Hillrom Liko User manual

In this document, the person being lied is referred to as the paent, and the person helping is referred to as the caregiver.
Product Descripon
Liko’s Extension Loops are intended for simple adjustments to Liko’s accessory range. They aach to strap loops and loop
straps in order to adjust the length as required.
The Extension Loops come in two dierent lengths, and in the colours green or grey. The length you choose depends on how
great an adjustment you want to make.
Liko™ Extension Loop
Instrucons for Use
7EN160184 Rev. 2
ENGLISH 2020
IMPORTANT!
Liing and transferring a paent always involves a certain level of risk. Read the instrucons for use for both the paent
li and liing accessories before use. It is important to completely understand the contents of the instrucons for use.
The equipment should only be used by trained personnel. Ensure that the liing accessories are suitable for the li used.
Exercise care and cauon during use. As a caregiver, you are always responsible for the paent’s safety. You must be aware
of the paent’s ability to make it through the liing situaon. If something is unclear, contact the manufacturer or supplier.

2www.hillrom.com7EN160184 Rev. 2 • 2020
These symbols can be found in this document and/or on the product.
Symbol Descripon
Symbol Descripon
Warning; this situaon requires extra care and aenon
Read instrucons for use before use
CE mark
Legal manufacturer
Date of manufacturing
Product Idener
Serial Number
Medical device
Do not dry clean
Do not iron
Tumble drying
Do not tumble dry
Washing
Symbol is always in combinaon with recommended temperature
in °C and °F.
Latex Free
Periodic inspecon
Do not bleach
Line drying in shade
Facing Out Direcon upwards and symbol on outside of equipment.
Facing Out Symbol on outside of equipment.
(01) 0100887761997127
(11) Y Y MM DD
(21) 012345678910
GS1 Data Matrix Barcode that may contain following informaon.
(01) Global Trade Item Number
(11) Producon Date
(21) Serial Number

3www.hillrom.com7EN160184 Rev. 2 • 2020
Before liing, keep the following points in mind:
• Note that the sling’s geometry changes when you aach Extension Loops to individual strap loops. A change to the sling’s
geometry can aect safety, so be careful during the tesng phase, which is to be conducted by an authorized prescriber.
• Check to make sure that the Extension Loops are correctly aached to the sling / liing accessories before each li. Be
especially aenve aer washing.
• Although the Liko sling bars are equipped with latches, special cauon must be exercised. Before the paent is lied from
the underlying surface, but when the straps are fully extended, make sure the straps are correctly connected to the sling
bar hooks.
• Always work ergonomically. Use the paent’s ability to acvely parcipate in the operaons.
• When the sling is not being used, do not place in direct sun light.
Incorrect aachment of sling to slingbar may cause severe injury to the paent.
Manually turning the paent in bed may cause injuries to the caregiver.
Safety Instrucons
Medical Device Class I Product
Product Changes
Liko products undergo connuous development, which is why we reserve the right to make product changes without prior
noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
Design and Quality by Liko in Sweden
Liko is quality cered according to ISO 9001 and its equivalent for the medical device industry ISO 13485. Liko is also cered
according to environmental standard ISO 14001.
Noce to Users and/or Paents in EU
Any serious incident that has occurred in relaon to the device, should be reported to the manufacturer and the competent
authority of the Member State in which the user and/or paent is established.

4www.hillrom.com7EN160184 Rev. 2 • 2020
Assembly
Check the product before each use. Check the following points with regard to wear and damage:
• Straps
• Seams
Do not use damaged liing accessories.
If anything is unclear, please contact the manufacturer or supplier.
Care and Maintenance
Washing instrucons: Please see the Extension Loop product label and the aached appendix ”Care and Maintenance of Liko
Slings”.
Periodic Inspecon
The product must be inspected at least once every 6 months. More frequent inspecons might be required if the products
are used or washed more oen than normal. For protocols please contact your Hill-Rom representave.
Expected Life Time
If the product is made of green woven polyester webbing, the product has an expected life me of 5 years. If the product is
made of grey polyester, the product has an expected life me of 3 years. The expected life me is based on 10 uses per day
and washing once per week, according to washing instrucons. Hill-Rom recommends the product to be used only during its
expected life me.
Recycling Instrucons
The enre Extension Loop should be sorted as Combusble waste.
Hill-Rom evaluates and provides guidance to its users on the safe handling and disposal of its devices to aid in the prevenon
of injury, including, but not limited to: cuts, punctures of the skin, abrasions, and any required cleaning and disinfecon of the
medical device aer use and prior to its disposal. Customers should adhere to all federal, state, regional, and/or local laws and
regulaons as it pertains to the safe disposal of medical devices and accessories.
If in doubt, the user of the device shall rst contact Hill-Rom Technical Support for guidance on safe disposal protocols.

5www.hillrom.com7EN160184 Rev. 2 • 2020
Areas of Use
1. Increasing the distance
between head and slingbar
Extend all the sling’s/liing acces sory’s
strap loops to increase the distance of
the paent’s head from the slingbar.
Note that the longer the extension
loops used, the higher the sling’s
construcon height, which can make a
li to the desired level more dicult.
2. Simplifying connecon
to the slingbar
If the sling’s/liing accessory’s
strap loops do not reach up to the
slingbar – extend all the sling’s
strap loops in order to improve
ease of connecon. Too much
extension can make it dicult to li
the paent to the desired level.
3. More upright sing posion
When you connect the leg supports
on a sling overlapped under both legs,
you may somemes need to extend
the leg support loops to achieve
a more upright sing posion.
4. Less bend in the hip
Extend the sling’s leg support loop to
achieve a more open hip angle. This
can be done on one or the other or
both leg support loops as needed.
5. Adjustment of loop strap length
Extend the sling’s/liing accessory’s
loop straps if they are too short.
The Extension Loop can be aached
to one of the outer loops on the loop
strap as needed.
6. In combinaon with Comfort Sling
Plus/Comfort Sling
When you combine Comfort Sling Plus
Mod. 300/310/350/360 or Comfort
Sling Mod. 30/31/35/36 with Liko Sling
Cross-bars or Side Bars you must always
extend the slings upper strap loops. This
combinaon provides a more reclined
sing posion with less bend in the hip
joint. See the instrucons for use of the
slings.

© Copyright Liko R&D AB 2020. ALL RIGHTS RESERVED.
Liko AB
Nedre vägen 100
975 92 Luleå, Sweden
[phone]
www.hillrom.com
Liko AB is a subsidiary of Hill-Rom Holdings Inc.
Name Prod. No. Extends Maximum load
Extension Loop, green, 12 cm 3691102 12 cm (5 inch.) 150 kg (330 lbs.)/loop
Extension Loop, green, 22 cm 3691103 22 cm (9 inch.) 150 kg (330 lbs.)/loop
Extension Loop, grey, 12 cm 3691302 12 cm (5 inch.) 150 kg (330 lbs.)/loop
Extension Loop, grey, 22 cm 3691303 22 cm (9 inch.) 150 kg (330 lbs.)/loop
Overview Liko™ Extension Loop
Approved combinaons
=
=
12 cm
22 cm
Liko’s Extension Loops are only to be used together with Liko’s liing accessory range. We approve combinaons with the
following liing accessories in accordance with the areas of use (1 - 6) described on page 5.
Explanaon: 1 = Must be used 2 = May be used 3 = May be used, but note that the sling’s geometry has changed 4 = Not
relevant/Not advised
* Extend all of the product’s strap loops.
** With crossed leg supports.
Area of
Use 1*
Area of
Use 2*
Area of
Use 3
Area of
Use 4
Area of
Use 5
Area of
Use 6
Universal Sling, Mod. 00/02 2 2 2 2 4 4
Ultra Sling, Mod. 06 - see the product´s instrucon for use - - - - - -
Original Sling, Mod. 10/11 2 2 2 2 4 4
Original High Back Sling, Mod. 20/21 2 2 2 2 4 4
Silhouee Sling, Mod. 22 2 2 2 2 4 4
Solo High Back Sling, Mod. 25 2 2 2 2 4 4
So Original High Back Sling, Mod. 26 2 2 2 2 4 4
Comfort Sling, Mod. 30/31/35/36 2 2 4 4 4 1
Comfort Sling Plus, Mod. 300/310/350/360 2 2 4 4 4 1
Hygiene Sling, Mod. 40/41/45/46 2 4 3 3 2 4
HygieneVest, Mod. 50/55 2 4 2 2 2 4
MasterVest, Mod. 60/64 2 4 4 4 2 4
Vest for Standing Shell, Mod. 67 2 2 4 4 2 4
Amputee Sling Mod. 70/75 2 2 3 3** 4 4
LI Pants, Mod. 92 2 4 4 4 2 4
Ultra Li Pants, Mod. 920 2 4 4 4 2 4
Liko Straps, Prod. No. 3590115 3 3 4 4 4 4
Head Support 2 2 4 4 4 4
Stat RepoSheet Original 4 4 4 4 4 4
Sabina - accessories
SupportVest, Mod. 91 4 2 4 4 4 4
Solo SupportVest, Mod. 911 4 2 4 4 4 4
SafetyVest, Mod. 93/94 4 2 4 4 2 4
ComfortVest, Mod. 95 4 2 4 4 2 4
Seatstrap 4 2 4 4 2 4
Stretcher - accessories
LiSheet Octo, Mod 83 4 2 4 4 4 4
Solo Octo LiSheet, Mod 83 4 2 4 4 4 4
LiStrap Octo, Mod 83 4 2 4 4 4 4
Cross Strap Octo, Mod 83 4 2 4 4 4 4
LiSheet XL, Mod 84 4 2 4 4 4 4
LiStrap XL, Mod 84 4 2 4 4 4 4
