Hisense H4 series User manual

Hisense •Roku TV
H4 Model Series
User Manual
This user manual contains all of the informaon that you need to
set up, use, maintain and enjoy your TV.

Copyright statement
© 2014 Hisense Company Ltd. and Roku, Inc. All rights reserved. ROKU, the ROKU Logo, “HAPPY STREAMING.”, and
“NOW THIS IS TV.” are trademarks and/or registered trademarks of Roku, Inc. in the United States and other
countries. Material in this User Manual is the property of Hisense Company Ltd. and its subsidiaries, and Roku, Inc.,
and is protected under US and International copyright and/or other intellectual property laws. Reproduction or
transmission of the materials, in whole or in part, in any manner, electronic, print, or otherwise, without the prior
written consent of the Hisense Company Ltd. and Roku, Inc. is a violation of Hisense Company Ltd. and Roku, Inc.’s
rights under the aforementioned laws.
No part of this publication may be stored, reproduced, transmitted or distributed, in whole or in part, in any
manner, electronic or otherwise, whether or not for a charge or other or no consideration, without the prior
written permission of Roku, Inc. and Hisense Company Ltd.
Requests for permission to store, reproduce, transmit or distribute materials may be made to the following
addresses:
Hisense USA Corporation
7310 McGinnis Ferry Road
Suwanee, GA 30024
Roku, Inc.
12980 Saratoga Ave., Suite D
Saratoga, CA 95070
Hisense, Roku, Inc., and any and all other Hisense or Roku, Inc. product names, logos, slogans or marks are
registered trademarks of Hisense Company Ltd. and its subsidiaries and Roku, Inc. All other trademarks are the
property of their respective holders.
ii

Disclaimers
**Notwithstanding anything to the contrary, including in any or all descriptions, representations, statements or
other communications related to this Hisense device (hereinafter “Device”) made in any form whatsoever and at
any time, some or all of the pre-installed, or subsequently installed Application Services may not be available or
capable of functioning as intended by the provider of the Application Services in any or all usage areas for reasons
outside of Hisense’s control, including but not limited to, Internet access, local service limitations, etc. Any
purchase or use of the Device, including any Application Services, is purely at the user’s risk. Application Services
are provided on an as-available basis without warranties of any kind, either expressed or implied, that the
Application Service will be uninterrupted or error-free, including but not limited to vagaries of weather, disruption
of Service, acts of God, warranties of title, local or regional limitations, no infringement, NOR IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. No advice or information given by
Hisense, providers, affiliates, or contractors or their respective employees shall create such a warranty. Hisense
specifically disclaims responsibility for any or all Application Services from functioning at any time, and by
purchasing the Device, you accept such disclaimer without any claim on Hisense. You are solely responsible for
providing an active and working connection to the Internet, along with any and all hardware and/or software
necessary to use the Hisense Device as intended.
**Illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specification may be changed without notice.
iii

Important Safety
Instructions
FCC statement
NOTE:
This equipment has been tested and found to
comply with the limits for a class B digital Device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio Communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the
equipment and the receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.
FCC ID Number for wireless networking module:
TC2-N1002
The wireless networking module complies with
FCC radiation exposure limits set forth for an
uncontrolled environment. This device should be
installed and operated with a minimum distance
of 20 centimeters between the radiator and your
body.
This TV incorporates High-Definition Multimedia
Interface (HDMITM) technology.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
Hisense and associated logos where applicable
are registered trademarks of Hisense Group in
the United States and/or other countries. All
iv
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufcient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

other trademarks are property of their respective
owners. © 2014 Hisense USA, Corporation. All
Rights Reserved.
* Specifications subject to change without notice.
Energy Star
Your Hisense TV is ENERGY STAR ®qualified in the
”ECO” mode. It meets strict energy efficiency
guidelines set by the U.S. Environmental
Protection Agency and Department of Energy.
ENERGY STAR is a joint program of these
government agencies, designed to promote
energy efficient products and practices. Changes
to certain features, settings, and functionalities of
this TV (i.e. TV Guide, Picture, Sound) can
increase or change the power consumption.
Depending upon such changed settings, the
power consumption may exceed the limits
required for the ENERGY STAR qualification in the
“ECO-mode”.
NOTE
Where the MAINS plug or an appliance coupler is
used as the disconnect device, the disconnect
device shall remain readily operable.
WARNING
The manufacturer is not responsible for any radio
or TV interference caused by unauthorized
modifications to this equipment. Such
modifications could not void the user’s authority.
Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
v

CHILD SAFETY:
It Makes a Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy our new product, please keep these safety tips
in mind:
THE ISSUE
The home theater entertainment experience is a growing trend
and larger flat panel displays are a popular purchase. However,
flat panel displays should always be supported on the proper
stands or installed according to the manufacturer’s
recommendations.
Flat panel displays that are inappropriately situated on
dressers, bookcases, shelves, desks, speakers, chests or carts
may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
•One size does not fit all. Follow the manufacturer’s recommendations for the safe installation
and use of your flat panel display.
•Carefully read and understand all enclosed instructions for
proper use of this product.
•Don’t allow children to climb on or play with furniture and
television sets.
•Don’t place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
•Remember that children can become excited while watching a
program – especially on a larger-than-life flat panel display.
Care should be taken to place or install the display where it
cannot be pushed, pulled over or knocked down.
•Care should be taken to route all cords and cables connected
to the flat panel display so that they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY,
ALWAYS:
•Use a mount that has been recommended by the display manufacturers and/or listed by an
independent laboratory (such as UL CSA, ETL)
•Follow all instructions supplied by the display and wall mount manufacturers.
vi

•If you have any doubts about your ability to safely install
your flat panel display, contact your retailer about
professional installation.
•Make sure that the wall where you are mounting the display
is appropriate. Some wall mounts are not designed to be
mounted to walls with steel studs or old cinder block
construction. If you are unsure, contact a professional installer.
•A minimum of two people are required for installation. Flat panel displays can be heavy.
vii

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. Apparatus should not be exposed to dripping
or splashing, and objects filled with liquids,
such as vases, should not be placed on the
apparatus.
16. An outside antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power circuits,
or where it can fall into such power lines or
circuits. When installing an outside antenna
system, extreme care should be taken to
keep from touching such power lines or
circuits, as contact with them might be fatal.
17. Do not overload wall outlets and extension
cords, as this can result in a risk of fire or
electric shock.
18. Do not push objects through any openings in
this unit, as they may touch dangerous
voltage points or short out parts that could
result in fire or electric shock. Never spill or
spray any type of liquid into the unit.
19. If an outside antenna or cable system is
connected to the unit, be sure the antenna or
cable system is grounded to provide some
protection against voltage surges and built-
up static charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding
of the mast and supporting structure,
grounding of the lead-in wire to an antenna
viii
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufcient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

discharge unit, size of grounding conductors,
location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
20. When replacement parts are required, be
sure the service technician uses replacement
parts specified by the manufacturer or those
that have the same characteristics as the
original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.
21. Upon completion of any service or repairs to
this unit, ask the service technician to
perform safety checks to determine that the
unit is in proper operating condition.
22. When you connect the product to other
equipment, turn off the power and unplug all
of the equipment from the wall outlet.
Failure to do so may cause an electric shock
and serious personal injury. Read the owner's
manual of the other equipment carefully and
follow the instructions when making any
connections.
23. Sudden high volume sound may cause
hearing or speaker damage. When you use
headphones, (if the unit is equipped with a
headphone jack) keep the volume at a
moderate level. If you use headphones
continuously with high volume sound, it may
cause hearing damage.
CONDENSATION:
Moisture will form in the operating section of the
unit if the unit is brought from cool surroundings
into a warm room or if the temperature of the
room rises suddenly. When this happens, unit's
performance will be impaired. To prevent this, let
the unit stand in its new surroundings for about
an hour before switching it on, or make sure that
the room temperature rises gradually.
Condensation may also form during the summer
if the unit is exposed to the breeze from an air
conditioner. In such cases, change the location of
the unit.
HOW TO HANDLE THE LCD PANEL:
Do not press hard or jolt the LCD panel. It may
cause the LCD panel glass to break and injury may
occur.
If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
If the liquid gets in your mouth, immediately
gargle and consult with your doctor. Also, if the
liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
Possible adverse effects on LCD panel:
If a fixed (non-moving) pattern remains on the
LCD Panel for long periods of time, the image can
become permanently engrained in the LCD Panel
and cause subtle but permanent ghost images.
This type of damage is NOT COVERED BY YOUR
WARRANTY. Never leave your LCD Panel on for
long periods of time while it is displaying the
following formats or images:
•Fixed Images, such as stock tickers, video
game patterns, TV station logos, and
websites.
•Special Formats that do not use the entire
screen. For example, viewing letterbox
style (16:9) media on a normal (4:3) display
(black bars at top and bottom of screen); or
viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on
left and right sides of screen).
ix

The following symptoms are not signs of malfunction but technical limitation. Therefore,we disclaim
any responsibility for these symptoms.
LCD Panels are manufactured using an extremely
high level of precision technology; however,
sometimes parts of the screen may be missing
picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic
equipment that produces electromagnetic waves.
Some equipment placed too near this unit may
cause interference.
Effect on infrared devices - There may be
interference while using infrared devices such as
infrared cordless headphones.
Declaration of conformity
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received including interference that may
cause undesired operation.
End of life directives
Your TV also contains material that can be
recycled and reused. For disposal or recycling
information, contact your local authorities or the
Electronic Industries Alliance at
www.eia.org to find a recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp
video quality. Occasionally, a few non-active
pixels may appear on the screen as a fixed black
(in the case of a dead pixel), blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV, and are not
considered defects.
Power source
TO USE AC POWER
1. The power cord is attached to the TV at
the factory.
2. Connect the AC cord into an AC outlet.
WARNING
Do not connect this unit to the power using any
device other than the supplied AC cord. This
could cause fire, electrical shock, or damage.
Do not use with a voltage other than the power
voltage specified. This could cause fire, electrical
shock, or damage.
CAUTION
When this unit is not used for a long time, (e.g.,
away on a trip) in the interest of safety, be sure
to unplug it from the AC outlet.
Do not plug/unplug the AC cord when your hands
are wet. This may cause electrical shock.
x

Table of Contents
Important Safety Instructions ...................................................................................................................... iv
Welcome to Hisense • Roku TV .................................................................................................................... 1
Package contents ...................................................................................................................................... 1
Required tools and devices ....................................................................................................................... 2
Lifting and moving the Hisense • Roku TV................................................................................................ 2
Installing the stand on your Hisense • Roku TV........................................................................................ 2
Installing a wall mount bracket (not included) ......................................................................................... 2
Locating ports and buttons on your Hisense • Roku TV............................................................................... 4
Buttons and ports on the Hisense • Roku TV ........................................................................................... 4
Connecting devices to your Hisense • Roku TV ........................................................................................ 5
Simplified TV… Endless entertainment......................................................................................................... 9
The new standard in Smart TVs ................................................................................................................ 9
Get the most out of your new Hisense • Roku TV.................................................................................... 9
Guided Setup...............................................................................................................................................11
Connected Hisense • Roku TV Home Screen..........................................................................................18
Non-connected Hisense • Roku TV Home screen...................................................................................19
Benefits of connecting ................................................................................................................................ 20
Connecting brings out the full potential of your Hisense • Roku TV!.....................................................20
What is streaming? .................................................................................................................................21
But what if I didn’t connect my Hisense • Roku TV? ..............................................................................22
Setting up Antenna TV ................................................................................................................................ 23
Why do I have to set up the TV tuner? ................................................................................................... 23
How do I set up the TV tuner? ................................................................................................................23
Using your Hisense • Roku TV..................................................................................................................... 27
Hisense • Roku TV status light ................................................................................................................27
Hisense • Roku TV panel buttons ...........................................................................................................28
Standby mode energy savings ................................................................................................................ 28
Hisense • Roku TV Remote control.........................................................................................................29
Getting around........................................................................................................................................29
Watching broadcast TV channels............................................................................................................ 32
Switching TV inputs.................................................................................................................................34
xi

Playing content from USB storage devices .............................................................................................34
Playing content from local network media servers ................................................................................34
Adjusting Hisense • Roku TV settings .........................................................................................................36
Settings menu .........................................................................................................................................36
Options menu..........................................................................................................................................37
Advanced picture settings....................................................................................................................... 38
Searching for movies and shows.................................................................................................................41
How do I search?.....................................................................................................................................41
I found a show, now what?.....................................................................................................................42
Using the Roku Channel Store .................................................................................................................... 43
Customizing your Hisense • Roku TV..........................................................................................................44
Rearrange tiles ........................................................................................................................................44
Edit broadcast TV channel lineup ........................................................................................................... 45
Rename inputs ........................................................................................................................................46
Remove unwanted tiles ..........................................................................................................................46
Change themes .......................................................................................................................................47
Change sound effects volume.................................................................................................................47
Configure power settings........................................................................................................................47
Configure parental controls ....................................................................................................................48
More settings.............................................................................................................................................. 55
Changing network settings...................................................................................................................... 55
Changing caption settings....................................................................................................................... 56
Changing time settings............................................................................................................................57
Scanning for broadcast TV channels again ............................................................................................. 58
Using the Hisense • Roku TV in a home theater..................................................................................... 58
Restarting the Hisense • Roku TV ...........................................................................................................61
Resetting the Hisense • Roku TV ............................................................................................................61
Getting system updates ..........................................................................................................................62
Other devices ..............................................................................................................................................65
Getting and using the Roku mobile app..................................................................................................65
Using a universal remote ........................................................................................................................65
FAQ..............................................................................................................................................................66
Quick problem-solving tips ......................................................................................................................... 67
Legal statement ..........................................................................................................................................69
xii

Welcome to Hisense • Roku
TV
Congratulations on the purchase of your new Hisense • Roku TV! This User Manual provides information
about the numerous features and instructions to connect devices to your TV, attach the TV stand,
complete the Guided Setup, configure your settings, stream content and much more.
Because we value your business, we want to keep you in the know of ‘all things Hisense’. Using your
mobile phone, scan the first QR code to register your TV and the second QR code to access the Support
page. Depending on the make and model of your phone, you may need to download a QR code scanning
application.
You can also access the Product Registration or Support page by visiting http://www.hisense-
usa.com/support or www.hisense-usa.com/support/productreg.asp
Product Registration page QR code Product Support page QR code
Package contents
IMPORTANT: Look inside the styrofoam (within the upper and bottom parts of the box) to make sure
that you have removed all items that come with the TV.
Your package in which you purchased this Hisense • Roku TV contains the following items:
•Hisense • Roku TV (with the Power cord attached)
•TV stand cover
•TV stand base
•Hisense Roku TV Quick Start Guide
•Important Safety Information and Warranty Card leaflet
•2 AAA batteries for the remote
•Hisense • Roku TV Remote
•8 Phillips screws (total): 4 (M5x12mm); 4 (ST4x16 mm)
1

Required tools and devices
•Phillips screwdriver (not included) to attach the TV stand
•Wireless router or access point (not included) for Internet connectivity
Lifting and moving the Hisense • Roku TV
•We recommend that at least 2 people are available to lift and transport the TV.
•Before moving or lifting the TV, disconnect the power cord and all cables.
•When holding the TV, face the screen away from you to avoid damage.
•Hold the top and bottom of the TV firmly.
Installing the stand on your Hisense • Roku TV
Follow the steps and illustrations below to install the stand.
Installing a wall mount bracket (not included)
Your TV can be mounted on a wall using a wall mount bracket (not supplied) that can be purchased
separately. Before you begin the installation instructions provided by the wall mount manufacturer, we
suggest that you do the following things:
•Remove the TV stand if you already attached it
•Place the TV face down on a clean, safe and cushioned surface
•Place the spacers (not included) in the corresponding bracket holes
2
1
Base
Stand cover
Screw (ST4×16)
Base
Stand cover
2
Insert the stand cover into the base as shown.
Secure the stand cover to the base with 4 screws (ST4×16).
Place the TV face down on a soft surface and secure the
stand to the TV with the 4 (M5x12) screws.
3 Screw
(M5×12)

CAUTION
•Be sure to use the spacers (not provided) between the TV and the bracket when attaching the
mount.
•To prevent internal damage to the TV and ensure it is mounted securely, be sure to use fixing
screws (not provided) that are 9.5 - 11.5 mm in length when measured from the attaching
surface of the mounting hook
•When you mount your TV on the wall or place it on furniture, maintain a distance of at least 4
inches between the TV and other objects (walls, cabinet sides, and so on) to ensure proper
ventilation and prevent the TV from overheating.
•Do not mount the TV at more than a 12 degree tilt.
•Do not use screws that differ from the length and diameter that we have recommended.
•Do not fasten the screws too firmly. This may damage the TV or cause it to fall, leading to
personal injury. Hisense is not liable for these kinds of accidents.
•Be careful when you touch the TV. Some parts may be warm or hot.
•Do not place any type of fabric or papers underneath, on top of, or beside the TV. This can block
ventilation and cause a fire.
•For detailed information about installing the wall mount bracket, see the third-party
manufacturer’s instructions or contact a professional installer for assistance.
•Do not operate or handle the TV with wet hands
Follow instructions provided with the Wall-Mount bracket.
•If you are not sure of your ability to complete the installation, contact a professional installer for
assistance. Hisense is not responsible for any damages or injuries that occur due to mishandling
or incorrect assembly.
•The screws that we recommend are 9.5-11.5 mm in length when measured from the attaching
surface of the TV rear cover. The diameter and length of the screws differ depending on the
Wall-Mount Bracket model.
3
Correct way to aach the TV stand Correct way to aach the wall mount bracketd
Leave at least this much
space around the set.
Leave at least this much
space around the set.
4 inches
(10cm)
4 inches
(10cm) 4 inches
(10cm)
4 inches
(10cm)
4 inches
(10cm)
2 3⁄8inches
(6cm)
12 inches
(30cm) 12 inches
(30cm)
Wall Wall
Air circulation is blocked.
Inadequate air circulation can make the TV overheat and cause a re.

Locating ports and buttons
on your Hisense • Roku TV
Buttons and ports on the Hisense • Roku TV
4
USB
HDMI 3
DC 5V 0.5A(MAX)
HDMI 2
TV Bottom View
TV Side View
Button View
HDMI 1(ARC) VIDEO L
AV IN
R
Ant/Cable /AUDIO
OUT
DIGITAL
AUDIO OUT
AC power cord
AC power cord

Connecting devices to your Hisense • Roku TV
This section provides the steps to connect various types of devices to the TV.
Connecting an antenna, cable or satellite box
1. Connect one end of a coaxial cable (not included) to the [RF OUT] jack on the antenna, cable or
satellite box. If you are using an antenna with twin-lead cable, you may need a 300-75 Ohm adapter
(not provided) to connect it to the back of your TV. Likewise, if you are using several antennas, you
may need a combiner (not provided).
2. Connect the other end of the cable to the [ANT/CABLE IN ] jack on the side of the back panel.
3. Select Antenna TV as the input source on the Home screen to setup the TV for antenna use.
Connecting an Audio Visual (AV) device with a composite cable
1. Use the audio and video cables to connect the composite video/audio jacks (of the external AV
device) to the AV IN jacks of the TV. (Video = yellow, Audio Left = white, and Audio Right = red).
2. Plug the connected devices into the AV connectors on the TV before switching it on.
3. Select AV as the input source on the Home screen.
5
or ANT OUT
Cable
EXTERNAL DEVICESTV JACK
ANT/CABLE
(not included)
VHF/UHF/Antenna
DVD Player/Recorder
Video
Camera
EXTERNAL DEVICES
Set-top box
Satellite Receiver
Satellite
antenna
cable
A/V OUT
Video
L
R
White(L)
White(L)
Yellow(Video)
Yellow(Video)
Red(R)
Red(R)
TV JACK
VIDEO
AV IN
L R
AV Cable
(not included)
VCR

Connecting an AV device with an HDMI cable
This type of connection supports digital connections between HDMI-enabled AV devices such as a
Personal Video Recorder (PVR), DVD, Blu-ray, AV receiver and digital devices. In addition, some devices
(such as a PVR or DVD player) require an HDMI signal to be set to Output in the settings of the device.
For instructions, please refer to the User Manual for the device.
1. Use an HDMI cable to connect the [HDMI] output jack of the AV device to one of the [HDMI]
jacks on the TV.
2. Plug the connected devices into the HDMI jack .
3. Select the corresponding HDMI input on the Home screen.
Note: The HDMI connector provides video and audio signals. It is not necessary to connect an audio
cable.
Connecting a headphone
You can connect headphones or an analog sound bar to the [AUDIO OUT] jack on your set. While the
headphone is connected, the sound from the built-in speakers will be disabled.
Connecting an Audio Receiver with a digital audio cable
1. Use an audio cable to connect the digital [AUDIO IN] jack of the AV device to the [DIGITAL AUDIO
OUT] jack of the TV. Another option is to use an RCA Y-cable (1/8”-stereo mini to L/R phono - not
provided) to connect analog sound system to the [AUDIO OUT]jack of the TV.
2. Plug the connected devices into the corresponding input on the TV.
3. Select the corresponding source on the audio receiver.
6
HDMI
HDMI
TV JACK
EXTERNAL DEVICES
DVD
Set-top Box
HDMI Cable
(not included)
TV JACK
Audio Cable
(not included)

Note: To use the Audio Return Channel (ARC) technology, you must connect an HDMI cable from
your amplifier HDMI ARC connector to the [HDMI ARC] connector on the TV.
Connecting a USB device to the USB port
1. Browse photos, music and movies by inserting your USB device into the [USB] port.
2. Select the Roku Media Player tile from the Home screen
Connecting to the Internet through a wireless networking device
This section shows how to establish a wireless Internet connection for your TV.
Our built-in wireless LAN adapter supports the IEEE 802.11 b/g/n communication protocols and we
recommend that you use an IEEE 802.11n router. When you play a video over an IEEEE 802.11 b/g
connection, the video may not play smoothly.
Note
•You must use the built-in Wireless LAN Adapter to use a wireless network because the TV does
not support an external USB network adapter.
•To use a wireless network, your TV must be connected to a wireless IP sharer. If the wireless IP
sharer supports Dynamic Host Configuration Protocol (DHCP), your TV can use a DHCP or static
IP address to connect to the wireless network.
•Select a channel for the wireless IP sharer that is not currently being used. If the channel set for
the wireless IP sharer is currently being used by another device nearby, this will result in
interference and communication failure.
•If you apply a security system other than the systems listed below, it will not work with the TV.
7
TV JACKS
EXTERNAL DEVICES
Powerless
Bass Speaker
Speaker
Audio Amplier
DIGITAL
AUDIO OUT
/AUDIO
OUT
White(L)
Red(R)
Audio Cable
(not included)
Audio Cable
(not included)
Wireless IP Sharer(Router)
(with DHCP Server)
LAN Cable
Wireless LAN Adapter
built-in TV set
The LAN Port on
the Wall
(not included)

•If Pure High-throughput (Greenfield) 802.11N mode is selected and the Encryption type is set to
WEP, TKIP or TKIP-AES (WPS2 Mixed) for your Access Point (AP), then the TV will not support a
connection in compliance with these wireless certification specifications.
•If your access point (AP) supports Wi-Fi Protected Setup (WPS), you can connect to the network
via Push Button Configuration (PBC) or PIN (Personal Identification Number). WPS will
automatically configure the SSID.
8
