HiStone HK528 Series User manual


User Manual
HK528 Series All-in-One Point-of-Sale (POS)


Qingdao Histone Intelligent Commercial System Co.,Ltd.

HK528 Series All-in-One POS System 

‐1‐
General User Notices
Thank you very much for choosing Hisense HK960U Series POS System. Please read
the user manual thoroughly and get to know deeper understandings before installing
and using the machine. Keep the user manual for future reference in case of questions
during the use.
In the interest of continuing product improvement, Hisense reserves the right to change
or update product specifications, functions, or software without notice. Features,
functions, and operations described in this manual may not exactly the same since the
products are sold in different regions. In some circumstances, pictures shown are
illustrative protypes only and may differ from the actual product. Contact our customer
service or your dealer for the latest information before reading this user manual.

The machine installation must be carried out by a professional technician or a dealer.
Hisense will not accept any responsibility for damage arising out of unauthorized
modification or failure to follow the instructions to replace the connected peripherals and
cables.
Warning:
Static may cause damage to the POS.
Incorrectly replacing a battery can result in an explosion. Make sure to only
replace the battery with the same or equivalent type as recommended by the
manufacturer (Hisense). Discard used batteries according to the manufacturer’s
instructions.
Do not remove the peripheral device before you turn off the system.
Turn on the system after you turn on peripheral devices and turn off the
peripheral devices after you turn off the system.
The manufacturer reserves the right to change or modify any information or
specifications contained in this manual without prior notice.
Product Standard Number: Q/0202 RSR527
Product Name：Hisense HK960U Series All-in-One Point-of-Sale (POS)

HK960U Series All-in-One POS System 

‐2‐
1. System Introduction
The Hisense HK528 Series All-in-One Point-of-Sale (POS) adopts an open
operating system, flexible component structure, and standard peripheral interface.
It can be used both networking or stand-alone and applies in commercial
enterprises such as retail stores, supermarkets, convenience stores, and hotels.
All major components are standard parts, so the quality is reliable, easy to maintain
and upgrade, also cost-effectively making it more competitive with similar products.
Basic Product Configuration
Category Parts HK528
System
CPU J6412
Memory 4G DDR4 (Up to 32G)
Storage 128G SSD (Up to 256G)
LCD Size 15.6”FHD LCD
Resolution 1920*1080
Touch Screen Capacitive touch screen
Ethernet 1*RJ45 (1000M)
Second Display (optional) 15.6”FHD LCD 1920*1080
10.1” WXGA LCD1280*800
External
Audio 1*3W
Card Reader (optional) Magnetic card reader /RFID reader
Fingerprint Reader (optional) Support

HK528 Series All-in-One POS System

‐3‐
2. I/O Panel
3. Environmental Absolute Grade
Category Description
Environment
Power Input AC 100~240V 50-60Hz (grounding)
Working Temperature 0°C - 40°C
Working Humidity 35%～80%
Storage Temperature -20°C - 55°C
Storage Humidity 20%～93%
1.24V Cash Drawer 2. 24V Power Input
3. LAN 4. USB *6
5. COM1 6. AUDIO
7. COM2

HK528 Series All-in-One POS System 

‐4‐
4. System Dimensions
Dual-screen 15.6+15.6 Device, W x D x H: 380 x 250 x 375
Dual-screen Device15.6+10.1 W x D x H: 380 x 250 x 375

HK528 Series All-in-One POS System 

‐5‐
5. Unpacking and Inspection
1) Before unpacking, inspect the outer packing box is in good condition and check if
there is any visible damage. Contact your dealer if you notice that the package is
damaged as soon as possible.
2) The HK528 series product is carefully packed in an EPE cushion and in a carton
box to protect it. Check the packaging bag for any damage before removing them.
3) When taking out the machine from the carton handle it carefully and avoid
bumping.
4) Check the packing accessories and ensure the items are included: a power
adapter, a power cable and connecting cables.
5) Check the machine and inspect it for obvious scratches or appearance damages.
6) The machine must be installed by a service technician or by an authorized dealer.

HK528 Series All-in-One POS System

‐6‐
6. Instruction for Usage
1) Switching Instruction
Start-up: When the adapter is connected, press the Power button on the right
back side of the bottom of the machine, see the button indicator light on, then
start-up can be achieved.
2) Instructions for using magnetic stripe cards
When swiping the card, the machine should be placed on a hard horizontal plane.
Please scratch the magnetic strip of the magnetic strip card inward from the swipe
slot.
The card swiping process should be smooth and uniform.
3) Instructions for using RFID contactless cards
The RFID contactless card reader module is located behind the right side of the
Host. (with a contactless payment sign)
When the induction card is not received, please place the card above the induction
area.
7. Safety Notes
1) The cash register requires that the external power supply should be grounded well.
The ground resistance value should be less than 0.1Ωand the machine must
connect to a grounded international three 3-pin power socket.
If the power supply is ungrounded or improperly grounded may cause leakage
current. It will be hazardous to the user and also affect the normal operation of
the cash register.
2) During the operation, must use a three 3-pin power socket and a UPS that meet
CCC certification national standards. It needs to be grounded well and the supply
voltage shall be stable. Make sure the voltage of the outlet provides shall be in line
with the voltage marked on the label of the unit.
3) The unit shall be used under dry, ventilated & clean environment away from
sunlight.Avoid making the air vent of the host machine blocked or covered. Ensure
the air vent has an exhaust outlet with a certain opening gap.
4) The product is a Level A one, it may cause radio interference in living environment.
In such case, users may need to take practical & feasible measures against the
interference.
5) Be sure neither to lengthen cable nor to replace parts at your will, if you have any

HK528 Series All-in-One POS System 

‐7‐
demand, please contact with the reseller.
6) Be sure not to unplug or plug in any live part or external device when they are in
energized state, and the connecting cables of the POS between parts shall be
connected securely.
7) When inserting USB flash or disk, you shall kill virus to prevent the host machine
from virus. Android doesn't support NTFS file system. If the USB flash drive you
insert is NTFS file system, it won't be supported.
8) Do not switch on or off the host frequently, because it is easy to result in damage
on the machine.
9) Be sure not to sprinkle any liquid or fall any object into the unit.
10) Be sure not to keep heavy, strenuous movement, shake & heavy strike away from
the POS.
11) If any liquid sprinkles or any sundry falls into the unit, please shut it down
immediately & switch off power supply, take batteries down, dry the liquid or
remove the sundry. If you take the batteries down, you shall reset CMOS.
12) In case of safety fault, such as peculiar smell, abnormal sound, leakage, and other
faults, you must switch off the power supply at once and then contact with reseller.
When the POS is not in use, you shall switch off power supply. Do not directly turn
off the main power supply, you should exit the application program, turn off the
machine, then turn off the main power supply, and put on a dust cover.

HK528 Series All-in-One POS System

‐8‐
8. Declaration of the Presence Condition of the Restricted
Substances Marking
Unit
部件
名称
Condition of the Restricted Substances Marking
有毒有害物质或元素
铅(Pb) 汞(Hg) 镉(Cd) 六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
Main Board
主板 O O O O O O
Internal Storage
内存 O O O O O O
Hard Disk
硬盘 O O O O O O
Power
电源 O O O O O O
Main Display
显示器 O O O O O O
Customer Display
顾客显示器 O O O O O O
Keyboard
键盘 O O O O O O
Printer
打印机 O O O O O O
CPU Fan
CPU 风扇 O O O O O O
Cables
各种线缆 O O O O O O
Cash Drawer
钱箱 O O O O O O
Chassis
机箱 O O O O O O
Packaging Carton
包装葙 O O O O O O
*本标准格式依据SJ/T11364的规定编制。
This table is prepared in accordance with the provisions of SJ/T 11364.
O: 表示该有毒有害物质在该部件所有均质材料中的含量均在GB/T26572规定的限量要求以
下。 O: Indicates that this toxic or hazardous substance contained in all of the
homogeneous materials for this part is below the limit requirement in GB/T 26572.
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出GB/T26572规定的限量
要求。 X: Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement in GB/T 26572.

HK528 Series All-in-One POS System
‐9‐
9. Accessories Annexes
10. Others
For the drivers of other peripheral devices, refer to the USB driver from the package.
You can log in to Hisense website or contact Hisense via 24h customer service hotline.
Website：http://pos.hisense.com
24h customer service hotline：[phone]
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help. Caution:
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
No. Item Qty Note
1 POS 1
2 Adaptor 1
3 Power Cable 1

HK528 Series All-in-One POS System
‐10‐
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.



产 品 使 用 档 案
机器信息 （条形码粘贴处）
（含机型+机器序号+生产日期） 填写日期
第
一
联
用
户
保
留
用
户
信
息
用户名称 用户地址
联系人 联系电话
服
务
信
息
服务单位 服务单位地址
服务人员 联系电话
保修期限 自 年 月 日 起 至 年 月 日
产 品 使 用 档 案
机器信息 （条形码粘贴处）
（含机型+机器序号+生产日期） 填写日期
第
一
联
用
户
保
留
用
户
信
息
用户名称 用户地址
联系人 联系电话
服
务
信
息
服务单位 服务单位地址
服务人员 联系电话
保修期限 自 年 月 日 起 至 年 月 日
产 品 使 用 档 案
机器信息 （条形码粘贴处）
（含机型+机器序号+生产日期） 填写日期
第
一
联
用
户
保
留
用
户
信
息
用户名称 用户地址
联系人 联系电话
服
务
信
息
服务单位 服务单位地址
服务人员 联系电话
保修期限 自 年 月 日 起 至 年 月 日




QC：
