Hilti MFP-KF User manual

1× MFP-KF
3× HST3-M12 × 85 #2113978 /
HUS3-H 10 × 90 #2079914
1× Set MFP-UL #2223129 /
1× Set MFP-UL-I #2223133
1× AM-M16 4.8
1× GR-G 1 1/4"
1× MFP-KF
4× HST3-M12 × 85 #2113978 /
HUS3-H 10 × 90 #2079914
1× Set MFP-UL2 #2223131 /
1× Set MFP-UL2-I #2223135
2× AM-M16 4.8
1× GR-G 1 1/4"
1× 1× 1× 1× 1×
1× 1× 2× 2× 2×
KF 30/40
#335218
KF 30/40
#335218
F
F
MFP-KF + MFP-UL2 /
MFP-KF + MFP-UL2-I
MFP-KF + MFP-UL /
MFP-KF + MFP-UL-I
MFP-KF + MFP-UL/MFP-UL-I
#Name Fmax (N)
2238671 MFP-KF 76 2.000
2238672 MFP-KF 89 2.500
2238673 MFP-KF 114 3.000
2 2 3 8 674 MFP-KF 133 3.500
2238675 MFP-KF 140 3.500
2238676 MFP-KF 159 4.000
2238677 MFP-KF 168 4.000
2238678 MFP-KF 219 4.000
2238679 MFP-KF 273 4.000
MFP-KF + MFP-UL2/MFP-UL2-I
#Name Fmax (N)
2238671 MFP-KF 76 2.000
2238672 MFP-KF 89 2.500
2238673 MFP-KF 114 3.000
2 2 3 8 674 MFP-KF 133 3.500
2238675 MFP-KF 140 3.500
2238676 MFP-KF 159 4.000
2238677 MFP-KF 168 4.000
2238678 MFP-KF 219 4.000
2238679 MFP-KF 273 4.000
2240470 A1
12.04.2019
A
B
2240470 A1-04.2019
MFP-KF
1/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

#Name
2238671 MFP-KF 76 16 12 Nm
2238672 MFP-KF 89 16 12 Nm
2238673 MFP-KF 114 16 12 Nm
2238674 MFP-KF 133 18 20 Nm
2238675 MFP-KF 140 18 20 Nm
2238676 MFP-KF 159 18 20 Nm
2238677 MFP-KF 168 18 20 Nm
2238678 MFP-KF 219 18 20 Nm
2238679 MFP-KF 273 24 45 Nm
VH
GR-G 1 1/4"
V
MFP-UL/ -UL-I
V= H-150mm
MFP-UL2/ -UL2-I
V= H-190mm
0 mm
0 mm
H
H
de Auswahl des Schweissverfahren, Schweisszusatz und die Auslegung der Kehlnahtgrösse obliegt dem Kunden!
en Selection of the welding process, welding addition and the design of the fillet weld size is the responsibility of the customer!
fr La sélection du procédé de soudage, de l'addition de soudage et de la conception de la taille de la soudure d'angle est à la charge du client!
it La selezione del processo di saldatura, l'aggiunta della saldatura e la progettazione della dimensione della saldatura del raccordo sono
responsabilità del cliente!
a
a
KF 30/40
#335218
SW
1 2
3 4
5 6 7
MFP-KF
2/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

+
30
15 Nm
(11 ft-lb)
α
β
α = β
max. 15°
max. 15°
SW
3
3
1
1
2
2
> 0mm /
max. 20mm
24
15 Nm
(11 ft-lb)
1
2
B1, B2
MFP-UL/ -UL-I
1× B1
MFP-UL2/ -UL2-I
1× B1, 1× B2
B1= (H - 50mm) × 1.5
B2= B1 - 50mm
H
B2B1
#Name
2238671 6 7 Nm
2238672 6 7 Nm
2238673 18 20 Nm
2 2 3 8 674 18 20 Nm
2238675 18 20 Nm
2238676 18 20 Nm
2238677 18 20 Nm
2238678 18 20 Nm
2238679 18 20 Nm
SW
3
1
2
8
13
9 10
11 12 14
MFP-KF
3/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

F
F
1× MFP-KF
6× HST3-M12 × 85 #2113978 /
HUS3-H 10 × 90 #2079914
1× Set MFP-ULD #2223130 /
1× Set MFP-ULD-I #2223134
2× AM-M16 4.8
2× GR-G 1 1/4"
1× MFP-KF
8× HST3-M12 × 85 #2113978 /
HUS3-H 10 × 90 #2079914
1× Set MFP-ULD2 #2223132 /
1× Set MFP-ULD2-I #2223136
4× AM-M16 4.8
2× GR-G 1 1/4"
2× 2× 2× 2× 2×
2× 2× 4× 4× 4×
KF 30/40
#335218
KF 30/40
#335218
MFP-KF + MFP-ULD2 /
MFP-KF + MFP-ULD2-I
MFP-KF + MFP-ULD /
MFP-KF + MFP-ULD-I #Name Fmax (N)
2238678 9.000
2238679 12.000
2238680 14.000
2238681 14.000
2238682 14.000
2238683 14.000
2238684 14.000
2238685 14.000
2238670 14.000
#Name Fmax (N)
2238678 9.000
2238679 12.000
2238680 14.000
2238681 14.000
2238682 14.000
2238683 14.000
2238684 14.000
2238685 14.000
2238670 14.000
MFP-KF + MFP-ULD/MFP-ULD-I
MFP-KF + MFP-ULD2/MFP-ULD2-I
C
D
MFP-KF
4/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

H
a
a
KF 30/40
#335218
H
+
H
V
MFP-ULD/ -ULD-I
2×
V= H-100mm
MFP-ULD2/ -ULD2-I
2×
V= H-140mm
GR-G 1 1/4“
V
de Auswahl des Schweissverfahren, Schweisszusatz und die
Auslegung der Kehlnahtgrösse obliegt dem Kunden!
en Selection of the welding process, welding addition and the design
of the fillet weld size is the responsibility of the customer!
fr La sélection du procédé de soudage, de l'addition de soudage et
de la conception de la taille de la soudure d'angle est à la charge
du client!
it La selezione del processo di saldatura, l'aggiunta della saldatura
e la progettazione della dimensione della saldatura del raccordo
sono responsabilità del cliente!
1
3 4 5
2
6 7
MFP-KF
5/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

0 mm0 mm
H
B2B1
+
30
80 Nm
(60 ft-lb)
1
1
1
1
3
3
2
2
B1, B2
MFP-ULD/ -ULD-I
2× B1
MFP-ULD2/ -ULD2-I
2× B1, 2× B2
B1 = (H - 50mm) × 1.5
B2= B1 - 70mm
1
2
α
β
α = β
max. 15°
max. 15°
> 0mm /
max. 20mm
24
15 Nm
(11 ft-lb)
3
1
2
SW
#Name
2238678 MFP-KF 219 18 20 Nm
2238679 MFP-KF 273 24 45 Nm
2238680 MFP-KF 324 24 45 Nm
2238681 MFP-KF 356 24 45 Nm
2238682 MFP-KF 368 24 45 Nm
2238683 MFP-KF 406 24 45 Nm
2238684 MFP-KF 457 24 45 Nm
2238685 MFP-KF 508 24 45 Nm
2238670 MFP-KF 609 24 45 Nm
SW
8 9 10
1311 12 14
MFP-KF
6/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

F
F
MFP-KF + MFP-UHD2
MFP-KF + MFP-UHD
KF 30/40
#335218
KF 30/40
#335218
1× MFP-KF
4× HST3-M16 × 135
#2105858 /
HUS3-H 14 × 130
#2079923
2× AM-M16 4.8
2× GR-G 1 1/4"
1× MFP-KF 4× AM-M16 4.8
2× GR-G 1 1/4"
8× HST3-M16 × 135
#2105858 /
HUS3-H 14 × 130
#2079923
4× HST3-M12 × 85
#2113978 /
HUS3-H 10 × 90
#2079914
4× HST3-M12 × 85
#2113978 /
HUS3-H 10 × 90
#2079914
1× Set MFP-UHD
#2223138
1× Set MFP-UHD2
#2223140
MFP-KF + MFP-UHD
#Name Fmax (N)
2238678 9.000
2238679 12.000
2238680 14.5 0 0
2238681 16.500
2238682 16.50 0
2238683 18.000
2238684 18.000
2238685 20.000
2238670 20.000
MFP-KF + MFP-UHD2
#Name Fmax (N)
2238678 9.000
2238679 12.000
2238680 14.5 0 0
2238681 16.500
2238682 16.50 0
2238683 18.000
2238684 18.000
2238685 20.000
2238670 20.000
2× 2×
2× 2× 4×
2× 2×
4× 4× 8×
E
F
MFP-KF
7/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

MFP-UHD
2×
V= H-100mm
MFP-UHD2
2×
V= H-140mm
GR-G 1 1/4“
H
V
V
H
a
a
KF 30/40
#335218
H
+
de Auswahl des Schweissverfahren, Schweisszusatz und die
Auslegung der Kehlnahtgrösse obliegt dem Kunden!
en Selection of the welding process, welding addition and the design
of the fillet weld size is the responsibility of the customer!
fr La sélection du procédé de soudage, de l'addition de soudage et
de la conception de la taille de la soudure d'angle est à la charge
du client!
it La selezione del processo di saldatura, l'aggiunta della saldatura
e la progettazione della dimensione della saldatura del raccordo
sono responsabilità del cliente!
3 4 5
6 7
1
2
MFP-KF
8/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

B1= (H - 50mm) × 1.5
B2= B1 - 70mm
MFP-UHD
2× B1
MFP-UHD2
2× B1, 2× B2
M16
B1, B2
α
β
α = β
max. 15°
max. 15°
1
2
H
B2B1
0 mm0 mm
+
30
80 Nm
(60 ft-lb)
1
1
1
1
3
3
2
2
#2113978/
#2079914
SW
#Name
2238678 MFP-KF 219 18 20 Nm
2238679 MFP-KF 273 24 45 Nm
2238680 MFP-KF 324 24 45 Nm
2238681 MFP-KF 356 24 45 Nm
2238682 MFP-KF 368 24 45 Nm
2238683 MFP-KF 406 24 45 Nm
2238684 MFP-KF 457 24 45 Nm
2238685 MFP-KF 508 24 45 Nm
2238670 MFP-KF 609 24 45 Nm
SW
1311 12
8 9 10
MFP-KF
9/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00

1
3
2
2
2
# 2105858 /
# 2079923
1
2
1
3
12
3
> 0mm / max. 20mm
24
80 Nm
(60 ft-lb)
15 16 1714
MFP-KF
10/10
Printed: 12.04.2019 | Doc-Nr: PUB / 5489101 / 000 / 00
