Hilti TE2 User manual

11
en
General information
In these operating instructions, this symbol indi-
cates points of particular importance to safety. The
instructions at these points must always be observed
in order to avoid the risk of serious injury.
Caution: high voltage
The numbers refer to the illustrations. The illustra-
tions can be found on the fold-out cover pages. Keep
these pages open while you read the operating instruc-
tions.
In these operating instructions, the power tool to which
these operating instructions apply is referred to as “the
tool”.
It is essential that the operating
instructions are read before the
tool is operated for the first time.
Always keep these operating
instructions together with the tool.
Ensure that the operating
instructions are with the tool when
it is given to other persons.
Operating controls 
Chuck release ring (TE 2-M)
Function selector switch
Control switch
Forwards / reverse switch (TE 2 / TE 2-S / TE 2-M)
Lockbutton
Component parts 
Dust shield
Chuck
Side handle
Type plate
Description
The TE 2 / TE 2-E / TE 2-S / TE 2-M is an electrically pow-
ered rotary hammer with pneumatic hammering mech-
anism designed for professional use.
The following items are supplied: power tool, (quick-
release chuck TE 2-M), operating instructions, grease
(except TE 2-E), toolbox.
The following conditions must always be observed
when the tool is in use:
– The tool must be connected to an alternating current
electric supply in compliance with the information
given on the type plate.
– The tool is for hand-held use only.
– The tool must not be used in places where the sur-
rounding conditions may present a risk of explosion.
– Changes or modifications to the tool are not per-
missible.
– To avoid the risk of injury, use only the genuine Hilti
accessories and additional equipment specified for
use with this tool.
– Observe the information printed in the operating
instructions concerning operation, care and main-
tenance. The tool and its ancillary equipment may
present hazards when used incorrectly by untrained
personnel or when used not as directed.
TE 2/TE 2-E/TE 2-S/TE 2-M Rotary Hammer
Read the
operating
instructions
before use.
Return waste
material for
recycling
Contents Page
General information 11
Description 11
Technical data 13
Safety rules 14
Before use 15
Operation 16
Drilling 16
Forwards/reverse rotation 17
Insert tools and accessories 17
Care and maintenance 17
Disposal 18
Manufacturer's warranty – tools 18
Troubleshooting 19
Declaration of conformity 19
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 11

12
en
The tool is designed for the following uses:
Use Required insert tools Diameter range
TE 2 / TE 2-E / TE 2-S / TE 2-M:
Hammer drilling in concrete, Drill bits with TE-C connection end Drilling in concrete:
masonry and natural stone – Short hammer drill bits Anchor holes of 4–22 mm dia.
– Long hammer drill bits Through holes of 4–22 mm dia.
TE 2-S:
Drilling with precision Drill bits with TE-C connection end Drilling in brittle materials:
hammering action in perforated – TE-C hammer drill bits Anchor holes of 4–22 mm dia.
brick, tiles and marble – Thin-barrel core bits Cutting sockets of 25–68 mm dia.
TE 2 / TE 2-E / TE 2-S:
Drilling in wood, drywall panels Quick-release chuck
and metal with TE-C adaptor
for insert tools
with cylindrical shank or hexagonal shank
for rotary-only drilling
Wood drill bits 4–20 mm dia.
Metal drill bits 3–13 mm dia.
Hole saws 25–68 mm dia.
TE 2-M:
Drilling in wood, drywall panels, Interchangeable quick-release chuck
tiles and metal for insert tools
with cylindrical shank or hexagonal
shank for rotary-only drilling:
Wood drill bits 4–10 mm dia. in 2nd gear
10–20 mm dia. in 1st gear
Metal/stepped drill bits 3– 8 mm dia. in 2nd gear
8–13 mm dia. in 1st gear
Hole saws 25–68 mm dia. in 1nd gear
– The tool is intended for professional use.The tool
may be operated, serviced and repaired only by
authorized, trained personnel. This personnel must
be informed of any special hazards that may be
encountered.
Main features of the tool
Class II electrical protection (double insulated) Z
Mechanical torque-limiting clutch
Grip and side handle with vibration absorption
TE-C chuck
TE-C insert tool system
Variable speed switch
Rotary-only drilling mode
Gearing and hammering mechanism with permanent
grease lubrication
Pivotable side handle (360°)
Mechanical depth gauge
Interface for quick-release chuck (TE 2-M)
Precision hammering action (TE 2-S)
High spindle speed without hammering action (TE 2-M)
Lockbutton for sustained operation
Right of technical changes reserved
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 12

13
en
Technical data
Rated power 650 W
Nominal voltage ✱100 V 110 V 120 V 220 V 230 V 240 V
Nominal current input ✱6.9 A 6.5 A 6.1 A 3.1 A 3.0 A 2.9 A
Mains frequency 50–60 Hz
Weight of tool without side handle 2.4 kg (TE2 / TE2-S / TE2-E)
2.7 kg (TE2-M)
Weight as per EPTA-Procedure 01/2003 2.7 kg (TE2 / TE2-S / TE2-E)
2.9 kg (TE2-M)
Dimensions (l×h×w) 352×203×89 mm (TE 2 / TE 2-E / TE 2-S)
360×203×89 mm (TE2-M)
Minimum distance between wall and hole drilled 34 mm
Speed 0– 930 r.p.m. (hammer drilling)
0–1200 r.p.m. (in 1st gear TE 2 / TE 2-E / TE 2-S / TE 2-M)
0–2500 r.p.m. (in 2nd gear TE2-M)
Hammering speed:
Precision hammering action 0–2600 blows/min. (TE 2-S)
Full hammering action 0–4600 blows/min. (TE 2 / TE 2-E / TE 2-S / TE 2-M)
Single impact energy Nm (J):
Precision hammering action 0.6 Nm (TE2-S)
Full hammering action 1.8 Nm (TE 2 / TE 2-E / TE 2-S / TE 2-M)
Typical drilling performance in medium-hard B35 8 mm dia.: 550 mm/min
concrete 10 mm dia.: 500 mm/min
12 mm dia.: 400 mm/min
Noise and vibration information (measured in accordance with EN 60745-2-6 prAB: 2005):
Typical A-weighted sound power level (LwA): 102 dB (A)
Typical A-weighted emission sound power level (LpA): 91dB (A)
For the given sound power level
as per EN 60745, the tolerance is 3 dB
Wear ear protection!
Triaxial vibration value (vibration vector sum)
measured in accordance with EN 60745-2-1 prAA: 2005
Drilling in metal, (ah, D) .2.8 m/s2
measured in accordance with EN 60745-2-6 prAB: 2005
Hammer drilling in concrete, (ah, HD) 13.5 m/s2
Uncertainty (K) for triaxial vibration value 1.5 m/s2
✱The tool is offered in different versions for various mains voltages. Please refer to the information on the
type plate for the nominal voltage and nominal current input of your tool.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 13

14
en
Safety rules
1. General safety rules
-WARNING- Read all instructions! Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury. The term "power tool" in all of
the warnings listed below refers to your mains operat-
ed (corded) power tool or battery operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
1.1 Work area
a) Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable liq-
uids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
1.2 Electrical safety
a) Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of elec-
tric shock.
b) Avoid body contact with earthed or grounded sur-
faces such as pipes, radiators, ranges and refrig-
erators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
1.3 Personal safety
a) Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use
a power tool while you are tired or under the influ-
ence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in
serious personal injury.
b) Use safety equipment. Always wear eye protec-
tion. Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c) Avoid accidental starting. Ensure the switch is in
the off position before plugging in. Carrying power
tools with your finger on the switch or plugging in
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turn-
ing the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in per-
sonal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the pow-
er tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jew-
ellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of these devices
can reduce dust related hazards.
1.4 Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety mea-
sures reduce the risk of starting the power tool acci-
dentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the pow-
er tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool's oper-
ation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions and
the work to be performed. Use of the power tool for
operations different from those intended could result
in a hazardous situation.
1.5 Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 14

15
en
2. Additional safety rules
2.1 Personal safety
a) Wear ear protectors. Exposure to noise can cause
hearing loss.
b) Use auxiliary handles supplied with the tool. Loss
of control can cause personal injury.
c) Always hold the tool with both hands on the grips
provided. Keep the grips dry, clean and free from
oil and grease.
d) Exercise your fingers during pauses between work
to improve the blood circulation in your fingers.
e) Avoid contact with rotating parts. Switch the tool on
only once it has been brought into the working posi-
tion close to the workpiece.
f) Breathing protection must be worn when the tool is
used without a dust removal system for work that
creates dust.
g) To avoid tripping and falling when working, always
lead the sypply cord, extension cord and dust extrac-
tion hose away to the rear.
h) When drilling or chiseling through-holes, check that
no person is present in the danger area immedi-
ately behind the work surface.
2.2 Power tool use and care
a) Secure the workpiece. Use clamps or a vice to hold
the workpiece in place. The workpiece is thus held
more securely than by hand and both hands remain
free to operate the tool.
b) Ensure that the insert tools used are equipped with
the appropriate connection end system and that
they are properly fitted and secured in the chuck.
c) In the event of a power faillure, switch the tool off
and unplug the supply cord. This prevents inadver-
tent starting when the power returns.
d) In the event of an interruption in the electric supply
and before laying the tool down each time, check
that the lockbutton for sustained operation has been
released. Release the lockbutton if necessary. Fail-
ure to observe this point could cause the tool to start
unexpectedly when the power returns.
e) Do not apply an excessive quantity of grease to the
drill bit connection end. Excess grease may other-
wise be forced out of the chuck during operation.
2.3 Electrical safety
a) Before beginning work, check the working area (e.g.
with a metal detector) to ensure that no concealed
electric cables or gas and water pipes are present.
External metal parts of the tool may become live if,
for example, an electric cable is damaged inadvertenly.
This presents a serious risk of electric shock.
b) Check the condition of the supply cord and its plug
connections and have it replaced by a qualified elec-
trician if damage is found. Check the condition of
the extension cord and replace it if damage is found.
Do not touch the supply in the event of it suffering
damage while working. Disconnect the supply cord
plug from the socket. Damaged supply cords and
extension cords present a risk of electric shock.
c) Dirty or dusty electric tools should thus be checked
at a Hilti service center at regular intervals, espe-
cially if used frequently for working on conductive
materials. Dust (especially dust from conductive
materials) or dampness adhering to the surface of
the tool may, under unfavorable conditions, present
a risk of electric shock.
2.4 Work area
a) Ensure that the workplace is well lit.
b) Ensure that the workplace is well ventilated.
Poorly ventilated workplaces may be injurious to the
health due to exposeure to dust.
2.5 Personal protective equipment
The user and any other persons in the vicinity must
wear suitable eye protection, a hard hat, ear protection
and protective gloves when the tool is in use. Breath-
ing protection must be worn if no dust removal sys-
tem is used.
Wear ear
protection
Wear
protective
gloves
Wear
breathing
protection
Wear eye
protection
Wear a
hard hat
Before use
It is essential that the safety precautions print-
ed in these operating instructions are read and observed.
Fitting the side handle
1.Unplug the tool from the mains socket.
2. Release the side handle clamping band by turning
the handle in a counter-clockwise direction.
3. Fit the side handle clamping band over the chuck
and onto the cylindrical section at the front end of
the tool.
4. Pivot the side handle into the desired position.
5. Tighten the side handle securely to prevent inad-
vertent movement.
Check that the side handle is seated securely.
The supply voltage must correspond to the infor-
mation on the type plate.
If extension cords are used: Only extension cords
of a type approved for the intended use and of adequate
cross section may be used. Failure to observe this point
may result in reduced performance of the tool and over-
heating of the cord. Damaged extension cords must be
replaced.
Use only insert tools with TE-C connection end.
Don’t exert excessive pressure on the tool. This will not
increase its hammering power.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 15

16
en
At low temperatures: The tool requires to reach a mini-
mum operating temperature before the hammering mech-
anism begins to operate. Switch on the tool and position
the tip of the drill bit on the work surface. While the tool
is running, apply light pressure briefly and repeatedly
until the hammering mechanism begins to operate.
Operation
CAUTION: In the event of the drill bit sticking, the tool
will pivot about its own axis.
Always use the tool with the side handle fitted and hold
it securely with both hands applying an opposing torque
so that the clutch releases in the event of the drill bit
sticking.
Use a vice or clamp to secure loose workpieces.
Fitting the insert tool 
1. Unplug the supply cord from the mains socket.
2. Check that the connection end of the insert tool is
clean and lightly greased. Clean it and grease it if nec-
essary.
3. Check that the sealing lip of the dust shield is clean
and in good condition. Clean the dust shield if nec-
essary or replace it if the sealing lip is damaged.
4. Push the connection end of the insert tool into the
chuck and, while applying slight pressure, rotate the
insert tool until it engages in the guide grooves.
5. Push the insert tool further into the chuck until it is
heard to engage.
6. Check that the insert tool has engaged correctly (pull
by hand).
Removing the insert tool
-CAUTION-
– The insert tool may become hot during use. There is
a risk of burning the hands. Wear protective gloves
when changing insert tools.
1. Unplug the supply cord from the mains socket.
2. Open the chuck by pulling back the locking sleeve.
3. Pull the insert tool out of the chuck.
Drilling
Hammer drilling (TE 2 / TE 2-E / TE 2-S / TE 2-M) /
precision hammering action (TE 2-S)
1. Insert the drill bit into the chuck.
5b
5a
2. Turn the function selection switch to the hammer
drilling position ( ) until the gearing is engaged
. Rotate the chuck spindle slightly if necessary.
Check that forwards rotation is selected (I.).
3. Use of the precision hammering action ( ) is advan-
tageous when drilling in brittle materials (e.g. tiles,
marble, perforated brick). This will improve the qual-
ity of the holes drilled .
4. Connect the supply cord to the power supply.
5. Pivot the side handle, with or without the depth gauge,
to the desired angle and tighten the handle to lock it
in this position. Check that the side handle is seated
and attached securely .
6. Bring the tip of the drill bit into contact with the work
surface at the position where the hole is to be drilled
and press the control switch slowly. Drill at low speed
until the drill bit centres itself in the hole.
7. Press the control switch fully and continue drilling at
full power.
Rotary-only drilling (without hammering action)
(TE 2 / TE 2-E / TE 2-S)
Turn the function selection switch to the drilling posi-
tion ( ) . When the switch is in this position, only the
rotary movement is transmitted to the TE-C insert tool
or chuck adaptor for insert tools with cylindrical shanks.
Rotary-only drilling (without hammering action)
(TE 2-M)
Turn the function selection switch to the 1st gear or 2nd
gear drilling position . When the switch is in these
positions, only the rotary movement is transmitted to
the TE-C insert tool or quick-release chuck.
Use of a high spindle speed can be advantageous when
drilling in metal or wood. For higher drilling speed, the
function selection switch must be engaged in the 2nd
gear position ( 2) .
Changing the chuck (TE 2-M)
Pull the chuck release ring towards the front and remove
the chuck completely. When fitting the chuck, pull the
release ring towards the front and hold it in this posi-
tion. Push the chuck onto the guide tube as far as it will
go and release the ring. Rotage the chuck until it engages
and the ring snaps back into its original position . The
TE-C interchangeable chuck or quick-release inter-
changeable chuck may be fitted to the TE 2-M with chuck
interface .
Drilling using the depth gauge
We recommend the use of the depth gauge for drilling
holes accurately to the desired depth. The depth gauge
is integrated in the side handle, which can be pivoted
and locked in position. Release the side handle (turn
counter-clockwise), set the depth gauge to the desired
drilling depth and tighten the side handle (turn clock-
wise) .
7d
7d7b
7b
7c
7a
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 16

17
en
Care and maintenance
Care of the tool
The outer casing of the tool is made from impact-resis-
tant plastic. Grip sections, the dust shield and the sup-
ply cord protective sleeve are made from an elastomer
material.
Clean the outside of the tool at regular inter-
vals using a slightly damp cloth. Don’t use a spray, steam
pressure cleaning equipment or running water for clean-
ing. This may negatively affect the electrical safety of the
tool. Always keep the grip surfaces of the tool free from
oil and grease. Don’t use cleaning agents which contain
silicone.
Never operate the tool when the ventilation slots
are blocked. Clean the ventilation slots carefully using
a dry brush. Don’t permit foreign objects to enter the
interior of the tool.
Clean the dust shield on the chuck at regular intervals
using a clean, dry cloth. Carefully wipe the sealing lip
and grease it with a little Hilti grease. It is essential that
the dust shield is replaced when the sealing lip is dam-
aged. Proceed as follows: Insert a screwdriver at the
edge of the dust shield and lift it out in a forwards direc-
tion. Clean the contact surface and insert a new dust
shield. Press it in firmly until it engages.
Also take care of your insert tools. Clean off dirt and dust
deposits and protect your insert tools from corrosion
by wiping them from time to time with an oil-soaked rag.
Always keep the connection end clean and lightly greased.
Maintenance
Regularly check all external parts of the tool for
damage and to ensure that all controls operate fault-
lessly. Don’t operate the tool when parts are damaged
or when the controls do not function faultlessly. Have
your electric tool repaired by a Hilti service center.
Forwards / reverse rotation
(TE 2 / TE 2-S / TE 2-M)
For screwdriving, the desired direction of rotation can
be selected simply by moving the switch .
For forwards rotation, select position ( ) and for rever-
se rotation, select position ( ).
When the tool is operated in reverse rotation, the func-
tion selection switch should be engaged in the posi-
tion for drilling without hammering action ( / 1st gear).
For drilling, always ensure that forwards rotation
( ) is selected.
Insert tools and accessories
Use only insert tools with TE-C connection end or straight
shank bits with quick release chuck or adaptor .
Hilti power tools have been designed to work opti-
mally as a system together with Hilti insert tools.
Accordingly, highest performance and longest life
expectancy can be achieved when you use this pow-
er tool with Hilti insert tools. A comprehensive pro-
gramme of insert tools and accessories is available for
the TE-C system . Details of the entire programme
can be found in the current Hilti product catalogue.
Should you require insert tools not included in the stan-
dard programme, please contact the Hilti customer ser-
vice department or your Hilti sales representative. Hilti
offers a comprehensive range of special insert tools in
professional quality.
Check your insert tools at regular intervals and
replace them in good time. A damaged or badly worn
connection end may result in damage to the power tool.
Drill bits with chipped or broken carbide tips may no
longer drill holes of the specified diameter, thus influ-
encing their suitability for anchor fastenings.
Please observe the instructions on care and mainte-
nance of your insert tools given in the following section.
Dust removal (TE DRS-S) 
A DRS extraction head can be attached to the side han-
dle / depth gauge. An industrial vacuum cleaner is used
to remove drilling dust and fragments.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 17

18
en
Manufacturer's warranty – tools
Hilti warrants that the tool supplied is free of defects
in material and workmanship. This warranty is valid so
long as the tool is operated and handled correctly,
cleaned and serviced properly and in accordance with
the Hilti Operating Instructions, and the technical sys-
tem is maintained. This means that only original Hilti
consumables, components and spare parts may be
used in the tool.
This warranty provides the free-of-charge repair or
replacement of defective parts only over the entire lifes-
pan of the tool. Parts requiring repair or replacement
as a result of normal wear and tear are not covered by
this warranty.
Additional claims are excluded, unless stringent
national rules prohibit such exclusion. In particular,
Disposal
Return waste material for recycling
Most of the materials from which Hilti power tools are manufactured can be recycled. The materials must be cor-
rectly separated before they can be recycled. In many countries, Hilti has already made arrangements for taking
back your old electric tools for recycling. Please ask your Hilti customer service department or Hilti sales repre-
sentative for further information.
Only for EU countries
Disposal of electric tools together with household waste is not permissible!
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment and
its implementation in accordance with national law, electric tools that have reached the end of their
life must be collected separately and returned to an environmentally compatible recycling facility.
Hilti is not obligated for direct, indirect, incidental
or consequential damages, losses or expenses in
connection with, or by reason of, the use of, or inabil-
ity to use the tool for any purpose. Implied warranties
of merchantability or fitness for a particular purpose
are specifically excluded.
For repair or replacement, send tool or related parts
immediately upon discovery of the defect to the address
of the local Hilti marketing organization provided.
This constitutes Hilti's entire obligation with regard to
warranty and supersedes all prior or contemporane-
ous comments and oral or written agreements con-
cerning warranties.
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 18

19
en
Troubleshooting
Symptom Possible cause Possible solution
The tool doesn’t start Fault in the electric power supply Plug in another electric tool and check
whether it starts
Defective supply cord or plug Have it checked by an electrical
specialist and replace if necessary
Switch defective Have it checked by an electrical
specialist and replace if necessary
No hammering action The tool is too cold Allow tool to reach the minimum
operating temperature
See section “Before use”
Function selection switch Set function selection switch to
set to rotary drilling hammer drilling
Tool doesn’t produce full Cross-section of the Use an extension cord of adequate cross-
power extension cord is inadequate sectional area. See section “Before use”
Control switch is not pressed fully Press the control switch as far as it will go
Function selection switch set Set function selection switch
to precision hammering action to hammer drilling
Forwards / reverse switch set Set forwards / reverse switch
to reserve when drilling to forwards
Drill bit cannot be released Chuck not opened fully Pull the chuck locking sleeve back as
far as it will go and remove the insert
tool
EC declaration of conformity
Description: Rotary Hammer
Designation: TE2 / TE 2-E / TE2-S / TE2-M
Year of design: 2005
We declare, under our sole responsibility, that this product
complies with the following directives and standards:
89/336/EWG, 98/37/EG, EN 55014-1, EN 55014-2,
EN 60745-1, EN 60745-2-6, EN 61000-3-2, EN 61000-3-3
Hilti Corporation
Peter Cavada Matthias Gillner
Head of BU Head of BA
Quality and Process Management Electric Tools & Accessories
BA Electric Tools & Accessories
11/2006 11/2006
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 19

20
02_BA_TE2_S_M_P1_en.qxd 31.08.2007 10:39 Uhr Seite 20
