Hisense Babysense 5s User manual

Infant Movement Monitor
5S
Sensor | Do not use | Sensor
Slot
Illustration 6
Sensor|Do not use | Sensor
Hanging hook
Blue movement
indicator light Red alert
alarm light
Red low battery
warning light On/Off
button
I llustration 8
Speaker
Control
Unit
Cable Cable
Bed/Crib
base
Control unit holder
Illustration 5
13
2
Ensure you read this user guide before installing and
using the product.
Babysense is a high quality, high sensitivity
electronic device which must be handled with care:
• Do not handle roughly, drop or throw.
• Follow the installation instructions carefully to
ensure that it is installed securely and correctly.
• Babysense is not a toy. Do not allow children of any
age to play with it.
• Do not put any additional baby or pet in the bed.
Babysense cannot be used for two infants in one bed.
• You must undertake the performance test daily of
the Babysense monitor (as set out on page 3).
• Do not operate a vaporiser or ventilator directly
towards the bed.
• To avoid possible danger from sensor cords,
ensure that excess cords are pulled back under
the mattress, secured with the included cable tie
and are not visible or reachable.
• Install 4 new and identical size AA 1.5 volt batteries,
preferably alkaline.
• IMPORTANT: It is strongly advised that every
caregiver learn how to give first aid.
Babysense monitors and alerts, but cannot prevent
any type of distress. The responsibility for assistance and
applying first aid rests on caretakers, who must personally
check the baby as often as necessary. Babysense senses
movements and motion only, and cannot
monitor other occurrences. The purpose of the device
is to alert when stopping or slowing of movement
occur.
Babysense is a unique safety and reassurance system
which helps give parents peace of mind, alerting if
movements stop or become irregularly slow, giving
critical time to intervene. There are a number of
cautionary steps which are internationally
recommended for SAFE SLEEPING:
* Always lay your baby to sleep on his or her back.
* Refrain from smoking near or around your baby.
* Avoid over-heating of the baby's surroundings.
* Do not leave any objects near your baby that can
cause suffocation.
Babysense is an addition to these precautions.
Babysense is a movement monitor for home use,
intended for basically healthy infants up to one year
of age, and is not to be relied on for use with premature
or high-risk infants requiring constant medical supervision.
Babysense continually detects the baby's motion
and movements, and will set off a sound and visual
alarm if movement stops for 20 seconds or if
the monitor detects less than 10 micro-
mo vement s pe r mi nute. The system's non-touch
sensor pads under the mattress monitor baby's
movement without restraining him.
1. Insert, in accordance with the markings, 4 new and
identical size AA 1.5 volt batteries, preferable alkaline.
Close the battery cover.
Note: Do not mix old and new batteries.
Note: For replacing the batteries, remove the battery
cover by inserting a flat screwdriver into the opening
recess (see illustration 7).
Note: Please dispose of used batteries in accordance
with local waste regulations.
2. Place the control unit holder on the base of the
crib or bed and in between two bars as shown in
illustration 1.
3.Sensor pad installation:
• When using for an infant not yet able to crawl, place
one sensor pad as shown in illustration 2. Make sure the
sensor is placed underneath the baby's position in the
crib.
• When the baby begins to crawl, and is able to move
onto areas not "covered" by a single sensor pad, attach
the second sensor and place the two sensors as shown
in illustration 2.
PLEASE NOTE: The sensors shall be placed with the
marking “THIS SIDE UP” facing upwards.
Warnings
Principal Of Operation
Installation
Please note
7. Should the design of the crib/bed not allow proper
installation with the control unit holder, please use the
optional hanging hook (see illustration 6) and hang the
control unit from the bottom edge of the crib.
8. Press the control unit holder or hanging hook firmly
into the slot in the back of the control unit (see
illustration 5 and 6).
9. Place the mattress firmly on top of the sensor
pads. If the mattress cannot be in contact with the
sensor pads, or if the bed base is soft, padded or
contains springs, place extra plywood on the bed
base, place the sensor pads on the plywood and
place the mattress firmly on top (see section 4).
IMPORTANT: To avoid possible danger from sensor
cords, ensure that excess cords are pulled back
under the mattress, secured with the included cable
tie and are not visible or reachable.
See illustration 8 for layout of control unit featuring:
• On/Off button.
• Blue movement indicator light.
• Acoustic and visual red alarm light.
• Low battery red warning light.
Babysense is ready for operation and use once the
installation is complete. To operate, follow the
below instructions:
• Place your baby in the crib/bed.
• Press the On/Off button to turn on the control unit.
• Red lights switch on briefly and a double click
sound is heard.
• When any movement is sensed, the blue light
flashes.
User Guide
4. When using a crib/bed equipped with spring
base, place extra wooden board (plywood) under
each sensor pad, as shown in illustration 3. The
recommended size of the board is at least 17’’ x 11’’
and 1/2’’ thick.
5. Pass the cord(s) of the sensor pad(s) through
special openings in the holder. (see illustration 4)
6. Attach end(s) of the cord(s) to the outlets
marked "SENSOR" on the back of control unit
(see illustration 6 and 7). When using one sensor
pad, attach to either “SENSOR” outlet.
PLEASE NOTE: Do not attach any cable to the
blocked socket, marked "DO NOT USE"
Babysense is a highly sensitive device which
monitors a baby's motion and movements through
the mattress during sleep. There are two main
causes of malfunction - technical malfunctions and
malfunctions due to environmental factors.
In order to minimize technical problems, follow
installation and operation instructions carefully.
Due to the high sensitivity of Babysense, it can be
influenced by fans, wind, air conditioning,
vibrating household sources and so forth. Such
environmental effects could be picked up by the
sensors on a similar level to that of slight movements,
thus preventing or delaying alarm activation.
Do not conduct the performance test by picking up
baby out of bed and waiting for the alarm to sound
• The performance test should be conducted
while the baby is not in bed.
• Turn the unit on and take two steps back from bed.
• Ensure the alarm goes off within 20 seconds
(due to absence of movement).
• The alarm may sound with or without
preliminary ticking.
• Check the alarm can be heard in all locations
throughout the home or place of care.
• If the alarm does not sound within 20
seconds refer to the troubleshooting at page 4.
• The performance test must be conducted daily.
Isolated cases of false alarms are possible. Check if caused
by faulty connection of the sensor pad(s) to the control
unit, connection of only one sensor pad when the
baby is can move off the immediate area, connection
of two sensor pads far apart from each other when the
baby is not crawling yet, or failure of the sensor pads to
be directly against the mattress.
In case of false alarms, refer to the troubleshooting
guide. If the problem cannot be solved, please
contact your nearest BABYSENSE representative.
Sensor | Do not use | Sensor
Slot
Battery
cover
Blocked socket
DO NOT USE
“Sensor”
sockets
Illustration 7
Opening
recess
Speaker
Layout of control unit
Operation
Testing Operation
Technical malfunction
Environmentally caused malfunction
Conduct this performance test daily
False alarms
Cables
Illustration 4
Control unit
holder
Illustration 1
Control unit holder
Cables
Sensor
Sensor
Sensor pads
(Under mattress)
Control unit
Illustration 2
Top crib/bed view
For babies not
yet able to crawl
For crawling babies
Top crib/bed view
• Acoustic and visual red light alarms are activated
if the baby's movement stops or slows significantly.
• If the red low-battery warning light flashes,
replace all batteries as soon as possible. If in
addition clicking is heard, all batteries must be
replaced immediately.
• Turn off by pressing the On/Off button before
taking your baby out of crib/bed.
Plywood
Illustration 3
SensorSensor
Spring base
Top crib/bed view

This product is warranted to be free from defects in
material and workmanship for a period of (1) year
from the date of purchase, except as noted below.
BabySense LLC will repair or replace this product, at
our option, at no cost. This warranty does not apply to
product that has been damaged as a result of
improper maintenance or other misuse. This warranty
is also void if the owner repairs or modifies the
product in any way. BabySense LLC is not liable for any
incidental or consequential damage with regard to this
product. Warranty also excludes any liability other than
above. No other warranties are given. If you have a
claim under this warranty, do not return to the store.
Please contact BabySense customer service at:
[email protected]
Distributed by:
BabySense LLC
3910 Adler Place
Suite 115
Bethlehem, PA 18017
For additional information, please visit our website or
call the toll free number:
Website: www.babysensellc.com
Toll free number: 1-877-780-3033
Made by Hisense Ltd.
ISO 9001:2008 and ISO 13485:2003 certified
23, Becker St. Rishon le Zion 7535929, Israel
www.hisense.co.il
Limited 1 Year warranty
Since 1991
User Guide
English
4
V.BS5S.3.EN.4.15
• Baeries are not inserted
correctly or may be flat.
• Check baeries are inserted in the Control Unit observing the
correct polarity.
• Control Unit requires 4 X AA 1.5V Alkaline baeries (not supplied).
• Baeries low. • If red low-baery warning light flashes, replace all baeries as
soon as possible. If in addion clicking is heard, all baeries must
be replaced immediately.
• Sensor pad is out of order.
• Cable is connected to
monitor’s blocked socket.
• Connect one sensor pad lay the baby on the bed for 1 minute.
If the alarm does not acvate, the sensor pad is in order. If the alarm
acvates, disconnect and place the sensor pad aside.
• Connect the other sensor pad and repeat steps above.
• Do not connect any cables to the blocked socket (only to “SENSOR” socket).
• The maress is not
touching the sensor pads.
• Make sure that the maress and the sensor pads
are touching.
• The maress is raised (there is
an object near the sensor pads).
• Make sure that there are no objects next to the sensor pads
• Placing two sensors next to each
other or using one sensor when the
baby is of crawling age, or using two
sensor pads far apart from
each other when baby is young and
is not crawling yet.
• Connect according to instrucons.
• It is important to use only one sensor pad when the baby is young and is
not crawling yet.
• It is important to make sure that two sensor pads are used when the baby is
moving around.
• Make sure the sensors are placed directly underneath the baby's posion in
the bed/crib.
• The maress does not enable
transfer of baby movements. (a rigid
maress, a maress with springs or
a maress with air pockets).
• Place extra plywood under the sensor pad so that the sensor pad and
the maress will be ghtly pressed together (see page 2, secon 4).
• Performance test is not correct. • Do not conduct performance test by picking up the baby out of bed
and waing for the alarm to sound.
Kindly conduct performance test according to guidance in page 3.
• Environmental influences
detected by the sensor
pads, such as wind, fan, air
condioner, baby mobile toy,
vibraons.
• Perform a test which will detect the source of the movement that the
device detects. For example, sources of wind such as: air condioner, an
open window or a fan; movements of a baby mobile (which can vibrate
even if it's not turned on) walking around the bed area. Soluons:
Eliminate sources of wind, remove the baby mobile etc. Aer neutralizing
all environmental influences, perform the test again. If even aer
neutralizing all of the environmental influences, the alarm does not go
off within 20 seconds, perform the following:
1. Test the control unit:
- Disconnect all cables from the control unit.
- Turn control unit on (with no cables aached).
- Alarm acvaon within 20 seconds indicates that the unit is OK –
proceed to the next steps.
- If the alarm does not sound within 20 seconds, stop using the device
and contact your local distributor.
2. Test each sensor pad separately:
- Connect one sensor pad to either “SENSOR” socket on control unit.
- Turn control unit on and take two steps back from the bed.
- Alarm acvaon within 20 seconds indicates that the sensor is OK –
perform the above procedures with the second sensor pad.
- If the alarm does not sound within 20 seconds, place the sensor pad aside.
Note: If one of the sensor pads is NOT OK, connue using the product
with only the one correctly funconing sensor. If one or both sensors
are NOT OK, contact your local distributor for further guidance.
3. Test two sensor pads together:
- If both sensors were OK in Step 2, connect both sensors to “SENSOR”
sockets on the control unit.
- Turn control unit on and take two steps back from the bed.
- Alarm acvaon within 20 seconds indicates that the sensors are OK –
connue using the product.
- If the alarm does not sound within 20 seconds, connect one sensor only and
continue using the product. Contact your local distributor for further guidance.
Solution
Possible Cause
Symptom
Lights on Control Unit
don’t illuminate when
turned ON
Low baery warning
(red light) on the
Control Unit
False alarm up to 1/2
minute from acvang
False alarm aer 1/2
minute from acvang
Delayed alarms
while taking the baby
out of the bed
The alarm does
not go off within
20 seconds when
performing the
correct
performance test
Troubleshooting Guide
5
Other phenomena, symptoms, malfunctions – if you cannot find and solve the
problem, please contact us at www.babysensellc.com
Powered by 4 size AA, 1.5 volt batteries.
Power consumption approx. 1mA.
Battery life approx. 6 months using alkaline batteries.
Alarm volume typically 85dB SPL at distance of
3.5 feet.
Size of sensor pad is 216 mm.
Technical Specifications
Contents
• Control Unit
• Control Unit Holder
• Optional hanging hook
• 2 Sensor pads
• 2 Cable Ties
• User guide
Please note that the batteries are not supplied.
Babysense requires no special treatment beyond
replacing batteries when the battery indicator light
goes on. The sensor pads and control unit may be
wiped with a damp cloth.
Batteries should be removed and the device stored in
a dry shaded place when not in use.
Caring for your Babysense
It is recommended to replace sensors
every two years
Infant Movement Monitor
5S
