HiStone HK568U Series User manual
User Manual
（HK568U Series All-in-One POS device）
QingDao Histone Intelligent Commercial System Co.,Ltd.
General User Notices
Thank you very much for choosing our cash register. Before installing and using this
product, please read this manual carefully so as to have a deep understanding of its
performance. Please keep this manual well for future reference if you encounter
problems in use.
In order to improve the products, the company will adopt new technologies, new
components and new software as much as possible. Therefore, the company has the
right to make changes without notice. The features, functions and operations described
in this manual may not be completely consistent with the performance of the machines
sold by our company in various places. In some cases, the pictures are only prototypes
of the equipment. Before using this manual, you should ask our company or dealers
applicable information.
This equipment must be installed by after-sales service personnel or dealers. The
company is not responsible for any consequences caused by unauthorized changes to
the equipment or replacement of connecting equipment and cables in accordance with
regulations.
Warning:
Static may cause damage to the POS.
Incorrectly replacing a battery can result in an explosion. Make sure to only
replace the battery with the same or equivalent type as recommended by the
manufacturer (Histone). Discard used batteries according to the manufacturer’s
instructions.
Do not remove the peripheral device before you turn off the system.
Turn on the system after you turn on peripheral devices and turn off the
peripheral devices after you turn off the system.
The manufacturer has the right to modify the content of the manual without prior notice!
Product standard number: Q/HSK J03001
Product Standard Name: Commercial Cash Register
Application range
Our POS devices adopts an open system, flexible component structure and standard
peripheral interface. The product is suitable for network connection or stand-alone use in
supermarkets, department stores, convenience stores, hotels and other commercial
enterprises; all main components adopt standard Products, so the product quality is
reliable, it is easy to upgrade the system, the maintenance of components is convenient
and simple, and the reasonable cost performance makes it more competitive compared
with similar products.
Product basic configuration ：
catrg
ory
part HK568U
host
processor i3-1115G4
i5-1145G7
Memory Standard 4G DDR4
storage Standard 128G SSD
operator display 15.6" FHD LCD with a resolution of 1920*1080
ethernet 1000M Ethernet
customer
display(optional)
10.1" FHD LCD with a resolution of 1280*800
15.6" FHD LCD with a resolution of 1920*1080
printer (optional) 58mm thermal printer
80mm thermal printer
cash drawer
(optional)
steel cash box
Magnetic card
reader (optional)
Magnetic Stripe Card Reader/RFID
Contactless Card Reader
barcode scanner
(optional)
Support (1D/2D scanning)
Interfaces
HK568U Mainboard
1. Cash drawer interface 2. 24V power input
3. Power USB 4. RJ45 network port
16
234
5
7
891011
5. HDMI 6. RJ50 serial port
7. USB*2 8. Audio output
9. USB*2 10. RJ50 serial port
11. RJ50 serial port
Environmental Absolute Grade
Category Description
Environment
Power Input AC 100~240V 50-60Hz (grounding)
Working Temperature 0°C - 40°C
Working Humidity 35%～80%
Storage Temperature -20°C - 55°C
Storage Humidity 20%～93%
System Dimensions
Single screen, length×width×height: 380mm*198mm*327mm; main screen flip angle 0-45°
15.6-inch main screen + 10.1-inch secondary screen, length×width×height:
380mm*205mm*353mm; the flip angle of the main screen is 0-45°, and the flip angle of the
secondary screen is 0-30°
15.6-inch main screen + 15.6-inch secondary screen, length × width × height:
380mm*205mm*362mm; main screen flip angle 0-45°, secondary screen flip angle 0-30°
Unpacking and Inspection
1) Before unpacking, inspect the outer packing box is in good condition and check if there is
any visible damage. Contact your dealer if you notice that the package is damaged as soon
as possible.
2) When taking out the machine from the carton handle it carefully and avoid
bumping.
3) Check the packing accessories and ensure the items are included: a power
adapter, a power cable and connecting cables.
4) Check the machine and inspect it for obvious scratches or appearance damages.
5) The machine must be installed by a service technician or by an authorized dealer.
Instruction for Usage
1) Switching Instruction
Start-up: When the adapter is connected, press the Power button on the right
back side of the bottom of the machine, see the button indicator light on, then
start-up can be achieved.
2) Instructions for using magnetic stripe cards
When swiping the card, the machine should be placed on a hard horizontal plane.
Please scratch the magnetic strip of the magnetic strip card inward from the swipe
slot.
The card swiping process should be smooth and uniform.
3) Instructions for using RFID contactless cards
The RFID contactless card reader module is located behind the right side of the
Host. (with a contactless payment sign)
When the induction card is not received, please place the card above the induction
area.
Instructions for matching the printer adapter
When the system is configured with printers of different specifications, adapters with
corresponding power need to be used together. See the table below for matching
instructions：
Printer Specifications adapter power rate
no printer 60W
58mm thermal printer 60W
80mm thermal printer 120W
Safety Notes
1) The cash register requires that the external power supply should be grounded well.
The ground resistance value should be less than 0.1Ωand the machine must
connect to a grounded international three 3-pin power socket. If the power supply is
ungrounded or improperly grounded may cause leakage current. It will be hazardous to
the user and also affect the normal operation of the cash register.
2) During the operation, must use a three 3-pin power socket and a UPS that meet
CCC certification national standards. It needs to be grounded well and the supply
voltage shall be stable. Make sure the voltage of the outlet provides shall be in line
with the voltage marked on the label of the unit.
3) The unit shall be used under dry, ventilated & clean environment away from
sunlight. Avoid making the air vent of the host machine blocked or covered. Ensure the
air vent has an exhaust outlet with a certain opening gap.
4) The product is a Level A one, it may cause radio interference in living environment.
In such case, users may need to take practical & feasible measures against the
interference.
5) Be sure neither to lengthen cable nor to replace parts at your will, if you have any
demand, please contact with the reseller.
6) Be sure not to unplug or plug in any live part or external device when they are in
energized state, and the connecting cables of the POS between parts shall be
connected securely.
7) The RJ11 interface on the rear of the main unit is connected to the cash drawer, it
is not a communication port, and users cannot use this port for dial-up Internet access.
8) When inserting USB flash or disk, you shall kill virus to prevent the host machine
from virus. Android doesn't support NTFS file system. If the USB flash drive you insert is
NTFS file system, it won't be supported.
9) Do not switch on or off the host frequently, because it is easy to result in damage
on the machine.
10)Be sure not to sprinkle any liquid or fall any object into the unit.
11)Be sure not to keep heavy, strenuous movement, shake & heavy strike away from
the POS.
12)If any liquid sprinkles or any sundry falls into the unit, please shut it down
immediately & switch off power supply, take batteries down, dry the liquid or remove the
sundry. If you take the batteries down, you shall reset CMOS.
13)In case of safety fault, such as peculiar smell, abnormal sound, leakage, and other
faults, you must switch off the power supply at once and then contact with reseller.
When the POS is not in use, you shall switch off power supply. Do not directly turn off the
main power supply, you should exit the application program, turn off the machine, then
turn off the main power supply, and put on a dust cover.
1
Labeling description of product components
This product meets the environmental requirements of the "Administrative
Measures for Restricting the Use of Hazardous Substances in Electrical and
Electronic Products".
Within the environmental protection use period, there will be no leakage and
precipitation of harmful substances during the use of consumers, which will affect the
health of consumers, so you can use it with confidence.
Disposal and recycling tips
When this product is not needed or its life is over, please abide by the relevant
national laws and regulations on the recycling of waste electrical and electronic
products, and hand it over to a local manufacturer with nationally recognized
recycling qualifications for recycling. Recyclers need to properly dispose of
components containing hazardous substances, and must not dispose of them
arbitrarily.
Environmental protection use period
The environmental protection use period of this product is 10 years.
PartName
Toxic and hazardous substances or elements
铅
(Pb
)
汞
(Hg) 镉
(Cd) 六价铬
(Cr6+) 多溴
联
苯
(PBB
)
多溴二苯醚
(PBDE)
DIB
PBBP DBP DEHP
motherboardOOOOOOOOOO
MemoryOOOOOOOOOO
harddiskOOOOOOOOOO
powersupplyOOOOOOOOOO
monitorOOOOOOOOOO
2
customerdisplayOOOOOOOOOO
keyboardOOOOOOOOOO
printerOOOOOOOOOO
CPUfanOOOOOOOOOO
variouscablesOOOOOOOOOO
cashboxOOOOOOOOOO
ChassisOOOOOOOOOO
PackagingOOOOOOOOOO
*The format of this standard is prepared according to the provisions of SJ/T11364.
"O" indicates that the content of the toxic and hazardous substance in all homogeneous materials of
the part is below the limit requirement specified in GB/T26572.
"X" indicates that the content of the toxic and hazardous substance in at least one homogeneous
material of the part exceeds the limit requirement specified in GB/T26572.
Note: DIBP-diisobutyl phthalate
BBP-butyl phthalate
DBP-dibutyl phthalate
DEHP-di(2-ethylhexyl)phthalate
Accessories Annexes
Others
For the drivers of other peripheral devices, refer to the USB driver from the package.
You can log in to Histone website or contact Histone via 24h customer service hotline.
Website：http://hics.Histonetec.com
24h customer service hotline：4006-585-111
No. Item Qty Note
1 POS 1
2 Adaptor 1
3 Power Cable 1
3
FCC Statement:
Thisdevicecomplieswithpart15oftheFCCRules.Operationis subject to the
following
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevice
must accept any interference received, including interference that may cause
undesiredoperation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforacClassB
digitaldevice,pursuanttopart15oftheFCCRules.Theselimits are designed to
providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterference will not
occurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
—Reorientorrelocatethereceivingantenna.
—Increasetheseparationbetweentheequipmentandreceiver.
—Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected
—Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Caution: Any changes or modifications not expressly approved bytheparty
responsible
forcompliancecouldvoidtheuser'sauthoritytooperatetheequipment.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunctionwithanyotherantennaortransmitter.
This equipment should be installed and operated with minimum distance 20cm
betweentheradiator&yourbody
4
QC：
QINGDAO HISTONE INTELLIGENT COMMERCIAL SYSTEM CO.,LTD.
HQ Office: Qingdao, China
Phone: 0086-532-55751230
Fax: 0086-532-55751234
Website: http://hics.Histonetec.com/
24h customer service hotline
24h
Ser
ving
4006-585-111
Table of contents
Other HiStone Touch Terminal manuals
