60” MISTRALTM
CEILING FAN INSTRUCTION MANUAL
Model No. HF1161
HINKLEY
PAIR WITH HINKLEY APP
DOWNLOAD ON APP STORE or GOOGLE PLAY
WIFI
DC
DC MOTOR
CONTROL
DAMP
READY
TO USE.
CONTROL
PRE-PAIRED.
INDOOR / COVERED OUTDOOR FAN

hinkley.com
2
WE WANT YOU TO LOVE YOUR NEW FAN
SO WE’RE HERE IF YOU HAVE A QUESTION, NEED SOME
HELP OR WANT TO CHAT ABOUT OUR PRODUCTS, SEND
SUGGESTIONS OUR WAY TOO - WE’RE ALWAYS LOOKING TO
MAKE YOUR EXPERIENCE WITH HINKLEY A POSITIVE ONE.
This manual contains complete instructions for the
installation and operation of this fan. It has been
designed to make the installation process as easy as
possible. If you are unfamiliar or uncomfortable with
wiring, please contact a qualified electrician. If you
need additional assistance or have any questions,
please reach out to us.
For warranty information, visit hinkley.com.
> [e-mail]
> 800.HINKLEY
> LET’S SEE THAT HINKLEY STYLE @HINKLEY
#HINKLEYSTYLE

02 GENERAL INSTALLATION & OPERATING INSTRUCTIONS
03 IMPORTANT SAFETY PRECAUTIONS
03 TOOLS & MATERIALS REQUIRED
04 UNPACKING YOUR FAN
05 PREPARATION
05 INSTALLING THE HANGING BRACKET
06 INSTALLING THE BLADES
07 HANGING THE FAN
09 ELECTRICAL CONNECTIONS
10 FINISHING THE INSTALLATION
11 INSTALLING THE WALL CONTROL
13 OPERATION
15 CARE AND CLEANING
15 TROUBLESHOOTING
16 HINKLEY APP/WIFI
©2023 Hinkley Lighting, Inc. hinkley.com 1
TABLE OF CONTENTS
WARNING:
Read and follow these instructions carefully and be mindful of all warnings shown throughout.
READY
TO USE.
CONTROL
PRE-PAIRED.
NOTE: If PAIRING is necessary, refer to the control pairing instructions in the operations
section of this Instruction Manual.

hinkley.com
2
GENERAL INSTALLATION & OPERATION INSTRUCTIONS
To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning.
To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in
accordance with local codes, ordinances and/or the National Electric Code. If you are unfamiliar with the methods of installing electrical wiring
and products, secure the services of a qualified and licensed electrician as well as someone who can check the strength of the supportive
ceiling members and make the proper installation(s) and connections.
WARNING: To reduce the risk of fire, electric shock, or other personal injury, mount fan only on an outlet box or supporting system marked
acceptable for fan support of 35 lbs (15.9 kg) or less and use mounting screws provided with the outlet box. Most outlet boxes commonly used
for the support of lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a qualified electrician if in doubt.
Make sure that your installation site will not allow rotating fan blades to come in contact with any object. Blades should be at least 10 feet from
floor.
Blades should be attached before motor housing is hung and in place. Fan motor housing should be kept in the carton until ready to be
installed to protect its finish. If you are installing more than one ceiling fan, make sure that you do not mix fan blade sets, as each blade is part
of a weighted set.
After making electrical connections, spliced conductors should be turned upward and pushed carefully up into outlet box. The wires should be
spread apart with the common conductor and the grounding conductor on one side of the outlet box, and the “HOT” wires on the other side.
Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and should be installed per the light kit’s
installation instructions.
After fan is completely installed, check to make sure that all connections are secure to prevent fan from falling and/or causing damage or injury.
The fan can be made to work immediately after installation - the bearings are adequately charged with grease so that, under normal conditions,
further lubrication should not be necessary for the life of the fan.
CAUTION: Do not ingest battery - Chemical bum hazard. Keep new and used batteries away from children.
The remote control supplied with a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal bums in just
2 hours and can lead to death.
If the battery compartment does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
WARNING: To reduce the risk of fire or electric shock, this fan should only be used with fan speed control part no. JY1126T manufactured by
Satellite Electronic (Zhongshan) Ltd.
Note: Suitable for use in damp locations. Use only with light kits marked “Suitable for use in damp locations.”
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
