Hitachi CL 10D2 Manual

POWER TOOLS
TECHNICAL DATA
AND
SERVICE MANUAL
CORDLESS STUD CUTTER
CL 10D2
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. F842 Jan. 2001
C
MODEL
CL 10D2

ELECTRIC TOOL PARTS LIST
LIST NO.
CORDLESS STUD CUTTER
Model CL 10D2
2001
•
1
•
25
(E1)
F842

*ALTERNATIVE PARTS
ITEM
NO. CODE NO.
DESCRIPTION REMARKS
NO.
USED
PARTS CL 10D2
1 -- 01
1 CAUTION PLATE (C) 1
2 319-416 HOUSING (A).(B) SET 1
3 307-604 PUSHING BUTTON 1
4 319-773 SPRING 1
5 HITACHI LABEL 1
6 319-401 HOOK 1
7 307-607 WRENCH HOLDER 1
8 301-653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 9
9 NAME PLATE 1
10 968-643 RETAINING RING (E-TYPE) FOR D4 SHAFT 1
11 944-458 HEX. BAR WRENCH 4MM 1
12 319-839 SWITCH HOLDER 1
13 303-988 SWITCH (IP SOLDER TYPE) W/O LOCK 1
14 319-414 SWITCH ASS’Y 1 INCLUD.13
15 991-666 TERMINAL SUPPORT 1
* 16 318-370 BATTERY EB 1230H (W/ENGLISH N.P.) 1
* 16 310-378 BATTERY EB 12B (W/ENGLISH N.P.) 1
17 305-558 TAPPING SCREW (W/FLANGE) D5X25 (BLACK) 4
18 307-624 RETURN SPRING 1
19 307-622 GEAR COVER 1
20 629-VVM BALL BEARING 629VVC2PS2L 1
21 319-407 THIRD PINION 1
22 319-406 SECOND GEAR 1
23 608-VVM BALL BEARING 608VVC2PS2L 1
24 609-VVM BALL BEARING 609VVC2PS2L 1
25 939-544 RETAINING RING FOR D15 SHAFT (10 PCS.) 1
26 302-714 WASHER 1
27 310-254 RING GEAR 1
28 319-405 SECOND PINION 1
29 319-404 IDLE GEAR 2
30 307-609 NEEDLE 2
31 307-608 WASHER 1
32 600-1VV BALL BEARING 6001VVCMPS2L 1
33 319-413 MOTOR 1
34 998-471 HEX. SOCKET HD. BOLT M5X12 3
35 319-393 FINAL GEAR 1
36 939-546 RETAINING RING FOR D18 SHAFT (10 PCS.) 1
37 307-606 MACHINE SCREW (W/WASHERS) M4X20 (BLACK) 2
38 319-838 COVER 1
39 319-396 BOLT (A) 1
40 987-203 SEAL LOCK SCREW (W/SP. WASHER) M4X12 2
41 319-398 RETURN PLATE 1
42 319-397 BRACKET (A) 1
43 931-875 TAPPING SCREW D5X35 2
44 319-395 BRACKET (B) 1
45 949-574 LOCK NUT M12 (10 PCS.) 1
46 309-180 STUD GUIDE ASS’Y 1 INCLUD.47,48
47 949-458 SPRING WASHER M10 (10 PCS.) 1
48 309-621 BOLT W3/8X75 1
49 CAUTION PLATE (F) 1
50 998-486 SPECIAL BOLT M5X9 2

*ALTERNATIVE PARTS
ITEM
NO. CODE NO.
DESCRIPTION
REMARKS
NO.
USED
PARTS CL 10D2
1 -- 01
51 308-779 SPACER M8 (10 PCS.) 2
52 308-564 CUTTER ASS’Y M8 (1 PAIR) 2 INCLUD.51
53 319-399 ROLLER (A) 1
54 319-400 ROLLER PIN 1
55 319-394 CAM SHAFT 1
56 948-015 FEATHER KEY 5X5X10 2

*ALTERNATIVE PARTS
STANDARD ACCESSORIES
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO.
DESCRIPTION REMARKS
NO.
USED
ITEM
NO. CODE NO.
DESCRIPTION REMARKS
NO.
USED
CL 10D2
Printed in Japan
(010125N) 1 -- 01
501 319-774 CASE 1
502 CHARGER (MODEL UC 14YF2) 1
503 308-569 TRIMMER M8 1
601 308-563 CUTTER ASS’Y M6 (1 PAIR) 2 INCLUD.602
602 309-181 SPACER M6 (10 PCS.) 2
603 308-565 CUTTER ASS’Y M10 (1 PAIR) 2 INCLUD.604
604 308-780 SPACER M10 (10 PCS.) 2
605 998-479 CUTTER W3/8" (1 PAIR) 2
606 308-568 TRIMMER M6 1
607 308-570 TRIMMER M10 1
608 308-567 TRIMMER W3/8" 1
