Hisense HRBF125S User manual

HRBF125
HRBF125S
HRBF125B

Contents
2
Installing your new appliance...................
Description of the appliance.....................
Controls...............................................
Using your appliance...............................
Helpful hints and tips...............................
Cleaning and car...................................e
Troubleshooting......................................
Disposal of the appliance.......................
8
9
9
10
11
12
13
14
Safety and warning information…........2
For your safety and correct usage before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
,
responsible for damages caused by omission.
Hisense Refrigerator
Safety for children and otherswho are vulnerable people
According to EN standard
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.

3
Hisense Refrigerator
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.

WARNING Risk of fire / flammable materials
:

5

6
Hisense Refrigerator
Do not place food products directly against the air outlet on
the rear wall.
The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant instructions
for storage.
Frozen food can cause frost burns if consumed straight from
the chill compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the chill compartment if
your hands are damp/wet,as this could cause skin abrasions
or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Do not consume ice popsicles or ice cubes straight from the
chill compartment as this can cause freezer burn to the
mouth and lips.
To avoid items falling and causing injury or damage to the
appliance, do not overload the door racks or put too much
food in the crisper drawers.
caution!
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam

Hisense Refrigerator
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be locate close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
Note: Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.(This clause applies only to the
EU region.)
7

50
8
Hisense Refrigerator
SN
50
For sufficient leveling and air circulating in
the lower rear section of the appliance, the
bottom feet may need to be adjusted.
To allow the doors to self-close,tilt the top
backwards by about 10mm.
180
Space necessary for free
circulation of air

9
Hisense Refrigerator
View of the appliance
Note:Due to unceasing modification of our products,your refrigerator may be slightly different from
this instruction manual,but its functions and using methods remain the same.
1.Screw hole
2.
3.Roll-bond evaporator
4.Water drain tray
5.Temperature controller
6.Glass shelf
7.Cabinet
8.Fruit and vegetable crisper
9.Bottom feet
10.Upper hinge cover
11.Refrigerator door
12.Upper shelf
13.Middle shelf
Insert the plug of the connection leadinto an outlet with protective earth contact.The temperature selector knob is located on the right side of the fridge.7HPSHUDWXUH &RQWURO
Thermostat
knob
Starting up and temperature
regulation
•Insert the plug of the connection lead
into the plug socket with a protective
grounding contact. When the
refrigerator compartment door is
opened, the internal lighting is
switched on.
•The temperature selector knob is
located on the RH side of the
refrigerator compartment.
Setting “0” means: Off
Clockwise rotate the knob to turn on the
appliance.
Setting “1” means:
Highest temperature, warmest setting.
Setting “7” means:
Setting “7” (end-stop) means: Lowest
temperature, coldest setting.
14.Lower shelf
15.Gasket part
Chiller room cover
(Chiller is not used as a freezer)

10
Hisense Refrigerator
Chiller compartment
It is suitable for storing pre-frozen food,
but it is not a freezer.
IMPORTANT!
Normally we advise you select settingof 4 , if you want the temperature
warmer or colder please turn the knobto lower or higher setting accordingly.Though the unit is energy efficient, it ismore efficient at lower positionsettings. IMPORTANT!
High ambient temperatures (e.g. on
hot summer days) and a cold setting on
the temperature regulator e.g.position
"7" , it can cause the compressor to
run continuously or even non-stop!
When the refrigerator is in use, the
compressor needs t o be on and off normally to ensure its defrosting. Therefore, we should avoid setting the refrigerator’s notch too high("7"’). If
you find the refrigerator frosts too much, please set the refrigerator’s notch lower. Remove all food. Unplug the power cord.
Clean and dry thoroughly.
Leave the door open slightly to
prevent odour and mould growth .months:
Vacation Tips: if the appliance
will not be used for several
There is one shelf in refrigerator
chamber,and they can be taken out to
be cleaned or get a larger space.

11
Hisense Refrigerator
necessary.
·
Don’t store warm food or evaporating
liquid in the appliance.
·Place the appliance in a well ventilated,
humidity free, room. Please refer to
Installing your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient configuration.
Hints for fresh food refrigeration
Do not place hot food directly into the
refrigerator , the internal temperature will
increase resulting in the compressor having
to work harder and will consume m ore
energy.
Do cover or wrap the food，particularly if it
has a strong flavor.
Place food properly so that air can
circulate f reely around it.
Meat (All Types) Wr ap in polythene food:
wrap and place on the shelf above the
vegetable drawer. Always follow food
storage times and use by dates suggested
by manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
Butter and cheese:
Should be wrapped in airtight foil or plastic
film wrap.
Milk bottles:
Should have a lid and be stored in the
door racks.
Switching off y our a ppliance
If the a ppliance needs to be switched off
for an extended period, the following steps
should be taken preventing mould on
the appliance.
1.Remove all the food.
2.Remove the power plug from the mains
socket.
3. Clean aand dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
Hints f or refrigeration

12
Hisense Refrigerator
Cleaning and care
For hygienic reasons the appliance
(including exterior and interior accessories)
Replaceing the lamp bulb(or LED):
Warning:The LED must not be replaced
by the user! If the LED is
damaged,contact the customer helpline
for assistance.
remove frost from the chill

13
Hisense Refrigerator
please see below.
.
.
.

14
Hisense Refrigerator
The Lamp bulb (or LED) may be damaged. Refer to replace
Lamp bulbs (or LED) in cleaning and care chapter
food in chill compartment
is not freezering or
staying frozen
chill compartment is not a freezering and is not designed to
freeze food or keep food frozen.Do not attempt to freeze
food in this compartment.

Hisense Refrigerator
To avoid contamination of food, please respect the following instructions
Opening the door for long periods can cause a significant increase of the temperature
in the compartments of the appliance.
systems.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
- Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making icecream and making ice cubes.
- One-, two- and three-star compartments are not suitable for the freezing of fresh food.
-
- Clean regularly surfaces that can come in contact with food and accessible drainage
Order Compartments
TYPE
Target storage
temp.[℃]Appropriate food
1Fridge
Eggs, cooked food, packaged food, fruits and
vegetables, dairy products, cakes, Drinks and
other foods which are not suitable for freezing.
2≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended time is 3 months – nutrition
values and taste decrease with time), suitable
3≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
（recommended time is 3 months – nutrition
values and taste decrease with time). Not
suitable for freezi ng fresh food．
4≤-12
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
（recommended time is 2 months – nutrition
values and taste decrease with time). Not
suitable for freezing fresh food.
5≤-6
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
（recommended time is 1 month – nutrition
values and taste decrease with time). Not
suitable for freezing fresh food.
6Zero-star -6 0
Fresh pork, beef, fish, chicken, some packaged
processed foods, etc. (Recommended to eat
within the same day, preferably not later than
3 days) .
Partially packed/wrapped up encapsulated
processed foods (non-freezable foods)
7Chill -3~
+3
Fresh/frozen pork, beef, chicken, freshwater
aquatic products, etc.(7 days below 0 ℃and
above 0 ℃is recommended for consumption
within that day, preferably no more than 2 days).
Seafood (less than 0 for 15 days, it is not
recomm ended to store above 0 ℃)
15
~
Four-star
Three-star
Two-star
One-star
for freezing fresh food.
≤+ 4

8Fresh Food 0 +4
Fresh pork, beef, fish, chicken, cooked food, etc.
(Recommended to eat within the same day,
preferably no more than 3 days)
9Wine +5 +20
red wine,white wine,sparkling wine etc.
Water dispenser cleaning (special for water dispenser products):
- Clean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould developing within the appliance.
Note: please store different foods according to the compartments or target storage
temperature of your purchased products.
Hisense Refrigerator
WARNING! Food needs to be packed in bags before putting into the refrigerator, and
liquids need to be packed in bottles or capped containers to avoid the problem that
the product design structure is not easy to clean.
~
~
16

4233516
