Hitachi UC 3SML User manual

TECHNICAL DATA
AND
SERVICE MANUAL
CHARGER
UC 3SML
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. H803 Mar. 2008
U
MODEL
UC 3SML
Hitachi 
Power Tools

Model UC 3SML
CHARGER
LIST NO. H803
(E1)
2
5
6
7
3
4
1
501
502
503

PART
S
UC 3SML
DESCRIPTION REMARKS
* 1 329-878 CAUTION PLATE 1
* 1 329-879 CAUTION PLATE 1 FOR USA, CAN
2 329-880 CASE (A). (B) SET 1
3 329-857 FUSE (3.15A) EUROPE, USA, CAN 1
4 324-900 TERMINAL (A) 3
5 329-881 PRINTED CIRCUIT BOARD ASS'Y 1 INCLUD. 3, 4
6 326-358 TAPPING SCREW (W/FLANGE) D3X18 3
7 NAME PLATE 1
STANDARD ACCESSORIE
S
DESCRIPTION REMARKS
* 501 328-526 DC-CORD 1
* 501 329-882 DC-CORD 1 FOR USA, CAN
* 502 329-885 AC-ADAPTER (EURO) 1
* 502 329-884 AC-ADAPTER (U.K) 1
* 502 329-883 AC-ADAPTER (USA) 1
503 328-527 STRAP 1
- 2 - Printed in Japan 3 - 08
(080305N)
*ALTERNATIVE PARTS
