Hisense RS723N4WCU Mounting instructions

MODEL NUMBER
Before operating this unit, please read this manual thoroughly,
and retain for future reference
RS723N4WCU

so that anyone using it,
throught its life ,will be
properly informed on its
usage and safety notices.
15
19

warining - Fill with
potable water only!

compressor.
Adequate air circulation
should be around the
appliance, lacking this leads
to overheating. To achieve
sufficient ventilation, follow
the instructions relevant to
installation.
Wherever possible the back
of the product should not be
too close to a wall to avoid
touching or catching warm
parts (compressor,
condenser) to prevent the
risk of a fire, follow the
instructions relevant to
installation.
The appliance must not be
locate close to radiators or
cookers.
Service
Any electrical work required
to do the servicing of the
appliance should be carried
out by qualified electrician or
competent person.
This product must be
serviced by an authorized
Service Center, and only
genuine spare parts must be
used.
1)If the appliance is Frost
Free.
2)If the appliance contains
freezer compartment.
Make sure that the mains
plug is accessible after the
installation of the appliance.
7

8

Description of the appliance
View of the appliance
1. Freezer zone LED light 11. Fresh zone LED light
3. Freezer door Rack (two star zone)
12. Wind channel cover in fresh
Note: Due to unceasing modification of our products, your refrigerator may be slightly
different from this Instruction Manual, but its functions and using methods remain
2. Wind channel cover in freezer
13. Water tank
4. Freezer shelf 14. Fresh shelf
5. Temperature regulator(on freezer door)
15. Wine rack (optional)
7. Freezer door gasket
8. Freezer drawer 18. Fresh door gasket
9. Freezer door Rack 19. Bottles block stripe (optional)
16. F resh door Rack
6.Movable twist ice-maker (optional)
17. Fruit and vegetables Crisper
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
10. Adjustable feet 20. Bottom cover
9
the same.

10

11

12

The water dispenser located in the fridge
door, is for storing drinking water. With this
appliance you can obtain chilled water
easily without opening the refrigerator. You
should be informed of following tips.
Before using
Before using this appliance for the first time,
you should use it as follows.
1. Hold one bottom side of the water tank
by a hand, lift up the opposite side by the
other hand,when the slot of the water tank
2. Hold the two sides of the water tank
tightly, lift up and put out of the water tank.
is off from the guide, change hands to
3. Unscrew the head, then clean head ,lids
and the water tank.
Caution!
Drain the water tank befor you take it down!
Assembling
After cleaning, please assemble the parts
including the head, water tank and lids as
follows:
1. Put the seal ring in order first ( the seal
2. Hold the two sides of the water tank
tightly, fit the water tank along the guids
4. When you hear clicks by both sides and
the same time the both sides of the waterat
is closed to the door liner, It means the tank
installation is completed.
3. Push the two sides of the water tank
downward as the picture shows.
seal ring
ring can not turn up), then insert the head
into the hole.
repeat these steps.
guide
slot
head
on the door.
Filling water
Before you fill the drinking water into the
water tank, ensure that the water tank is
steady and in a correct position.
13

Warning!
Don’t touch the other parts of the
appliance when filling water, it may
cause the water leakage.
Dispensing water
1.Make sure the cover of the water tank
is fitted on.
2.Close the fridge door and check the
dispenser.
Before you dispense the water, make
sure the lock device is on the “Unlock”
Warning!
The lock is defined as “child lock”.
Don’t push the dispenser lever forward
strongly, when the dispenser is on “Lock”
situation, it may damage the mechanism.
Receiving Water
You should use the correct cups to receive
water underneath the water dispenser.
Caution!
Fill with water up to 4L ( which is
suggested) and not above the level.
Otherwise, it may overflow when the lids
We recommend that you fill the water by
the following ways.
1.Remove the small lid and fill water from
the inlet of the larger lid.
2.Remove the cover of the rank, and then
fill water inside directly.
is closed.
appliance, you should dry it by natura
drying or using the dryer. If you have used
the water dispenser for many times, the
water in the receiving tank may drop on the
Warning!
Don’t push the dispenser lever forward
without cup, it may cause the water leakage
from the dispenser.
Cleaning
1.Put the water tank out of the door
carefully and then wash the tank, lid, and
head lightly in water.
2.After you have successfully cleaned the
floor, which may make your floor wet, and
you should clean the tank with dry towel
regularly before overflow.
situation.
14

They should be wrapped in airtight foil or
plastic film wrap
15

16

17

18

Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental
safe recycling.
