Hillrom Liko Ultra Series User manual

Product Descripon
Liing heavy paents requires special liing techniques
and specially designed liing accessories. UltraTwin is the
name of Liko’s system for liing up to 500 kg (1100 lbs).
The system is based on the use of two LikorallTM li motors
working together which also allows individual maneuvering
that is helpful in posioning of the paent to upright,
semi-reclined or lying posion. Ultra Twist is an accessory
to the UltraTwin system, which facilitates 360° rotaon of
the paent and gives great advantage to transfers from bed,
liing to gurney, ambulaon or when used in conned spaces
etc. Ultra Twist is available in two versions (Wide and Slim), to
suit dierent liing needs.
In this document, the person being transferred is referred to as the paent and the person helping them is referred to as the
caregiver.
UltraTwist Slim and UltraTwist Wide can be used with
sling bars for transfers in seated posion, e.g. between bed
and wheelchair or to/from the toilet. UltraTwist Wide can also
be used with stretchers for horizontal transfers of the paent,
e.g., in surgery or X-ray situaons.
For liing of heavy paents Liko oers a wide range of specially
designed liing accessories.
Ultra Control Unit can be used with LikorallTM li motors. It is
used for simplied maneuvering with one hand control when
combining two li motors installed in separate rails.
UltraTwist Slim
UltraTwist Wide
Liko™ Ultra Li System
Instrucon for Use
Applies to the following models:
UltraTwist Slim Prod. No. 3126045
UltraTwist Wide Prod. No. 3126047
Ultra Control Unit Prod. No. 3126040
IMPORTANT!
Liing and transferring a paent always involves a certain level of risk. Read the instrucons for use for both the paent
li and liing accessories before use. It is important to completely understand the contents of the instrucons for use.
The equipment should only be used by trained personnel. Ensure that the liing accessories are suitable for the li used.
Exercise care and cauon during use. As a caregiver, you are always responsible for the paent’s safety. You must be aware
of the paent’s ability to make it through the liing situaon. If something is unclear, contact the manufacturer or supplier.
7EN111103 Rev. 3
ENGLISH 2020
Ultra Control Unit

2w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Table of Contents
Symbol Descripon .......................................................................................................................... 3
Safety Instrucons ........................................................................................................................... 4
Technical Data .................................................................................................................................. 4
Measurements ................................................................................................................................. 4
Maximum Load ............................................................................................................................... 5
Denions ........................................................................................................................................ 5
Recommended Liing accessories ................................................................................................... 6
Operaon ......................................................................................................................................... 6
From bed to chair/wheelchair with UltraTwist Slim and UltraControl Unit .................................... 7
From bed to chair/wheelchair with UltraTwist Wide ....................................................................... 8
Liing with a stretcher on UltraTwist Wide ...................................................................................... 9
Inspecon and Maintenance .......................................................................................................... 10

3w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Symbol Descripon
These symbols can be found in this document and/or on the product.
Symbol Descripon
For indoor use only.
The product has extra protecon against electric shock (Insulaon Class II).
Protecon level against electric shock Type B.
Warning; this situaon requires extra care and aenon.
Read instrucon for use before use.
CE mark
IP N1 N 2 Protecon level against: ingress of solid objects (N1) and ingress of water (N2).
Legal Manufacturer.
Date of manufacture.
Cauon! consult instrucons for use.
Read instrucon for use before use.
Baery.
,
Pb
,
All baeries in this product must be recycled separately.
- Pb underneath the symbol indicate baeries containing lead
- Single Black line underneath the symbol indicate this product have been placed on the market aer 2005.
UL Recognized Component Mark for Canada and the United States.
EFUP, Environmental Friendly Usage Period (years).
Environmentally-friendly product which can be recycled and reused.
The Australian Safety/EMC.
PSE Mark (Japan).
Product Idener.
Serial Number.
Medical Device.
Recyclable.
The safety and essenal performance of medical electrical equipment.
Proof of Product compliance to North American safety standards.
Non-ionizing electromagnec radiaon.
X%
Y% ≤Tmin
Duty cycle for non-connuous operaon.
The maximum acve operaon me X% of any given me unit, followed by a deacvaon me, Y%.
The acve operaon me shall not exceed the specied me in minutes, T.
(01) 0100887761997127
(11) Y Y MM D D
(21) 012345678910
GS1 Data Matrix Barcode that may contain following informaon
(01) Global Trade Item Number
(11) Producon Date
(21) Serial Number

4w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Safety Instrucons
Before liing, keep the following points in mind:
• liing accessories are properly connected to the li;
• the correct liing accessory has been chosen, with respect to the type, size, material and design in relaon to the
needs of the paent.
• plan the liing and transfer operaon carefully, so the paent is as comfortable and secure as possible;
• idenfy which of the li motors is controlled with the single arrows on the hand control. Make sure that this motor li at the
head end of a stretcher (marked with a head symbol), alternavely, the wider of the two sling bars;
• ensure that wheels/castors on the bed, gurney, etc. are locked during the liing operaon;
• the li strap is not twisted or worn and can be run freely in and out of the li motor;
• liing accessories are not damaged;
• the sling/li sheet is correctly and securely applied to the paent, so that there is no risk of personal injury
• the liing accessory is correctly applied to the li;
• the sling’s/li sheet’s strap loops are correctly applied to the sling bar hooks when the sling’s/li sheet’s straps are
extended, but before the paent is lied from the underlying surface.
Never leave a paent unaended during a transfer situaon!
Incorrect aachment of sling to slingbar may cause severe injury to the paent!
UltraTwist must always be assembled by an authorized technician; see current installaon instrucons.
Technical Data
Weight: 18.7 kg (41 lbs) - Ultra Twist Slim (excl. li motors) Material (casing): Aluminium and steel
24.5 kg (54 lbs) - Ultra Twist Wide (excl. li motors)
1.3 kg (2,8 lbs) - Ultra Control Unit (excl. li motors)
Max. load: 500 kg (1100 lbs)
The device is intended for indoor use.
Ultra Twist Wide Prod. no. 3126047
A: 1130 mm (44.5 inch.)
B: 544 mm (21.4 inch.)
C: 500 mm (19.7 inch.)
D: 27 mm (1.1 inch.)
E: 306 mm (12.5 inch.)
F: 184 mm (7.2 inch.)
H: 141 mm (5.7 inch.)
A
C
B
D
E
F
H
A
C
E
HD
B
Ultra Twist Slim Prod. no. 3126045
A: 542 mm (21.3 inch.)
B: 305 mm (12.0 inch.)
C: 500 mm (19.7 inch.)
D: 104 mm (4.1 inch.)
E: 270 mm (10.6 inch.)
H: 16 mm (0.6 inch.)
Measurements
Medical Device Class I Product
Ultra Control Unit Prod. no. 3126040
A: 320 mm (12.6 inch.)
B: 45 mm (1.8 inch.)
C: 160 mm (6.3 inch.)

5w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Maximum Load
Dierent maximum loads may apply to dierent products on the assembled li system: li, sling bar, sling and any other
accessories used. For the assembled li system, the maximum load is always the lowest maximum load rang for any of
the components. To maintain the 500 kg (1100 lbs) maximum load rang, two Likorall
TM
250 ES li units are used. It is also
essenal that the accessories that are used are intended for the same maximum load or greater.
Study the markings on the li and liing accessories and contact your Hill-Rom representave if you have any quesons.
Denions
Ultra Twist Slim (with LikorallTM li motors)
Ultra Twist Wide (with LikorallTM li motors)
1
2
3
5
4
13
7
11
12
10
8
8
6
9
1
2
3
5
4
7
11
12
10
8
8
1. HandControl UT
2. Q-Link
3. Li strap
4. Emergency stop
5. Manoeuvre contact
6. Carriage (pair)
7. Rotaon plate (360 ° )
8. Wheel set
9. Rail H70
10. Mounng rail
11. Li motor (LikorallTM)
12. Connecon box
13. Mounng bracket
Ultra Control Unit (with LikorallTM li motors)
1
2
3
5
4
11
12

6w w w . hillrom. com
7EN111103 Rev. 3 • 2020
UltraTwist Slim and Ultra Control Unit– liing in a seated posion
For this combinaon we recommend two Universal Slingbar 600 (Prod. No. 3156086) or Universal SlingBar 450
(Prod. No. 3156085) together with Universal SlingBar 600 (Prod. No. 3156086). If you use slingbars with two dierent
widths, the wider of the two sling bars is intended for use with the sling’s upper strap loops and the narrower sling bar
is to be used with the leg support´s strap loops.
UltraTwist Wide – liing in a seated posion
For this combinaon we recommend two Universal Slingbar 600 (Prod. No. 3156086) or Universal SlingBar 450
(Prod. No. 3156085) together with Universal SlingBar 600 (Prod. No. 3156086). If you use slingbars with two dierent
widths, the wider of the two sling bars is intended for use with the sling’s upper strap loops and the narrower sling bar
is to be used with the leg support´s strap loops.
UltraTwist Wide – horizontal liing
For horizontal liing, we recommend UltraStretch (Prod. No. 3156058).
This can be used with a full li sheet (Prod. No. 3684105-106).
Operaon
HandControl UT (included with UltraTwist)
Controls both li motors: Up Down
Controls one of the li motors: Up Down
Charging
The li motor baeries are charged via the hand control. One baery charger (accessory) is sucient for the enre system if
HandControl UT is used. For complete charging instrucons, see the instrucon for use for the respecve li motor.
Recommended Liing Accessories
Using liing accessories other than those approved can entail a risk.
Below, we present recommended sling bars and accessories for use with Ultra Li systems.

7w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Before starng the liing operaon it is important to ensure that the sling bars are properly connected to the li
motor´s li straps. Below, we illustrate a transfer from bed to wheelchair using Original HighBack Sling Mod. 200 alt. 26.
From bed to chair/wheelchair with UltraTwist Slim and UltraControl Unit
1. Apply the sling as described in the instrucon for use.
Before the paent is lied from the underlying
surface, but when the straps are properly extended, it is
important to ensure that the straps are correctly aached
to the sling bars. In conjuncon with liing, use the bed’s
raising and lowering funcons.
For advice on how to regulate the paent’s sing
posture, see below.
Load must be applied to all four hooks during liing.
2. Placement of the paent in a chair is facilitated by
UltraTwist’s rotaon funcon. Grasp the sling bars, sling
and/or the paent’s legs/knees and rotate to
the desired posion.
Note! Rotaon funcon not applicable for Ultra Control
Unit. Plan li accordingly.
3. Guide the paent toward the chair. Lower the paent.
By raising or lowering only one of the two li strap´s you may adjust the paent in posion for a comfortable and secure
transfer. Seat the paent in a more upright posion (A) when transferring to a chair, and seat the paent in a more reclined
posture (B) when transferring to a bed. The paent’s sing posture is manouvered via the lower buons (single arrows) on
the HandControl UT, or with the hand control that manouvers the li motor which lis the upper body.
Adjusng the paent’s sing posture (leaning in a seated posion)
When liing, always li with both li motor´s!
1. 2. 3.
A. B.

8w w w . hillrom. com
7EN111103 Rev. 3 • 2020
From bed to chair/wheelchair with UltraTwist Wide
Before starng the liing operaon it is important to ensure that the sling bars are properly connected to each li motor´s li
strap. Recommended sling bars for UltraTwist Wide: Universal SlingBar 600 and Universal SlingBar 450. Universal SlingBar 600
is intended for the sling’s upper strap loops and is connected to the li strap that is manouvered via the lower buons on the
hand control. Universal SlingBar 450 is intended for the leg support´s strap loops. Below, we illustrate a transfer from bed to
wheelchair using the above-menoned sling bars and an Original HighBack Sling Mod. 200 alt. 26.
1. Apply the sling as described in the instrucon for use.
Before the paent is lied from the underlying
surface, but when the straps are properly extended,
it is important to ensure that the straps are correctly
aached to the sling bar. In conjuncon with liing, use
the bed’s raising and lowering funcons.
For advice on how to regulate the paent’s sing
posture, see below.
Load must be applied to all four hooks during liing.
2. Placement of the paent in a chair is facilitated by UltraTwist’s
rotaon funcon. Grasp the sling bars, sling and/or the
paent’s legs/knees and rotate to the desired posion.
3. Guide the paent toward the chair. Lower the paent.
Adjusng the paent’s sing posture (leaning in a seated posion)
When liing, always li with both li motor´s!
1. 2. 3.
B.
A.
By raising or lowering only one of the two li strap´s you may adjust the paent in posion for a comfortable and secure
transfer. Seat the paent in a more upright posion (A) when transferring to a chair, and seat the paent in a more reclined
posture (B) when transferring to a bed. The paent’s sing posture is manouvered via the lower buons (single arrows) on
the HandControl UT, or with the hand control that manouvers the li motor which lis the upper body.

9w w w . hillrom. com
7EN111103 Rev. 3 • 2020
Lifting with a stretcher on UltraTwist Wide
UltraTwist Wide should be used when liing with a stretcher. We recommend the use of UltraStretch (see page 6). Below,
liing with UltraStretch and LiSheet XL is illustrated. Carefully study the instrucon for use for the accessories used.
1. Apply the li sheet as described in the instrucon for
use. Guide the UltraStretch over the paent and lower
to about half a metre above the bed. Hang all of the
strap loops on the stretcher. Note that the stretcher
has a head end and a foot end (see marking with head
symbol).
Ensure that all strap loops are properly hooked
when the straps are extended but before the paent is
lied from the underlying surface.
2. During liing, check to ensure that the paent is
resng in the desired posion: fully prone or with
the head slightly higher. If necessary, this can be
regulated by raising or lowering one of the li
motors.
UltraTwist Wide can rotate 360 ° . This is a great advantage if you
need to change bedding, li to a stretcher or when liing in
conned spaces. Grasp the stretcher and rotate the paent to
the desired posion.
When liing, always li with both li motor´s!

Inspecon and Maintenance
For trouble-free use, certain details should be checked each day the li is used:
• Check the li system for any signs of external damage.
• Check carriage funcon.
• Check the sling bar’s/stretcher’s Quick-release Hook safety funcon.
• Ensure that all screws are ghtened.
When necessary, clean the li with a moist cloth, using warm water or disinfectant. NOTE! Do not use cleaning agents that
contain phenol or chlorine, since these can damage aluminium and plasc materials.
The li should not be exposed to running water.
Service
A periodic inspecon of the UltraTwist should be carried out at least once a year.
Periodic inspecon, repair and maintenance may be performed only in accordance with the Liko service manual by
personnel authorized by Liko and using original Liko spare parts.
Service Agreement
Liko oers the opportunity to enter into service contracts for the maintenance and regular inspecon of your Liko product.
Expected Life Time
The product has an expected life me of 10 years when correctly handled, serviced and periodically inspected in
accordance with Liko’s instrucons.
Transport and Storage
The environment in which the product is transported and stored should have a temperature of 10–40 ˚C (50-104 °F) and a
relave humidity of 30–75 %. The atomspheric pressure should be 700–1060 hPa.
Recycling
Ultra Control Unit should be recycled as Waste of Electrical and Electrical Equipment (WEEE). Electronic parts on UltraTwist
should be recycled as Waste of Electrical and Electrical Equipment (WEEE) and the rest of the product as scrap metal.
Hillrom evaluates and provides guidance to its users on the safe handling and disposal of its devices to aid in the prevenon
of injury, including, but not limited to: cuts, punctures of the skin, abrasions, and any required cleaning and disinfecon of the
medical device aer use and prior to its disposal. Customers should adhere to all federal, state, regional, and/or local laws and
regulaons as it pertains to the safe disposal of medical devices and accessories.
If in doubt, the user of the device shall rst contact Hillrom Technical Support for guidance on safe disposal protocols.
Product Changes
Change to Liko products undergo connuous development, which is why we reserve the right to make product changes
without prior noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
Design and Quality by Liko in Sweden
The management system for both manufacturing and development of the product is cered in accordance with ISO9001
and its equivalent for the medical device industry, ISO13485. The management system is also cered in accordance with the
environmental standard ISO14001.
Noce to Users and/or Paents in EU
Any serious incident that has occurred in relaon to the device, should be reported to the manufacturer and the competent
authority of the Member State in which the user and/or paent is established.
© Copyright Liko R&D AB 2020. ALL RIGHTS RESERVED.
Liko AB
Nedre vägen 100
975 92 Luleå, Sweden
[phone]
www.hillrom.com
Liko AB is a subsidiary of Hill-Rom Holdings Inc.
