HindlePower AT30 SERIES Training manual

AT30 SERIES
Operating and Service Instructions
MICROPROCESSOR-CONTROLLED
FLOAT BATTERY CHARGER
THREE PHASE INPUT
(25 - 1,000 Adc)
JA5011-03

HOW TO READ THE AT30 MODEL NUMBER
The AT30 configured model number is coded to describe the unit's features and options. Please identify
the model number printed onthe data nameplate decal, and write it in the spaces provided below.
AT30
A B C D E F G H J K L M N P
Follow the chart below to determine the configuration of the AT30.
DESCRIPTION CODE FEATURE DESCRIPTION CODE FEATURE
A SERIES AT30 AT30 BATTERYCHARGER S STANDARD
012 12 Vdc M MEDIUMAIC
024 24 Vdc H HIGH AIC
048 48 Vdc
F
AC CIRCUIT
BREAKER
RATING
(SEE TABLE) 0NO AC BREAKER
B NOMINAL
DC OUTPUT
VOLTAGE 130 130 Vdc F SUPPLIED
CODE FEATURE CODE FEATURE G AC FUSES
(200 kAIC) X NOT SUPPLIED
025 25 Adc 200 200 Adc S STANDARD
030 30 Adc 250 250 Adc M MEDIUMAIC
040 40 Adc 300 300 Adc H HIGH AIC
050 50 Adc 400 400 Adc
H
DC CIRCUIT
BREAKER
RATING
(SEE TABLE) 0NO DC BREAKER
075 75 Adc 500 500 Adc F SUPPLIED
100 100 Adc 600 600 Adc J DC FUSES
(20 kAIC) X NOT SUPPLIED
125 125 Adc 800 800 Adc
C NOMINAL DC OUTPUT
CURRENT
150 150 Adc 1K0 1,000 Adc A SUPPLIED
F FILTERED (STANDARD w/BATT) K AUX ALARM
RELAYBOARD X NOT SUPPLIED
E ELIMINATOR (w/oBATTERY)
S SPECIAL 30 mVRMS (at 130V BATT) G SUPPLIED
D DC OUTPUT
FILTERING
U UNFILTERED
L COPPER
GROUND BUS X NOT SUPPLIED
208 208 Vac 60 Hz L SUPPLIED
240 240 Vac 60 Hz M LIGHTNING
ARRESTOR X NOT SUPPLIED
480 480 Vac 60 Hz
600 550-600 Vac 60 Hz F APPLIED
220 220 Vac 50/60 Hz N FUNGUS
PROOFING X NOTAPPLIED
380 380 Vac 50/60 Hz S APPLIED
E AC INPUT
VOLTAGE
416 416 Vac 50/60 Hz P STATIC
PROOFING X NOTAPPLIED
DESCRIPTION CODE FEATURE DESCRIPTION CODE FEATURE
INPUT AND OUTPUT INTERRUPTING CAPACITY RATINGS
ORDER
CODE
CIRCUIT
BREAKER
TYPE
AC CIRCUIT
BREAKER RATINGS
(208/240/480 Vac) *
DC CIRCUIT
BREAKER RATINGS
(125/250 Vdc)
OPTIONAL AC
FUSE RATING
(208-600 Vac)
OPTIONAL DC
FUSE RATING
(12/24/48/130 Vdc)
S STANDARD 5,000 AIC 5,000 AIC
M MEDIUM AIC 25,000 AIC 10,000 AIC 200,000 AIC 20,000 AIC
H HIGHAIC 65,000 AIC 20,000 AIC
* Contact your sales representative 500-600 Vac 60Hz circuit breaker AIC ratings.
NOTICE .
The factory-configured model number printed on the AT30 data nameplate decal does not
feature certain options and accessories. Nor does it feature any field-installed options. Check off below
any options and/or accessories that are initially included, or are installed after shipment.
wall/rack-mounting brackets zero-center ground detection meter w/test switch
NEMA Type 2 drip shield end of discharge alarm relay
NEMA Type 4 (12/13) cabinet battery discharge alarm relay
cabinet heater strips barrier type auxiliary alarm terminal block(s)
pad/key lock for front panel door external temperature compensation probe
analog ac voltmeter w/sel switch DNP3 Level 2 / Modbus communications module
analog ac ammeter w/sel switch forced load sharing interconnection cable
Please find the serial number on the
data nameplate and record it here:

MANUFACTURER'S WARRANTY
Remove this sheet as needed from bound manual.
FIVE-YEAR WARRANTY
NEW PRODUCT - BATTERY CHARGER
[applies only to product(s) delivered within the United States and Canada]
Product Details:
Battery Charger Model:
Factory Ordering Code:
Battery Charger Serial Number:
Date Shipped:
Date Energized:
 Standard Warranty
This product is warranted to be free from defects in material and
workmanship for a period of five (5) years from date of manufacture.
During the term of the warranty period: parts, assemblies, or components
deemed to be defective will be repaired or replaced at the manufacturer's
option, free of charge. All costs related to removal, reinstallation and
transportation will be paid by the purchaser/customer and/or operator of
the product. Evaluation, repair and/or replacement of any defective
part(s) are FOB manufacturer's factory.
This warranty does not cover products or parts that are damaged from
improper use or abuse, as determined by the manufacturer. Accessory
items or additional items carry only their respective manufacturer’s
warranty. Consumable items (such as fuses and electrolytic capacitors),
which wear out under normal use are specifically not covered by this
standard warranty. Any consequential damage due to diagnosis or repair
by any party other than the manufacturer's authorized personnel is not
covered under this warranty.

MANUFACTURER'S WARRANTY
Remove this sheet as needed from bound manual.
 Extended Spare Parts Warranty
The manufacturer's extended warranty includes all items as mentioned in
the "Standard Warranty" as previously listed, plus reasonable in/out
freight costs related to a warranty claim for parts. Said freight cost is
based on either standard UPS rates or common carrier only, as
appropriate. Contact your sales representative for more information &
pricing regarding the extended spare parts warranty.
 Magnetic Parts 25-Year Extended Warranty
(equal to 5% of the original purchase price)
Lifetime warranty (limited to 25 years from date of shipment) covers
battery charger major electromagnetic components (T1 transformer, L1
inductor & L2 inductor) as applicable. Coverage is for 100% replacement
of any covered magnetic component that fails during normal use. Abuse,
neglect, and damage from outside sources or improper application will
make this warranty null and void. The manufacturer reserves the right to
make final determination regarding the application of this warranty. The
manufacturer will be responsible for costs related to inbound and
outbound freight of warranted magnetic components (T1, L1 & L2).
Freight cost is based on standard UPS rates or common carrier only, as
appropriate. Costs related to removal and/or reinstallation of warranted
magnetic components will be the responsibility of the purchaser/customer
and/or operator of the product. Contact your sales representative for more
information & pricing regarding the magnetic parts extended warranty.
.NOTICE .
Requests for returns or warranty claims must be made via manufacturer's
Return Material Authorization (RMA) instructions and assignment.
Contact your sales representative for more information & pricing
regarding returns or warranty claims. Returns that do not follow this
procedure will not be honored.
Election to any of the above offered extended warranties must be done
within the terms of the initial standard warranty.

IMPORTANT SAFETY INSTRUCTIONS
i
PLEASE READ AND FOLLOW
ALL SAFETY INSTRUCTIONS
NOTICE
1. Before using the AT30, read all instructions and cautionary markings on:
A) this equipment, B) battery, and C) any other equipment to be used in
conjunction with the AT30.
2. This manual contains important safety and operating instructions, and should
therefore be filed for easy access.
3. Remove all jewelry, watches, rings, etc. before proceedingwith installation or
service.
4. Maintain at least 6in / 152mm of free air on all vented surfaces for cooling.
Allow sufficient clearance to open the front panel for servicing.
5. Connect or disconnect the battery only when the AT30 is off, to prevent
arcing or burning.
6. Do not operate the AT30 if it has been damaged in any way. Refer to
qualified service personnel.
7. Do not disassemble the AT30. Only qualified service personnel should
attempt repairs. Incorrect reassembly may result in explosion, electrical
shock, or fire.
8. Do not install the AT30 outdoors, or in wet or damp locations, unless
specifically ordered for that environment.
9. Do not use the AT30 for ANY purpose not described in this manual.
!WARNING
1. Do not touch any uninsulated parts of the AT30, especially the input and
output connections, as there is the possibility of electrical shock.
2. During normal operation, batteries may produce explosive gas. Never smoke,
use an open flame, or create arcs in the vicinity of the AT30 or the battery.
3. Turn the AT30 off before connecting or disconnecting the battery to avoid
shock hazards and/or equipment damage.
4. De-energize and lock out all ac and dc power sources to the AT30 before
servicing.
5. Do not operate the AT30 with any power source that does not match the
specified ac and dc voltage ratings. Refer to the data nameplate decal affixed
to the outside panel for operational requirements.
6. Do not operate the AT30 with the acrylic safety shield or any other supplied
guards removed or improperly installed.

TABLE OF CONTENTS
ii
HOW TO READ THE AT30 MODEL NUMBER......................................... Inside Front Cover
MANUFACTURER'S WARRANTY..............................................................Removable Form
IMPORTANT SAFETY INSTRUCTIONS................................................................................i
1 Receiving and Installing the AT30 Battery Charger
1.1 Storing the AT30.............................................................................................2
1.2 Reporting shipping damage.............................................................................2
1.3 Unpacking and inspecting the AT30.................................................................2
Inspection checklist.........................................................................................2
1.4 Moving the AT30 ............................................................................................3
Enclosure type and weight table ......................................................................3
1.5 Mounting the AT30 .........................................................................................4
1.5.1 Floor-Mounting the AT30...........................................................................4
1.5.2 Wall-Mounting the AT30............................................................................6
1.5.3 Rack-Mounting the AT30...........................................................................8
1.6 Changing the transformer taps.......................................................................10
1.7 Making the ac input connections....................................................................12
1.8 Making the dc output connections..................................................................14
1.9 Wiring the AT30 for remote sensing...............................................................16
1.10 Wiring to the remote alarm contacts...............................................................18
Auxiliary Alarm Relay PC Board (optional)......................................................19
1.11 Installing the temperature compensation probe (optional)................................20
Using temperature compensation ..................................................................22
1.12 Installing the AT30 for remote communications (optional)................................23
1.13 Installing the AT30 for forced load sharing (optional) .......................................23
2 Operating the AT30 Battery Charger
2.1 Starting the AT30
2.1.1 Understanding the start-up sequence.......................................................24
2.1.2 Checking the installation .........................................................................24
2.1.3 Starting the AT30....................................................................................24
Using the digital meter............................................................................24
Factory settings table..............................................................................25
2.2 Using the AT30 front panel features
2.2.1 If the meter displays an error message.....................................................26
2.2.2 Selecting the meter mode........................................................................26
2.2.3 Selecting the Float or Equalize mode.......................................................27
2.2.4 Choosing the Equalize method................................................................27
Manual Timer method .............................................................................27
Manual Equalize method.........................................................................28
Auto-Equalize Timer method ...................................................................28
2.2.5 Testing the front panel indicators .............................................................29
2.2.6 Testing the Auxiliary Alarm Relay PC Board (optional) ..............................29
2.2.7 Interpreting the alarm indicators...............................................................29

TABLE OF CONTENTS
iii
2.3 Setting the AT30 parameters
2.3.1 Understanding parameter settings ...........................................................30
2.3.2 Setting the Float and Equalize voltages ...................................................31
2.3.3 Setting the Equalize timer ....................................................................... 32
2.3.4 Setting the Alarms.................................................................................. 32
Setting the high and low dc voltage alarms...............................................33
Adjusting ground detection sensitivity ......................................................34
Disabling the ground detection alarm....................................................... 35
2.3.5 Setting the Current Limit value ................................................................35
2.3.6 Enabling the high dc voltage shutdown feature......................................... 36
2.3.7 Adjusting the Voltmeter accuracy.............................................................37
2.3.8 Using the Low Level Detector (LLD) ........................................................ 38
2.3.9 Using the front panel security feature....................................................... 39
2.4 Performing routine maintenance.................................................................... 40
Sample preventive maintenance procedure.................................................... 42
3 Servicing the AT30 Battery Charger
3.1 A step-by-step troubleshooting procedure...................................................... 44
3.2 Interpreting front panel error messages..........................................................45
3.3 Using the troubleshooting chart.....................................................................48
3.4 Troubleshooting chart begins on.................................................................... 49
3.5 Replacing defective components...................................................................58
3.6 Ordering replacement parts...........................................................................62
APPENDIX A: AT30 Performance Specifications.............................................................64
APPENDIX B: Field Installable Accessories .................................................................... 65
APPENDIX C: Standard Drawings *
Outline: AT30 Batt Chgr NEMA-1 Style-5018 / -5030 / -163 Enclosure..........................66 / 68 / 70
Internal Component Layout: AT30 Style-5018 / -5030 / -163 Encl w/Common Opts.....72 / 74 / 76
Instrument Panel / PC Board Detail: AT30 Series Battery Charger..............................................78
Schematic: AT30 Series Battery Charger - Standard w/o Options...............................................80
Schematic: AT30 Series Battery Charger - with Common Options ..............................................82
Connection Diagram: AT30 Battery Charger - Power Wiring w/Common Options.......................84
Connection Diagram: AT30 Battery Charger - Control (Signal) Wiring.........................................86
Connection Detail: AT30 Battery Charger - I/O Panels & Rectifier Assemblies............................88
APPENDIX D: Recommended Float/Equalize Voltages / Temp. Compensation ............. 90
APPENDIX E: DNP3 Level 2 / Modbus Communications Module..................................... 91
APPENDIX F: Forced Load Sharing.................................................................................92
APPENDIX G: CE Grounding Compliance ....................................................................... 94
APPENDIX H: Remote Shutdown..................................................................................... 95
APPENDIX J: Battery Open Alarm................................................................................... 96
MANUAL SPECIFICATIONS........................................................................................... 100
RELATED DOCUMENTS (web-based content).......................................... Inside Back Cover
* Acustomized record drawing package is available for your particular AT30, featuring an
itemized internal component layout, electrical schematic with component ratings, and a full
connection diagram. If thestandard drawings featured in this manual are not sufficient, please
contact your Sales Representative for drawing availability from the AT30 manufacturer.

RECEIVING THE AT30
2
1. RECEIVING THE AT30
1.1. STORING THE AT30
If you store the AT30 for more than a few days before installation, store it
the original shipping container, and in a temperature controlled, dry
climate. Ambient temperatures of 0 to 122 °F / -18 to 50 °C are
acceptable. Storage should not exceed two (2) years due to the limited
shelf life of the dc filter capacitors when they are not in service.
1.2. REPORTING SHIPPING DAMAGE
Upon delivery of the AT30 (or related products) if you discover any
damage or shortage, make notation on all copies of delivering carrier's
delivery receipt before signing and notify the delivery person of your
findings. If loss or damage is discovered after delivery, notify delivering
carrier immediately and request an inspection. The manufacturer does not
assume any liability for damage during transportation or handling.
Should the products require an inspection by (or return to) the
manufacturer, please contact your sales representative for further
instructions. Any returned material must be properly packed in
compliance with shipping regulations. It is preferable to use the original
shipping materials if possible. Mark the outside of the shipping container
with the Return Material Authorization (RMA) number issued by the
manufacturer.
1.3. UNPACKING AND INSPECTING THE AT30
Carefully remove all shipping materials from the AT30. Remove the
AT30 from the shipping pallet for inspection. Save all shipping materials
until you are sure that there is no shipping damage.
Once the AT30 is unpacked, inspect the unit for possible shipping
damage, using the checklist below. If shipping damage has occurred,
refer to Section 1.2 on this page for proper reporting.
INSPECTION CHECKLIST
 Enclosure exterior and interior are not marred or dented.
 There is no visible damage to exterior or interior components.
 All internal components are secure.
 Printed circuit boards are firmly seated on their standoffs.
 All hardware is tight.
 All wire terminations are secure.
 The User's Manual and Quick Setup Sheet are supplied.
 You received all items on the packing list.

INSTALLING THE AT30
3
1.4. MOVING THE AT30
Once you have established that the AT30 is undamaged, identify the
enclosure style of your unit. Refer to the table below.
Standard AT30 NEMA-1 Type Enclosures
( Style-5018 / Style-5030 / Style-163 / Style-198 )
Output Voltage
Ampere
Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
25 Adc n/a n/a n/a Style-5018
30 Adc n/a n/a n/a Style-5018
40 Adc n/a n/a n/a Style-5018
50 Adc Style-5018 Style-5018 Style-5018 Style-5018
75 Adc Style-5018 Style-5018 Style-5018 Style-5018
100 Adc Style-5018 Style-5018 Style-5018 Style-5030
125 Adc Style-5030 Style-5030 Style-5030 Style-5030
150 Adc Style-5030 Style-5030 Style-5030 Style-5030
200 Adc Style-5030 Style-5030 Style-5030 Style-5030
250 Adc Style-5030 Style-5030 Style-5030 Style-163
300 Adc Style-5030 Style-5030 Style-5030 Style-163
400 Adc n/a Style-163 Style-163 Style-163
500 Adc n/a Style-163 Style-163 Style-198
600 Adc n/a Style-163 Style-198 Style-198
800 Adc n/a Style-198 Style-198 Style-198
1,000 Adc n/a Style-198 Style-198 Style-198
Comprehensive weight data for the different models is available in the
AT30 product literature (JF5018-00). The four standard NEMA Type 1
enclosures do not feature top lifting eyes for moving. Move the AT30
with a forklift whenever possible, using the supplied shipping pallet.
Place the AT30 onto a floor-mount installation using a forklift, lifting the
enclosure from the bottom between the mounting legs. To lift the Style-
5018 enclosure into a wall-mount or rack-mount installation, use a heavy-
duty sling or a scissor lift.
For further AT30 standard cabinet information, refer to the table below
and the standard drawings featured in Appendix C, starting on page 66.
NEMA-1 Enclosure Outline Drawing Internal Layout Drawing
Style-5018 JE5085-00 JE5088-99
Style-5030 JE5086-00 JE5089-99
Style-163 JE5095-00 JE5098-99
Style-198 JE5096-00 JE5099-99

INSTALLING THE AT30
4
1.5. MOUNTING THE AT30
The AT30 must be installed in manner that allows easy access to the front
ac (CB1) and dc (CB2) circuit breakers. Chose a mounting method for the
AT30 enclosure from the table below.
ENCLOSURE
MANUAL
SECTION MOUNTING METHOD Style-5018 Style-5030/163/198
1.5.1 Floor-Mounting STANDARD STANDARD
1.5.2 Wall-Mounting OPTIONAL n/a
19in / 483mm
Rack-Mounting n/a n/a
1.5.3 23-24in / 584-610mm
Rack-Mounting OPTIONAL n/a
1.5.1. Floor-Mounting the AT30
Floor-mounting is the standard means of installing all the AT30
enclosures. When floor-mounting the AT30, consider the following:
1. Refer to the outline drawings in Appendix C, starting on page 66, for the
overall footprint of the Style-5018, Style-5030, and Style-163 enclosures.
2. Be conscious of planned ac input and dc output wiring to the AT30,
selecting conduit entrances carefully. Note the standard pre-fab conduit
knockouts located on the sides (and sometimes tops) of the enclosures.
3. The location:
• Should be free of drips and splatter. If falling particles and liquids are a
problem, install NEMA-2 type drip shield accessory (EI0191-0#). For
kit availability, see ordering information in Appendix B on page 65.
• Should be between 0 and 122 °F / -18 and 50 °C, with relative humidity
between 5% and 95% non-condensing.
• Must be free of flammable or explosive materials.
4. Maintain at least 6in / 152mm of free air on all vented surfaces for cooling.
5. Allow at least 36in / 914mm front clearance for access to the AT30 for
operation and maintenance.
PROCEDURE (Style-5018)
1. Install four (4) 0.25in / 6.4mm anchor bolts into the floor, per the mounting
dimensions featured in the outline drawing (JE5085-00).
2. Carefully lift the AT30 above the anchor bolts using the methods described
in Section 1.4. Guide the enclosure onto the floor bolt pattern and lower it
into place.
3. Add appropriate mounting hardware onto the floor-mounting anchor bolts
and tighten securely.

INSTALLING THE AT30
5
PROCEDURE (Style-5030)
1. Install four (4) 0.375 / 9.5mm or 0.5in/12.7mm anchor bolts into the floor,
per the mounting dimensions featured in the outline drawing (JE5086-00).
2. Carefully lift the AT30 above the anchor bolts using the methods described
in Section 1.4. Guide the enclosure onto the floor bolt pattern and lower it
into place.
3. Add appropriate mounting hardware onto the floor-mounting anchor bolts
and tighten securely.
PROCEDURE (Style-163 / Style-198)
1. Install four (4) 0.5in/12.7mm anchor bolts into the floor, per the mounting
dimensions featured in the outline drawings (JE5095-00 / JE5096-00).
2. Carefully lift the AT30 above the anchor bolts using the methods described
in Section 1.4. Guide the enclosure onto the floor bolt pattern and lower it
into place.
3. Add appropriate mounting hardware onto the floor-mounting anchor bolts
and tighten securely.
GRAPHICS - STANDARD NEMA-1 TYPE AT30 ENCLOSURES
Style-5018
see outline drawing
JE5085-00
Style-5030
see outline drawing
JE5086-00
Style-163
see outline drawing
JE5095-00

INSTALLING THE AT30
6
1.5.2. Wall-Mounting the AT30 (Style-5018 enclosure only)
To install the AT30 onto a vertical surface, the standard Style-5018
enclosure does not need to be modified, but a special wall-mounting
accessory (EI5008-00) is required. For kit availability see ordering
information in Appendix B on page 65. The kit includes two (2)
mounting brackets, appropriate hardware, and Installation Instructions
(JA5063-00) for the wall-mounting procedure.
When wall-mounting the AT30, consider the following:
1. The wall must be strong enough to properly support the weight of the AT30
and the mounting brackets. Comprehensive weight data for the different
models is available in the AT30 product literature (JF5018-00). The
weight of your AT30 may be different from the literature value, depending
on supplied features, options, or accessories.
2. Be conscious of planned ac input and dc output wiring to the AT30,
selecting conduit entrances carefully. Note the standard pre-fab conduit
knockouts located on the sides the Style-5018 enclosure.
3. The location:
• Should be free of drips and splatter. If falling particles and liquids are a
problem, install NEMA-2 type drip shield accessory (EI0191-0#). For
kit availability, see ordering information in Appendix B on page 65.
• Should be between 0 and 122 °F / -18 and 50 °C, with relative humidity
between 5% and 95% non-condensing.
• Must be free of flammable or explosive materials.
4. Maintain at least 6in / 152mm of free air on all vented surfaces for cooling.
5. Allow at least 36in / 914mm front clearance for access to the AT30 for
operation and maintenance.
PROCEDURE
1. Install eight (8) 0.25in / 6.4mm anchor
bolts (not supplied) rated to support the
AT30 weight plus a safety factor of at
least two (2) times, into the wall.
2. Mount the triangular brackets to the wall.
3. Carefully lift the Style-5018 enclosure
onto the mounted triangular brackets.
4. Use the supplied 0.25in / 6.4mm hardware
to mount the enclosure to the wall-
mounting brackets and tighten securely.
5. Refer to the graphics on the opposite page
for the AT30 Style-5018 wall-mounting
pattern and enclosure footprint.
6. Dimensions are in/mm.

INSTALLING THE AT30
7
GRAPHICS - WALL-MOUNTING THE AT30
NOTES
1. Refer to the Style-5018 enclosure outline drawing (JE5085-00) in
Appendix C on page 66 for overall size, mounting dimensions, and cabinet
specifications.
2. See Installation Instructions (JA5063-00) for the special Style-5018 wall-
mounting procedure.

INSTALLING THE AT30
8
1.5.3. Rack-Mounting the AT30 (Style-5018 enclosure only)
Smaller AT30s can be installed in 23-24in /584-610mm relay racks with
standard EIA hole spacing. The Style-5018 enclosure does not need to be
modified for rack mounting, but a special kit (EI0193-0#) is required.
For kit availability see the ordering information in Appendix B on page
65. The kit includes two (2) mounting brackets, hardware, and
Installation Instructions (JA0091-03) for the rack-mounting procedure.
When rack-mounting the AT30, consider the following:
1. The relay rack must be strong enough to properly support the weight of the
AT30. Comprehensive weight data for the different models is available in
the AT30 product literature (JF5018-00). The weight of your AT30 may
be different from the literature value, depending on supplied features,
options, or accessories.
2. Be conscious of planned ac input and dc output wiring to the AT30,
selecting conduit entrances carefully. Note the standard pre-fab conduit
knockouts located on the sides of the enclosures. Ensure that planned
conduit is accessible after the AT30 is rack-mounted.
3. The location:
• Should be free of drips and splatter. If falling particles and liquids are a
problem, install a NEMA-2 type drip shield accessory (EI0191-02). For
kit availability, see ordering information in Appendix B on page 65.
• Should be between 0 and 122 °F / -18 and 50 °C, with relative humidity
between 5% and 95% non-condensing.
• Must be free of flammable or explosive materials.
4. Maintain at least 6in / 152mm of free air on all vented surfaces for cooling.
5. Allow at least 36in / 914mm front clearance for access to the AT30 for
operation and maintenance.
PROCEDURE
1. Attach the two (2) relay rack-mounting brackets
to the sides of the Style-5018 enclosure, using
the four (4) small pre-fab knockouts as guides.
2. Mount the brackets to the AT30, using the
supplied 0.25in / 6.4mm hardware and tighten
securely.
3. Using a scissor lift, guide the AT30 into the
front face of the 23in / 584mm EIA relay rack.
4. Adjust the height of the AT30 and mount in
place using appropiate hardware (not supplied).
5. Refer to the graphics on the opposite page for
the rack-mounted enclosure footprint.

INSTALLING THE AT30
9
GRAPHICS - RACK-MOUNTING THE AT30
NOTES
1. Rack-mount AT30 Style-5018 enclosures are installed from the front.
2. Refer to the Style-5018 enclosure outline drawing (JE5085-00) in
Appendix C on page 66 for overall size and cabinet specifications.
3. Refer to the detailed Installation Instructions (JA0091-03) supplied with
the kit for the special rack-mounting procedure.

INSTALLING THE AT30
10
1.6. CHANGING THE TRANSFORMER TAPS
...!CAUTION... Before connecting external power to the AT30, verify
the ac input voltage listed on the data nameplate decal, and the tag
attached to the ac breaker (CB1). The power isolation transformer (T1) is
designed with an ac input voltage tolerance of +10% to -12%.
If available on-site ac supply voltage does not match the AT30 input
requirements, you may need to replace certain ac components. See
Section 3.6 on page 62 for ordering replacement parts. Failure to use
properly rated components may damage the AT30.
If your AT30 was supplied with one of the following ac input voltage
features, the transformer (T1) is re-tappable:
• 208 or 240 Vac 60Hz
• 220 or 240 Vac 50/60Hz
• 380 or 416 Vac 50/60Hz
• 550 or 600 Vac 60Hz
If the AT30 was supplied with the 480 Vac 60Hz ac input feature, the
transformer will only accept the listed voltage. Do not attempt to re-tap
this transformer. If the transformer is not re-tappable, a full ac feature
change is needed. Contact your sales representative for ordering all
voltage and current-specific ac replacement parts (T1, CB1 & VR2-VR5).
. .!WARNING .Before changing the transformer (T1) taps, shut down
the AT30. Lock out ac and dc power supplies. Merely turning off
(opening) the AT30 internal circuit breakers does not eliminate live
voltages inside the enclosure. Allow filter capacitors (C1/C2) to bleed
off. De-energize any external wiring to the AT30 alarm relay contacts
(TB3/TB4). Verify no internal voltages are present before proceeding.
AT30s are designed and manufactured from the factory to accept a single
ac input supply voltage. Transformer re-taps for 208/240, 220/240,
380/416, or 550/600 Vac do not require additional changes. For a more
detailed description of this procedure, or for ac voltage changes not listed,
refer to Service Instruction (JD5026-03).
AT30 isolation transformers featured bolted connections, protected with
heat shrink insulation, which may need to be removed.
NOTICE This procedure refers only to three-phase input AT30
Series battery chargers. Refer to similar procedures for single-phase
input AT10.1 Series chargers. See Section 1.6 in O&SI (JA0102-01) for
Group I models, or O&SI (JA0102-02) for Group II models. Otherwise,
damage to the AT30 and site equipment may occur.

INSTALLING THE AT30
11
PROCEDURE
1. Shut down the AT30, then see Section 3.5 for necessary steps to follow
when accessing internal components within the enclosure.
2. Verify that no internal voltages are present before proceeding.
3. Refer to the images below and identify the three (3) primary-side "taps"
(H#) on the AT30 power isolation transformer (T1).
AT30 THREE PHASE ISOLATION TRANSFORMER
(excludes 480 Vac non-tappable variant)
TOP VIEW LAYOUT (T1) SCHEMATIC (T1)
4. Inspect the transformer wiring inside the AT30 and identify the primary
"taps" (T1-H1, T1-H2 & T1-H3), usually arranged left-to-right.
5. Refer to the table below and rewire primary connections as needed.
jumper setting
208 or 220 or 380 or 550 Vac jumper setting 240 or 416 or 600 Vac
H1, H2 & H3 set to "1" H1, H2 & H3 set to "2"
6. Always use all three (3) jumpers, as shown above.
7. Check work for tight connections, and no exposed wires touching ground.
8. ...!CAUTION... Confirm any protection devices, upstream from the
AT30, are adequately sized for the new ac input voltage and current. For
maxium ac input current values, refer to standard (DC5016-00).
9. Restart the AT30 using the procedure in Section 2.1.
10. Contact the factory for a new data nameplate with revised ac input values.
11. For further details, refer to Service Instruction (JD5026-03).

INSTALLING THE AT30
12
1.7. MAKING THE AC INPUT CONNECTIONS
!WARNING
The AT30 is a commercial product, and not intended for use in a
residential environment, or to be powered by low-voltage public mains.
It is the responsibility of the installer of the AT30 to provide suitable ac
supply wiring. Wiring must be approved for use in the country in which
the AT30 is installed. When selecting wire sizes, consult the data
nameplate decal affixed to the front panel of the AT30 for maximum
voltage and current requirements. The AT30 must also be grounded in
accordance with the electrical rules of the country where installed.
Follow these steps to connect ac power to the AT30:
1. Confirm that the AT30 main power transformer (T1) is properly jumpered for
your ac input supply voltage. See Section 1.6 for details.
2. Use a branch circuit breaker or fused disconnect switch upstream from the
AT30. This device should have lockout capability so that the ac input supply to
the AT30 can be de-energized for charger maintenance. A time delay circuit
breaker or slow-blow fuse is recommended.
3. Size the branch circuit breaker or fused disconnect switch for the maximum ac
input current of the AT30. This rating is listed on the left-hand side of the
AT30 data nameplate. For a comprehensive list of these maximum ac input
values, access standard (DC5016-00).
NOTICE
An ac feeder breaker (or fuse) is required if the AT30 features 480 Vac
input, is equipped with the standard AIC breaker, and no ac fuses. The
feeder must be rated to interrupt the short-circuit currentof the ac supply.
4. Size ac input wiring per the National Electric Code (NEC) and local codes for
the trip rating of the branch circuit breaker or fused disconnect switch.
5. Do not run external ac input power wiring through the same conduit of the
AT30 enclosure as external dc output power wiring.
6. All site requirements of your facility take precedence over these instructions.
PROCEDURE
1. Remove the acrylic safety shield (if supplied).
2. Run the ac input supply wiring into the AT30, ending at terminals TB1-L1,
TB1-L2, TB1-L3, and TB1-GND on the I/O panel board.
3. The AT30 features four (4) CU-AL compression lugs on the ac input terminals.
• Style-5018 and Style-5030 enclosure ac lugs accept #14 - 1/0 AWG wire
• Style-163 and Style-198 enclosure ac lugs accept #6 AWG - 350 MCM wire
4. Strip 0.50in / 13mm from the insulation of the incoming ac input supply wiring.
5. Connect the wires to the appropriate ac lugs as shown on the next page.
6. Using proper tools, securely tighten the compression screws on the ac lugs to
proper torque specifications.
7. Check all connections and reinstall the acrylic safety shield (if supplied).

INSTALLING THE AT30
13
MAKING THE AC INPUT CONNECTIONS - GRAPHICS
Style-5018
I/O Terminal
Board (TB1)
Detail
user-supplied ac input wiring
user-supplied ac input wiring
Style-5030
I/O Terminal
Board (TB1)
Detail
user-supplied ac input wiring
Style-163
I/O Terminal
Board (TB1)
Detail
NOTES !CAUTION
1. The ac input terminal hardware fastens other components mounted to the I/O
panel (TB1-L#). Be careful not to disconect any other component leads.
2. Conduit must be properly grounded, and in compliance with the national wiring
rules of the country where installed.
3. Use copper or aluminum conductors only.

INSTALLING THE AT30
14
1.8. MAKING THE DC OUTPUT CONNECTIONS
It is the responsibility of the installer of the AT30 to provide suitable dc
output, battery, and dc load wiring. Follow these steps to connect the
battery to the AT30:
1. Size the dc wiring to minimize voltage drop. The acceptable wire size
depends on your installation. As a guideline, the voltage drop should not
exceed 1% of nominal output voltage at full current.
2. Size the dc output wiring per your battery manufacturer's specifications and
local codes for the rating of the batteries and/or load.
3. The AT30 is factory wired to regulate the output voltage at the output
terminals. If the total voltage drop is greater than 1% (e.g., 1.3V for a 130
Vdc system), remote sense wiring is recommended, see Section 1.9.
4. Do not run the external dc power wiring through the same conduit of the
AT30 enclosure as the external ac power wiring.
5. All specific requirements of your facility take precedence over these
instructions.
PROCEDURE
1. Use a dc disconnect switch or circuit breaker between the AT30 and the dc
bus. This device should have lockout capability to allow the AT30 to be
disconnected from the dc bus for maintenance.
2. Remove the acrylic safety shield (if supplied).
3. Run the dc wiring to terminals TB1(+) and TB1(-) on the I/O panel board in
the enclosure. CU-AL Compression lugs are supplied for your convenience.
• Style-5018 enclosure dc output lugs accept #14 - 1/0 AWG wire
• Style-5030/163 enclosure dc output lugs accept #6 AWG - 350 MCM wire
4. Strip the insulation 0.5in / 12.7mm on the incoming ac wires and connect the
wires to the appropriate dc lugs as shown on the next page.
5. Using proper tools, securely tighten the compression screws on the lugs to
proper torque values.
6. Check all connections and reinstall the acrylic safety shield (if supplied).
!CAUTION
NOTES
1. The dc output terminal hardware fastens other components mounted to the
I/O panel. Be careful not to disconect any other component leads.
2. Always use a proper ground.
3. Use copper or aluminum conductors only.
4. Refer to images on the following page for I/O panel layout.
