Hisense RB403N4EW1 Operation instructions

RB403N4EW1
RB403N4EY1
RB403N4EC1
RB403N4EC2

Contents
Brief introduction
Important safety instructions
General safety and daily use ●
Don't try to repair the appliance
yourself. It is dangerous to alter the
specifications or modify this product in
any way. Any damage to the cord may
cause short circuit, fire or electric
shock.
Pay attention not to damage the
tubing of the refrigerant circuit.
Don't place too much food directly
against the air outlet on the rear wall of
both the refrigerator and freezer
compartment, as it affects sufficient air
circulation.
●
●
recommend that you follow the
guidelines below.
Store any food in accordance with the
storage instructions from the
manufacturer.
Don't use mechanical devices or any
other means to speed up the defrosting
process, unless they are approved by
the manufacturer.
It is important to use your
appliance safely. We
CE notice
This product has been determined to be in compliance with the Low Voltage
Directive(2006/95/EC),the Electromagnetic Compatibility Directive(2004/108/EC)and
the Eco-Design Directive(2009/125/EC) implemented by Regulation(EC) No
643/2009 of the European Union
This appliance is intended to be used
in household and similar applications
such as:
-Staff kitchen- areas in shops, offices
and other working environments;
-Farmhouses by clients in hotels,
motels and other residential types of
environment;
-Bed and breakfast type of
environments.
If you feel that the appliance is not
operating correctly, please check the
Troubleshooting page for assistance. If
still in doubt contact the customer
service help line for assistance or to
arrange a call out by an authorized
service engineer.
●
●
Thank you for your choosing our
products. We are sure you will find
your new appliance a pleasure to use.
Before you use the appliance, we
recommend that you read through
these instructions carefully, which
provides details about its usage and
functions.
Please ensure that all people using
this appliance are familiar with its
operations and safety features. It is
important that you install the appliance
correctly and pay attention to the safety
instructions carefully.
We recommend that you keep this
user's manual with the appliance for
future reference and retain it to any
future users
●
●
Hisense Refrigerator
2
Brief introduction……………………….2
Important safety instructions…………2
Installing your new appliance………...4
Description of the appliance………….9
Display controls……………………...11
Using your appliance…………………13
Helpful hints and tips……………… 14
Cleaning and care……………………15
Troubleshooting………………………16
Disposal of the appliance……………18

Safety for children and infirm persons
Safety about electricity
●
●
●
●
●
●
●
●
●
●
Unpack the appliance and check
through the appliance. Should any
damage be evident, don't plug in the
appliance but contact the shop
immediately from which you purchased
it. Keep all packing materials in this
case.
We recommend that you wait for 4
hours before connecting the appliance
to allow the refrigerant to flow back into
the compressor.
The appliance must be applied with
single phase alternating current of
220~240V/50Hz. If the voltage
fluctuates exceeding the upper limit,
A.C. automatic voltage regulator of
more than 350W should be applied to
the refrigerator for safety use.
The mains plug must be accessible
when the appliance is installed.
This appliance must be earthed.
-This appliance is fitted with a fused
plug in accordance with local
standard. The fused plug should be
suitable for use in all houses fitted
with sockets in accordance with
current specifications.
-If the fitted plug is not suitable for
your socket outlets, it should be cut
off and carefully disposed of. To avoid
a possible shock hazard, do not insert
the discarded plug into a socket. If in
doubt contact a qualified, registered
electrician.
Do not use extension cords or
multiple sockets which could cause
overloading of wiring circuits and could
cause a fire.
Always plug your appliance into its
own individual electrical socket which
has a voltage rating that matched the
rating plate.
Make sure that the plug is not
squashed or damaged. Otherwise, it
may cause short circuit, electric shock
or overheat and even cause a fire.
Do not insert the mains plug if the
socket is loose, there is a risk of
electric shock or fire.
●
●
Don't place hot items near the plastic
components of this appliance.
Frozen food must not be refrozen once
it has been thawed out.
Don't store bottled or canned drinks
(especially carbonated drinks) in the
freezer compartment. Bottles and cans
may explode.
Do not consume ice popsicles or ice
cubes straight from the freezer as this
can cause freezer burn to the mouth
and lips.
To avoid items falling and causing
injury or damage to the appliance, do
not overload the door racks or put too
much food in the crisper drawers.
●
●
This appliance can be used by
children aged from 8 years old
above and persons with reduced
physical, sensory or mental
capabilities, or lack of experience and
knowledge, If they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance.Cleaning and user
maintenance shall not be made by
children without supervision.
Keep all packaging away from
children to avoid risk of suffocation.
Protect children from being scalded
by touching the very hot compressor at
the rear bottom of appliance
Don't place items on top of the
appliance as this could cause injury
should they fall off.
Never allow children to play with the
appliance by hanging or standing over
or on the doors, racks, shelves and
drawers etc.
●
●
●
To avoid the risks that are
always present when using an
electric appliance, we recommend that
you pay more attention to the
instructions about electricity below.
Hisense Refrigerator
3
Keep ventilation openings clear of
obstruction.

The refrigerant and risk of fire
Installing your new appliance
Ventilation of appliance
●
●
●
●
●
●
●
●
●
●
●
75
100
100
Before using the appliance for the first
time, you should be informed of the
following tips.
In order to improve efficiency
of the cooling system and save
energy, it is necessary to maintain
good ventilation around the appliance
for the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest :It is advisable for there to be
at least 75mm of space from the back
to the wall, at least 100mm from its
top,at last 100mm from its side to the
wall and a clear space in front to allow
the doors to open 135°. As shown in
following diagrams.
Note:
This appliance performs well within
the climate class showed in the table
below.
in the refrigerant circuit. Check the
compressor label on the rear of the
appliance to see which refrigerant is
used for your appliance.
If the appliance contains iso-butane
(R600a) refrigerant, which is
environmentally friendly but flammable,
ensure that tubing of the refrigerant
circuit is not damaged during
transportation and installation to avoid
risk of fire caused by leaking
refrigerant.
Keep burning candles, lamps and
other items with naked flames and
sources of ignition away from the
appliance and ventilate the room
thoroughly to avoid the risk of fire and
eye injury should any leakage of
refrigerant (R600a) exist.
Do not store products which contain
flammable propellants (e.g. spray
cans) or explosive substances in the
appliance.
The room space must be at least 1m³
per 8g of refrigerant (R600a). The
amount of refrigerant in your appliance
is indicated on the rating plate inside.
Switch off the appliance and
disconnect it from the mains power
before you clean or move it.
Never unplug the appliance by pulling
on the electrical cord. Always grip the
plug firmly and pull straight out from
the socket to prevent damaging the
power cord.
Do not operate the appliance without
the light cover of interior lighting.
Any electrical component must be
replaced or repaired by a qualified
electrician or authorized service
engineer. Only genuine spares should
be used.
Do not use electrical appliances such
as ice cream makers inside the food
storage compartments of the
appliance, unless they are approved
by the manufacturer.
Do not look direct into the LED light
located in the refrigerator compartment
with optical instruments to avoid eye
injuries. If it is not functioning correctly,
consult a qualified, registered
electrician or replace it in accordance
with the “cleaning and care” chapter.
The appliance contains a
small quantity of refrigerant
(R600a or R134a)
100
100
Hisense Refrigerator
4
755
1283
1004

Climate class Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
It may not work properly if being left at
a temperature above or below the
indicated range for a long period.
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct
sunlight，rain or frost. Stand the
appliance away from heat sources
such as stoves, fires or heaters.
Leveling of appliance
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. You can adjust
them manually by hand or by using a
suitable spanner.
To allow the doors to self-close, tilt
the top backwards by about 10mm.
●
●
●
●
Reversing the door
The side at which the door opens can
be changed, from the right side (as
supplied) to the left side, if the
installation site requires.
Warning! When reversing the door, the
appliance must not be connected to
the mains. Ensure that the plug is
removed from the mains socket..
Tools you will need
8mm socket wrench Cross-shaped screwdriver
8mm wrench
Thin-blade screwdriver
Note: Before you start lay the
refrigerator on its back in order to
gain access to the base, you should
rest it on soft foam packaging or
similar material to avoid damaging
the backboard of the refrigerator. To
reverse the door, the following steps
are generally recommended.
1. Stand the refrigerator upright.
Open the upper door to take out all
door racks (to avoid racks damaged)
and then close the door.
≤10mm
Hisense Refrigerator
5
Door racks
2. Open part ① on top of the
refrigerator body from right side and
then take down part ③ and part ④ on
the upper door in the same way. Take
down part ② and put it back to the
plastic bag.

③Upper cover of upper door
②Upper hinge cover (right)
①Upper cover
④Corner cover
3. Take down the corner cover.
Note: Please hold the upper door by hand
during step 4 to prevent door dropping.
4. Remove the screws ①, and
remove part②.
5. Remove the upper door and place it
on a smooth surface with its panel
upwards. Loose screws③, detach part
② and part ①then install part ①and
another part (in the plastic bag)to the
left side with screws③.Put part②just
detached back to plastic bag.
②
6. Loose screws used to fix the middle
hinge and remove middle hinge. Then
remove the lower door.
1 2
3
3
Special flange self-tapping
screws
②
③
①
② Stop block
③ Self-tapping screws
① Door holder
Hisense Refrigerator
6
①
②part
1
7. Place the lower door on a smooth
surface with its panel upwards. Loose
screws③detach part②and part
①.Turn part①by 180°and then install
①and part②to corresponding position
on left side together with screws③.
，

8. Change screw hole covers on
middle cover plate from left to right (as
shown in figure below).
9. Place refrigerator flatwise, remove
part③ and then loose screws④.
Remove part ② and part①.
10. Screw out lower hinge, change it to
the near hole site, and then screw up
and mount washer.
② Front foot fixed board
④ Self-tapping screws
③ Adjustable bottom feet part
① Lower hinge part（right）Note: washer may
stick to lower door.
washer
Lower hinge part (left)
Note: washer may
stick to lower door. Washer
11.Just remount to the step 9,change
part①to left and part②to right and then
fix them with screws④. Finally install
part③.
12. Move the lower door and adjust its
position to align lower hole site and
upper hinge axis. Turn the middle
hinge by 180, change the washer on
the axis to the upper side, adjust the
middle hinge to the appropriate
position and then install it.
13. Screw out The upper hinge axis,
turn the upper hinge over and fix axis
on it. Then place it at side for use.
12
Hisense Refrigerator
7
② Stop block
③ Self-tapping screws
① Door holder
②
③
①

14. Move the upper door to appropriate
position, adjust part① and upper door,
then fix part① by screws②. (Please
hold upper door by hand when
installing)
①
②
15. Install part the upper hinge
cover(which is in the plastic bag).
16.Reverse part① by 180°and install it
onto the right corner of upper door，
then mount part②. (both of which are
taken down in step 2)
18. Open the upper door, mount door
racks and then close it.
upper hing e cover(left )
1 2
1 1
2
Hisense Refrigerator
17. install part①, and then install
part②
8

Description of the appliance
Cabinet
2.Display board part
3.KED light
4.Glass shelf
5.Crisper cover
6.Fruit and vegetables crisper
7.Upper freezer drawer
8.Upper freezer glass shelf
9.Middle freezer drawer(huge box)
10.Middle freezer glass shelf
11.Lower freezer drawer
12.Adjustable bottom feet
13.Fridge door
14.Egg tray(in the shelf)
15.Middle fridge door shelf
16.Lower fridge door shelf
17.Fridge door seal
18.Freezer door seal
19.Freezer door
1. View of the appliance
RB403N4EW1
RB403N4EY1
RB403N4EC1
Hisense Refrigerator
Note: Due to unceasing modification of our products, your refrigerator may be
slightly different from this instruction manual, but its functions and using methods
remain the same. To get more space in the freezer, you can remove drawers
(except lower freezer drawer),installtion bracket and integrative ice maker/twistable
ice tray.
Note1: RB403N4EW1 for white panels
Note2: RB403N4EY1 for gouache yellow panels
Note3: RB403N4EC1 for imitation stainless panels
9

Description of the appliance
Cabinet
2.Display board part
3.KED light
4.Glass shelf
5.Crisper cover
6.Fruit and vegetables crisper
7.Crisper cover of Moisture 0 Cool
8.Moisture 0 Cool
9.Upper freezer drawer
10.Upper freezer glass shelf
11.Middle freezer drawer(huge box)
12.Middle freezer glass shelf
13.Lower freezer drawer
14.Adjustable bottom feet
15.Fridge door
16.Egg tray(in the shelf)
17.Middle fridge door shelf
18.Lower fridge door shelf
19.Fridge door seal
20.Freezer door seal
21.Freezer door
1. View of the appliance
RB403N4EC2
Hisense Refrigerator
Note: Due to unceasing modification of our products, your refrigerator may be
slightly different from this instruction manual, but its functions and using methods
remain the same. To get more space in the freezer, you can remove drawers
(except lower freezer drawer),installtion bracket and integrative ice maker/twistable
ice tray.
10
