HIKOKI CM 12Y User manual

Disc Cutter
手提切斷機
CM 12Y
Handling Instructions
使用說明書
Read through carefully and understand these instructions before use.
使用前務請詳加閱讀
000BookCM12Y.indb1000BookCM12Y.indb1 2018/03/229:50:502018/03/229:50:50

2
12
4
3
5
6
7
2
1
3
43
5
6
7
4
8
9
0
5
!
6
@
6
9
0
7
#
%
$7
8
&
^
&a
*44 6 mm
(43Z 7 mm
a
17 mm
000BookCM12Y.indb2000BookCM12Y.indb2 2018/03/229:50:502018/03/229:50:50

3
English 中國語 ﺔﻳﺑﺭﻌﻟﺍ
1Dust collector hose 集塵器軟管 ﺔﺑﺭﺗﻷﺍ ﻊﻣﺟﻣ ﻡﻭﻁﺭﺧ
2Hose 軟管 ﻡﻭﻁﺭﺧﻟﺍ
3Wheel washer (B) 輪墊圈（B） (B) ﺔﻠﺟﻌﻟﺍ ﺔﻘﻠﺣ
4Wheel washer (C) 輪墊圈（C） (C) ﺔﻠﺟﻌﻟﺍ ﺔﻘﻠﺣ
5Spindle 心軸 ﻥﺍﺭﻭﺩﻟﺍ ﺩﻭﻣﻋ
6Bolt 螺栓 ﺭﺎﻣﺳﻣ
7Diamond wheel 金剛石輪鋸 ﺔﻳﺳﺎﻣﻟﺍ ﺔﻠﺟﻌﻟﺍ
8Knob 旋鈕 ﺽﺑﻘﻣ
9Tighten 緊ﻁﺑﺭ
0Loosen 鬆ﻙﻓ
!Lock pin 鎖定銷 ﺕﻳﺑﺛﺗ ﺭﺎﻣﺳﻣ
@Wrench 扳手 ﻁﺑﺭ ﺡﺎﺗﻔﻣ
#Pipe handle 管手把 ﺔﺑﻭﺑﻧﻷﺍ ﺽﺑﻘﻣ
$Work piece 工件 ﻝﻣﻋ ﺔﻌﻁﻗ
%Premarked line 預劃線 ًﺎﻘﺑﺳﻣ ﺯﻳﻣﻣ ﻁﺧ
^Wear limit 磨損極限 ﻝﻛﺂﺗﻟﺍ ﺩﺣ
&No. of carbon brush 碳刷號 ﻥﻭﺑﺭﻛﻟﺎﺑ ﻝﻘﺻﻟﺍ ﺓﺎﺷﺭﻓ ﻡﻗﺭ
*Usual carbon brush 通常碳刷 ﺔﻳﺩﺎﻌﻟﺍ ﻥﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻓ
(Auto-stop carbon brush 自動停止碳刷 ﻑﻗﻭﺗﻟﺍ ﺔﻳﺋﺎﻘﻠﺗ ﻥﻭﺑﺭﻛﻟﺎﺑ ﻝﻘﺻ ﺓﺎﺷﺭﻓ
000BookCM12Y.indb3000BookCM12Y.indb3 2018/03/229:50:512018/03/229:50:51

4
English
GENERAL SAFETY RULES
WARNING!
Read all instructions
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
The term “power tool” in all of the warnings listed below
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) Work area
a) Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
of fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b)Use safety equipment. Always wear eye
protection.
Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c) Avoid accidental starting. Ensure the switch is
in the offposition before plugging in.
Carrying power tools with your finger on the switch
or plugging in power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of these devices can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
before making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tools operation.
If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits
etc., in accordance with these instructions and
in the manner intended for the particular type
of power tool, taking into account the working
conditions and the work to be performed.
Use of the power tool for operations different from
intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach
of children and infirm persons.
000BookCM12Y.indb4000BookCM12Y.indb4 2018/03/229:50:512018/03/229:50:51

5
English
PRECAUTION ON USING DISC CUTTER
1. Never attach any tool except the diamond wheel or
cutting wheel as specified by the manufacturer (see
optional accessories).
Do not operate the cutter while applying water.
2. Always check the diamond wheel before starting
the machine. If it is cracked, broken or bent, do not
use it. Carefully start the machine to check for other
abnormalities.
3. Using the diamond wheel to cut metal will shorten its
service life or will result in breakage. Never use the
diamond wheel to cut metal.
4. Start working only when maximum rotation speed is
reached.
5. Excessive force overloads the motor and reduces
working efficiency and service life. Always cut concrete,
tile or stone with a cutting depth of 50 mm or less. If the
cutting depth is more than 50mm, cut the workpiece 2
or 3 times. If the workpiece is cut with a cutting depth of
more than 50 mm, the service life of the diamond wheel
will be reduced and the motor may seize.
6. Do not use this machine to cut asbestos.
7. In operations using a cutting wheel, if flame comes out,
cover the dust collection adapter with a rubber cap and
be sure to wear protective glasses.
SPECIFICATIONS
Voltage (by areas)* (110 V, 115 V, 120 V, 127 V, 220 V, 230 V, 240 V)
Power input 2400 W*
No-load speed 5000 /min
Dimensions of diamond wheel
Outer dia. 305 mm
Thickness 2.0 mm
Hole dia. 22.2 mm / 20 mm
Max. cutting depth 100 mm
Weight (without cord and diamond wheel) 11.5 kg
* Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) Hose ............................................................................. 1
(2) Wrench ......................................................................... 1
(3) Protcetive glasses........................................................ 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
(1) Diamond wheels for dry cutting (segment type)
Type Wheel dia. (mm) Code No. Thickness (mm) Hole dia. (mm)
For concrete and masonry
305
985618
2.8 22.2
For concrete and masonry
(For heavy duty) 312367
For abrasive materials 985619 3.0
(2) Cutting wheels
Type Wheel dia. (mm) Code No. Hole dia. (mm) per pkg.
Metal cutting wheel
305
985609 22.2
10 pcs.
985608 25.4
Masonry cutting wheel 985611 22.2
985610 25.4
(3) Wheel washer (A) (hole diameter 25.4 mm)
Optional accesories are subject to change without notice.
APPLICATION
○Cutting or scribing concrete
○Cutting or scribing tile
○Cutting or scribing stone
○Cutting or scribing roof tile
○Cutting steel
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a power receptacle while
the power switch is in the ON position, the power tool
will start operating immediately, which could cause a
serious accident.
000BookCM12Y.indb5000BookCM12Y.indb5 2018/03/229:50:512018/03/229:50:51

6
English
3. Extension cord
When the work area is removed from the power source,
use an extension cord of sufficient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
4. Checking and installing the diamond wheel
Check the diamond wheel is a specified one and is not
cracked, broken or bent. Check the diamond wheel is
installed securely. For installation, refer to “Installing/
removing diamond wheel”.
5. Check that the knob used to secure the wheel
guard is tight.
Make sure that the knob that secures the wheel guard is
adequately tight.
If this knob is loose, it may result in injury to the operator.
(Fig. 4)
INSTALLING DUST COLLECTION HOSE
When cutting a material which generates cutting dust, use
the dust collection hose as follows:
(1) Remove the rubber cab and install the accessory hose.
(Fig. 1)
(2) Install the dust collector hose for the power tool in the
accessory hose. (Fig. 1)
CAUTION
○Do not use the dust collection hose when cutting metal.
○Always install a rubber cap on the dust collection
adapter when the dust collection hose is not used.
INSTALLING/REMOVING DIAMOND WHEEL
1. Installation
(1) Wipe the cutting dust from the spindle and washers.
(2) Make sure the rotation direction of the diamond wheel
conforms to the direction indicated on the wheel guard
and install the diamond wheel as shown in Fig. 2 and 3.
• Install the wheel washer (B) (silver) on the inner side
when the hole diameter of the diamond wheel is 22.2
mm.
• Install the wheel washer (C) (black) on the inner side
when the hole diameter of the diamond wheel is 20.0
mm.
(3) Press the lock pin and secure the spindle. Tighten
the bolt adequately with the provided wrench.
(Fig. 5 and 6)
NOTE
○Always use the provided wrench to secure the bolt.
○Be careful because the bolt tightens to the left
(counterclockwise direction) to prevent it from being
loosened during cutting. (Fig. 6)
2. Removal
Remove the bolt with the provided wrench and remove
the diamond wheel. (Fig. 6)
CUTTING
1. Wheel guard adjustment (Fig. 4)
Adjust the wheel guard angle with the knob so dust and
debris from the material or sparks do not contact the
operator during the cutting operation.
2. Cutting Procedures (Fig. 7)
(1) Place this tool on the material to be cut and align the
premarked line and the diamond wheel.
The cutting can be performed smoothly if you cut
straight ahead on the scribed line in the initial cut.
(2) Turn on the switch when the diamond wheel is not
touching the material to be cut.
CAUTION
○Always check the diamond wheel before starting work.
Never use a diamond wheel which is cracked, broken or
bent.
○Do not apply water or coolant to the diamond wheel.
○Start cutting only when diamond wheel reaches its
maximum speed.
○If the diamond wheel seizes or there is any abnormal
noise, immediately turn the power off.
○Never use the diamond wheel to cut zig zag or curved
lines. Never use the side surface of the diamond wheel.
Never use to perform inclination cutting.
○If excessive force is applied to the diamond wheel to
make it align with the premarked line during cutting,
this might not only overload the motor and cause burn
damage but may also overheat the diamond wheel and
shorten the service life.
○Take care not to allow the power cord to come into
contact with the diamond wheel during operation.
○When the work is completed, turn the power offand
disconnect the power plug from the receptacle.
MAINTENANCE AND INSPECTION
1. Inspection the diamond wheel
A worn diamond wheel overloads the motor and
reduces working efficiency. Replace with a new one.
2. Diamond Wheel Clogging
The rate of wear of the diamond layer cutting edge
will vary depending on the type of material being cut,
the cutting speed, etc. In general, materials which
produce granular cutting particles may scrape the
boding agent and hasten the wear of the diamond
layer. On the other hand, materials which produce
powdery cutting particles may cause clogging of the
diamond layer which will reduce cutting efficiency.
When clogging occurs, additional force applied in an
attempt to increase cutting speed will sometime cause
sparks to appear around the circumference of the
diamond wheel. In such a case, stop using the cutter
and carefully inspect the cutting edge by rubbing it
with your fingers. If the diamond layer feels smooth (no
roughness or abrasiveness), it is clogged with dust and
must be “dressed”.
For thorough dressing, approximately 5 meters of
slightly accelerated cutting at a depth of 10 mm in a
relative soft material which produces granular cutting
particles (such as a cement block or brick) will restore
the cutting effectiveness of the diamond layer and will
extend the service life of the diamond wheel.
The diamond material is susceptible to high
temperatures and will begin to deteriorate at
approximately 600°C. Higher temperatures will cause
decomposition of the diamond material. Accordingly, it
is important to perform “dressing” as soon as clogging
or sparking occurs.
3. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be loose, retighten them immediately. Failure to do so
could result in serious hazard.
4. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
000BookCM12Y.indb6000BookCM12Y.indb6 2018/03/229:50:512018/03/229:50:51

7
English
5. Inspecting the carbon brushes (Fig. 8)
The motor employs carbon brushes which are
consumable parts. Since an excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with a new one having the same carbon brush
numbers shown in the figure when it becomes worn to
or near the “wear limit”. In addition, always keep carbon
brushes clean and ensure that they slide freely within
the brush holders.
6. Replacing a carbon brush
Disassemble the brush cap with a minus-head
screwdriver. The carbon brush can then be easily
removed.
NOTE
Due to HiKOKI’s continuing program of reserch and
development, the specifications herein are subject to
change without prior notice.
000BookCM12Y.indb7000BookCM12Y.indb7 2018/03/229:50:512018/03/229:50:51

8
中國語
一般安全規則
警告！
閱讀所有說明
未遵守下列之說明可能導致電擊、火災及/或嚴重傷
害。
「電動工具」一詞在下列警告中，關係到電源操作
（有線）之電動工具或電池操作（無線）之電動工
具。
記住這些說明
1) 工作場所
a) 保持工作場所清潔及明亮。
雜亂及昏暗區域易發生意外。
b) 勿在易產生爆炸之環境中操作，譬如有易燃液
體、瓦斯或粉塵存在之處。
電動工具產生火花會引燃粉塵或煙氣。
c) 當操作電動工具時，保持兒童及過往人員遠
離。
分神會讓你失去控制。
2) 電氣安全
a) 電動工具插頭必須與插座配合，絕不可以任何
方法修改插頭，且不得使用任何轉接插頭於有
接地之電動工具。
不修改插頭及所結合之插座可減少電擊。
b) 避免身體接觸到接地面諸如管子、散熱器、爐
灶及冰箱。
如果你的身體接地或搭地，會增加電擊的危
險。
c) 勿讓電動工具淋雨或曝露在潮濕的環境下。
電動工具進水會增加電繫的危險。
d) 勿濫用電源線。絕勿使用電源線去纏繞、拖拉
電動工具或拔插頭，保持電源線遠離熱氣、油
氣、尖角或可動零件。
損壞或纏繞的電源線會增加電繫之危險。
e) 電動工具在室外操作時要使用一適合室外用的
延長線。
使用合適之室外用延長線會減少電擊的危險。
3) 人員安全
a) 保持機警，注意你正在做什麼，並運用普通常
識操作電動工具。
當你感到疲勞或受藥品、酒精或醫療影響時，
勿操作電動工具。
操作中瞬間的不注意可能造成人員嚴重的傷
害。
b) 使用安全裝備，常時佩戴安全眼鏡。
安全裝備有防塵口罩、防滑安全鞋、硬帽，或
在適當情況下使用聽覺防護，可減少人員傷
害。
c) 避免意外地啟動。在插電前確認開關是在
“off”的位置。
以手指放在開關握持電動工具，或在電動工具
的開關於“on”的狀況下插上插頭，都會導致
意外發生。
d) 在將電動工具啟動前，先卸下任何調整用鑰匙
或扳手。
扳手或鑰匙遺留在電動工具的轉動部位時，可
能導致人員傷害。
e) 身體勿過度伸張，任何時間要保持站穩及平
衡。
以便在不預期的狀態下，能對電動工具有較好
的控制。
f) 衣著要合宜，別穿太鬆的衣服或戴首飾。保持
你的頭髮、衣服及手套遠離轉動部位。
寬鬆的衣服、手飾及長髮會被捲入轉動部位。
g) 如果裝置要用於粉塵抽取及集塵設施，要確保
其連接及正當使用。
使用此類裝置能減少與粉塵有關之危害。
4) 電動工具之使用及注意事項
a) 勿強力使用電動工具，使用正確之電動工具為
你所需。
正確使用電動工具會依其設計條件使工作做得
更好更安全。
b) 如果開關不能轉至開及關的位置，勿使用電動
工具。
任何電動工具不能被開關所控制是危險的，必
須要修理。
c) 在做任何調整、更換配件或收存電動工具時，
要將插頭與電源分開，且/或將電池從電動工
具中取出。
此種預防安全措施可減少意外開啟電動機之危
險。
d) 收存停用之電動工具，遠離兒童，且不容許不
熟悉電動工具或未瞭解操作電動工具說明書的
人操作電動工具。
在未受過訓練的人手裡，電動工具極為危險。
e) 保養電動工具，檢核是否有可動零件錯誤的結
合或卡住、零件破裂及可能影響電動工具操作
的任何其他情形。
電動工具如果損壞，在使用前要修好。許多意
外皆肇因於不良的保養。
f) 保持切割工具銳利清潔。
適當的保養切割工具，保持銳利之切削鋒口，
可減少卡住並容易控制。
g) 按照說明書使用電動工具、配件及刀具等，使
用特殊型式之電動工具時要考量工作條件及所
執行之工作。
使用電動工具未如預期用途之操作時，會導致
危害。
000BookCM12Y.indb8000BookCM12Y.indb8 2018/03/229:50:512018/03/229:50:51

中國語
9
5） 維修
a) 讓你的電動工具由合格修理人員僅使用相同的
維修零件更換。
如此可確保電動工具的安全得以維持。
注意事項
不可讓孩童和體弱人士靠近工作場所。
應將不使用的工具存放在孩童和體弱人士伸手不及的
地方。
使用手提切斷機時的注意事項
1. 請勿使用廠家指定（參見選購附件）的金剛石輪
鋸或切斷輪鋸以外的其它刀具。請勿將本切斷機
用於水中操作。
2. 每次使用本機前，請先檢查金剛石輪鋸。如發現
有破裂、損傷或彎曲，請勿使用。開始使用前還
應仔細檢查是否有其它異常。
3. 用金剛石輪鋸切斷金屬會縮短其使用壽命。因此
請不要用金剛石輪鋸切斷金屬。
4. 請在達到最大轉速時再開始工作。
5. 用力過度會給馬達增加負載並減小工作效率，縮
短使用壽命。在切斷混凝土、瓷磚或岩石時，請
保持切斷厚度為 50mm 或更小。如果切斷厚度大
於 50mm，則將工件切斷 2 到 3 次。如果切斷工
件時切斷厚度大於 50mm，金剛石輪鋸的使用壽
命會縮短，馬達也可能受磨損。
6. 請不要用本機切斷石棉。
7. 在使用切斷輪鋸操作時，如果有火花濺出，請裝
上有橡皮套的集塵器，並且戴上防護眼鏡。
規 格
電壓（按地區）* (110 V, 115 V, 120 V, 127 V, 220 V, 230 V, 240 V)
輸入功率 2400 W*
無負荷速度 5000 轉分
金剛石輪鋸的外形尺寸
外徑 305 mm
厚度 2.0 mm
孔徑 22.2 mm / 20 mm
最大切斷厚度 100 mm
重量 (不包含電纜線和金剛石輪鋸) 11.5 kg
* 當須改變地區時應檢查產品上的銘牌。
標 準 附 件
(1) 軟管 ................................................................... 1
(2) 扳手 ................................................................... 1
(3) 防護眼鏡 ............................................................ 1
標準附件可能不預先通告而徑予更改。
選購附件（分開銷售）
(1) 用於乾切斷的金剛石輪鋸 (分裝式)
類型 輪鋸直徑 (mm) 編號 厚度 (mm) 孔徑 (mm)
用於混凝土和磚石
305
985618 2.8 22.2
用於混凝土和磚石(大功率) 312367
用於研磨材料 985619 3.0
000BookCM12Y.indb9000BookCM12Y.indb9 2018/03/229:50:512018/03/229:50:51

10
中國語
(2) 切斷輪鋸
類型 輪鋸直徑 (mm) 編號 孔徑 (mm) 每包
金屬切斷輪鋸
305
985609 22.2
10 片
985608 25.4
磚石切斷輪鋸 985611 22.2
985610 25.4
注意
○ 在切斷金屬時請不要使用集塵器。
○ 集塵器不使用時，請套上橡皮套。
安裝/拆除金剛石輪鋸
1. 安裝
(1) 擦淨心軸和墊圈上的切削塵屑。
(2) 按護刃器上標出的方向旋轉金剛石輪鋸，按圖 2
和圖 3 所示安裝金剛石輪鋸。
•
金剛石輪鋸的孔徑是 22.2mm 時，在內側安裝
輪墊圈 (B) (銀)。
•
金剛石輪鋸的孔徑是 20.2mm 時，在內側安裝
輪墊圈 (C) (黑)。
(3) 按下鎖定銷固定輪墊圈。用提供的扳手擰緊螺
栓。(圖 5 和圖 6)
注意
○ 請使用提供的扳手緊固螺栓。
○ 請注意要向左 (逆時針) 擰緊螺栓，以保持它
在切斷過程中不松動。(圖 6)
2. 拆除
用提供的扳手拆除螺栓，並拆除金剛石輪鋸。
(圖 6)
切 斷
1. 調節護刃器 (圖4)
用旋鈕調節護刃器的角度，防止在切斷操作中從
材料上落下的灰塵和碎屑或火花濺到操縱者身
上。
2. 切斷操作 (圖7)
(1) 將本機放在要切斷的材料上，將金剛石輪鋸和預
劃線對準。
如果在下刀時對準預劃線來切，則切斷操作比較
順利。
(2) 在金剛石輪鋸未接觸切斷材料時，打開電源開
關。
(3) 輪墊圈 (A) (孔徑 25.4mm)
標準附件可能不預先通告而徑予更改。
用 途
○ 切斷或刻劃混凝土
○ 切斷或刻劃瓷磚
○ 切斷或刻劃岩石
○ 切斷或刻劃瓦片
○ 切斷鋼材
作 業 之 前
1. 電源
確認所使用的電源與工具銘牌上標示的規格是否
相符。
2. 電源開關
確認電源開關是否切斷。若電源開關接通，則插
頭插入電源插座時電動工具將出其不意地立刻轉
動，從而招致嚴重事故。
3. 延伸電纜
若作業場所移到離開電源的地點，應使用容易足
夠、鎧裝合適的延伸線纜，並且要盡可能地短
些。
4. 檢查和安裝金剛石輪鋸
檢查金剛石輪鋸是否符合規格而且無破裂、損傷
或彎曲。檢查金鋼石輪鋸是否安裝可靠。有關安
裝請參閱“安裝/拆除金剛石輪鋸”。
5. 檢查用來固定輪鋸護刃器的旋鈕是否擰緊
確定用來固定輪鋸護刃器的旋鈕已經擰緊。
如果旋鈕松動，可能會引起操作者人身傷害事
故。(圖 4)
安裝集塵器軟管
在切斷材料時，如果有切斷塵屑產生，請按以下步驟
安裝集塵器軟管︰
(1) 拔掉橡皮套並裝上連接軟管。(圖 1)
(2) 在連接軟管上為電動工具安裝集塵器。(圖 1)
000BookCM12Y.indb10000BookCM12Y.indb10 2018/03/229:50:512018/03/229:50:51

中國語
11
注意
○ 在開始工作前，請檢查金剛石輪鋸。請勿使用
有斷裂、破損和彎曲的金剛石輪鋸。
○ 請不要在金剛石輪鋸上涂水或冷卻液。
○ 請在金剛石輪鋸達到最大轉速時開始工作。
○ 如果金剛石輪鋸卡住或出現異常噪聲，請立即
關閉電源。
○ 請勿使用金剛石輪鋸切割鋸齒形或曲線。請勿
使用金剛石輪鋸的側面進行操作。請不要用來
切斷斜面。
○ 在切斷過程中，如果為了將金剛石輪鋸對準預
劃線而用力過度，不僅會使馬達增加負載並引
起燒毀，而且還會使金剛石輪鋸過熱而縮短使
用壽命。
○ 注意在操作中不要將電源線碰到金剛石輪鋸。
○ 工作結束後，關閉電源並將電源插頭從插座上
拔下。
維護和檢查
1. 檢查金剛石輪鋸
磨損的金剛石輪鋸使馬達增加負載並降低工作效
率，請更換新的金剛石輪鋸。
2. 金剛石輪鋸的堵塞
金剛石輪鋸的金剛石層刀刃的磨損率根據被切斷
的材料類型和切斷速度等變化。一般，產生粉末
切斷顆粒的材料會刮落添加劑並加速金剛石層的
磨損。另一方面，產生粉末切斷顆粒的材料會引
起金剛石層的堵塞，從而降低切斷效率。當堵塞
發生時，試圖提高速度時就要施加更大的力，有
時在金剛石輪鋸周圍會產生火花。這時，停止使
用本切斷機，仔細地用手指觸摸刀刃進行檢查。
如果感覺到金剛石層光滑 (無粗燥感或磨削性)，
則被塵屑堵塞了，必須進行清理。
在清理時，在一個厚度 10mm、相對柔軟並產生
粉末切斷顆粒的材料 (例如，水泥塊或磚塊) 上以
較快的速度切斷約 5m，從而恢複金剛石層的切斷
性能，延長金剛石輪鋸的工作壽命。
金剛石材料對高溫敏感，在大約 600℃ 時性能開
始退化，更高的溫度會引起金剛石材料的分解，
因此，一旦產生堵塞或火花，必須立即進行清
理。
3. 檢查安裝螺釘
要經常檢查安裝螺釘是否緊固妥善。若發現螺釘
鬆了，應立即重新扭緊，否則會導致嚴重的事
故。
4. 電動機的維護
電動機繞線是電動工具的心臟部。應仔細檢查有
無損傷，是否被油液或水沾濕。
5. 檢查碳刷（圖 8）
馬達使用碳刷，它是消耗部品，因為使用過久的
碳刷將會導致馬達故障，用具有相同碳刷號的新
碳刷去更換舊的，碳刷編號用數字表示碳刷何時
用舊或接近於磨損極限此外，要經常保持碳刷清
潔以及保証它在刷握裡能自由滑動。
6. 更換碳刷
用無頭螺絲刀卸下碳刷蓋，然後可以很容易地取
下碳刷。
註
為求改進，本手冊所載規格可能不預先通告而徑
予更改。
000BookCM12Y.indb11000BookCM12Y.indb11 2018/03/229:50:512018/03/229:50:51

12
ﺔﻳﺑﺭﻌﻟﺍ
٤
ﻙﺭﺣﻣﻟﺍ ﺔﻧﺎﻳﺻ
4
.ﺔﻗﺎﻁﻟﺍ ﺓﺍﺩﺃ ﻥﻣ "ﻁﺳﻭﻷﺍ ءﺯﺟﻟﺍ" ﻭﻫ ﻙﺭﺣﻣﻟﺍ ﺓﺩﺣﻭ ﻑﻠﻣ
.ءﺎﻣﻟﺍ ﻭﺃ ﺕﻳﺯﻟﺍ ﺔﻁﺳﺍﻭﺑ ﻪﻠﻠﺑ ﻭﺃ/ﻭﻑﻠﻣﻟﺍ ﻑﻠﺗ ﻡﺩﻋ ﻥﻣ ﺭﺍﺭﻣﺗﺳﺎﺑ ﺩﻛﺎﺗ
(8ﻝﻛﺷﻟﺍ) ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﺹﺣﻓ
5
.ﺓﺭﻣﻌﻣ ﺭﻳﻏ ءﺍﺯﺟﻷﺍ ﻥﻣ ﻲﻫﻭ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﻙﺭﺣﻣﻟﺍ ﻙﻠﻬﺗﺳﻳ
،ﻙﺭﺣﻣﻟﺎﺑ ﻝﻛﺎﺷﻣ ﺩﻭﺟﻭ ﻪﻧﻋ ﺞﺗﻧﻳ ﺩﻗ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﻝﻛﺂﺗ ﻥﻷ ﺍًﺭﻅﻧ
ﺓﺎﺷﺭﻔﻟﺍ ﻡﻗﺭ ﺱﻔﻧ ﺎﻬﻳﺩﻟ ﺓﺩﻳﺩﺟ ﻯﺭﺧﺄﺑ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﻝﺍﺩﺑﺗﺳﺎﺑ ﻡﻗ
ﺩﺣ" ﻥﻣ ﺎﻬﺑﺍﺭﺗﻗﺍ ﻭﺃ ﺎﻬﻠﻛﺂﺗ ﺩﻧﻋ ﻝﻛﺷﻟﺍ ﻲﻓ ﺢﺿﻭﻣ ﻭﻫ ﺎﻣﻛ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ
ﺭﺍﺭﻣﺗﺳﺎﺑ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﻑﻳﻅﻧﺗﺑ ﻡﻗ ،ﻙﻟﺫ ﻰﻟﺇ ﺔﻓﺎﺿﻹﺎﺑ ."ﻝﻛﺂﺗﻟﺍ
.ﺓﺎﺷﺭﻔﻟﺍ ﺽﺑﺎﻘﻣ ﻝﺧﺍﺩ ﺔﺳﻼﺳﺑ ﺎﻬﻗﻻﺯﻧﺍ ﻥﻣ ﺩﻛﺄﺗﻟﺍﻭ
ﺔﻳﻧﻭﺑﺭﻛﻟﺍ ﺓﺎﺷﺭﻔﻟﺍ ﻝﺍﺩﺑﺗﺳﺍ 6
ﺵﺭﻔﻟﺍ ﺔﻟﺍﺯﺇ ﻥﻛﻣﻳ .ﺕﺎﺣﺗﻓ ﻭﺫ ﻙﻔﻣ ﻝﻼﺧ ﻥﻣ ﺓﺎﺷﺭﻔﻟﺍ ﺔﻳﻁﻏﺃ ﻙﻔﺑ ﻡﻗ
.ﺔﻟﻭﻬﺳﺑ ﺔﻳﻧﻭﺑﺭﻛﻟﺍ
ﺔﻅﺣﻼﻣ
ﺕﺎﻔﺻﺍﻭﻣﻟﺍ ﺭﻳﻐﺗﺗ ،ﺭﻣﺗﺳﻣﻟﺍ ﺭﻳﻭﻁﺗﻟﺍﻭ ﺙﺣﺑﻠﻟ HiKOKI ﺞﻣﺎﻧﺭﺑﻟ ﺎًﻌﺑﺗ
.ﻕﺑﺳﻣ ﻡﻼﻋﺇ ﻥﻭﺩ ﺎﻧﻫ ﺓﺭﻭﻛﺫﻣﻟﺍ
000BookCM12Y.indb12000BookCM12Y.indb12 2018/03/229:50:512018/03/229:50:51

13
ﺔﻳﺑﺭﻌﻟﺍ
۳
ﺕﺎﻘﻳﺑﻁﺗ
ﺔﻧﺎﺳﺭﺧﻟﺍ ﻡﻳﺳﻘﺗ ﻭﺃ ﻊﻳﻁﻘﺗ
○
ﻁﻼﺑﻟﺍ ﻡﻳﺳﻘﺗ ﻭﺃ ﻊﻳﻁﻘﺗ
○
ﺭﺎﺟﺣﻷﺍ ﻡﻳﺳﻘﺗ ﻭﺃ ﻊﻳﻁﻘﺗ
○
ﻁﻼﺑﻟﺍ ﻑﻘﺳﺃ ﻡﻳﺳﻘﺗ ﻭﺃ ﻊﻳﻁﻘﺗ
○
ﺏﻠﺻﻟﺍ ﻊﻳﻁﻘﺗ
○
ﻝﻳﻐﺷﺗﻟﺍ ﻝﺑﻗ
ﺔﻗﺎﻁﻟﺍ ﺭﺩﺻﻣ
1
ﺕﺎﺑﻠﻁﺗﻣﻟ ﻕﺑﺎﻁﻣ ﻪﻣﺍﺩﺧﺗﺳﺍ ﻡﺗﻳﺳ ﻱﺫﻟﺍ ﺔﻗﺎﻁﻟﺍ ﺭﺩﺻﻣ ﻥﺃ ﻥﻣ ﺩﻛﺄﺗ
.ﺞﺗﻧﻣﻟﺍ ﻰﻠﻋ ﺓﺩﻭﺟﻭﻣﻟﺍ ﻡﺳﻻﺍ ﺔﺣﻭﻟ ﻰﻠﻋ ﺓﺩﺩﺣﻣﻟﺍ ﺔﻗﺎﻁﻟﺍ
ﺔﻗﺎﻁﻟﺍ ﺡﺎﺗﻔﻣ
2
ﺱﺑﺎﻘﻟﺍ ﻝﻳﺻﻭﺗ ﺔﻟﺎﺣ ﻲﻓ .ﻑﺎﻘﻳﺇ ﻊﺿﻭﻟﺍ ﻰﻠﻋ ﺔﻗﺎﻁﻟﺍ ﺡﺎﺗﻔﻣ ﻥﺃ ﻥﻣ ﺩﻛﺄﺗ
ﺓﺍﺩﺃ ﻝﻳﻐﺷﺗ ﻡﺗﻳﺳﻓ ،ﻝﻳﻐﺷﺗ ﻊﺿﻭﻟﺍ ﻰﻠﻋ ﺔﻗﺎﻁﻟﺍ ﺡﺎﺗﻔﻣ ﻥﺎﻛﻭ ﺱﺑﻘﻣﻟﺎﺑ
.ﺭﻳﻁﺧ ﺙﺩﺎﺣ ﻉﻭﻗﻭ ﻰﻟﺇ ﻱﺩﺅﻳ ﺩﻗ ﺎﻣﻣ ،ﺭﻭﻔﻟﺍ ﻰﻠﻋ ﺔﻗﺎﻁﻟﺍ
ﻲﻓﺎﺿﻹﺍ ﻝﻳﺻﻭﺗﻟﺍ ﻙﻠﺳ
3
ﻝﻳﺻﻭﺗ ﻙﻠﺳ ﻡﺩﺧﺗﺳﺍ ،ﺔﻗﺎﻁﻟﺍ ﺭﺩﺻﻣ ﻥﻣ ﻝﻣﻌﻟﺍ ﺔﻘﻁﻧﻣ ﺔﻟﺍﺯﺇ ﺩﻧﻋ
ﻝﻳﺻﻭﺗﻟﺍ ﻙﻠﺳ ﻝﻅﻳ ﻥﺃ ﺏﺟﻳ .ﺔﻧﻧﻘﻣ ﺔﻌﺳﻭ ٍﻑﺎﻛ ﻙﻣﺳ ﻭﺫ ﻲﻓﺎﺿﺇ
.ﻉﺎﻁﺗﺳﻣﻟﺍ ﺭﺩﻘﺑ ﺍًﺭﻳﺻﻗ ﻲﻓﺎﺿﻹﺍ
(ﺎﻬﺑﻳﻛﺭﺗﻭ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺹﺣﻓ
4
ﻭﺃ ﺔﻘﻘﺷﺗﻣ ﺭﻳﻏ ﺎﻬﻧﺃ ﻥﻣ ﻕﻘﺣﺗﻭ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺹﺣﻓﺍ
ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺏﻳﻛﺭﺗ ﻥﻣ ﻕﻘﺣﺗ .ﺔﻳﻧﺛﻧﻣ ﻭﺃ ﺓﺭﻭﺳﻛﻣ
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺔﻟﺍﺯﺇ/ﺏﻳﻛﺭﺗ" ﻰﻟﺇ ﻊﺟﺭﺍ ،ﺏﻳﻛﺭﺗﻠﻟ .ﻥﺎﻣﺄﺑ
."ﺱﺎﻣﻟﺍ
.ﻪﻁﺑﺭ ﻡﺎﻛﺣﺇ ﻡﺗ ﺔﻠﺟﻌﻟﺍ ﻲﻗﺍﻭ ﻡﺎﻛﺣﻹ ﻡﺩﺧﺗﺳﻣﻟﺍ ﺽﺑﻘﻣﻟﺍ ﻥﺃ ﻥﻣ ﻕﻘﺣﺗ
5
.ﻪﻁﺑﺭ ﻡﺎﻛﺣﺇ ﻡﺗ ﺔﻠﺟﻌﻟﺍ ﻲﻗﺍﻭ ﻁﺑﺭ ﻡﻛﺣﻳ ﻱﺫﻟﺍ ﺽﺑﻘﻣﻟﺍ ﻥﺃ ﻥﻣ ﺩﻛﺄﺗ
(4ﻝﻛﺷﻟﺍ) .ﻝﻳﻐﺷﺗﻟﺍ ﻝﻣﺎﻋ ﺔﺑﺎﺻﺇ ﻰﻟﺇ ﻱﺩﺅﻳ ﺩﻘﻓ ،ﺎًﻳﺧﺗﺭﻣ ﺽﺑﻘﻣﻟﺍ ﻥﺎﻛ ﺍﺫﺇ
ﺏﺍﺭﺗﻟﺍ ﻊﻳﻣﺟﺗ ﻡﻭﻁﺭﺧ ﺏﻳﻛﺭﺗ
ﻡﻭﻁﺭﺧ ﻡﺩﺧﺗﺳﺍ ،ﻊﻁﻘﻟﺍ ﻥﻋ ﺔﺟﺗﺎﻧ ﺔﺑﺭﺗﺃ ﺎﻬﻧﻣ ﺩﻟﻭﺗﺗ ﻲﺗﻟﺍ ﺩﺍﻭﻣﻟﺍ ﻊﻁﻗ ﺩﻧﻋ
:ﻲﻠﻳ ﺎﻣﻛ ﻊﻳﻣﺟﺗ
(1ﻝﻛﺷﻟﺍ) .ﻕﺣﻠﻣﻟﺍ ﻡﻭﻁﺭﺧﻟﺍ ﺏﻳﻛﺭﺗﺑ ﻡﻗﻭ ﻲﻁﺎﻁﻣﻟﺍ ءﺎﻁﻐﻟﺍ ﺔﻟﺍﺯﺈﺑ ﻡﻗ (1)
.ﻕﺣﻠﻣﻟﺍ ﻡﻭﻁﺭﺧﻟﺍ ﻲﻓ ﺔﻗﺎﻁﻟﺍ ﺓﺩﻌﻟ ﺭﺎﺑﻐﻟﺍ ﻊﻣﺟﻣ ﻡﻭﻁﺭﺧ ﺏﻳﻛﺭﺗﺑ ﻡﻗ (2)
(1ﻝﻛﺷﻟﺍ)
ﻪﻳﺑﻧـﺗ
.ﻥﺩﺎﻌﻣﻟﺍ ﻊﻁﻗ ﺩﻧﻋ ﺭﺎﺑﻐﻟﺍ ﻊﻳﻣﺟﺗ ﻡﻭﻁﺭﺧ ﻡﺩﺧﺗﺳﺗ ﻻ
○
ﻡﺩﻋ ﺩﻧﻋ ﺭﺎﺑﻐﻟﺍ ﻊﻳﻣﺟﺗ ﺊﻳﺎﻬﻣ ﻰﻠﻋ ﻲﻁﺎﻁﻣﻟﺍ ءﺎﻁﻐﻟﺍ ﺏﻳﻛﺭﺗﺑ ﻡﻗ
○
.ﺭﺎﺑﻐﻟﺍ ﻊﻳﻣﺟﺗ ﻡﻭﻁﺭﺧ ﻡﺍﺩﺧﺗﺳﺍ
ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺔﻟﺍﺯﺇ/ﺏﻳﻛﺭﺗ
ﺏﻳﻛﺭﺗﻟﺍ 1
.ﺕﺍﺩﺭﻭﻟﺍﻭ ﻥﺍﺭﻭﺩﻟﺍ ﺭﻭﺣﻣ ﻥﻣ ﻊﻁﻘﻟﺍ ﺭﺎﺑﻏ ﺢﺳﻣﺍ (1)
ﻊﻣ ﻕﻓﺍﻭﺗﻳ ﻱﺫﻟﺍﻭ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﻥﺍﺭﻭﺩﻟﺍ ﻩﺎﺟﺗﺍ ﻥﻣ ﺩﻛﺄﺗ (2)
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺏﻳﻛﺭﺗﺑ ﻡﻗﻭ ﺔﻠﺟﻌﻟﺍ ﻲﻗﺍﻭ ﻰﻠﻋ ﺩﺩﺣﻣﻟﺍ ﻩﺎﺟﺗﻻﺍ
.3ﻭ2ﻝﻛﺷﻟﺍ ﻲﻓ ﺢﺿﻭﻣ ﻭﻫ ﺎﻣﻛ ﺱﺎﻣﻟﺍ
ﺎﻣﺩﻧﻋ ﻲﻠﺧﺍﺩﻟﺍ ﺏﻧﺎﺟﻟﺍ ﻰﻠﻋ (ﻲﺿﻔﻟﺍ) (B) ﺔﻠﺟﻌﻟﺍ ﺓﺩﺭﻭ ﺏﻳﻛﺭﺗﺑ ﻡﻗ •
ﻲﻫ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋﻭ ﺔﺣﺗﻔﻟﺍ ﺭﻁﻗ ﻥﻭﻛﻳ
.ﻡﻣ 22.2
ﺎﻣﺩﻧﻋ ﻲﻠﺧﺍﺩﻟﺍ ﺏﻧﺎﺟﻟﺍ ﻰﻠﻋ (ﺩﻭﺳﺃ) (C) ﺔﻠﺟﻌﻟﺍ ﺓﺩﺭﻭ ﺏﻳﻛﺭﺗﺑ ﻡﻗ •
.ﻡﻣ 20.0 ﻲﻫ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋﻭ ﺔﺣﺗﻔﻟﺍ ﺭﻁﻗ ﻥﻭﻛﻳ
ﺭﺎﻣﺳﻣﻟﺍ ﻡﺎﻛﺣﺈﺑ ﻡﻗ .ﻥﺍﺭﻭﺩﻟﺍ ﺭﻭﺣﻣ ﻥﻳﻣﺄﺗﺑ ﻡﻗﻭ ﻝﻔﻘﻟﺍ ﻥﺳ ﻰﻠﻋ ﻁﻐﺿﺍ (3)
(6ﻭ5ﻝﻛﺷﻟﺍ) .ﺭﻓﻭﺗﻣﻟﺍ ﺡﺎﺗﻔﻣﻟﺍ ﻊﻣ ٍﻑﺎﻛ ﻝﻛﺷﺑ
ﺔﻅﺣﻼﻣ
.ﺭﺎﻣﺳﻣﻟﺍ ﻁﺑﺭﻟ ﺭﻓﻭﺗﻣﻟﺍ ﺡﺎﺗﻔﻣﻟﺍ ﺎًﻣﺋﺍﺩ ﻡﺩﺧﺗﺳﺍ
○
ﺏﺭﺎﻘﻋ ﺱﻛﻋ ﻩﺎﺟﺗﺍ ﻲﻓ) ﺭﺎﺳﻳﻠﻟ ﻪﻣﺎﻛﺣﺇ ﻡﺗﻳ ﺭﺎﻣﺳﻣﻟﺍ ﻥﻷ ﺭﺫﺣﻟﺍ ﺥﻭﺗ
○
(6ﻝﻛﺷﻟﺍ) .ﻊﻁﻘﻟﺍ ءﺎﻧﺛﺃ ﻩﺅﺎﺧﺗﺭﺍ ﻥﻣ ﻪﻌﻧﻣﻟ (ﺔﻋﺎﺳﻟﺍ
ﺔﻟﺍﺯﻹﺍ
2
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺔﻟﺍﺯﺈﺑ ﻡﻗﻭ ﺭﻓﻭﺗﻣﻟﺍ ﺡﺎﺗﻔﻣﻟﺎﺑ ﺭﺎﻣﺳﻣﻟﺍ ﺔﻟﺍﺯﺈﺑ ﻡﻗ
(6ﻝﻛﺷﻟﺍ) .ﺱﺎﻣﻟﺍ
ﻊﻁﻘﻟﺍ
(4ﻝﻛﺷﻟﺍ) ﺔﻠﺟﻌﻟﺍ ﻲﻗﺍﻭ ﻁﺑﺿ 1
ﻡﺎﻁﺣ ﻭﺃ ﺭﺎﺑﻐﻟﺍ ﺱﻣﻼﻳ ﻻﻲﻛﻟ ﺽﺑﻘﻣﻟﺎﺑ ﺔﻠﺟﻌﻟﺍ ﻲﻗﺍﻭ ﺔﻳﻭﺍﺯ ﻁﺑﺿﺍ
.ﻊﻁﻘﻟﺍ ﺔﻳﻠﻣﻋ ءﺎﻧﺛﺃ ﻝﻐﺷﻣﻟﺍ ﺕﺍﺭﺍﺭﺷﻟﺍ ﻭﺃ ﺓﺩﺎﻣﻟﺍ
(7ﻝﻛﺷﻟﺍ) ﻊﻁﻘﻟﺍ ﺕﺍءﺍﺭﺟﺇ 2
ﺩﺩﺣﻣﻟﺍ ﻁﺧﻟﺎﺑ ﺎﻬﺗﺍﺫﺎﺣﻣﻭ ﺎﻬﻌﻁﻗ ﻡﺗﻳ ﻲﻛ ﺓﺩﺎﻣﻟﺍ ﻰﻠﻋ ﺓﺩﻌﻟﺍ ﻩﺫﻫ ﻊﺿ (1)
.ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋﻭ ﺎًﻘﺑﺳﻣ
ﻁﺧﻟﺍ ﻰﻠﻋ ﻡﺎﻣﻸﻟ ﺱﺃﺭﻟﺍ ﻊﻁﻘﺑ ﺕﻣﻗ ﺍﺫﺇ ﻕﻓﺭﺑ ﻊﻁﻘﻟﺍ ءﺍﺭﺟﺇ ﻥﻛﻣﻳ
.ﻲﻟﻭﻷﺍ ﻊﻁﻘﻟﺍ ﻲﻓ ﻡﺳﻘﻣﻟﺍ
ﺓﺩﺎﻣﻟﺍ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺱﻣﻼﺗ ﻻﺎﻣﺩﻧﻋ ﺡﺎﺗﻔﻣﻟﺍ ﻝﻳﻐﺷﺗﺑ ﻡﻗ (2)
.ﺎﻬﻌﻁﻗ ﺩﺍﺭﻣﻟﺍ
ﻪﻳﺑﻧـﺗ
ﻡﺩﺧﺗﺳﺗ ﻻ.ﻝﻣﻌﻟﺍ ءﺩﺑ ﻝﺑﻗ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻥﻣ ﺎًﻣﺋﺍﺩ ﻕﻘﺣﺗ
○
.ﺔﻳﻧﺛﻧﻣﻟﺍ ﻭﺃ ﺓﺭﻭﺳﻛﻣﻟﺍ ﻭﺃ ﺔﻘﻘﺷﺗﻣﻟﺍ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ
.ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﺕﺍﺩﺭﺑﻣﻟﺍ ﻭﺃ ﻩﺎﻳﻣﻟﺍ ﻡﺩﺧﺗﺳﺗ ﻻ
○
ﺔﻋﺭﺳﻟﺍ ﻰﻟﺇ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻝﺻﺗ ﺎﻣﺩﻧﻋ ﻊﻁﻘﻟﺍ ﺃﺩﺑﺍ
○
.ﻯﻭﺻﻘﻟﺍ
ﺩﻭﺟﻭ ﺔﻟﺎﺣ ﻲﻓ ﻭﺃ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺓﺭﺍﺭﺣ ﺕﻌﻔﺗﺭﺍ ﺍﺫﺇ
○
.ﺭﻭﻔﻟﺍ ﻰﻠﻋ ﺔﻗﺎﻁﻟﺍ ﻝﻳﻐﺷﺗ ﻑﺎﻘﻳﺈﺑ ﻡﻘﻓ ،ﺔﺟﻋﺯﻣ ءﺎﺿﻭﺿ
ﻭﺃ ﺔﺟﺭﻌﺗﻣ ﻁﻭﻁﺧ ﻊﻁﻘﻟ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻡﺩﺧﺗﺳﺗ ﻻ
○
ﻻ.ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﻲﺑﻧﺎﺟﻟﺍ ﺢﻁﺳﻟﺍ ﻡﺩﺧﺗﺳﺗ ﻻ.ﺔﻳﻧﺣﻧﻣ
.ﻝﺋﺎﻣﻟﺍ ﻊﻁﻘﻟﺍ ءﺍﺭﺟﻹ ﺎﻬﻣﺩﺧﺗﺳﺗ
ﻱﺫﺎﺣﺗ ﺎﻬﻠﻌﺟﻟ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﺔﻁﺭﻔﻣ ﺓﻭﻗ ﻡﺍﺩﺧﺗﺳﺍ ﻡﺗ ﺍﺫﺇ
○
ﻰﻠﻋ ﺩﺋﺍﺯﻟﺍ ﻝﻣﺣﻟﺎﺑ ﻙﻟﺫ ﻡﻭﻘﻳ ﻻﺩﻘﻓ ،ﻊﻁﻘﻟﺍ ءﺎﻧﺛﺃ ﺎًﻘﺑﺳﻣ ﺩﺩﺣﻣﻟﺍ ﻁﺧﻟﺍ
ﻙﻟﺫ ﻱﺩﺅﻳ ﺩﻗ ﻥﻛﻟﻭ ﻕﺍﺭﺗﺣﻻﺍ ﻥﻋ ﺞﺗﺎﻧ ﺭﺭﺿ ﺙﻭﺩﺣ ﻭﺃ ﻁﻘﻓ ﻙﺭﺣﻣﻟﺍ
ﺭﻣﻋ ﺭﻳﺻﻘﺗﻭ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻯﺩﻟ ﺓﺩﺋﺍﺯﻟﺍ ﺔﻧﻭﺧﺳﻟﺍ ﻰﻟﺇ
.ﺎﻬﺑ ﺔﻣﺩﺧﻟﺍ
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺔﺳﻣﻼﻣ ﻥﻣ ﺔﻗﺎﻁﻟﺍ ﻙﻠﺳﻟ ﺡﺎﻣﺳﻟﺍ ﻥﻣ ﺭﺫﺣﻟﺍ ﺥﻭﺗ
○
.ﻝﻳﻐﺷﺗﻟﺍ ءﺎﻧﺛﺃ ﺱﺎﻣﻟﺍ
ﻥﻣ ﺔﻗﺎﻁﻟﺍ ﺱﺑﻘﻣ ﻝﺻﻓﺍﻭ ﺔﻗﺎﻁﻟﺍ ﻝﻳﻐﺷﺗ ﻑﺎﻘﻳﺈﺑ ﻡﻗ ،ﻝﻣﻌﻟﺍ ﻝﺎﻣﺗﻛﺍ ﺩﻧﻋ
○
.ﺱﺑﻘﻣﻟﺍ
ﺹﺣﻔﻟﺍﻭ ﺔﻧﺎﻳﺻﻟﺍ
ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺹﺣﻓ 1
ﻥﻣ ﻝﻠﻘﺗﻭ ﻙﺭﺣﻣﻟﺍ ﻝﻣﺣ ﻥﻣ ﺩﻳﺯﺗ ﺔﻠﻛﺂﺗﻣﻟﺍ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ
.ﺓﺩﻳﺩﺟ ﻯﺭﺧﺄﺑ ﺎﻬﻟﺩﺑﺗﺳﺍ .ﻝﻣﻌﻟﺍ ﺓءﺎﻔﻛ
:ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺔﻗﺎﻋﺇ
2
ﺓﺩﺎﻣﻟﺍ ﻉﻭﻧﻟ ﺎًﻌﺑﺗ ﺱﺎﻣﻟﺍ ﺔﻘﺑﻁ ﻊﻁﻗ ﺔﻓﺎﺣ ﻝﻛﺂﺗ ﻝﺩﻌﻣ ﻉﻭﻧﺗﻳ ﻑﻭﺳ
ﺞﺗﻧﺗ ﻲﺗﻟﺍ ﺩﺍﻭﻣﻟﺍ ،ﺎًﻣﻭﻣﻋ .ﻙﻟﺫ ﺭﻳﻏﻭ ﻊﻁﻘﻟﺍ ﺔﻋﺭﺳﻭ ﺎﻬﻌﻁﻗ ﻡﺗﻳ ﻲﺗﻟﺍ
ﺔﻘﺑﻁ ﻝﻛﺂﺗ ﻥﻣ ﻉﺭﺳﺗﻭ ﻁﺑﺭﻟﺍ ﻝﻣﺎﻋ ﺵﺩﺧﺗ ﺩﻗ ﺔﻳﺑﻳﺑﺣ ﻊﻁﻗ ﺕﺎﺋﻳﺯﺟ
ﻝﻛﺷ ﻰﻠﻋ ﻊﻁﻗ ﺕﺎﺋﻳﺯﺟ ﺞﺗﻧﺗ ﻲﺗﻟﺍ ﺩﺍﻭﻣﻟﺍ ،ﺭﺧﻵﺍ ﺏﻧﺎﺟﻟﺍ ﻰﻠﻋ .ﺱﺎﻣﻟﺍ
ﺓءﺎﻔﻛ ﻥﻣ ﻝﻠﻘﺗ ﻑﻭﺳ ﻲﺗﻟﺍﻭ ﺱﺎﻣﻟﺍ ﺔﻘﺑﻁ ﺔﻗﺎﻋﺇ ﻲﻓ ﺏﺑﺳﺗﺗ ﺩﻗ ﻕﻭﺣﺳﻣ
ﺓﺩﺎﻳﺯﻟ ﺔﻟﻭﺎﺣﻣﻛ ﺔﻳﻓﺎﺿﺇ ﺓﻭﻗ ﻡﺍﺩﺧﺗﺳﺍ ﻡﺗﻳ ،ﺔﻗﺎﻋﺇ ﺙﻭﺩﺣ ﺩﻧﻋ .ﻊﻁﻘﻟﺍ
ﻝﻭﺣ ﺭﻬﻅﺗ ﻑﻭﺳ ﻲﺗﻟﺍﻭ ﺕﺍﺭﺍﺭﺷ ﺞﺗﻧﺗ ﻑﻭﺳ ﻲﺗﻟﺍﻭ ﻊﻁﻘﻟﺍ ﺔﻋﺭﺳ
ﻡﺍﺩﺧﺗﺳﺍ ﻑﺎﻘﻳﺈﺑ ﻡﻗ ،ﺔﻟﺎﺣﻟﺍ ﻩﺫﻫ ﻲﻓ .ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻁﻳﺣﻣ
ﺕﺩﺑ ﺍﺫﺇ .ﻙﻌﺑﺎﺻﺈﺑ ﺎﻬﻛﺣ ﺔﻁﺳﺍﻭﺑ ﻊﻁﻘﻟﺍ ﺔﻓﺎﺣ ﺭﺫﺣﺑ ﺹﺣﻓﺍﻭ ﻊﻁﺎﻘﻟﺍ
ﺔﻁﺳﺍﻭﺑ ﺎﻬﺗﻗﺎﻋﺇ ﻡﺗﺗ ﻑﻭﺳﻓ ،(ﻁﺷﻛ ﻭﺃ ﺵﻭﺩﺧ ﻼﺑ) ﺔﻣﻋﺎﻧ ﺱﺎﻣﻟﺍ ﺔﻘﺑﻁ
."ﺎﻬﺣﺳﻣ" ﻡﺗﻳ ﻥﺃ ﺏﺟﻳﻭ ﺭﺎﺑﻐﻟﺍ
ﻕﻣﻌﺑﻭ ﻕﻓﺭﺑ ﻪﻌﻳﺭﺳﺗ ﻡﺗﻳ ﻱﺫﻟﺍ ﻊﻁﻘﻟﺍ ﻥﻣ ﺎًﺑﻳﺭﻘﺗ ﺭﺗﻣ 5،ﻝﻣﺎﻛﻟﺍ ﺢﺳﻣﻠﻟ
ﻰﻠﻋ) ﺔﻳﺑﻳﺑﺣ ﻊﻁﻗ ﺕﺎﺋﻳﺯﺟ ﺞﺗﻧﺗ ﻲﺗﻟﺍﻭ ﺎًﻳﺑﺳﻧ ﺔﻧﻳﻟ ﺓﺩﺎﻣ ﻲﻓ ﻡﻣ 10
ﺔﻳﻟﺎﻌﻓ ﺩﻳﻌﺗﺳﺗ ﻑﻭﺳ ﻲﺗﻟﺍﻭ (ﺏﻭﻁﻟﺍ ﻭﺃ ﺔﻳﺗﻧﻣﺳﻷﺍ ﻝﺗﻛﻟﺍ ﻝﺎﺛﻣﻟﺍ ﻝﻳﺑﺳ
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﺔﻣﺩﺧﻟﺍ ﺭﻣﻋ ﻥﻣ ﺩﻳﺯﺗ ﻑﻭﺳﻭ ﺱﺎﻣﻟﺍ ﺔﻘﺑﻁﻟ ﻊﻁﻘﻟﺍ
.ﺱﺎﻣﻟﺍ
ﺭﻭﻫﺩﺗﻟﺍ ﻲﻓ ﺃﺩﺑﺗ ﻑﻭﺳﻭ ﺔﻌﻔﺗﺭﻣ ﺓﺭﺍﺭﺣ ﺕﺎﺟﺭﺩﻟ ﺱﺎﻣﻟﺍ ﺓﺩﺎﻣ ﺽﺭﻌﺗﺗ
ﻑﻠﺗ ﻲﻓ ﺏﺑﺳﺗﺗ ﻲﺗﻟﺍﻭ ﺔﻳﻭﺋﻣ ﺔﺟﺭﺩ 600 ﻰﻠﻋﻷﺍ ﺓﺭﺍﺭﺣﻟﺍ ﺕﺎﺟﺭﺩ ﺩﻧﻋ
ﺙﻭﺩﺣ ﺩﺭﺟﻣﺑ "ﺢﺳﻣﻟﺍ" ءﺍﺭﺟﺇ ﻱﺭﻭﺭﺿﻟﺍ ﻥﻣ ،ﻙﻟﺫﻟ ﺎًﻘﻓﻭ .ﺱﺎﻣﻟﺍ ﺓﺩﺎﻣ
.ﺕﺍﺭﺍﺭﺷﻟﺍ ﻭﺃ ﺔﻗﺎﻋﻹﺍ
ﺕﻳﺑﺛﺗﻟﺍ ﺭﻳﻣﺎﺳﻣ ﺹﺣﻓ
3
ﺎﻬﻁﺑﺭ ﻡﺎﻛﺣﺇ ﻥﻣ ﺩﻛﺄﺗﻟﺍﻭ ﺕﻳﺑﺛﺗﻟﺍ ﺭﻳﻣﺎﺳﻣ ﺔﻓﺎﻛﻟ ﻱﺭﻭﺩﻟﺍ ﺹﺣﻔﻟﺎﺑ ﻡﻗ
.ﺭﻭﻔﻟﺍ ﻰﻠﻋ ﺎﻬﻁﺑﺭ ﻡﺎﻛﺣﺈﺑ ﻡﻗ ،ﺭﻳﻣﺎﺳﻣ ﺔﻳﺃ ﻙﻓ ﺔﻟﺎﺣ ﻲﻓ .ﺢﻳﺣﺻ ﻝﻛﺷﺑ
.ﺭﻁﺎﺧﻣ ﻰﻟﺇ ﻙﻟﺫﺑ ﻡﺎﻳﻘﻟﺍ ﻲﻓ ﻝﺷﻔﻟﺍ ﺽﺭﻌﻳ ﺩﻘﻓ
000BookCM12Y.indb13000BookCM12Y.indb13 2018/03/229:50:522018/03/229:50:52

14
ﺔﻳﺑﺭﻌﻟﺍ
۲
ﺹﺭﻘﻟﺍ ﻊﻁﺎﻗ ﻡﺍﺩﺧﺗﺳﺍ ﺩﻧﻋ ﺔﻣﺯﻼﻟﺍ ﺕﺎﻁﺎﻳﺗﺣﻻﺍ
ﺔﻠﺟﻋ ﻭﺃ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ءﺎﻧﺛﺗﺳﺎﺑ ﺓﺩﻋ ﻱﺃ ﻝﻳﺻﻭﺗﺑ ﻡﻘﺗ ﻻ1
ﺕﺎﻘﺣﻠﻣﻟﺍ ﻊﺟﺍﺭ) ﻊﻳﻧﺻﺗﻟﺍ ﺔﻬﺟ ﻝﻼﺧ ﻥﻣ ﺢﺿﻭﻣ ﻭﻫ ﺎﻣﻛ ﻊﻁﻘﻟﺍ
.(ﺔﻳﺭﺎﻳﺗﺧﻻﺍ
.ﻩﺎﻳﻣﻟﺍ ﻡﺍﺩﺧﺗﺳﺍ ءﺎﻧﺛﺃ ﻊﻁﺎﻘﻟﺍ ﻝﻳﻐﺷﺗﺑ ﻡﻘﺗ ﻻ
ﻲﻓ .ﺯﺎﻬﺟﻟﺍ ﻝﻳﻐﺷﺗ ﻝﺑﻗ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻥﻣ ﺎًﻣﺋﺍﺩ ﻕﻘﺣﺗ 2
ﻡﻗ .ﺎﻬﻣﺍﺩﺧﺗﺳﺎﺑ ﻡﻘﺗ ﻼﻓ ،ﺎﻫﺅﺎﻧﺛﻧﺍ ﻭﺃ ﺎﻫﺭﺳﻛ ﻭﺃ ،ﺎﻬﻟ ﻕﻘﺷﺗ ﺙﻭﺩﺣ ﺔﻟﺎﺣ
.ﻯﺭﺧﻷﺍ ﺔﻳﻌﻳﺑﻁﻟﺍ ﺭﻳﻏ ﺭﻭﻣﻷﺍ ﻥﻣ ﻕﻘﺣﺗﻠﻟ ﺭﺫﺣﺑ ﺯﺎﻬﺟﻟﺍ ﻝﻳﻐﺷﺗﺑ
ﻥﻣ ﻝﻠﻘﻳ ﻑﻭﺳ ﻥﺩﺎﻌﻣﻟﺍ ﻊﻁﻘﻟ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻡﺍﺩﺧﺗﺳﺍ 3
ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﻡﺩﺧﺗﺳﺗ ﻻ.ﺭﺳﻛﻟﺍ ﻰﻟﺇ ﻱﺩﺅﻳ ﻭﺃ ﻲﺿﺍﺭﺗﻓﻻﺍ ﺭﻣﻌﻟﺍ
.ﻥﺩﺎﻌﻣﻟﺍ ﻊﻁﻘﻟ ﺱﺎﻣﻟﺍ
.ﻥﺍﺭﻭﺩﻟﺍ ﺔﻋﺭﺳﻟ ﻰﺻﻗﻷﺍ ﺩﺣﻟﺍ ﻰﻟﺇ ﻝﻭﺻﻭﻟﺍ ﺩﻧﻋ ﻝﻳﻐﺷﺗﻟﺍ ﺃﺩﺑﺍ
4
ﻝﻣﻌﻟﺍ ﺓءﺎﻔﻛ ﻥﻣ ﻝﻠﻘﺗﻭ ﻙﺭﺣﻣﻟﺍ ﻰﻠﻋ ﻁﺭﻔﻣ ﻝﻛﺷﺑ ﻝﻣﺣﺗ ﺓﺩﺋﺍﺯﻟﺍ ﺓﻭﻘﻟﺍ 5
ﻊﻁﻗ ﻕﻣﻋ ﻊﻣ ﺭﺎﺟﺣﻷﺍ ﻭﺃ ﻁﻼﺑﻟﺍﻭ ﺔﻧﺎﺳﺭﺧﻟﺍ ﻊﻁﻘﺑ ﻡﻗ .ﺔﻣﺩﺧﻟﺍ ﺭﻣﻋﻭ
ﺔﻌﻁﻗ ﻊﻁﻗﺍ ،ﻡﻣ 50 ﻥﻣ ﺭﺑﻛﺃ ﻊﻁﻘﻟﺍ ﻕﻣﻋ ﻥﺎﻛ ﺍﺫﺇ .ﻝﻗﺃ ﻭﺃ ﻡﻣ 50
ﺩﻳﺯﻳ ﻊﻁﻗ ﻕﻣﻌﺑ ﻝﻣﻌﻟﺍ ﺔﻌﻁﻗ ﻊﻁﻗ ﻡﺗ ﺍﺫﺇ .ﺕﺍﺭﻣ ﺔﺛﻼﺛ ﻭﺃ ﻥﻳﺗﺭﻣ ﻝﻣﻌﻟﺍ
ﺩﻗﻭ ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻌﻟ ﺔﻣﺩﺧﻟﺍ ﺭﻣﻋ ﻝﻘﻳ ﻑﻭﺳﻓ ،ﻡﻣ 50 ﻥﻋ
.ﻙﺭﺣﻣﻟﺍ ﻥﺧﺳﻳ
.ﺱْ ﻭُﺗﺳَﺑْﺳﻷﺍ ﻊﻁﻘﻟ ﺯﺎﻬﺟﻟﺍ ﺍﺫﻫ ﻡﺩﺧﺗﺳﺗ ﻻ
6
ﺔﻳﻁﻐﺗﺑ ﻡﻘﻓ ،ﺏﻬﻠﻟﺍ ﺝﺭﺧ ﺍﺫﺇ ،ﻊﻁﻘﻟﺍ ﺔﻠﺟﻋ ﻡﺩﺧﺗﺳﺗ ﻲﺗﻟﺍ ﺕﺎﻳﻠﻣﻌﻟﺍ ﻲﻓ 7
ﺕﺍﺭﺎﻅﻧﻟﺍ ءﺍﺩﺗﺭﺍ ﻥﻣ ﺩﻛﺄﺗﻭ ﻲﻁﺎﻁﻣ ءﺎﻁﻐﺑ ﺔﺑﺭﺗﻷﺍ ﻊﻳﻣﺟﺗ ﺊﻳﺎﻬﻣ
.ﺔﻳﻗﺍﻭﻟﺍ
ﺕﺎﻔﺻﺍﻭﻣﻟﺍ
*(ﺔﻘﻁﻧﻣﻟﺍ ﺏﺳﺣ) ﻲﺑﺭﻬﻛﻟﺍ ﺩﻬﺟﻟﺍ(ﺕﻟﻭﻓ 240 ،ﺕﻟﻭﻓ 230 ،ﺕﻟﻭﻓ 220 ،ﺕﻟﻭﻓ 127 ،ﺕﻟﻭﻓ 120 ،ﺕﻟﻭﻓ 115 ،ﺕﻟﻭﻓ 110)
ﺔﻗﺎﻁﻟﺍ ﻝﺎﺧﺩﺇ*ﺕﺍﻭ 2400
ﻝﻣﺣ ﻥﻭﺩﺑ ﺔﻋﺭﺳﻟﺍﺔﻘﻳﻗﺩ/ 5000
ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋ ﺩﺎﻌﺑﺃ
ﻡﻣ 305 ﻲﺟﺭﺎﺧﻟﺍ ﺭﻁﻘﻟﺍ
ﻡﻣ 2.0 ﻙﻣﺳﻟﺍ
ﻡﻣ 20 / ﻡﻣ 22.2 ﺔﺣﺗﻔﻟﺍ ﺭﻁﻗ
ﻊﻁﻘﻟﺍ ﻕﻣﻌﻟ ﻰﺻﻗﻷﺍ ﺩﺣﻟﺍﻡﻣ 100
(ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺔﻠﺟﻋﻭ ﻙﻠﺳﻟﺍ ﻥﻭﺩﺑ) ﻥﺯﻭﻟﺍﻡﺟﻛ 11.5
ﺔﻘﻁﻧﻣﻟﺍ ﺏﺳﺣ ﺭﻳﻳﻐﺗﻠﻟ ﺔﺿﺭُﻋﺎﻬﻧﺃ ﺙﻳﺣ ﺞﺗﻧﻣﻟﺍ ﻰﻠﻋ ﺓﺩﻭﺟﻭﻣﻟﺍ ﻡﺳﻻﺍ ﺔﺣﻭﻟ ﺹﺣﻓ ﻥﻣ ﺩﻛﺄﺗ *
ﺔﻳﺳﺎﻳﻗ ﺕﺎﻘﺣﻠﻣ
1............................................................... ﻡﻭﻁﺭﺧﻟﺍ (1)
1.................................................................. ﺡﺎﺗﻔﻣﻟﺍ (2)
1........................................................ﺔﻳﻗﺍﻭﻟﺍ ﺕﺍﺭﺎﻅﻧﻟﺍ (3)
.ﺭﺎﻁﺧﺇ ﻥﻭﺩ ﺔﻳﺳﺎﻳﻘﻟﺍ ﺕﺎﻘﻠﺣﻣﻟﺍ ﺭﻳﻳﻐﺗ ﻥﻛﻣﻳ
(ﺔﻠﺻﻔﻧﻣ ﻉﺎﺑُﺗ) ﺔﻳﺭﺎﻳﺗﺧﺍ ﺕﺎﻘﺣﻠﻣ
(ﻝﺻﺎﻔﻟﺍ ﻉﻭﻧ) ﺱﺎﻣﻟﺍ ﺓﺭﺎﺳﻛﺑ ﺦﻳﻠﺟﺗ ﺕﻼﺟﻋ (1)
ﻉﻭﻧﻟﺍ(ﻡﻣ) ﺔﻠﺟﻌﻟﺍ ﺭﻁﻗﻡﻗﺭ ﺩﻭﻛ(ﻡﻣ) ﻙﻣﺳﻟﺍ(ﻡﻣ) ﻡﻭﻁﺭﺧﻟﺍ ﺭﻁﻗ
ﺔﻳﺭﺟﺣﻟﺍ ﻥﺩﺎﻌﻣﻟﺍﻭ ﺔﻧﺎﺳﺭﺧﻠﻟ
305
985618
2.8
22.2 ﺔﻳﺭﺟﺣﻟﺍ ﻥﺩﺎﻌﻣﻟﺍﻭ ﺔﻧﺎﺳﺭﺧﻠﻟ
(ﻝﻳﻘﺛﻟﺍ ﻝﻣﺣﻠﻟ)
312367
ﺔﻁﺷﺎﻛﻟﺍ ﺩﺍﻭﻣﻠﻟ
9856193.0
ﻊﻁﻘﻟﺍ ﺕﻼﺟﻋ (2)
ﻉﻭﻧﻟﺍ(ﻡﻣ) ﺔﻠﺟﻌﻟﺍ ﺭﻁﻗﻡﻗﺭ ﺩﻭﻛ(ﻡﻣ) ﻡﻭﻁﺭﺧﻟﺍ ﺭﻁﻗﺔﻣﺯﺣ ﻝﻛﻟ
ﻥﺩﺎﻌﻣﻟﺍ ﻊﻁﻗ ﺔﻠﺟﻋ
305
98560922.2
ﻊﻁﻗ 10 98560825.4
ﺔﻳﺭﺟﺣﻟﺍ ﻥﺩﺎﻌﻣﻟﺍ ﻊﻁﻗ ﺔﻠﺟﻋ
98561122.2
98561025.4
(ﻡﻣ 25.4 ﻡﻭﻁﺭﺧﻟﺍ ﺭﻁﻗ) (ﺃ) ﺔﻠﺟﻌﻟﺍ ﺓﺩﺭﻭ (3)
.ﺭﺎﻁﺧﺇ ﻥﻭﺩ ﺔﻳﺭﺎﻳﺗﺧﻻﺍ ﺕﺎﻘﻠﺣﻣﻟﺍ ﺭﻳﻳﻐﺗ ﻥﻛﻣﻳ
000BookCM12Y.indb14000BookCM12Y.indb14 2018/03/229:50:532018/03/229:50:53

15
ﺔﻳﺑﺭﻌﻟﺍ
۱
ﺔﻣﺎﻌﻟﺍ ﺔﻣﻼﺳﻟﺍ ﺕﺎﻣﻳﻠﻌﺗ
!!! ﺭﻳﺫﺣﺗ
ﺕﺎﻣﻳﻠﻌﺗﻟﺍ ﻊﻳﻣﺟ ﺓءﺍﺭﻗ ﻰﺟﺭﻳ
ﺔﻣﺩﺻ ﺙﻭﺩﺣ ﻰﻟﺇ ﻩﺎﻧﺩﺃ ﺔﺣﺿﻭﻣﻟﺍ ﺕﺎﻣﻳﻠﻌﺗﻟﺍ ﻩﺫﻬﺑ ﻡﺍﺯﺗﻟﻻﺍ ﻡﺩﻋ ﻱﺩﺅﻳ ﺩﻗ
.ﺓﺭﻳﻁﺧ ﺔﺑﺎﺻﺇ ﻭﺃ ﻕﻳﺭﺣ ﺏﻭﺷﻧ ﻭﺃ ﺔﻳﺑﺭﻬﻛ
ﺔﺣﺿﻭﻣﻟﺍ ﺕﺍﺭﻳﺫﺣﺗﻟﺍ ﻊﻳﻣﺟ ﻲﻓ ﺩﺭﺍﻭﻟﺍ "ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ" ﺢﻠﻁﺻﻣﻟﺍ
ﺓﺩﻌﻟﺍ ﻭﺃ ﻙﺑ ﺔﺻﺎﺧﻟﺍ (ﺔﻳﻛﻠﺳﻟﺍ) ﺔﻳﺳﻳﺋﺭﻟﺍ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻰﻟﺇ ﺭﻳﺷﻳ ﻩﺎﻧﺩﺃ
.ﺔﻳﺭﺎﻁﺑﻠﻟ (ﺔﻳﻛﻠﺳﻼﻟﺍ) ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ
:ﺔﻳﻟﺎﺗﻟﺍ ﺕﺎﻣﻳﻠﻌﺗﻟﺍ ﻉﺎﺑﺗﺍ ﻰﺟﺭﻳ
ﻝﻣﻌﻟﺍ ﺔﻘﻁﻧﻣ ﻥﺎﻣﺃ (1
.ﻙﻠﻐﺷ ﻥﺎﻛﻣ ﺓءﺎﺿﺇ ﻥﺳﺣﻭ ﺔﻓﺎﻅﻧ ﻰﻠﻋ ﻅﻓﺎﺣ (ﺃ
ﺏﺑﺳﺗﺗ ﺓءﺎﺿﻣ ﺭﻳﻐﻟﺍ ﻝﻣﻌﻟﺍ ﺕﻻﺎﺟﻣﻭ ﻝﻣﻌﻟﺍ ﻥﺎﻛﻣ ﻲﻓ ﻰﺿﻭﻔﻟﺎﻓ
.ﺙﺩﺍﻭﺣ ﻉﻭﻗﻭ ﻲﻓ
ﺩﻭﺟﻭ ﻲﻓ ﻱﺃ ﺔﻳﺭﺎﺟﻔﻧﺍ ءﺍﻭﺟﺃ ﻲﻓ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﻝﻳﻐﺷﺗﺑ ﻡﻘﺗ ﻻ(ﺏ
.ﺭﺎﺑﻏ ﻭﺃ ﻝﺎﻌﺗﺷﻼﻟ ﺔﻠﺑﺎﻗ ﺕﺍﺯﺎﻏ ﻭﺃ ﻝﺋﺍﻭﺳ
.ﺔﻧﺧﺩﻷﺍ ﺭﺎﺑﻏ ﻝﺎﻌﺷﺇ ﻰﻠﻋ ﻝﻣﻌﺗ ﺓﺭﺍﺭﺷ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﺙﺩﺣﺗ
ﻝﺎﻔﻁﻷﺍ ﻝﻭﺎﻧﺗﻣ ﻥﻋ ﺓﺩﻳﻌﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﻥﻭﻛﺗ ﻥﺃ ﻰﻠﻋ ﻅﻓﺎﺣ (ﺕ
.ﻙﺑ ﻥﻳﻁﻳﺣﻣﻟﺍ ﻭﺃ
ﻙﺩﻘﻓ ﻰﻟﺇ ﻱﺩﺅﺗ ﻥﺃ ﻥﻛﻣﻣﻟﺍ ﻥﻣ ﺕﻳﺗﺷﺗﻟﺍ ﻝﺎﻛﺷﺃ ﻥﻣ ﻝﻛﺷ ﻱﺃ
.ﺓﺭﻁﻳﺳﻟﺍ
ﺔﻳﺑﺭﻬﻛﻟﺍ ﺕﺎﻣﺩﺻﻟﺍ ﻥﻣ ﺔﻳﺎﻗﻭﻟﺍ (2
ﻱﺎﺑ ﺱﺑﺎﻘﻟﺍ ﻝﻳﺩﻌﺗ ﺭﻅﺣﻳ ،ءﺎﺑﺭﻬﻛﻟﺍ ﺫﻔﻧﻣﺑ ﺱﺑﺎﻘﻟﺍ ﻝﻳﺻﻭﺗ ﺏﺟﻳ (ﺃ
.ﺔﻘﻳﺭﻁ
.ﺔﻳﺿﺭﻷﺍ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﻊﻣ ﺊﻳﺎﻬﻣ ﺱﺑﺎﻗ ﻱﺃ ﻡﺩﺧﺗﺳﺗ ﻻ
ﺭﻁﺧ ﻥﻣ ﺔﻣﺋﻼﻣﻟﺍ ﺱﺑﺎﻘﻣﻟﺍﻭ ﺎﻫﺭﻳﻳﻐﺗ ﻡﺗﻳ ﻡﻟ ﻲﺗﻟﺍ ﺱﺑﺍﻭﻘﻟﺍ ﺽﻔﺧﺗ
. ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺕﺎﻣﺩﺻﻟﺍ ﺙﻭﺩﺣ
ﺏﻳﺑﺎﻧﻷﺍ ﻝﺛﻣ ﺔﻳﺿﺭﻷﺍ ﺢﻁﺳﻷﺍ ﻊﻣ ﻱﺩﺳﺟﻟﺍ ﺱﻣﻼﺗﻟﺍ ﺏﻧﺟﺗ (ﺏ
.ﺩﻗﺍﻭﻣﻟﺍﻭ ﺕﺎﺟﻼﺛﻟﺍﻭ ﺔﻳﺭﺍﺭﺣﻟﺍ ﺕﻻﺩﺎﺑﻣﻟﺍﻭ
ﻙﺎﻧﻫ ﺔﻳﺿﺭﻷﺍ ﺢﻁﺳﻷﺍ ﻙﻠﺗ ﻥﻣ ﻱﻷ ﻙﻣﺳﺟ ﺔﺳﻣﻼﻣ ﺔﻟﺎﺣ ﻲﻓ
.ﺔﻳﺑﺭﻬﻛ ﺔﻣﺩﺻﻟ ﻙﺿﺭﻌﺗﻟ ﺓﺭﻭﻁﺧ
.ﺔﺑﻭﻁﺭﻟﺍ ﻭﺃ ﺭﻁﻣﻠﻟ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﺽﺭﻌﺗ ﻻ(ﺕ
ﺓﺩﻌﻟﺍ ﻝﺧﺍﺩ ﻰﻟﺇ ءﺎﻣﻟﺍ ﺏﺭﺳﺗ ﻥﺇ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺕﺎﻣﺩﺻﻟﺍ ﺭﻁﺧ ﺩﺍﺩﺯﻳ
.ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ
ﻭﺃ ﻝﻣﺣﻟ ًﺎﻘﻠﻁﻣ ﻪﻠﻣﻌﺗﺳﺗ ﻻ،(ﻙﻠﺳﻟﺍ) ﻝﺑﺎﻛﻟﺍ ﻝﺎﻣﻌﺗﺳﺍ ءﻲﺳﺗ ﻻ(ﺙ
.ﺱﺑﻘﻣﻟﺍ ﻥﻣ ﺱﺑﺎﻘﻟﺍ ﺏﺣﺳﻟ ﻭﺃ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻊﻓﺩ ﻭﺃ ﺩﺷ
ﻑﺍﻭﺣﻟﺍ ﻭﺃ ﺕﻳﺯﻟﺍ ﻭﺃ ﺓﺭﺍﺭﺣﻟﺍ ﺭﺩﺎﺻﻣ ﻥﻋ ًﺍﺩﻳﻌﺑ ﻪﻳﻠﻋ ﻅﻓﺎﺣﻭ
.ﺔﻛﺭﺣﺗﻣﻟﺍ ﺯﺎﻬﺟﻟﺍ ءﺍﺯﺟﺃ ﻭﺃ ﺓﺩﺎﺣﻟﺍ
ﺕﺎﻣﺩﺻﻟﺍ ﺭﻁﺧ ﻥﻣ ﺔﻛﺑﺎﺷﺗﻣﻟﺍ ﻭﺃ ﺔﻔﻟﺎﺗﻟﺍ (ﻙﻼﺳﻷﺍ) ﺕﻼﺑﺎﻛﻟﺍ ﺩﻳﺯﺗ
.ﺔﻳﺑﺭﻬﻛﻟﺍ
ﻙﻠﺳ ﻡﺍﺩﺧﺗﺳﺎﺑ ﺢﺻﻧﻳ ،ﺝﺭﺎﺧﻟﺎﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻝﻳﻐﺷﺗ ﺔﻟﺎﺣ ﻲﻓ (ﺝ
.ﻲﺟﺭﺎﺧﻟﺍ ﻝﺎﻣﻌﺗﺳﻻﺍ ﻊﻣ ﺏﺳﺎﻧﺗﻳ (ﻝﺑﺎﻛ)
ﻥﻣ ﻝﻳﻠﻘﺗﻠﻟ ﻲﺟﺭﺎﺧﻟﺍ ﻝﺎﻣﻌﺗﺳﻻﺍ ﻊﻣ ﺏﺳﺎﻧﻣ ﻙﻠﺳ ﻡﺍﺩﺧﺗﺳﺎﺑ ﻡﻗ
.ﺔﻳﺑﺭﻬﻛ ﺔﻣﺩﺻﻟ ﺽﺭﻌﺗﻟﺍ ﺓﺭﻭﻁﺧ
ﺔﻳﺻﺧﺷﻟﺍ ﺔﻣﻼﺳﻟﺍ (3
ﺓﺩﻌﻟﺍ ﺔﻁﺳﺍﻭﺑ ﻝﻣﻌﻟﺎﺑ ﻡﻗﻭ ﻪﻠﻌﻔﺗ ﺎﻣ ﻰﻟﺇ ﻪﺑﺗﻧﺃﻭ ﺎًﻅﻘﻳ ﻥﻛ (ﺃ
ﻙﺭﻭﻌﺷ ﺔﻟﺎﺣ ﻲﻓ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻡﺩﺧﺗﺳﺗ ﻻ.ﻝﻘﻌﺗﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ
ﺩﺍﻭﻣ ﻭﺃ ﺔﻳﻭﺩﺃ ﻭﺃ ﺓﺭﺩﺧﻣ ﺩﺍﻭﻣ ﺭﻳﺛﺄﺗ ﺕﺣﺗ ﺕﻧﻛ ﺍﺫﺇ ﻭﺃ ﺏﻌﺗﻟﺎﺑ
.ﺔﻳﻟﻭﺣﻛ
ﻱﺩﺅﻳ ﺩﻗ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻡﺍﺩﺧﺗﺳﺇ ﺩﻧﻋ ﺓﺩﺣﺍﻭ ﺔﻅﺣﻠﻟ ﻩﺎﺑﺗﻧﻹﺍ ﻡﺩﻋ
.ﺓﺭﻳﻁﺧ ﺔﺑﺎﺻﺇ ﻰﻟﺇ
.ﻥﻳﻌﻠﻟ ﻲﻗﺍﻭﻟﺍ ﻉﺎﻧﻘﻟﺍ ءﺍﺩﺗﺭﺎﺑ ﺎًﻣﺋﺍﺩ ﻡﻗ .ﻥﺎﻣﻷﺍ ﺕﺍﻭﺩﺃ ﻡﺩﺧﺗﺳﺍ (ﺏ
ﺔﻳﺫﺣﺃ ﻭﺃ ﺭﺎﺑﻐﻟﺍ ﻥﻣ ﻲﻗﺍﻭﻟﺍ ﻉﺎﻧﻘﻟﺍ ﻝﺛﻣ ﻥﺎﻣﻷﺍ ﺕﺍﻭﺩﺃ ﻝﻣﻌﺗﺳ
ﻊﻣﺳﻟﺍ ﺔﻳﺎﻣﺣ ﺓﺯﻬﺟﺃ ﻭﺃ ﺔﺑﻠﺻ ﺔﻌﺑﻗ ﻭﺃ ﻕﻻﺯﻧﻼﻟ ﺓﺩﺎﺿﻣﻟﺍ ﻥﺎﻣﻷﺍ
ﺕﻻﺎﻣﺗﺣﺍ ﻝﻳﻠﻘﺗ ﻰﻠﻋ ﺔﻧﻳﻌﻣ ﻑﻭﺭﻅ ﻲﻓ ﺎﻬﻣﺍﺩﺧﺗﺳﺍ ﻡﺗﻳ ﻲﺗﻟﺍﻭ
.ﺔﻳﺻﺧﺷ ﺕﺎﺑﺎﺻﻹ ﺽﺭﻌﺗﻟﺍ
ﻊﺿﻭ ﻲﻓ ﺡﺎﺗﻔﻣﻟﺍ ﻥﺃ ﻥﻣ ﺩﻛﺄﺗ .ﺩﻭﺻﻘﻣﻟﺍ ﺭﻳﻏ ﻝﻳﻐﺷﺗﻟﺍ ﺏﻧﺟﺗ (ﺕ
.ﻝﻳﺻﻭﺗﻟﺍ ﻝﺑﻗ ﻑﺎﻘﻳﻹﺍ
ﻭﺃ ﺡﺎﺗﻔﻣﻟﺍ ﻲﻓ ﻙﻌﺑﺻﺇ ﺩﻭﺟﻭ ﻊﻣ ﺔﻗﺎﻁﻟﺍ ﺕﺍﻭﺩﺃ ﻝﻣﺣ ﻱﺩﺅﻳ
ﻝﻳﻐﺷﺗﻟﺍ ﻊﺿﻭ ﻲﻓ ﺡﺎﺗﻔﻣﻟﺍ ﺎﻬﻳﻓ ﻥﻭﻛﻳ ﻲﺗﻟﺍ ﺔﻗﺎﻁﻟﺍ ﺕﺍﻭﺩﺃ ﻝﻳﺻﻭﺗ
.ﺙﺩﺍﻭﺣ ﻉﻭﻗﻭ ﻝﺎﻣﺗﺣﺍ ﻰﻟﺇ
.ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻝﻳﻐﺷﺗ ﻝﺑﻗ ﻁﺑﺭﻟﺍ ﺡﺎﺗﻔﻣ ﻭﺃ ﻁﺑﺿﻟﺍ ﺩﺩﻋ ﻉﺯﻧﺍ (ﺙ
ﻥﻣ ﻙﺭﺣﺗﻣﻟﺍ ءﺯﺟﻟﺍ ﺭﺎﺳﻳ ﻰﻠﻋ ﻁﺑﺿ ﺡﺎﺗﻔﻣ ﻭﺃ ﻁﺑﺭ ﺡﺎﺗﻔﻣ ﺩﻭﺟﻭ
.ﺔﻳﺻﺧﺷ ﺔﺑﺎﺻﺇ ﺙﻭﺩﺣ ﻰﻟﺇ ﻱﺩﺅﻳ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ
ﻥﻳﺑﻭ ﻙﻧﻳﺑ ﺔﺑﺳﺎﻧﻣ ﺔﻓﺎﺳﻣ ﻙﺭﺗﺍ ،ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻥﻣ ﺏﺭﺗﻘﺗ ﻻ(ﺝ
.ﺕﺎﻗﻭﻷﺍ ﻊﻳﻣﺟ ﻲﻓ ﻙﻧﺯﺍﻭﺗ ﻰﻠﻋ ﻅﻓﺎﺣﻭ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ
ﻲﻓ ﻝﺿﻓﺃ ﻝﻛﺷﺑ ﺯﺎﻬﺟﻟﺍ ﻰﻠﻋ ﺓﺭﻁﻳﺳﻟﺍ ﻥﻣ ﻙﻟﺫ ﻙﻟ ﺢﻣﺳﻳﺳ
.ﺔﻌﻗﻭﺗﻣﻟﺍ ﺭﻳﻏ ﻑﻗﺍﻭﻣﻟﺍ
ﺎﻬﺑ ﻭﺃ ﺔﺿﺎﻔﺿﻓ ﺱﺑﻼﻣ ﻱﺩﺗﺭﺗ ﻻ،ﺔﺑﺳﺎﻧﻣ ﺱﺑﻼﻣ ءﺍﺩﺗﺭﺎﺑ ﻡﻗ (ﺡ
ﺱﺑﻼﻣﻟﺍﻭ ﻙﺭﻌﺷ ﺩﺎﻌﺑﺇ ﻰﻠﻋ ًﺎﻣﺋﺍﺩ ﻅﻓﺎﺣﻭ ،ﻲﻠﺣ ﻭﺃ ﺔﺑﺋﺎﺳ ﻑﺍﺭﻁﺃ
ﺓﺩﻌﻟﺍ ﻥﻣ ﺔﻛﺭﺣﺗﻣﻟﺍ ءﺍﺯﺟﻷﺍ ﻥﻋ ًﺍﺩﻳﻌﺑ ﺯﺎﻔﻘﻟﺍﻭ ﺎﻬﻳﺩﺗﺭﺗ ﻲﺗﻟﺍ
.ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ
ﻲﻠﺣﻟﺍ ﻭﺃ ﻑﺍﺭﻁﺃ ﺎﻬﺑ ﻲﺗﻟﺍ ﻭﺃ ﺔﺿﺎﻔﺿﻔﻟﺍ ﺱﺑﻼﻣﻟﺍ ﻙﺑﺷﺎﺗﺗ ﺩﻗ
.ﺏﺎﻘﺛﻣﻠﻟ ﺔﻛﺭﺣﺗﻣﻟﺍ ءﺍﺯﺟﻷﺎﺑ ﻝﻳﻭﻁﻟﺍ ﺭﻌﺷﻟﺍﻭﺃ
ﻡﺗﻳﻭ ﺔﻠﺻﺗﻣ ﻥﻣ ﺩﻛﺄﺗﻓ .ﺭﺎﺑﻐﻟﺍ ﻊﻳﻣﺟﺗﻭ ﻁﻔﺷ ﺯﺎﻬﺟ ﺏﻳﻛﺭﺗ ﺯﺎﺟ ﻥﺇ (ﺥ
.ﻡﻳﻠﺳ ﻝﻛﺷﺑ ﺎﻬﻣﺍﺩﺧﺗﺳﺍ
ﺭﻁﺎﺧﻣﻟﺍ ﻝﻳﻠﻘﺗ ﻰﻟﺇ ﺓﺯﻬﺟﻷﺍ ﻩﺫﻫ ﻡﺍﺩﺧﺗﺳﺍ ﻱﺩﺅﻳ ﻥﺃ ﻥﻛﻣﻣﻟﺍ ﻥﻣ
.ﺭﺎﺑﻐﻟﺎﺑ ﺔﻘﻠﻌﺗﻣﻟﺍ
ﺎﻬﺑ ﺔﻳﺎﻧﻌﻟﺍﻭ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻡﺍﺩﺧﺗﺳﺍ ﺔﻘﻳﺭﻁ (4
ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻡﺩﺧﺗﺳﺍﻭ ،ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻡﺍﺩﺧﺗﺳﺍ ﻲﻓ ﻁﺭﻔﺗ ﻻ(ﺃ
.ﻪﺑ ﻡﻭﻘﺗ ﻱﺫﻟﺍ ﻝﻣﻌﻠﻟ ﺔﺑﺳﺎﻧﻣﻟﺍ
ﻙﺩﻋﺎﺳﻳ ﺍﺫﻫ ﻥﺈﻓ ﻙﻟﺫﻟ ﺔﺻﺻﺧﻣﻟﺍ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻙﻣﺍﺩﺧﺗﺳﺍ ﺩﻧﻋ
ﻡﺗ ﻲﺗﻟﺍ ﺔﻣﻬﻣﻠﻟ ًﺎﻌﺑﺗ ًﺎﻧﻣﺃ ﺭﺛﻛﺃﻭ ﻝﺿﻓﺃ ﺔﺟﻳﺗﻧ ﻰﻠﻋ ﻝﻭﺻﺣﻟﺍ ﻰﻠﻋ
.ﺎﻬﻟ ﺏﺎﻘﺛﻣﻟﺍ ﻡﻳﻣﺻﺗ
ﺓﺩﻌﻟﺍ ﻡﺩﺧﺗﺳﺗ ﻻﻝﻣﻌﻟﺍ ﻥﻋ ﻝﻳﻐﺷﺗﻟﺍ ﺡﺎﺗﻔﻣ ﻝﻁﻌﺗ ﺔﻟﺎﺣ ﻲﻓ (ﺏ
.ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ
ﺎﻬﺑ ﺹﺎﺧﻟﺍ ﻝﻳﻐﺷﺗﻟﺍ ﺡﺎﺗﻔﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ ﻥﻛﻣﻳ ﻻﺔﻳﺋﺎﺑﺭﻬﻛ ﺓﺩﻋ ﻱﺃ
.ﺡﺎﺗﻔﻣﻟﺍ ﺍﺫﻫ ﺡﻼﺻﺇ ﺏﺟﻳﻭ ﺎﻬﻣﺍﺩﺧﺗﺳﺍ ﺩﻧﻋ ًﺍﺭﻁﺧ ﻝﻛﺷﺗ ﺎﻬﻧﺈﻓ
ﻭﺃ ﺕﻼﻳﺩﻌﺗ ﻱﺃ ءﺍﺭﺟﺇ ﻝﺑﻗ ﺔﻗﺎﻁﻟﺍ ﺭﺩﺻﻣ ﻥﻋ ﺱﺑﺎﻘﻟﺍ ﻝﺻﻔﺑ ﻡﻗ (ﺕ
.ﺔﻗﺎﻁﻟﺍ ﺕﺍﻭﺩﺃ ﻥﻳﺯﺧﺗ ﻭﺃ ﺕﺎﻘﺣﻠﻣﻟﺍ ﺭﻳﻳﻐﺗ
ﺭﻳﻏ ﻝﻛﺷﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻝﻳﻐﺷﺗ ﻩﺫﻫ ﻁﺎﻳﺗﺣﻻﺍ ﺕﺍءﺍﺭﺟﺇ ﻊﻧﻣﺗ
.ﺩﻭﺻﻘﻣ
ﻝﻭﺎﻧﺗﻣ ﻥﻋ ًﺃﺩﻳﻌﺑ ﺔﻣﺩﺧﺗﺳﻣ ﺭﻳﻐﻟﺍ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﻥﻳﺯﺧﺗﺑ ﻡﻗ (ﺙ
ﻝﻳﻐﺷﺗ ﻥﻋ ﺓﺭﻛﻓ ﻪﻳﺩﻟ ﺱﻳﻟ ﺹﺧﺷ ﻱﻷ ﺢﻣﺳﺗ ﻻﻭ ﻝﺎﻔﻁﻷﺍ
.ﺎﻬﻠﻳﻐﺷﺗ ﻭﺃ ﺕﺍﻭﺩﻷﺍ ﻩﺫﻫ ﻥﻣ ﺏﺍﺭﺗﻗﻻﺎﺑ ﺏﺎﻘﺛﻣﻟﺍ
ﻥﻳﺑﺭﺩﻣ ﺭﻳﻐﻟﺍ ﺹﺎﺧﺷﻷﺍ ﻱﺩﻳﺃ ﻲﻓ ﺓﺭﻭﻁﺧ ﻝﺛﻣﺗ ﻝﻳﻐﺷﺗﻟﺍ ﺕﺍﻭﺩﺃ
.ﺎﻬﻳﻠﻋ
ﺔﻳﺣﺎﻧ ﻥﻣ ًﺍﺩﻳﺟ ﺎﻬﺻﺣﻔﺑ ﻡﻗ ،ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺩﺩﻌﻟﺍ ﺔﻣﻼﺳ ﻥﻣ ﺩﻛﺄﺗ (ﺝ
ءﺯﺟ ﻱﺃ ﻲﻓ ﺭﺳﻛ ﻱﺃ ﺩﻭﺟﻭ ﻭﺃ ﺔﻛﺭﺣﺗﻣﻟﺍ ءﺍﺯﺟﻷﺍ ﻁﺑﺍﺭﺗ ﻯﺩﻣ
.ﺎﻬﻠﻳﻐﺷﺗ ﻰﻠﻋ ﺭﺛﺅﻳ ﺎﻣﺑ ﺎﻬﺋﺍﺯﺟﺃ ﻥﻣ
ﻝﺑﻗ ﺎﻬﺣﻼﺻﺇ ﺏﺟﻳ ﻝﻳﻐﺷﺗﻟﺍ ﺕﺍﻭﺩﺄﺑ ﻑﻠﺗ ﺙﻭﺩﺣ ﺔﻟﺎﺣ ﻲﻓ
.ﻡﺍﺩﺧﺗﺳﻻﺍ
ﺭﻳﻏ ﻝﻛﺷﺑ ﺔﻧﺎﻳﺻﻟﺍ ﺔﻳﻠﻣﻌﺑ ﻡﺎﻳﻘﻟﺍ ﻭﺃ ﻝﻳﻐﺷﺗﻟﺍ ﺕﺍﻭﺩﺃ ﺔﻧﺎﻳﺻ ﻡﺩﻋ
.ﺙﺩﺍﻭﺣﻟﺍ ﻥﻣ ﺭﻳﺛﻛﻟﺍ ﺙﻭﺩﺣ ﻰﻟﺇ ﻱﺩﺅﻳ ﺢﻳﺣﺻ
ﺔﻔﻳﻅﻧﻭ ﺓﺩﺎﺣ ﻊﻳﻁﻘﺗﻟﺍ ﺕﺍﻭﺩﺃ ﻰﻠﻋ ﻅﺎﻔﺣﻟﺍ ﻰﺟﺭﻳ (ﺡ
ﻝﻬﺳﻳ ﺙﻳﺣﺑ ﻑﺍﻭﺣﻟﺍ ﺓﺩﺎﺣ ﻊﻳﻁﻘﺗﻟﺍ ﺕﺍﻭﺩﺃ ﻰﻠﻋ ﻅﺎﻔﺣﻟﺍ ﻰﺟﺭﻳ
.ﺎﻬﻳﻓ ﻡﻛﺣﺗﻟﺍ
ﻕﻓﺍﻭﺗﻳ ﺎﻣﺑ ،ﺦﻟﺇ ﻊﻁﻘﻟﺍ ﻡﻼﻗﺃﻭ ﺕﺎﻘﺣﻠﻣﻟﺍﻭ ،ﺔﻗﺎﻁﻟﺍ ﺓﺍﺩﺃ ﻡﺩﺧﺗﺳﺍ (ﺥ
ﺔﻗﺎﻁﻟﺍ ﺓﺍﺩﺃ ﻉﻭﻧﻟ ﺔﺻﺻﺧﻣﻟﺍ ﺔﻘﻳﺭﻁﻟﺎﺑﻭ ﺕﺎﻣﻳﻠﻌﺗﻟﺍ ﻩﺫﻫ ﻊﻣ
ﺏﻭﻠﻁﻣﻟﺍ ﻝﻣﻌﻟﺍﻭ ﻝﻣﻌﻟﺍ ﻑﻭﺭﻅ ﺭﺎﺑﺗﻋﻻﺍ ﻲﻓ ﻊﺿﻭﻟﺍ ﻊﻣ ،ﺩﺩﺣﻣﻟﺍ
.ﻪﺑ ﻡﺎﻳﻘﻟﺍ
ﻰﻟﺇ ﺎﻬﻟ ﺔﺻﺻﺧﻣﻟﺍ ﺭﻳﻏ ﺽﺍﺭﻏﻸﻟ ﺔﻗﺎﻁﻟﺍ ﺓﺍﺩﺃ ﻡﺩﺧﺗﺳﺍ ﻱﺩﺅﻳ ﺩﻗ
.ﺭﻳﻁﺧ ﻑﻗﻭﻣ ﺩﻭﺟﻭ
ﺔﻣﺩﺧﻟﺍ (5
ﻁﻘﻓﻭ ﻥﻳﺻﺻﺧﺗﻣﻟﺍ ﻝﺑﻗ ﻥﻣ ﻁﻘﻓ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﻙﺗﺩﻋ ﺢﻳﻠﺻﺗﺑ ﺢﻣﺳﺍ (ﺃ
. ﻁﻘﻓ ﺔﻳﻠﺻﻷﺍ ﺭﺎﻳﻐﻟﺍ ﻊﻁﻗ ﻝﺎﻣﻌﺗﺳﺈﺑ
.ﺯﺎﻬﺟﻟﺍ ﻥﺎﻣﺃ ﻰﻠﻋ ﺔﻅﻓﺎﺣﻣﻟﺍ ﻙﻟﺫ ﻥﻣﺅﻳ
ﺕﺎﻁﺎﻳﺗﺣﻻﺍ
.ﻥﺳﻟﺍ ﺭﺎﺑﻛﻭ ﻝﺎﻔﻁﻷﺍ ﻝﻭﺎﻧﺗﻣ ﻥﻋ ًﺍﺩﻳﻌﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻊﺿﻭ ﻰﺟﺭﻳ
ﻥﻋ ﺓﺩﻳﻌﺑ ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺓﺩﻌﻟﺍ ﻰﻠﻋ ﻅﺎﻔﺣﻟﺍ ﺏﺟﻳ ﻡﺍﺩﺧﺗﺳﻻﺍ ﻡﺩﻋ ﺔﻟﺎﺣ ﻲﻓ
.ﻥﺳﻟﺍ ﺭﺎﺑﻛﻭ ﻝﺎﻔﻁﻷﺍ ﻝﻭﺎﻧﺗﻣ
000BookCM12Y.indb15000BookCM12Y.indb15 2018/03/229:50:532018/03/229:50:53

16
Item
No. Part Name
1 Rubber Cap 2 Machine Screw (W/Washers) M4×8 3 Dust Collector (B) 4 Dust Collector (A) 5 Spring Washer M4 6 Machine Screw M4×30 7 Machine Screw M4×12 8 Wheel Guard 9 Guard Holder
10 Seal Lock Screw (W/Sp. Washer) M5×10 11 Wheel Washer (B) 12 Wheel Washer (C) 13 Wheel Washer (D) 14 Bolt (Left Hand) M10×20 15 Pushing Button 16 Spring 17 Lock Pin 18 Machine Screw (W/Washers) M5×35 19 Hex. Socket Hd. Bolt (W/Flange) M5×16 20 Feather Key 4×4×25 21 Ball Bearing (6200VVCMPS2S) 22 Lock Sleeve 23 Gear 24 Seal Plate (A) 25 Knob 26 Bolt Washer M8 27 Super Lock Washer M8 28 Packing Gland 29 Bolt (Square) M8×30 30 Ball Bearing (6302DDUCMPS2S) 31 Spindle 32 Felt Packing 33 Spacer 34 Gear Pinion Ass’y 35 U-Nut M8 36 Pinion (A) 37 Space Washer 38 Seal Lock Flat Hd. Screw M4×10 39 Bearing Cover 40 Rubber Ring (B) 41 Ball Bearing (6301DDUCMPS2S) 42 Pipe Handle (B) 43 Joint Plate 44 Hex. Socket Hd. Bolt (W/Flange) M6×16 45 Hex. Socket Hd. Bolt (W/Flange) M6×30 46 Bolt Washer M12 47 Spring Washer M12 48 Bolt M12×25 49 Feather Key 3×3×10 50 Feather Key 4×4×12 51 Gear Cover Ass’y 52 Dust Guard 53 U-Nut (Left Hand) M8 54 Pinion
Item
No. Part Name
55 Thrust Washer (A) 56 Ball Bearing (6301VVCMPS2S) 57 Drive Shaft 58 First Gear (A) 59 Brush Terminal 60 Tube (D) 61 Brand Label 62 Washer M6 63 Machine Screw M6×35 64 Seal Plate (B) 65 Tapping Screw (W/Flange) D5×35 66 Inner Cover 67 Armature 68 Dust Seal 69 Fan Guide 70 Hex. Hd. Tapping Screw D5×75 71 Stator Ass’y 72 Housing Ass’y 73 Name Plate 74 Brush Cap 75 Carbon Brush 76 Brush Holder 77 Hex. Socket Set Screw M5×8 78 Bearing Bushing 79 Nut M6 80 Tail Cover 81 Tapping Screw (W/Flange) D5×25 82 Machine Screw M5×20 83 Spring Washer M5 84 Handle (A) 85 Diode 86 Handle (B) 87 Noise Suppressor 88 Tube (D) 89 Tapping Screw (W/Flange) D4×25 90 Grip Rubber 91 Cord Clip 92 Tapping Screw (F/Flange) D4×16 93 Switch 94 Tube (D) 95 Cord Armor 96 Cord
501 Hose 502 Wrench 17/9 MM 503 Eye Protector
Parts are subject to possible modification without notice due to improvements. 部件可能因技術改進而有所變更，恕不另行通知。
.ﺭﺎﻁﺧﺇ ﻥﻭﺩ ﻝﻳﺩﻌﺗﻟﺍ ﺔﻳﻧﺎﻛﻣﻹ ﺔﺿﺭﻋ ءﺍﺯﺟﻷﺍ ﻥﺈﻓ ﺭﻳﻭﻁﺗﻠﻟ ًﺎﻘﻓﻭ
000BookCM12Y.indb16000BookCM12Y.indb16 2018/03/229:50:532018/03/229:50:53

17
000BookCM12Y.indb17000BookCM12Y.indb17 2018/03/229:50:532018/03/229:50:53

18
000BookCM12Y.indb18000BookCM12Y.indb18 2018/03/229:50:532018/03/229:50:53

19
000BookCM12Y.indb19000BookCM12Y.indb19 2018/03/229:50:532018/03/229:50:53

806
Code No. C99072732 N
Printed in Japan
000BookCM12Y.indb20000BookCM12Y.indb20 2018/03/229:50:532018/03/229:50:53
