ORIGINAL OPERATING INSTRUCTIONS
SCM 22-A cordless circular saw
It is essential that the operating instructions
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1 General information 1
2Description 2
3 Insert tools, accessories 3
4 Technical data 4
5 Safety instructions 5
6Beforeuse 8
7 Operation 9
8 Care and maintenance 11
9 Troubleshooting 12
10 Disposal 12
11 Manufacturer’s warranty - tools 13
12 EC declaration of conformity (original) 13
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation “the
power tool” always refers to the SCM 22-A cordless
circular saw.
Operating controls and indicators 1
@Battery
;Release buttons with additional function (charge
status display activation)
=Charge status and fault display (lithium-ion battery)
%On / off switch
&Switch-on interlock
(Auxiliary grip
)Drive spindle lockbutton
+Hexagon socket wrench
§Clamping lever for cutting depth adjustment
/Parallel guide (rip fence)
:Pivoting guard
·Base plate
$Guard
£Drive spindle
|Mounting flange
¡Clamping flange
QClamping screw
WPivoting guard operating lever
EChip collector
RLED / viewing window
TParallel guide (rip fence) clamp
ZSaw blade position indicator
UCutting line indicator
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
seriousbodilyinjuryorfatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning Warning: electricity Warning: caustic
substances
Warning: hot
surface
en
1
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

Obligation signs
Wear eye
protection Wear a hard hat Wear ear protection Wear protective
gloves
Wear
breathing
protection
Symbols
Read the
operating
instructions
before use
Return waste
material for
recycling.
Volts Direct
current
Rated speed
under no
load
Revolutions
per minute Diameter Saw blade
Location of identification data on the power tool
The type designation and serial number can be found
on the type identification plate on the machine or tool.
Makeanoteofthisdatainyouroperatinginstructions
and always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
Generation: 01
Serial no.:
2 Description
2.1 Use of the product as directed
The power tool is a hand-held, cordless circular saw.
The tool is designed for cutting metals or metal-like materials up to a cutting depth of 57 mm.
Working on materials hazardous to the health (e.g. asbestos) is not permissible.
The power tool is designed for professional use and may be operated, serviced and maintained only by trained,
authorized personnel. This personnel must be informed of any special hazards that may be encountered. The power
tool and its ancillary equipment may present hazards when used incorrectlybyuntrainedpersonnelorwhenusednot
as directed.
The working environment may be as follows: construction site, workshop, renovation, conversion or new construction.
Modification of the power tool or tampering with its parts is not permissible.
The use of saw blades not in compliance with the given specification (e.g. diameter, speed of rotation, thickness) or
the use of cutting and grinding discs or blades made from high-alloy steel (HSS steel) is not permissible.
Do not use the saw to cut wood or wood-like materials, plastics, gypsum board, gypsum fiberboard and composite
materials.
Do not use the battery as a power source for other unspecified appliances.
To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
2.2 Switch
On / off switch with switch-on interlock
en
2
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

2.3 Grips
Grip and auxiliary grip
2.4 Safety precautions
Blade guard and pivoting guard
2.5 Lubrication
Grease lubrication
2.6 Protection against overload and overheating
The power tool is equipped with an electronic protection system to prevent overloading and overheating. The power
tool switches itself off automatically in the event of overloading and overheating. After releasing the on / off switch,
the power tool may not restart immediately when the switch is pressed again (while the power tool is cooling down).
2.7 Lithium‑ion battery charge status
Whenalithium-ionbatteryisused,thechargestatuscanbeindicatedbygently pressing one of the battery release
buttons (press until resistance is felt - do not release the battery). The display on the rear of the battery provides the
following information:
LEDs light constantly LEDs blink Charge status C
LED1,2,3,4 -C≧75%
LED1,2,3 -50 % ≦ C < 75 %
LED 1, 2 -25 % ≦ C < 50 %
LED 1 -10 % ≦ C < 25 %
-LED 1 C<10%
2.8 Items supplied as standard
1 Power tool
1Sawblade
1 Hexagon socket wrench
1 Operating instructions
1 Hilti toolbox (optional)
1 Cardboard box (optional)
1Ripfence
2.9 Additional items required for operating the tool
B22/2.6 or B22/3.3 Li‑ion battery and C4/36, C4/36‑ACS, C4/36‑90 or C4/36‑350 charger.
NOTE
Depending on the version, these items may be supplied with the power tool.
3 Insert tools, accessories
Accessories for the SCM 22‑A
Designation Short designation
Charger for Li-ion batteries C 4/36
Charger for Li-ion batteries C4/36-ACS
Charger for Li-ion batteries C 4/36‑90
Charger for Li-ion batteries C 4/36‑350
Battery B 22/2.6 Li‑Ion
en
3
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

Designation Short designation
Battery B 22/3.3 Li‑Ion
Rip fence
Recommended saw blade
Designation Short designation
Saw blade SC-C MU 165x20 z40 A
4 Technical data
Right of technical changes reserved.
Power tool SCM 22‑A
Rated voltage (DC voltage) 21.6 V
Weight in accordance with EPTA procedure 01/2003 4.0 kg
Dimensions (L x W x H) 370 mm x 206 mm x 242 mm
Base plate dimensions 248 mm x 127 mm
Specified blade diameter 160…165 mm
Saw blade disc thickness 1.2 mm
Kerf width 1.6 mm
Saw blade arbor size 20 mm
Cutting depth 57 mm
Speed under no load 3,500/min
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a standardized test
giveninEN60745andmaybeusedtocompareonetoolwithanother.Itmaybeused for a preliminary assessment
of exposure. The declared vibration emission level represents the main applications of the tool. However if the tool is
used for different applications, with different accessories or is poorly maintained, the vibration emission may differ.
This may significantly increase the exposure level over the total working period. An estimation of the level of exposure
to vibration should also take into account the times when the tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure level over the total working period. Identify additional safety
measures to protect the operator from the effects of vibration such as: maintaining the tool and the accessories,
keeping hands warm, organization of work patterns.
Noise and vibration information for the SCM 22-A (measured in accordance with EN 60745-2-5):
Depending on how the saw is used, the values may increase.
Typical A-weighted sound power level 88 dB (A)
Typical A-weighted emission sound pressure level 77 dB (A)
Uncertainty for the given sound level 3 dB (A)
Triaxial vibration values (vibration vector sum)
Sawing metal, ah1.2 m/s²
Uncertainty (K) 1.5 m/s²
Battery B 22/3.3 Li‑Ion B 22/2.6 Li‑Ion
Rated voltage 21.6 V 21.6 V
Capacity 3.3 Ah 2.6 Ah
Energy capacity 71.28 Wh 56.16 Wh
en
4
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

Battery B 22/3.3 Li‑Ion B 22/2.6 Li‑Ion
Weight 0.78 kg 0.78 kg
Type of cell Li‑Ion Li‑Ion
No. of cells 12 12
Deep discharge protection Yes Yes
5 Safety instructions
NOTE
The safety rules in section 5.1 contain all general safety
rules for power tools which, in accordance with the
applicable standards, must be listed in the operating
instructions. Accordingly, some of the rules listed may
not be relevant to this tool.
5.1 General power tool safety warnings
a) WARNING
Read all safety warnings and all instructions. Fail-
ure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury. Save all
warnings and instructions for future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
5.1.1Workareasafety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
5.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any ad-
apter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
theriskofelectricshock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
5.1.3 Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off‐position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before turn-
ing the power tool on. A wrench or a key left at-
tached to a rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
5.1.4 Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
en
5
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for opera-
tions different from those intended could result in a
hazardous situation.
5.1.5 Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
dentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejec-
ted from the battery may cause irritation or burns.
5.1.6 Service
a) Have your power tool servicedby a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
5.2 Safety instructions for all saws
5.2.1 Cutting procedures
a) DANGER
Keep hands away from cutting area and the blade.
Keep your second hand on auxiliary handle, or
motor housing. If both hands are holding the saw,
they cannot be cut by the blade.
b) Do not reach underneath the workpiece. The guard
cannot protect you from the blade below the work-
piece.
c) Adjust the cutting depth to the thickness of the
workpiece. Less than a full tooth of the blade teeth
should be visible below the workpiece.
d) Never hold piece being cut in your hands or across
your leg. Secure the workpiece to a stable plat-
form. It is important to support the work properly to
minimize body exposure, blade binding, or loss of
control.
e) Hold the power tool by insulated gripping surfaces
only, when performing an operation where the
cutting tool may contact hidden wiring. Contact
with a “live” wire will also make exposed metal parts
of the power tool “live” and could give the operator
an electric shock.
f) When ripping always use a rip fence or straight
edge guide. This improves the accuracy of cut and
reduces the chance of blade binding.
g) Always use blades with correct size and shape
(diamond versus round) of arbour holes. Blades
that do not match the mounting hardware of the saw
will run eccentrically, causing loss of control.
h) Never use damaged or incorrect blade washers
or bolt. The blade washers and bolt were specially
designed for your saw, for optimum performance and
safety of operation.
5.2.2 Further safety instructions for all saws
Kickback causes and related warnings
kickback is a sudden reaction to a pinched, bound or
misaligned saw blade, causing an uncontrolled saw to lift
up and out of the workpiece toward the operator;
when the blade is pinched or bound tightly by the kerf
closing down, the blade stalls and the motor reaction
drives the unit rapidly back toward the operator;
if the blade becomes twisted or misaligned in the cut, the
teeth at the back edge of the blade can dig into the top
surface of the wood causing the blade to climb out of the
kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided
by taking proper precautions as given below.
a) Maintain a firm grip with both hands on the saw
and position your arms to resist kickback forces.
Position your body to either side of the blade, but
not in line with the blade. Kickback could cause the
saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are
taken.
b) When blade is binding, or when interrupting a
cut for any reason, release the trigger and hold
the saw motionless in the material until the blade
comes to a complete stop. Never attempt to re-
move the saw from the work or pull the saw back-
ward while the blade is in motion or kickback
en
6
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

may occur. Investigate and take corrective actions
to eliminate the cause of blade binding.
c) When restarting a saw in the workpiece, centre
the saw blade in the kerf and check that saw
teeth are not engaged into the material. If saw
blade is binding, it may walk up or kickback from the
workpiece as the saw is restarted.
d) Support large panels to minimise the risk of blade
pinching and kickback. Large panels tend to sag
under their own weight. Supports must be placed
under the panel on both sides, near the line of cut
and near the edge of the panel.
e) Do not use dull or damaged blades. Unsharpened
or improperly set blades produce narrow kerf causing
excessive friction, blade binding and kickback.
f) Blade depth and bevel adjusting locking levers
must be tight and secure before making cut. If
blade adjustment shifts while cutting, it may cause
binding and kickback.
g) Use extra caution when sawing into existing walls
or other blind areas. The protruding blade may cut
objects that can cause kickback.
5.2.3 Safety instructions for circular saws with
outer pendulum guard
Lower guard function
a) Check lower guard for proper closing before each
use. Do not operate the saw if lower guard does
not move freely and close instantly. Never clamp
or tie the lower guard into the open position. If saw
is accidentally dropped, lower guard may be bent.
Raise the lower guard with the retracting handle and
make sure it moves freely and does not touch the
blade or any other part, in all angles and depths of
cut.
b) Check the operation of the lower guard spring.
If the guard and the spring are not operating
properly, they must be serviced before use. Lower
guard may operate sluggishly due to damaged parts,
gummy deposits, or a build-up of debris.
c) Lower guard may be retracted manually only for
special cuts such as “plunge cuts” and “com-
pound cuts.” Raise lower guard by retracting
handle and as soon as blade enters the mater-
ial, the lower guard must be released. For all other
sawing, the lower guard should operate automatic-
ally.
d) Always observe that the lower guard is covering
the blade before placing saw down on bench or
floor. An unprotected, coasting blade will cause the
saw to walk backwards, cutting whatever is in its
path.Beawareofthetimeittakesforthebladeto
stop after switch is released.
5.3 Additional safety instructions
5.3.1 Personal safety
a) Wear ear protectors. Exposure to noise can cause
hearing loss.
b) Always hold the power tool securely with both
hands on the grips provided. Keep the grips dry,
clean and free from oil and grease.
c) Breathing protection must be worn if the power
tool is used without a dust removal system for
work that creates dust.
d) Do not operate the power tool without the pro-
tective devices that belong to it.
e) Operate the powertool only as intended and when
it is in faultless condition.
f) Improve the blood circulation in your fingers by
relaxing your hands and exercising your fingers
during breaks between working.
g) Switch the power tool on only after bringing it into
position at the workpiece.
h) Remove the battery before storing or transporting
the power tool.
i) Always guide the power tool away from your body
when working with it.
j) Do not work with the power tool overhead.
k) Do not attempt to brake the speed of the saw
bladebypressingittotheside.
l) Do not touch the clamping flange or the clamping
screw while the power tool is running.
m) Never press the drive spindle lock button while
the saw blade is rotating.
n) Never direct the power tool toward persons.
o) Adjust the pressure applied to the saw blade and
the material being cut so that the blade does not
stall, possibly causing the power tool to kick back.
p) Avoid overheating the tips of the saw blade teeth.
q) Metal cuttings are sharp and present a risk of injury.
Keep your clothing closed so that metal cuttings
cannot find their way into your gloves, shoes or
other parts of your clothing.
r) Pay attention to the direction in which the metal chips
fly when sawing. Thechipsarehotandmaycause
fires or lead to burning and cutting injuries.
s) Children must be instructed not to play with the
power tool.
t) The power tool is not intended for use by children,
by debilitated persons or those who have received
no instruction or training.
u) Dust from materials such as paint or coatings
containing lead, mineral materials and metals may
present a health hazard. Contact with or inhalation
of the dust may cause allergic reactions and/or
respiratory diseases among operators or bystanders.
Certain dusts are considered to be carcinogenic
(cancer-causing), especially in conjunction with
other substances (chromate). Material containing
asbestosmaybeworkedononlybyspecialists.
Ensure that the workplace is well ventilated.
The use of a dust mask of filter class P2 is
recommended. Follow national requirements for
the materials you want to work with.
en
7
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

5.3.2 Power tool use and care
a) Secure the workpiece. Use clamps or a vice to
secure the workpiece. The workpiece is thus held
more securely than by hand and both hands remain
free to operate the power tool.
b) Check that the insert tools used are compatible
with the chuck system and that they are secured
in the chuck correctly.
c) Take care to ensure that metal cuttings do not
find their way into the tool or battery.
d) Empty the chip collector and clean the power
tool before putting it away in the toolbox or other
container for storage or transport. Metal chips may
otherwise fall out of the collector and find their way
into the power tool, battery or charger, presenting a
risk of damage or malfunction.
5.3.3 Electrical safety
Before beginning work, check the working area (e.g.
using a metal detector) to ensure that no concealed
electric cables or gas and water pipes are present.
External metal parts of the power tool may become
live, for example, when an electric cable is damaged
accidentally. This presents a serious risk of electric shock.
5.3.4 Battery use and care
a) Observe the special instructions applicable to the
transport, storage and use of Li-ion batteries.
b) Do not expose batteries to high temperatures or
fire. This presents a risk of explosion.
c) Do not disassemble, squash or incinerate batter-
ies and do not subject them to temperatures over
80°C. This presents a risk of fire, explosion or injury
through contact with caustic substances.
d) Use only batteries that are approved for use with
the applicable tool or appliance. Use of unap-
proved batteries or use of the batteries for areas of
application for which they are not approved presents
a risk of fire and explosion.
e) Do not charge or continue to use damaged bat-
teries (e.g. batteries with cracks, broken parts,
bent or pushed-in and/or pulled-out contacts).
f) If the battery gets too hot to touch, this may indicate
that it is faulty. Place the tool in a location where
it can be kept under observation, well away from
flammable materials, and allow it to cool down.
Contact Hilti Service after the battery has been
allowedtocool.
5.3.5 Work area
a) Ensure that the workplace is well lit.
b) Ensure that the workplace is well ventilated. Ex-
posure to dust at a poorly ventilated workplace may
result in damage to the health.
5.3.6 Personal protective equipment
The user and any other persons in the vicinity must
wear suitable eye protection, a hard hat, ear protec-
tion, protective gloves and breathing protection while
the tool is in use.
5.3.7 Safety precautions
Do not switch the power tool on if the saw blade,
the blade guard or the pivoting guard are not fitted
correctly.
6Beforeuse
6.1 Battery use and care
NOTE
Battery performance drops at low temperatures. Never
use the battery until the cells become fully discharged.
Change to the second battery as soon as a drop in per-
formance is noticed. Recharge the battery immediately
so that it is ready for reuse.
Store the battery in a cool, dry place. Never store the
battery where it is exposed to the heat of the sun, on a
radiator or behind glass, e.g. at a window. Batteries that
have reached the end of their life must be disposed of
safely and correctly to avoid environmental pollution.
Insert the battery in the corresponding charger.
6.2 Charging the battery
DANGER
Use exclusively the specified Hilti batteries and Hilti
battery chargers listed under “Accessories”.
en
8
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

DANGER
Ensure that the outer surfaces of the battery are clean
and dry before inserting it in the corresponding char-
ger. Read the operating instructions for the charger
for further information about the charging procedure.
6.2.1 Charging a new battery for the first time
Charge the battery fully before using it for the first time.
6.2.2 Charging a previously used battery
Ensure that the outer surfaces of the battery are clean
and dry before inserting it in the corresponding charger.
Read the operating instructions for the charger for further
information about the charging procedure.
Lithium-ion battery packs are ready to use at any time,
even when only partially charged. Charging progress
is indicated by the LED display (see charger operating
instructions).
6.3 Fitting the battery
CAUTION
Before fitting the battery, check that the power tool is
switched off and the switch-on interlock is activated
(not pressed). Use only the Hilti batteries approved
for use with this power tool.
CAUTION
Before inserting the battery in the tool, check to ensure
that the battery terminals and the contacts in the tool are
free from foreign objects.
1. Push the battery into the power tool from the rear as
far as it will go and until it is heard to engage with a
double click.
2. CAUTION A falling battery may present a risk of
injury to yourself and others.
Check that the battery is seated securely in the
power tool.
6.4 Removing the battery from the power tool
1. Press both release buttons and hold them in this
position.
2. Pull the battery out of the power tool toward the
rear.
6.5 Transport and storage of batteries
CAUTION
Empty the chip collector and clean the power tool
before putting it away in the toolbox or other container
for storage or transport. Metal chips may otherwise fall
out of the collector and find their way into the power
tool, battery or charger, presenting a risk of damage or
malfunction.
Pull the battery out of the locked position (working pos-
ition) and move it into the first click-stop position (trans-
port position).
If you disconnect a battery from the power tool for trans-
port or storage, make sure that the battery contacts are
not short-circuited. Remove loose metal items such as
screws, nails, clamps, loose screwdriving bits, wires or
metal cuttings and chips from the toolbox or transport
container, or prevent these items from coming into con-
tact with the battery.
Observe national and international transport regulations
when shipping batteries (transportation by road, rail, sea
or air).
7Operation
NOTE
If the blade has jammed, the tool will not restart by itself
after pressure on it has been released. The switch-on
interlock and the on/off button must be pressed again to
restart.
NOTE
The chip collector must always be fitted when the tool is
in use.
CAUTION
Wear protective gloves. The cutting edges of the saw
blade and cut edges of the workpiece are sharp. These
sharp edges present a risk of injury.
CAUTION
Wear protective glasses and a dust mask. The sawing
operation swirls up dust and chips into the air. The dust
and chips may be harmful to the eyes and respiratory
system.
CAUTION
Wear ear protectors. The power tool and the sawing
operation generate noise. Exposure to noise can cause
loss of hearing.
CAUTION
Secure the workpiece. Use clamps or a vice to secure
the workpiece. This will help to prevent vibration.
en
9
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

CAUTION
Do not saw off very narrow strips. Narrow strips may
be caught by the blade and pulled in, causing jamming,
or may be thrown out, presenting a risk of injury.
CAUTION
When sawing, take care to ensure that there are no
flammable materials in the vicinity and that no hot
metal cuttings fall onto highly flammable materials.
CAUTION
Do not use coolants or lubricants when sawing.
7.1 Changing the saw blade
CAUTION
Wear protective gloves when changing insert tools.
The tool, the clamping flange and the clamping screw get
hot.
CAUTION
Checkthatthebladetobefittedcomplieswiththe
technical requirements and that it is well sharpened. A
sharp saw blade is an essential requirement for a perfect
cut.
7.1.1 Removing the saw blade 2
1. Pull the battery out of the power tool.
2. Press the drive spindle lockbutton and hold it in this
position.
3. Turn the saw blade clamping screw with the hex.
socket wrench until the locking pin engages fully.
4. Release the clamping screw by turning the wrench
further clockwise.
5. Remove theclamping screw from the outer clamping
flange.
6. Open the pivoting guard by swinging it to the side
and then remove the saw blade.
7.1.2 Fitting the saw blade 3
1. Pull the battery out of the power tool.
2. Clean the mounting flange and the clamping flange.
3. Fit the mounting flange.
4. Open the pivoting guard.
5. CAUTION Only use blades which are suitable for
this saw. Observe the direction-of-rotation arrow
on the saw blade.
Fit the new saw blade.
6. Fit the outer clamping flange.
7. Press the drive spindle lockbutton.
8. Fasten the clamping flange with the clamping screw
by turning it anti-clockwise.
9. Before using the power tool, check that the saw
blade is securely attached.
7.2 Adjusting the cutting depth 4
The cutting depth can be infinitely adjusted between 0
and 57 mm.
1. Pull the battery out of the power tool.
2. Place the power tool on a supporting surface.
3. Release the cutting depth adjustment clamping
lever.
4. Lift the power tool in a scissor movement and set
the desired cutting depth by closing the clamping
lever.
7.3 Sawing along a line
The position of the saw blade is indicated by the mark
on the base plate. This allows accurate cuts to be made.
Theedgeofthelineindicatorcorrespondstotheinside
of the saw blade. The viewing window provides a better
view of the cutting line and thus helps ensure a more
accurate cut.
1. Secure the workpiece to prevent movement.
2. Position the workpiece so that the saw blade is free
to rotate beneath it.
3. Check to ensure that the on / off switch on the
power tool is in the “off” position.
4. Fit the battery into the power tool.
5. Position the forward section of the saw’s base plate
on the workpiece but do not bring the blade into
contact with the workpiece.
6. If the switch-on interlock has been pressed, switch
the power tool on by pressing the on/off button.
7. Guide the saw along the cutting line on the work-
piece at a suitable speed.
7.4 Sawing using the rip fence (accessory)
Use of the single arm rip fence allows precise cuts to be
made along the edge of the workpiece, or strips of even
width to be cut.
The rip fence can be fitted on either side of the base
plate.
7.5 Fitting / adjusting the parallel guide (rip
fence) 5
1. Remove the battery from the power tool.
2. Press the clamp together.
3. Push the parallel guide (rip fence) into the base plate
as far as you wish.
4. Release the clamp when the parallel guide is in the
desired position.
7.6 Emptying the chip collector 6
CAUTION
Wear protective gloves when emptying the chip col-
lector. The metal chips are sharp-edged and may be
hot.
en
10
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

CAUTION
Empty the chip collector and clean the power tool
before putting it away in the toolbox or other container
for storage or transport. Metal chips may otherwise fall
out of the collector and find their way into the power
tool, battery or charger, presenting a risk of damage or
malfunction.
When the power tool is in use you can check with the aid
of the viewing window whether the collector is full.
1. Remove the battery from the tool.
2. Pull the chip collector away from the tool to the rear.
3. Swing the two halves of the chip collector apart and
empty out its contents.
4. Push the chip collector onto the guard until in en-
gages in position.
7.7 Procedure if the chip / dust channel is blocked
1. Remove the battery from the tool.
2. Remove the chip collector.
3. Clean the chip / dust channel.
4. Check that moving parts on the power tool are work-
ing properly and not jamming. Check also whether
parts are broken or damaged in such a way that
may cause the power tool to malfunction.
8 Care and maintenance
CAUTION
Before beginning cleaning, remove the battery from
the power tool in order to prevent unintentional start-
ing.
8.1Careofinserttools
Clean off dirt and dust deposits adhering to the insert
tools and protect them from corrosion by wiping the
insert tools from time to time with an oil-soaked rag.
8.2 Care of the power tool
CAUTION
Keep the power tool, especially its grip surfaces,
clean and free from oil and grease. Do not use clean-
ing agents which contain silicone.
The outer casing of the power tool is made from impact-
resistant plastic. Sections of the grip are made from a
synthetic rubber material.
Never operate the power tool when the ventilation slots
are blocked. Clean the ventilation slots carefully using
a dry brush. Do not permit foreign objects to enter the
interior of the power tool. Clean the outside of the power
tool at regular intervals with a slightly damp cloth. Do
not use a spray, steam pressure cleaning equipment or
running water for cleaning. This may negatively affect the
electrical safety of the power tool.
8.3 Care of the Li-ion battery
Avoid ingress of moisture.
Charge the battery fully before using it for the first time.
In order to achieve maximum battery life, stop dischar-
ging the battery as soon as a significant drop in battery
performance is noticed.
NOTE
If use continues, further battery discharge will be stopped
automatically before the battery cells suffer damage.
Charge the battery using an approved charger from Hilti
designed for use with Li-ion batteries.
NOTE
- A conditioning charge (as is required with NiCd or
NiMH batteries) is not necessary.
- Interruption of the charging procedure has no negative
effect on battery life.
- Charging can be started at any time with no negative
effect on battery life. There is no memory effect (as
with NiCd or NiMH batteries).
- For best results, batteries should be stored fully
charged in a cool dry place. Storing the battery in
places subject to high ambient temperatures (e.g. at
a window) has an adverse effect on battery life and
increases the rate of self-discharge.
- If the battery no longer reaches full charge, it may
have lost capacity due to aging or overstressing. It
is still possible to work with this battery. You should,
however, soon replace the battery with a new one.
8.4 Cleaning the safety devices
1. Remove the saw blade before cleaning the safety
devices.
2. Clean the safety devices carefully with a dry brush.
3. Useasuitabletooltoremovedepositsorwood
chips from the inside surfaces of the safety devices.
4. Fit the saw blade.
8.5 Maintenance
WARNING
Repairs to the electrical section of the power tool may
be carried out only by trained electrical specialists.
Check all external parts of the power tool for damage
at regular intervals and check that all controls operate
faultlessly. Do not operate the power tool if parts are
damaged or when the controls do not function faultlessly.
Have the power tool repaired by Hilti Service.
8.6 Checking the power tool after care and
maintenance
After carrying out care and maintenance work on the
power tool, check that all protective and safety devices
are fitted and that they function faultlessly.
To check the pivoting guard, open the guard fully by
moving the guard operating lever.
en
11
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

The pivoting guard must close quickly and completely
when the guard operating lever is released.
9 Troubleshooting
Fault Possible cause Remedy
The power tool does not run. The battery is discharged or fitted
incorrectly. The battery must be heard to engage with a double click or, respectively,
needs to be charged.
Electrical fault. Remove the battery from the power
tool and contact Hilti Service.
The battery is discharged/hot. Deep discharge prevention / the elec-
tronics switch off. Insert the battery in
the charger or allow it to cool down.
The on / off button can not
be pressed, i.e. the button is
locked.
Not a fault (safety function). Press the switch-on interlock.
Running speed suddenly drops
considerably. The saw blade jams. Keep the saw blade running straight.
Chips are not transported into
the chip collector and thus fall
onto the base plate.
The chip collector is full or the chip
deflector is blocked. Empty the chip collector and/or clean the chip ejector channel.
The saw blade stalls. Saw advance pressure is too high. Reduce advance pressure and restart
the saw.
The tool doesn’t work and all 4
LEDs blink. The power tool has been overloaded. Release the control switch and press it again.
The overheating prevention cut-out
has been activated. Allow the power tool to cool down.
Clean the ventilation slots.
The power tool doesn’t run and
1LEDblinks. The battery is discharged. Change the battery and recharge the discharged battery.
The battery is too hot or too cold. Bring the battery to the recommen-
ded working temperature.
The battery runs down more
quickly than usual. Battery condition is not optimal. Have battery condition diagnosed by Hilti Service or replace with a new
battery.
The battery does not engage
with an audible double click. The retaining lugs on the battery are dirty. Clean the retaining lugs and check that the battery engages securely.
Contact Hilti Service if the problem
persists.
The power tool or the battery
becomes very warm. Electrical fault. Switch the power tool off immedi- ately, remove the battery and contact
Hilti Service.
The power tool has been overloaded
(application limits exceeded). Use the right power tool for the job (don’t use a low-powered tool for
heavy work).
10 Disposal
CAUTION
Improper disposal of the equipment may have serious consequences: the burning of plastic components generates
toxic fumes which may present a health hazard. Batteries may explode if damaged or exposed to very high
temperatures, causing poisoning, burns, acid burns or environmental pollution. Careless disposal may permit
unauthorized and improper use of the equipment. This may result in serious personal injury, injury to third parties and
pollution of the environment.
en
12
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

CAUTION
Dispose of defective batteries without delay. Keep them out of reach of children. Do not attempt to open or dismantle
batteries and do not dispose of them by incineration.
CAUTION
Dispose of the batteries in accordance with national regulations or return them to Hilti.
Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials
must be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements for
taking back your old power tools or appliances for recycling. Please ask your Hilti customer service department or
Hilti representative for further information.
For EC countries only
Disposal of electric tools together with household waste is not permissible.
In observance of the European Directive on waste electrical and electronic equipment and its imple-
mentation in accordance with national law, electrical appliances that have reached the end of their life
must be collected separately and returned to an environmentally compatible recycling facility.
11 Manufacturer’s warranty - tools
Please contact your local Hilti representative if you have
questions about the warranty conditions.
12 EC declaration of conformity (original)
Designation: Cordless circular saw
Type: SCM 22-A
Generation: 01
Year of design: 2011
We declare, on our sole responsibility, that this product
complies with the following directives and standards:
2006/42/EC, 2004/108/EC, 2006/66/EC, 2011/65/EU,
EN 60745‑1, EN 60745‑2‑5, EN ISO 12100.
Hilti Corporation, Feldkircherstrasse 100,
FL‑9494 Schaan
Jan Doongaji Paolo Luccini
Executive Vice President Head of BA Quality and
Process Management
Business Unit Power Tools &
Accessories
Business Area Electric
Tools & Accessories
12/2011 12/2011
Technical documentation filed at:
Hilti Entwicklungsgesellschaft mbH
Zulassung Elektrowerkzeuge
Hiltistrasse 6
86916 Kaufering
Deutschland
en
13
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03

*2033298*
2033298
Hilti Corporation
LI-9494 Schaan
Tel.: [phone]
Fax: [phone]
www.hilti.com
Hilti = registered trademark of Hilti Corp., Schaan
W 4082 | 0214 | 00-Pos. 8 | 1
Printed in China © 2014
Right of technical and programme changes reserved S. E. & O. 2033298 / A6
Printed: 12.03.2014 | Doc-Nr: PUB / 5075277 / 000 / 03
