slovakia (SK),
Slovenia (SI), Spain (ES), Sweden (SE), Switzerland (CH), and Turkey (TR).
In accordance with the Radio Equipment Regulations 2017 in the UK, the device
working in the 5150 to 5350 MHz frequency range is restricted to indoor use in the
United Kingdom.
Frequency Bands and Power (for CE/UKCA)
The frequency bands and modes and transmitting power (radiated and/or
conducted) nominal limits applicable to the following radio equipment are as
follows:
Wi-Fi: 2.4 GHz (2.4 GHz to 2.4835 GHz): 20 dBm; 5 GHz (5.15 GHz to 5.25 GHz): 23
dBm; 5 GHz (5.25 GHz to 5.35 GHz): 23 dBm; 5 GHz (5.47 GHz to 5.725GHz): 23
dBm; 5 GHz (5.725 GHz to 5.85 GHz): 14 dBm
Bluetooth: 24 GHz (2.4 GHz to 2.4835 GHz): 20 dBm
Use the power adapter provided by a qualified manufacturer. Refer to the product
specification for detailed power requirements.
Use the battery provided by a qualified manufacturer. Refer to the product
specification for detailed battery requirements.
Directive 2012/19/EU (WEEE Directive): Products marked with this symbol cannot
be disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info
According to the Waste Electrical and Electronic Equipment Regulations 2013:
Products marked with this symbol cannot be disposed of as unsorted municipal
waste in the United Kingdom. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
Directive 2006/66/EC and its amendment 2013/56/EU (Battery Directive): This
product contains a battery that cannot be disposed of as unsorted municipal waste
in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated collection point. For more information
see: www.recyclethis.info.
According to the Batteries and Accumulators (Placing on the Market) Regulations
2008 and the Waste Batteries and Accumulators Regulations 2009: This product
contains a battery that cannot be disposed of as unsorted municipal waste in the
United Kingdom. See the product documentation for specific battery information.
The battery is marked with this symbol, which may include lettering to indicate

Handheld Thermography Camera User Manual
v
cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery
to your supplier or to a designated collection point. For more information see:
www.recyclethis.info.
Warning: This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-003 (A)/NMB-003(A) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator & your body.
ce matériel est conforme aux limites de dose d'exposition aux rayonnements, CNR-102 énoncée
dans un autre environnement.cette eqipment devrait être installé et exploité avec distance
minimale de 20 entre le radiateur et votre corps.
(i) The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
(ii) The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725
MHz shall comply with the e.i.r.p. limit; and
(iii) The maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply
with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate.
(i)Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une
utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux.
(ii) Le gain d'antenne maximal autorisé pour les appareils dans les bandes 5250-5350 MHz et
5470-5725 MHz doivent respecter le pire limiter; et
(iii) Le gain d'antenne maximal autorisé pour les appareils dans la bande 5725-5825 MHz doivent
respecter le pire limites spécifiées pour le point-à-point et l'exploitation non point à point, le cas
échéant.

Handheld Thermography Camera User Manual
vi
KC
A급기기: 이기기는 업무용(A급) 전자파적합기기로써 판매자 또는 사용자는 이점을
주의하시기바라며, 가정 외의 지역에서 사용하는 것을 목적으로 합니다.

Handheld Thermography Camera User Manual
vii
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

Handheld Thermography Camera User Manual
viii
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss. Please read all the safety information carefully before using.
Laws and Regulations
●Use of the product must be in strict compliance with the local electrical safety regulations.
Transportation
●Keep the device in original or similar packaging while transporting it.
●Keep all wrappers after unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportation without the
original wrapper may result in damage on the device and the company shall not take any
responsibilities.
●DO NOT drop the product or subject it to physical shock. Keep the device away from magnetic
interference.
Power Supply
●Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(7.2 VDC, 890 mA) according to the IEC61010-1 standard. Please refer to technical specifications
for detailed information.
●Make sure the plug is properly connected to the power socket.
●DO NOT connect multiple devices to one power adapter, to avoid over-heating or fire hazards
caused by overload.
Battery
●Improper use or replacement of the battery may result in explosion hazard. Replace with the
same or equivalent type only. Dispose of used batteries in conformance with the instructions
provided by the battery manufacturer.
●The built-in battery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●For long-term storage of the battery, make sure it is fully charged every half year to ensure the
battery quality. Otherwise, damage may occur.
●DO NOT charge other battery types with the supplied charger. Confirm there is no flammable
material within 2 m of the charger during charging.
●DO NOT place the battery near heating or fire source. Avoid direct sunlight.
●DO NOT swallow the battery to avoid chemical burns.
●DO NOT place the battery in the reach of children.
●When the device is powered off and the RTC battery is full, the time settings can be kept for 3
months.
●The lithium battery voltage is 7.2 V, and the battery capacity is 4800 mAh.
●The battery is certified by UL2054.

Handheld Thermography Camera User Manual
ix
Maintenance
●If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●A few device components (e.g., electrolytic capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary.
●If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the device may be impaired.
●We recommend you send the device back for calibration once a year, and please contact the
local dealer for the information on maintenance points.
●Please notice that the current limit of USB 3.0 PowerShare port may vary with the PC brand,
which is likely to result in incompatibility issue. Therefore it’s advised to use regular USB 3.0 or
USB 2.0 port if the USB device fails to be recognized by PC via USB 3.0 PowerShare port.
●Your camera will periodically perform a self-calibration to optimize image quality and
measurement accuracy. In this process the image will pause briefly and you’ll hear a “click” as a
shutter moves in front of the detector. The self-calibration will be more frequent during start up
or in very cold or hot environments. This is a normal part of operation to ensure optimum
performance for your camera.
Using Environment
●Make sure the running environment meets the requirement of the device. The operating
temperature shall be -20°C to 50°C (-4°F to 122°F), and the operating humidity shall be 95% or
less.
●This device can only be safely used in the region below 2000 meters above the sea level.
●Place the device in a dry and well-ventilated environment.
●DO NOT expose the device to high electromagnetic radiation or dusty environments.
●DO NOT aim the lens at the sun or any other bright light.
●When any laser equipment is in use, make sure that the device lens is not exposed to the laser
beam, or it may burn out.
●The device is suitable for indoor and outdoor uses, but do not expose it in wet conditions.
●The level of protection is IP 54.
●The pollution degree is 2.
Technical Support
The https://www.hikmicrotech.com/en/contact-us.html portal will help you as a HIKMICRO
customer to get the most out of your HIKMICRO products. The portal gives you access to our
support team, software and documentation, service contacts, etc.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the
power cable, and contact the service center.

Handheld Thermography Camera User Manual
x
Laser Light Supplement Warning
Warning: The laser radiation emitted from the device can cause eye injuries, burning of skin or
inflammable substances. Prevent eyes from direct laser. Before enabling the Light Supplement
function, make sure no human or inflammable substances are in front of the laser lens. The wave
length is 650 nm, and the power is less than 1 Mw. The laser meets the IEC60825-1:2014 standard.
Laser maintenance: It is not necessary to maintain the laser regularly. If the laser does not work,
the laser assembly needs to be replaced in the factory under warranty. Keep the device power off
when replacing laser assembly. Caution-Use of controls or adjustments or performance of
procedures other than those specified herein may result in hazardous radiation exposure.
Manufacture Address
Room 313, Unit B, Building 2, 399 Danfeng Road, Xixing Subdistrict,Binjiang District, Hangzhou,
Zhejiang 310052, China
Hangzhou Microimage Software Co., Ltd.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without limitation, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government authorities for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between different countries.

Handheld Thermography Camera User Manual
xi
Contents
Chapter 1 Overview........................................................................................................................ 1
1.1 Device Description ............................................................................................................1
1.2 Main Function...................................................................................................................1
1.3 Appearance.......................................................................................................................3
Chapter 2 Preparation....................................................................................................................8
2.1 Charge Device ................................................................................................................... 8
2.1.1 Charge Device via Cable Interface .......................................................................... 8
2.1.2 Charge Battery via Charging Base........................................................................... 8
2.2 Mount Hand Strap ............................................................................................................9
2.3 Change Interchangeable Lens .........................................................................................10
2.4 Tilt Lens and Screen ........................................................................................................12
2.5 Power On/Off ................................................................................................................. 13
2.5.1 Set Auto Power-off Duration................................................................................13
2.6 Sleep and Wake .............................................................................................................. 13
2.7 Operation Method..........................................................................................................14
2.8 Menu Description ...........................................................................................................15
Chapter 3 Display Settings............................................................................................................ 16
3.1 Focus............................................................................................................................... 16
3.1.1 Focus Lens Manually ............................................................................................16
3.1.2 Laser Assisted Focus.............................................................................................17
3.1.3 Auto Focus............................................................................................................17
3.1.4 Continuous Autofocus..........................................................................................17
3.1.5 High Temperature Priority ................................................................................... 18
3.2 Set Screen Brightness......................................................................................................18
3.3 Set Display Mode............................................................................................................18
3.4 Set Palettes ..................................................................................................................... 19
3.4.1 Set Alarm Mode Palettes .....................................................................................20
3.4.2 Set Focus Mode Palettes ......................................................................................20
3.5 Adjust Display Temperature Range.................................................................................21

Handheld Thermography Camera User Manual
xii
3.6 Adjust Digital Zoom ........................................................................................................22
3.7 Display OSD Info .............................................................................................................22
Chapter 4 Temperature Measurement.........................................................................................23
4.1 Set Measurement Parameters........................................................................................ 23
4.1.1 Set Unit ................................................................................................................ 24
4.2 Set Image Measurement................................................................................................. 24
4.3 Set Measurement Tool....................................................................................................25
4.3.1 Measure by Custom Spot ..................................................................................... 25
4.3.2 Measure by Line...................................................................................................26
4.3.3 Measure by Rectangle..........................................................................................27
4.3.4 Measure by Circle................................................................................................. 28
4.4 Measure ΔT and ΔT Alarm ..............................................................................................29
4.5 Temperature Alarm ........................................................................................................30
4.5.1 Set Alarms for Exceptional Temperatures............................................................30
4.6 Clear All Measurements..................................................................................................31
Chapter 5 Route Inspection..........................................................................................................32
5.1 Create Inspection Route and Send Task to Device.......................................................... 32
5.2 Perform Route Inspection...............................................................................................33
5.3 Upload Inspection Result and View Report ....................................................................35
Chapter 6 Picture and Video.........................................................................................................37
6.1 Capture Picture...............................................................................................................37
6.2 Record Video................................................................................................................... 39
6.3 View and Manage Local Files ..........................................................................................40
6.3.1 Manage Albums ...................................................................................................40
6.3.2 Manage Files ........................................................................................................ 41
6.4 Local Analysis and Report Generation ............................................................................43
6.5 Export Files .....................................................................................................................44

Handheld Thermography Camera User Manual
xiii
Chapter 7 Calculate Area Size....................................................................................................... 45
Chapter 8 Distance Detection.......................................................................................................46
Chapter 9 Geographic Location Display........................................................................................47
Chapter 10 Direction Display........................................................................................................ 48
10.1 Calibrate Compass ........................................................................................................ 48
10.2 Magnetic Declination Correction ..................................................................................49
Chapter 11 Connect Bluetooth .....................................................................................................50
Chapter 12 Set LED Light............................................................................................................... 51
Chapter 13 Cast Device Screen to PC............................................................................................52
Chapter 14 Connect Device to Wi-Fi.............................................................................................53
Chapter 15 Set Device Hotspot..................................................................................................... 54
Chapter 16 Thermal View Mobile Client Connection....................................................................55
16.1 Connect via Wi-Fi .......................................................................................................... 55
16.2 Connect via Hotspot......................................................................................................55
Chapter 17 HDMI Image Output...................................................................................................56
Chapter 18 Maintenance.............................................................................................................. 57
18.1 View Device Information ..............................................................................................57
18.2 Set Date and Time.........................................................................................................57
18.3 Upgrade Device.............................................................................................................57
18.4 Restore Device ..............................................................................................................58
18.5 Initialize Memory Card..................................................................................................58
18.6 About Calibration..........................................................................................................58
Chapter 19 Appendix.................................................................................................................... 59
19.1 Common Material Emissivity Reference .......................................................................59
19.2 Device Command..........................................................................................................59
19.3 Device Communication Matrix......................................................................................60
19.4 FAQ ............................................................................................................................... 60

Handheld Thermography Camera User Manual
1
Chapter 1 Overview
1.1 Device Description
The handheld thermography camera is a device with both optical images and thermal images. It
can do thermography, distance measurement, video recording, snapshot capturing, alarm, and it
can connect to Wi-Fi, hotspot and Bluetooth. The built-in high-sensitivity IR detector and
high-performance sensor detects the variation of temperature and measure the real-time
temperature. Refer to the production specification on HIKMICRO website for detailed information.
The built-in laser module detects the target distance.
The device is easy to use, and adopts ergonomic design. It is widely applied to substations,
electricity prevention detection of companies, and reconnaissance survey of construction field.
1.2 Main Function
Temperature Measurement
Device detects the real-time temperature, and display it on the screen.
Route Inspection
Device can check the temperature of the check points in a predefined inspection route, and
upload the results to center client for analysis.
Distance Measurement
Device can detect the target distance with the laser light.
Fusion
Device can display fusion of thermal view and optical view.
Palette and Alarm
Device supports multiple palettes, and you can set the palette mode according to the alarm
function.
Geographical Location and Direction Display
For some models that are equipped satellite positioning module and compass, geographical
location and direction display are supported.
Note
The function is supported by certain models of this series.

Handheld Thermography Camera User Manual
2
HDMI Output
For some models that have a micro HDMI output interface, you can connect the device to a display
unit to view live image.
Client Software Connection
●Mobile Phone: Use HIKMICRO Viewer to see live image, capture, and recording, etc. on your
phone.
HIKMICRO Viewer Android
HIKMICRO Viewer iOS
●PC: Use HIKMICRO Analyzer
(https://www.hikmicrotech.com/en/industrial-products/hikmicro-analyzer-software.html) to
see live image, capture, recording, and receive alarm message, etc. on your PC.
Use HIKMICRO Inspector to create inspection routes, send route inspection task to devices,
collect inspection results and generate analysis reports.
Bluetooth
Device can be connected to headset via Bluetooth, and you can hear the voice in the recording or
capture.

Handheld Thermography Camera User Manual
3
1.3 Appearance

Handheld Thermography Camera User Manual
4

Handheld Thermography Camera User Manual
5
Figure 1-1 Appearance
Table 1-1 Button and Interface Description
No.
Description
Function
1
Navigation Button
Menu Mode:
Press , , , and to select parameters.
Press OK to confirm.
Non-Menu Mode:
Press to turn on/off the LED light supplement.
Press and to adjust focus.
2
File Button
Press to enter albums.
3
Back Button
Exit the menu or return to previous menu.
4 & 14
Function Button
Press to use the custom function.
5
Touch Screen
Show the live view interface.
Touch-screen operation.
6
Focus Ring
Adjust focus to find clear targets.
7
Light Sensor
Sense the ambient brightness.
8
Microphone
Used to add voice note.
9
Zoom Button
Press to zoom in, and press to zoom out.
10
Diopter Adjustment
Wheel
Adjust the dioptric correction for the viewfinder.
11
Capture Button
Press: capture snapshots/stop recording
Hold: start recording

Handheld Thermography Camera User Manual
6
No.
Description
Function
12
Focus Button
Press to start focus.
13
Laser Button
Press: measure the distance with laser once
Hold: measure the distance with laser continuously
15
Hand Strap Attachment
Point
Mount the hand strap.
16 & 34
Neck Strap Attachment
Point
Mount the neck strap.
17
Tripod Mount
Mount the tripod.
18
Viewfinder
View live view through the viewfinder. See Display
Switch Button.
19
Power Button
Press: standby mode/wake up device
Hold: power on/off
20
Display Switch Button
Switch the LCD and the Viewfinder.
21
Eyepiece Plug
Protect the eyepiece.
22
Loudspeaker
Play voice note and voice alarm.
23
Optical Lens
View the optical image.
24
Laser Distance Meter
Measure the distance with laser.
25
Supplement Light
Increase ambient brightness in dark environment.
26
Thermal Lens
View the thermal image.
27
Memory Card Slot
Insert the memory card in it.
28
SIM Card Slot
Not Available.
29
Data Exchange
Interface
Charge the device or export files with supplied cable.
30
Indicator
Indicate the charging status of the device.
Solid red: charging normally
Flashing red: charging exception
Solid green: fully charged
31
Micro HDMI Interface
Connect the device with HDMI cable. A cable converter
(HDMI Type D to HDMI Type A) is included in the
carrying case.
32
Battery Compartment
Install the battery in it.
