INSTRUCTION MANUAL
55’’ Colour TV
55HZT66U
427/7798
Important - Please read these instructions fully before installing or operating and keep for future
reference.
These instructions contain important information which will help you get the best from your
television and ensure safe and correct installation and operation.
For any help concerning set up and use of your TV please call the
Customer Helpline: 0345 604 0105
Lines open: 9am - 8pm Monday to Saturday and 10am - 4pm Sunday

English - 1 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Contents
Safety Information .................................................. 2
Getting Started ....................................................... 6
Support................................................................... 6
Getting Started ....................................................... 7
Notications & Features & Accessories.................. 7
Specication .......................................................... 9
Remote Control .................................................... 10
Connections...........................................................11
First Time Installation - USB Connections ............ 12
TV Menu Features and Functions ........................ 14
General TV Operation .......................................... 17
Connectivity Functions ......................................... 17
Wireless Display .................................................. 19
Using DLNA Network Service............................... 19
Internet Portal....................................................... 20
iPlayer Application ................................................ 21
Internet Browser ................................................... 22
Software Upgrade................................................. 23
Troubleshooting & Tips......................................... 23
Nero MediaHome Installation ............................... 24
DVB-T functionality information............................ 24
To Program Your SKY Remote For Your TV......... 24
Disposal information............................................. 27
PC Input Typical Display Modes .......................... 28
AV and HDMI Signal Compatibility ....................... 28
Supported File Formats for USB Mode ................ 29
Supported DVI Resolutions .................................. 30
Guarantee............................................................. 31

English - 2 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Safety Information
Don’t operate your TV in extreme ambient
conditions as this may cause damage to your TV..
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Note : Follow the on screen instructions for operating the
related features.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude
to constitute a risk of electric shock of persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT - Please read these instructions fully before installing or operating
Please read the following recommended safety
precautions carefully for your safety.
SOME DOS AND DON’TS ON THE SAFE USE OF
EQUIPMENT
This equipment has been designed and manufactured
to meet international safety standards but, like any
electrical equipment, care must be taken if you are
to obtain the best results and safety is to be assured.
**************
DO read the operating instructions before you attempt
to use the equipment.
DO ensure that all electrical connections (including
the mains plug, extension leads and inter-connections
between the pieces of equipment) are properly
made and in accordance with the manufacturer’s
instructions. Switch off and withdraw the mains plug
before making or changing connections.
DO consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
DO be careful with glass panels or doors on
equipment.
DO route the mains lead so that it is not likely to be
walked on, crushed, chafed, or subjected to excessive
wear and tear or heat.
**************
DON’T remove any xed cover as this may expose
dangerous voltages.
DON’T obstruct the ventilation openings of the
equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and
shorten the life of the equipment.
DON’T allow electrical equipment to be exposed to
dripping or splashing, or objects lled with liquids, such
as vases, to be placed on the equipment.
Preparation
Place the device on a solid even surface. For
ventilation, leave a free space of at least 10 cm
all around the set. To prevent any fault and unsafe
situations, do not place any objects on top of the set.
Use this device in moderate climates.
Operation temperature and operation humidity:
0ºC up to 40ºC, 85% rel. humidity max. (not blocking
ventilation openings).
Intended Use
This device is used to receive and display TV
programmmes. The different connection options make
an additional expansion of the reception and display
sources possible (various external devices). This device
is only suitable for dry interior use. This appliance is
intended solely for private domestic use and may not
be used for industrial and commercial purposes. We
exclude liability in principle, if the device is not used
as intended, or unauthorized modications have been
made. To operate your TV in extreme ambient conditions
may cause the damage of the device.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instructions concerning use
of the appliance by a person responsible for their
safety. Children should be supervised to ensure
that they do not play with the appliance.
Children may not recognize dangers. The
swallowing of batteries can be fatal. Keep batteries
always out of reach of small children. If a battery
is swallowed, seek immediate medical attention.
Keep the packaging lms out of reach of children,
there is a risk of suffocation.
**************

English - 3 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
DON’T place hot objects or naked ame sources
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to res.
DON’T use makeshift stands and NEVER x legs
with wood screws - to ensure complete safety always
t the manufacturer’s approved stand or legs with the
xings provided according to the instructions.
DON’T use equipment such as personal stereos or
radios so that you are distracted from the requirements
of trafc safety. It is illegal to watch television whilst
driving.
DON’T listen to headphones at high volume, as such
use can permanently damage your hearing.
DON’T leave equipment switched on when it is
unattended unless it is specically stated that it is
designed for unattended operation or has a stand-by
mode. Switch off using the switch on the equipment
and make sure that your family know how to do this.
Special arrangements may need to be made for inrm
or handicapped people.
DON’T continue to operate the equipment if you are in
any doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
ABOVE ALL
--- NEVER let anyone especially children push
anything into holes, slots or any other opening
in the case - this could result in a fatal electrical
shock;
--- NEVER guess or take chances with electrical
equipment of any kind
--- it is better to be safe than sorry!
Power source
• The TV should be operated only from a 220-240 V
AC, 50 Hz outlet.
• Warning: Do not leave your TV in standby or
operating mode when you leave your house.
Positioning the TV
• For ventilation, please leave a clear space of at least
10cm all around the TV.
• Do not block the ventilation openings.
• Do not place the TV on sloping or unstable surfaces,
the TV may tip over.
• To prevent damage to the TV, do not place any
objects on top of the TV.
• Only use the TV in moderate climates.
Power cord and plug
• Do not place the set, a piece of furniture, etc. on the
power cord (mains lead) or pinch the cord. Handle
the power cord by the plug. Do not unplug the
appliance by pulling from the power cord and never
touch the power cord with wet hands as this could
cause a short circuit or electric shock. Never make a
knot in the cord or tie it with other cords. The power
cords should be placed in such a way that they are
not likely to be stepped on. A damaged power cord
can cause re or give you an electric shock. When
it is damaged and needs to be replaced, it should
be done by qualied personnel.
• This TV receiver is supplied with a moulded mains
plug. The mains plug must not be cut off, as it may
contain a special radio interference lter, the removal
of which could lead to impaired performance. If you
wish to extend the lead, obtain an appropriate safety
approved extension lead or consult your dealer.
• Observe the manufacturers instructions when
connecting extension leads to the set. Check the
fuse rating on the new plug; this should be tted with
a 5 Amp fuse which conforms to either ASTA or BSI
(BS1362) approvals, these are easily identiable by
either the ASA or symbols. If you are in any doubt
about the installation of an extension lead, please
consult a competent electrician.
Moisture and Water
• Do not use this TV in a humid or damp place (avoid
bathrooms, the sink in the kitchen, and near the
washing machine).
• Do not expose this TV to rain or water, as this may
be dangerous.
• Do not place objects lled with liquids, such as
ower vases, on top of the TV. Avoid from dripping
or splashing.
• If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualied
personnel before operating it any further.
Ventilation
• The slots and openings on the TV set are intended
for ventilation and to ensure reliable operation.
• To prevent overheating, these openings must not be
blocked or covered in anyway.
Safety Information

English - 4 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Safety Information
Heat sources and Flames
• Do not expose the TV to direct sunlight
or other heat sources.
• The TV should not be placed near to
open ames and sources of intense
heat such as an electric heater.
• Ensure that no open ame sources, such as lighted
candles, are placed on top of the TV.
Headphone Volume
• Excessive sound pressure from earphones
and headphones can cause hearing loss,
please take care.
Wall Mounting (optional)
• To prevent injury, this TV must be securely attached to
the wall in accordance with the installation instructions
(if the option is available).
LCD Screen
• Occasionally, a few non-active pixels may appear
on the screen as a xed blue, green or red point.
Please note that this does not affect the performance
of your product.
• Take care not to scratch the screen with ngernails
or other hard objects.
Cleaning
• Before cleaning, unplug the TV from the wall socket.
• Do not use liquid or aerosol cleaners. Only use a
soft, dry cloth.
Batteries
• Warning: Incorrect installation of
batteries may cause battery leakage
and corrosion, resulting in damage to
the remote control.
• Do not mix old and new batteries, or
batteries of different types.
• Do not dispose of batteries in a re.
• Do not dispose of batteries with normal household
waste, take to a local recycling centre.
CAUTION: Insert the batteries / rechargeable
batteries in the correct polarity. Don´t try to
recharge non rechargeable batteries and under
no circumstances throw them into re. Danger of
explosion. Do not use unequal batteries (old and
new, Alkaline and carbon, etc.) simultaneously. If
you will not use the device for a long time, remove
the batteries and store the device in a dry and dust
free place. Improper use of batteries may cause an
explosion or leakage. If the batteries have leaked, use
gloves and clean the appliance thoroughly with a dry
cloth! Batteries should not be exposed to heat, such
as sunshine, re or the like.
Replacement Parts
When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specied by the manufacturer or have the
same specications as the original one. Unauthorised
substitutions may result in re, electrical shock or
other hazards.
Taking out of service and storing
Unplug the TV from the mains and pack the TV in
an appropriate cardboard box. Remove the batteries
from the remote control and pack the remote control
with the TV set.
NOTE: The TV set should be stored in a dry and
dust-free room.
Connection to a Television Distribution
System (Cable TV etc.) from Tuner
Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using
coaxial cable, may in some circumstances create a
re hazard.
Connection to a cable distribution system has
therefore to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator, see EN 60728-11).

English - 5 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Symbols in this Instruction Book
The following symbols are used in the Instruction
Book as a marker for restrictions and precautions
and safety instructions. Note such information for
security reasons.
WARNING
If you do not pay attention to such a marked warning,
it can cause serious injury or death. Note these
warnings strictly, in order to ensure a safe operation.
CAUTION
Such a precaution is marked, you should take up or
note, to avoid injury or property damage. Note these
instructions strictly, in order to ensure a safe operation.
IMPORTANT
Warnings on the appliance and restrictions are
displayed like this. Read this information strictly
in order to operate the system correctly and avoid
damage.
NOTE: Information about the operation and
additional explanations are marked like this. To be
aware of such information is recommended to ensure
that the functions can be used optimally.
The illustrations and the OSD in this operation manual
are for explanation purposes and may vary slightly
from the actual operations.
Safety Information
CAUTION
Do not put your ngers in the middle between the TV
and stand, especially when you carry the TV, as they
may be injured.
Occasionally, a few non-active pixels may appear on
the screen as a xed blue, green or red point. Please
note that this does not affect the performance of your
product. Take care not to scratch the screen with
ngernails or other hard objects.

English - 6 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Support
Getting Started
Technical experts are available 7 days a week
• Simple help and advice on setting up your digital
equipment (image).
• Guidance on connecting other devices to your
television such as a DVD player, Sky, home cinema
system or a games console.
• Order spare parts, including that lost remote control.
• Any other technical issues you may need assistance
with.
Call us today: 0 345 604 0105
Local call rates applies*
Lines open 9am-8pm Monday to Saturday and 10am-4pm Sunday.
*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines
depending on your call plan/tariff. Mobile and other providers costs may vary,
see www.bt.com/pricing for details.
For Security and training purposes, telephone calls to and from customer service centres
maybe recorded and monitored. Calls from Republic of Ireland will attract international
call charges.

English - 7 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Environmental Information
This television is designed to consume less energy
to help save the environment. To reduce energy
consumption, you should take the following steps:
You can use the Power Save Mode setting, located
in the Picture menu. If you set the Power Save Mode
as Eco, the TV will switch to energy-saving mode
and the luminance level of TV set will be decreased
to the optimum level. Note that some picture settings
will be unavailable to be changed when the TV is in
Power Save Mode.
If Picture Off is selected, “Screen will be off in
15 seconds.” message will be displayed. Select
PROCEED and press OK to continue. The screen
will be off immediately.
When the TV is not in use, please switch off or
disconnect the TV from the mains plug. This will also
reduce energy consumption.
Standby Notications
If the TV does not receive any input signal (e.g. from
an aerial or HDMI source) for 5 minutes, it will go
into standby. When you next switch-on, the following
message will be displayed: “TV switched to stand-by
mode automatically because there was no signal
for a long time.” Press OK to continue.
The Auto TV OFF option(in Settings>Other Settings
menu) is set to Off by default. If this setting is changed
and the TV has been left on and not been operated
during the set time, it will switch into standby mode
after the set time has expired. When you next switch-
on, the following message will be displayed. “TV
switched to stand-by mode automatically because
no operation was made for a long time.” Press OK
to continue.
Features
• Remote controlled colour TV.
• Fully integrated digital TV(DVB-T2)
• HDMI inputs are for connecting a device that has
a HDMI socket.
• USB input.
• Programme recording.
• Programme timeshifting.
• OSD menu system.
• Scart socket for external devices (such as DVD
Players, PVR, video games, etc.)
• Stereo sound system.
• Teletext.
• Headphone connection.
• Automatic programming system.
• Manual tuning.
• Automatic power down after up to six hours.
• Sleep timer.
• Child lock.
• Automatic sound mute when no transmission.
• NTSC playback.
• AVL (Automatic Volume Limiting).
• PLL (Frequency Search).
• PC input.
• Plug&Play for Windows 98, ME, 2000, XP, Vista,
Windows 7, 8 and 10
• Game Mode (Optional).
• Ethernet (LAN) for Internet connectivity and service
• 802.11n built in WIFI Support.
• DLNA
• 50Hz frequency scan.
Accessories Included
Remote Control
Batteries: 2 x AAA
Instruction Book
Quick Start Guide
Side AV Connection Cable
Mini scart adapter cable
TV Control Buttons & Operation
TV/AV
MENU
P/CH
1. Standby On/Off button
2. TV/AV button
3. Programme Up/Down buttons
4. Volume Up/Down buttons
Getting Started
Notications & Features & Accessories

English - 8 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Operation with the Buttons on the TV
Press button to decrease volume or
button to increase volume. Press P/
CH + button to select the next programme
or P/CH - button to select the previous
programme.
Press the or button at the same
time to view main menu. In the Main menu select
sub-menu using TV/AV button and set the sub-
menu using or buttons. To see
what options are available via the menu, refer
to the menu system section of this manual.
Press the TV/AV button in the control panel on the TV to
switch between AV modes.
Note: Function indications of the buttons will be
displayed on the screen when pressed.
Inserting the Batteries into the Remote
Lift the cover on the back of the remote upward
gently. Install two AAA batteries. Make sure to
match the + and - ends of the batteries in the
battery compartment (observe the correct polarity)
Replace the cover.
Connect Power
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket. After unpacking, allow
the TV set to reach the ambient room temperature
before you connect the set to the mains. Plug the
power cable to the mains socket outlet.
Antenna Connection
Connect the aerial TV plug to AERIAL INPUT (ANT-
TV) socket located on the rear bottom side of the TV.
Rear bottom side of the TV:
Notication
Manufactured under license from Dolby Laboratories.
TRADEMARK ACKNOWLEDGMENT
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
“HDMI, the HDMI logo and High-Denition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.”
“DLNA®©, the DLNA Logo and DLNA CERTIFIED®are
trademarks, service marks, or certication marks of
the Digital Living Network Alliance.”
“YouTube and the YouTube logo are trademarks of
Google Inc.”
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and DTS
TruSurround is a trademark of DTS, Inc. © DTS, Inc.
All Rights Reserved.
Information for Users on Disposal of Old
Equipment and Batteries
[European Union only]
These symbols indicate that equipment with these
symbols should not be disposed of as general
household waste. If you want to dispose of the
product or battery, please consider the collection
systems or facilities for appropriate recycling.
Notice: The sign Pb below the symbol for batteries indicates
that this battery contains lead.
Products
Battery

English - 9 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Digital Teletext
Press TXT ( ) button to view digital teletext
information. Operate it with the coloured buttons, cursor
buttons and the OK button. The operation method may
differ depending on the contents of the digital teletext.
Follow the instructions displayed on the digital teletext
screen. When the TXT ( ) button is pressed again, the
TV returns to television broadcast.
Specication
TV Broadcasting PAL B/G D/K K
Receiving Channels VHF (BAND I/III) - UHF
(BAND U) - HYPERBAND
Number of Preset
Channels
1000
Channel Indicator On Screen Display
RF Aerial Input 75 Ohm (unbalanced)
Operating Voltage 220-240V AC, 50Hz.
Audio DTS TruSurround
Audio Output Power
(WRMS.) (10% THD)
2x10W
Power Consumption 140 W
TV Dimensions DxLxH
(with foot)
292 x 1240 x 789
TV Dimensions DxLxH
(without foot)
38/47 x 1240 x 716
Display 55”
Display Resolution 1920 x 1080
Operation temperature
and operation
humidity:
0ºC up to 40ºC, 85% humidity
max
Vesa M6 400 x 400

English - 10 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Getting Started
Remote Control
4
789
0
1.,/@ 23
56
OK
Q.MENU
EXIT
BACK
LANG.
2
1
SOURCE
/
/
P+
P-
V+
V-
1. Source
2. Launches Netix Application
3. Internet Portal
4. Play ( in media browser mode )
5. No function
6. Rapid reverse ( in media browser mode )
7. Mono/Stereo - Dual I-II / Current language (in
DVB channels)
8. Green button
9. Red button
10. Numeric buttons
11. Channel List/TV source
12. Menu
13. Volume up / down
14. Back (Return) / Index (in TXT mode)
15. Favourite channel list
16. Expand (in TXT mode) / Screen size
17. My button 1 / Youtube (**)
18. My button 2 (***)
19. Teletext / Mix
20. Electronic programme guide
21. Mute
22. Info / Reveal (in TXT mode)
23. Exit
24. Ok / Select / Hold (in TXT mode)
25. Programme up / down
26. Navigation buttons
27. Quick menu
28. Previous programme
29. Blue button
30. Yellow button
31. Subtitle on / off
32. Rapid advance ( in media browser mode )
33. Stop ( in media browser mode )
34. Pause (in media browser mode)
35. Media browser
36. Launches Youtube
37. Standby button
38. Function LED
NOTE: The Remote Control range is approximately
7m / 23ft.
Using My button 1 (*)
This button’s main function is to run Youtube link.
However, if you want to change this function, you
can press MY BUTTON 1 for ve seconds when on
a desired source or channel, until the “MY BUTTON
IS SET” message is displayed on the screen. This
confirms that the selected MY BUTTON is now
associated with the selected function. Note that if
you perform rst time installation, MY BUTTON 1 will
return to its default function.
Using My Button 2 (**)
Press MY BUTTON 2 for ve seconds when on a
desired source or channel, until the “MY BUTTON
IS SET” message is displayed on the screen. This
confirms that the selected MY BUTTON is now
associated with the selected function.

English - 11 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Getting Started
Connections
Connector Type Cables Device
Scart
Connection
(back)
Mini Scart
Connection
(rear bottom)
Mini Scart adapter cable
(supplied)
VGA
Connection
(back)
PC/YPbPr
Audio
Connection
(back)
YPbPr or PC Connection Cable
(not supplied)
(Back)
HDMI
Connection
(rear bottom &
side)
S/PDIF
(Optical Out)
(rear bottom)
Side AV
(Audio/Video)
Connection
(side)
Side AV Cable
(supplied)
Headphone
Connection
(side)
YPbPr
Connection
(back) YPbPr Connection
(Cable not supplied)
USB
Connection
(side)
CI
Connection
(side)
CAM
module
Subwoofer
Connection
(back)
NOTE: When
connecting a device via
the YPbPr or Side AV
input, you must use a
connection cables to
enable connection. See
the illustrations above.
|To enable PC audio,
you will need to use the
SIDE AV CONNECTION
cable’s WHITE & RED
inputs. |If an external
device is connected via
the SCART socket, the TV
will automatically switch to
AV mode.|When receiving
DTV channels (Mpeg4
H.264) or while in Media
Browser mode, output
will not be available via
the scart socket. |When
using the wall mounting kit
(optional), we recommend
that you plug all your
cables into the back of the
TV before mounting on the
wall. |Insert or remove the
CI module only when the
TV is SWITCHED OFF.
You should refer to the
module instruction manual
for details of the settings.
| Each USB input of your
TV supports devices up to
500mA. Connecting devices
that have current value above
500mA may damage your TV.

English - 12 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Switching On/Off TV
Connect the power cord to the 220-240V AC, 50 Hz.
To Switch the TV On
Press the “ ” button, P+ / P- or a numeric button on
the remote control.
To Switch the TV Off
Press the “ ” button on the remote control or press
the “ ” push button on the TV. The TV will now switch
to standby mode.
To power down the TV completely, unplug the
power cord from the mains socket.
Note: When the TV is switched to standby mode, the standby
LED can blink to indicate that features such as Standby Search,
Over Air Download or Timer is active. The LED can also blink
when you switch on the TV from standby mode.
First Time Installation
Plug aerial cable into the ANT socket on your TV.
When turned on for the first time, the language
selection screen is displayed. Select the desired
language and press OK.
The First Time Installation (FTI) screen will be
displayed next. Set your preferences using the
navigation buttons and when nished, press OK to
continue.
You can activate Store mode option to be available
in “Other settings” menu and your TV’s settings will
be optimized for best display quality. A conrmation
screen will be displayed. Select YES to proceed.
If Home Mode is selected, Store mode will not be
available after the First Time Installation. Press OK
button to continue.
NOTE: You can press MENU button to cancel.
After all the available stations are stored, the Channel
List will be displayed on the screen. If you like how the
channels are sorted according to the LCN (*), please
select “Yes” and than press OK.
Press MENU button to quit channel list and watch TV.
(*) LCN is the Logical Channel Number system that
organizes available broadcasts in accordance with a
recognizable channel sequence (if available).
Media Playback via USB Input
You can connect a 2.5” and 3.5” inch (hdd with external
power supply) external hard disk drives or USB memory
stick to your TV by using the USB inputs of the TV.
IMPORTANT! Back up your les before making
any connections to the TV. The Manufacturer will
not be responsible for any le damage or data loss.
Certain types of USB devices (e.g. MP3 Players)
or USB hard disk drives/memory sticks may not be
compatible with this TV.
While formatting a USB hard disk that has 1TB (Tera
Byte) or more le capacity, you can experience
problems with the formatting process.
Quickly plugging and unplugging USB devices, is a
very hazardous operation. This may cause physical
damage to the USB port and the USB device itself.
Do not pull out the USB module while playing a le.
You can use USB hubs with your TV’s USB inputs.
External power supplied USB hubs are recommended
in such a case.
It is recommended to use the TV’s USB input(s)
directly, if you are going to connect a USB hard disk.
Media Browser Menu
You can play photo, music, and movie les stored
on a USB disk by connecting it to your TV. Connect
a USB disk to one of the USB inputs located on the
side of the TV. Pressing the MENU button while in the
Media Browser mode will access the Picture, Sound
and Settings menu options. Pressing the MENU button
again will exit from this screen. You can set your Media
Browser preferences by using the Settings Menu.
Loop/Shufe Mode Operation
Start playback with and
activate
TV plays next file and
loop the list.
Start playback with OK and
activate
The same file will
be played in a loop
(repeat).
Start playback with OK/
and activate
The file will be
played in a shuffle.
Getting Started
First Time Installation - USB Connections

English - 13 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Quick Menu
The Quick Settings menu allows you to access some
options quickly. This menu includes Power Save Mode,
Picture Mode, Favourites, Sleep Timer, FollowMe
TV, FollowMe TV to DMR , CEC RC Passthrough
options. Press Q.MENU button on the remote control
to view the quick menu. See the following chapters for
details of the listed features.
FollowMe TV (Optional)
With your mobile device you can stream the current
broadcast from your smart TV using the FollowMe
TV feature. Install the appropriate Smart Center
application to your mobile device. Start the application.
For further information on using this feature refer to
the instructions of the application you use.
Note: This application is not compatible with all mobile devices.
FollowMe TV to DMR (Optional)
This feature allows video streaming from your TV to
mobile devices using proper applications (e.g. UPnP -
Universal Plug and Play - applications like BubbleUPnP)
or to another TV. Activate FollowMe TV to DMR from the
System>Settings>More menu and timeshifting starts.
Start the application on your device and select your TV.
To stream to another TV press the Red button on the
remote after starting a timeshift recording by pressing
the Pause button on the remote. Device selection menu
will be displayed. Choose the receiver TV and press OK.
Note: FollowMeTV and FollowMe TV to DMR features require
a connected USB storage device with FAT32 format and enough
space in it. Media Renderer option in the More menu should be
set as Enabled. HD channels are not supported and both of the
devices must be connected to the same network.
E-Manual (Optional)
You can nd instructions for your TV’s features in
the E-Manual.
To use E-Manual, press to the Info button while main
menu is displayed on the screen.
By using the navigation buttons select a desired
category. Every category includes a different topics.
Select a topic and press OK to read instructions.
To close the E-Manual screen press the Exit button.
Note: The contents of the E-Manual may vary according
to model.
CEC and CEC RC Passthrough
This function allows to control the CEC-enabled
devices, that are connected through HDMI ports by
using the remote control of the TV.
The CEC option in the System>Settings>More menu
should be set as Enabled at rst. Press the Source
button and select the HDMI input of the connected CEC
device from the Source List menu. When new CEC
source device is connected, it will be listed in source
menu with its own name instead of the connected HDMI
ports name(such as DVD Player, Recorder 1 etc.).
The TV remote is automatically able to perform the
main functions after the connected HDMI source has
been selected.
To terminate this operation and control the TV via
the remote again, press and hold the “0-Zero” button
on the remote control for 3 seconds. Or press Quick
Menu button on the remote, highlight the CEC RC
Passthrough and set as Off by pressing Left or Right
button. This feature can also be enabled or disabled
under the System>Settings>More menu.
The TV supports also ARC(Audio Return Channel)
feature. This feature is an audio link meant to replace
other cables between the TV and the audio system
(A/V receiver or speaker system).
When ARC is active, TV does not mute its other audio
outputs automatically. So you need to decrease TV
volume to zero manually, if you want to hear audio from
connected audio device only (same as other optical or
co-axial digital audio outputs). If you want to change
connected device’s volume level, you should select that
device from the source list. In that case volume control
keys are directed to connected audio device.
System Audio Control
Allows an Audio Amplier/Receiver to be used with
the TV. The volume can be controlled using the
remote control of the TV. To activate this feature set
the Speakers option in the System>Settings>More
menu as Amplier. The TV speakers will be muted
and the sound of the watched source will be provided
from the connected sound system.
Note: The audio device should support System Audio Control
feature and CEC option should be set as Enabled.

English - 14 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
TV Menu Features and Functions
System - Picture Menu Contents
Mode You can change the picture mode to suit your preference or requirements. The Picture mode can
be set to one of these options: Cinema, Game, Sports, Dynamic and Natural.
Contrast Sets the lightness and darkness values of the screen.
Brightness Sets the brightness value for the screen.
Sharpness Sets the sharpness value for the objects displayed on the screen.
Colour Sets the colour value, adjusting the colors.
Power Save Mode To set the Power Save Mode as Eco, Picture Off and Disabled.
(When the Mode is Dynamic, Power Save mode is automatically set as disabled.)
Backlight
(Optional)
This setting controls the backlight level. The backlight function will be inactive if the Power
Save Mode is set to Eco. The backlight cannot be activated in VGA, Media Browser mode or
while the picture mode is set to Game.
Noise
Reduction
If the broadcast signal is weak and the picture is noisy, use the Noise Reduction setting to
reduce the amount of noise.
Advanced Settings
Dyanmic
Contrast You can change the Dynamic Contrast ratio to desired value.
Colour Temp Sets the desired colour tone.
Picture Zoom Sets the desired picture size from picture zoom menu.
Note: Auto option is only available in Scart mode with SCART PIN8 high voltage/low voltage switching.
Film Mode Films are recorded at a different number of frames per second to normal television programmes.
Turn this feature on when you are watching lms to see the fast motion scenes clearly.
Skin Tone Skin tone can be changed between -5 and 5.
Colour Shift Adjust the desired colour tone.
RGB Gain You can congure the colour temperature values using the RGB Gain feature.
HDMI True
Black
While watching from a HDMI source, this feature will be visible in the Picture Settings menu.
You can use this feature to enhance blackness in the picture.
Reset Resets the picture settings to factory default settings.(Except Game Mode)
Autoposition
(in PC mode) Automatically optimizes the display. Press OK to optimize.
H Position (in
PC mode) This item shifts the image horizontally to the right hand side or left hand side of the screen.
V Position (in
PC mode) This item shifts the image vertically towards the top or bottom of the screen.
Dot Clock (in
PC mode)
Dot Clock adjustments correct the interference that appear as vertical banding in dot intensive
presentations like spreadsheets or paragraphs or text in smaller fonts.
Phase (in PC
mode)
Depending on the resolution and scan frequency that you input to the TV set, you may see a hazy or noisy
picture on the screen. In such a case you can use this item to get a clear picture by trial and error method.
While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be
added to the Picture Settings while in PC mode.

English - 15 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
System - Sound Menu Contents
Volume Adjusts the volume level.
Equalizer Selects the equalizer mode. Custom settings can be made only when in user mode.
Balance This setting is used for emphasizing left or right speaker balance.
Headphone Sets headphone volume.
Sound Mode You can select a sound mode (if the selected channel supports).
Audio Link Press OK to open the Audio Link menu screen. Using this screen you can discover and
connect the sound devices to your TV wirelessly via Bluetooth.
AVL (Automatic
Volume Limiting) This function sets the sound to obtain xed output level between programmes.
Headphone/Lineout
When you connect an external amplier to your TV using the headphone jack, you can
select this option as Lineout. If you have connected headphones to the TV, set this
option as Headphone.
DTS TruSurround Enables or disables the DTS TruSurround. When activated, some features in the Sound
menu can not be altered.
Bass Gain Controls the bass gain level. Use Left or Right button to set.
Digital Out Sets digital out audio type.
System - Settings Menu Contents
Conditional Access Controls conditional access modules when available.
Language
Congures language settings (may change depending on the country selected)
Preferred and current settings will be available. Current settings can be changed
only if the broadcaster supports.
Parental
Enter correct password to change parental settings. You can easily adjust menu
lock, maturity lock(depending on the country selected) and child lock in this menu.
You can also set a new pin number.
Timers Sets sleep timer to turn off the TV after a certain time. Sets timers for selected
programmes.
Date/Time Sets date and time.
Sources Enables or disables selected source options.
Network Settings Displays network settings.
More...: Displays other setting options of the TV set
Menu Timeout Changes timeout duration for menu screens.
Scan Encrypted
Channels When this setting is on, the search process will locate the encrypted channels as well.
Blue Background Activates or deactivates the blue background system when the signal is weak or absent.
Software Upgrade To ensure that your TV always has the most up to date rmware.
Application Version Displays application version.
Hard of Hearing Enables any special feature sent from the broadcaster.
Audio Description
Audio description refers to an additional narration track for blind and visually impaired
viewers of visual media, including television and movies. You can use this feature, only
if the broadcaster supports that additional narration track.
Note: Audio description sound feature cannot be available in recording or time shifting mode.

English - 16 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Auto TV Off You can set the timeout value of the auto off feature. When the timeout value is reached
and the TV has not been operated for a selected time, the TV will go into standby mode.
Standby Search
(Optional)
If the Standby Search is set to On, when the TV is in standby mode, available
broadcasts will be searched. If the TV locates any new or missing broadcasts, a
menu screen will be displayed, asking you whether or not to execute these changes.
The Channel list will be updated and changed after this process.
Store Mode If you are displaying the TV in a store, you can activate this mode. Whilst Store
Mode is enabled, some items in the TV menu may not be available.
DLNA Renderer
DLNA renderer feature allows you to share les stored on your smartphone or tablet
pc. If you have a DLNA compatible smartphone or tablet pc and the appropriate
software is installed, you can share/play photos on your TV. See instructions of your
sharing software for more information. DLNA renderer mode will not be available
with internet portal feature.
Power Up Mode This setting confrigures the power up mode preference.
Virtual Remote
(optional) Enable or disable the virtual remote feature.
CEC With this setting you can enable and disable CEC functionality completely. Press
Left or Right button to enable or disable the feature.
Netix
You can view your ESN(*) number and deactivate Netix.
(*) ESN number is an unique ID number for Netix, created especially to
identify your TV.
Installation Menu Contents
Smart Remote
Press OK to open the Smart Remote menu screen. Using this screen you can
discover and connect the remote controller devices to your TV wirelessly via
Bluetooth.
Automatic Channel
Scan (Retune)
(If available)
Displays automatic tuning options. Digital Aerial: Searches and stores aerial
DVB stations. Digital Cable: Searches and stores cable DVB stations. Analogue:
Searches and stores analogue stations. Digital Aerial & Analogue: Searches
and stores aerial DVB and analogue stations. Digital Cable & Analogue:
Searches and stores cable DVB and analogue stations.
Manual Channel Scan This feature can be used for direct broadcast entry.
Network Channel Scan Searches for the linked channels in the broadcast system.
Analogue Fine Tune You can use this setting for ne tuning analogue channels. This feature is not
available if no analogue channels are stored.
First Time Installation Deletes all stored channels and settings, resets TV to factory settings.
Clear Service List (*) This setting is visible only when the Country option is set to Denmark, Sweden,
Norway or Finland. Use this setting to clear channels stored.

English - 17 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
The TV sorts all stored stations in the Channel List.
You can edit this channel list, set favourites or set
active stations to be listed by using the Channel List
options.
Conguring Parental Settings
To prohibit viewing of certain programmes, channels and
menus can be locked by using the parental control system.
To display parental lock menu options, the PIN number
should be entered. The factory default PIN number is
0000. After coding the correct PIN number, parental
settings menu will be displayed.
Menu Lock: Menu lock setting enables or disables
the menu access.
Maturity Lock: When set, this option gets the maturity
information from the broadcast and if this maturity
level is disabled, disables access to the broadcast.
Child Lock: When Child Lock is set, the TV can only
be controlled by the remote control. In this case the
control panel buttons will not work.
Set PIN: Denes a new PIN number.
Note: If the Country option is set to France, you can use 4725
as the default code.
Electronic Programme Guide (EPG)
Some, but not all channels send information about
the current and next programmes. Press the EPG
() button to view the EPG menu.
Up/Down/Left/Right: Navigate EPG.
OK: Displays programme options.
INFO: Displays, in detailed, information on the
programme selected.
GREEN: Switches to List Schedule EPG.
YELLOW: Switches to Timeline Schedule EPG.
BLUE: Displays ltering options.
Programme Options
In EPG menu, press the OK button to enter the
Event Options menu.
Select Channel
In EPG menu, using this option, you can switch
to the selected channel.
Set Timer / Delete Timer
After you have selected a programme in the EPG
menu, press the OK button. Select the Set Timer
on Event option and press the OK button. You
can set a timer for future programmes. To cancel
an already set timer, highlight that programme and
press the OK button. Then select “Delete Timer”
option. The timer will be cancelled.
General TV Operation
Using the Channel List
Note: It is not possible to record two channels at the
same time.
Connectivity Functions
Wired Connectivity
To Connect to a Wired Network
• You must have a modem/router connected to an
active broadband connection.
• Connect your PC to your modem/router. This can
be a wired or wireless connection.
• Connect your TV to your modem/router via an
ethernet cable. There is a LAN port at the rear
(back) of your TV.
Broadband ISP
connection
LAN (ethernet)
cable
LAN input on the rear
bottom side of the TV
• You will need to set up DLNA network to access
and play shared les, you must select the Media
Browser. Press the Menu button and select Media
Browser. Press OK to continue. Select the desired
le type and press OK. You must always use the
Media Browser screen to access and play shared
network les.
• PC/HDD/Media Player or any other devices that are
DLNA 1.5 compatible should be used with a wired
connection for higher playback quality.
Conguring Wired Device Settings
Network Type
The Network type can be selected as Wired or Wireless,
in accordance with the active connection to the TV set.
Select this as “Wired” if you are connecting via an
ethernet.
Conguration Status
This section displays the status of the connection.
IP Address
If an active connection is available, the IP address will
be displayed on this section. If you want to congure an
IP address preferences, press the GREEN button and
switch to the advanced mode.

English - 18 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
Conguring Wired Network Settings in
Advanced Mode
After pressing the GREEN button, the “Advanced
mode” will be available. While in Advanced Mode,
press the RED button to edit settings. When nished,
press OK to save, Press RETURN/BACK to cancel.
Wireless Connectivity
To Connect to a Wireless Network
• You must have a modem/router connected to an
active broadband connection.
• To congure your wireless settings please refer
to the Network settings section in this manual.
Broadband
ISP
connection
Wireless LAN
adaptor
USB inputs
on the rear
side of the TV
• A Wireless-N router (IEEE 802.11a/b/g/n) with
simultaneous 2.4 and 5 GHz bands is designed
to increase bandwidth. These are optimized for
smoother and faster HD video streaming, file
transfers and wireless gaming.
• Use a LAN connection for quicker file sharing
between other devices like computers.
• The frequency and channel differ depending on the area.
• The transmission speed differs depending on the
distance and number of obstructions between the
transmission products, the conguration of these
products, the radio wave conditions, the line trafc
and the products that you use. The transmission may
also be cut off or may get disconnected depending
on the radio wave conditions, DECT phones or any
other WiFi 11b appliances. The standard values of
the transmission speed are the theoretical maximum
values for the wireless standards. They are not the
actual speeds of data transmission.
• The location where the transmission is most effective
differs depending on the usage environment.
• The Wireless LAN adaptor supports 802.11 a,b,g &
n type modems. It is highly recommended that you
should use the IEEE 802.11n communication protocol
in order to avoid any possible problems while watching
videos.
• You must change your modem’s SSID when there are
any other modems around with the same SSID. You
can encounter connection problems otherwise. Use
a wired connection if you experience problems with a
wireless connection.
Conguring Wireless Device Settings
To enable Wi-Fi features, open the Network Settings
menu and select Network Type as Wireless Device
to start connection process.
Press the YELLOW button to scan the wireless
networks. A list of available networks will be displayed.
Please select your desired network from the list.
Note: If the modem supports N mode, you should set
N mode settings.
If the selected network is protected with a password,
please enter the correct key by using the virtual
keyboard. You can use this keyboard via the navigation
buttons and the OK button on the remote control.
Wait until the IP address is shown on the screen.
This means that the connection is now established. To
disconnect from a wireless network highlight “Network
Type” and press OK.
You can navigate between menu tabs by pressing left/
right buttons. The help bar on the bottom of the dialog
shows features that you may use. Press the BLUE
button to check your internet connection speed. Press
the GREEN button to switch to advanced mode and
then press the OK button to edit settings.
You can check the signal strenght by using the network
settings menu for the wireless device mode.
Other Information
Configuration Status: Displays Wi-Fi status as
connected or not connected.
IP Address: Displays the current IP address.
Network Name: Connected networks’ name will be
displayed.
Delete Saved Wi-Fi Proles
Saved proles will be deleted if you press the RED button
while the wireless device selection OSD is on the screen.
Connecting to your mobile device via WiFi
• If your mobile device has WiFi feature, you can connect
it to your TV via a router, in order to access the content
in your device. For this, your mobile device must have
an appropriate sharing software.
• Connect to your router following the steps stated above
in the “Wireless Connectivity” section.
• Afterwards, engage your mobile device with the router
and then activate the sharing software on your mobile
device. Then, select les that you want to share with
your TV.
• If the connection is established correctly, you will be
able to access the shared les from your mobile device
via the Media Browser of your TV.
• Enter the Media Browser menu and the playback
device selection OSD will be displayed. Select your
mobile device and press the OK button to continue.

English - 19 -
For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105
• If available, you can download a virtual remote
controller application from the server of your mobile
device application provider.
Note: This feature may not be supported on all mobile devices.
Wireless Display
Wireless Display is a standard for streaming video and
sound content by Wi-Fi Alliance. This feature provides
the ability to use your TV as wireless display device.
Using with mobile devices
There are different standards which enable sharing of
screens including graphical, video and audio content
between your mobile device and TV.
Then press the Source button on the remote and
switch to Wireless Display source.
A screen appears stating that the TV is ready for
connection.
Open the sharing application on your mobile device.
These applications are named differently for each
brand, please refer to the instruction manual of your
mobile device for detailed information.
Scan for devices. After you select your TV and
connect, the screen of your device will be displayed
on your TV.
Note: This feature can be used only if the mobile
device supports this feature. Scanning and connecting
processes differ according to the programme you
use. Android based mobile devices should have the
software version V4.2 and above.
Bluetooth Connectivity
Your TV supports Bluetooth technology. Pairing is
required before using the Bluetooth devices with
the TV set. You should do the followings to pair your
device with the TV:
*Set the device to pairing mode
*Start device discovery on the TV
Note: Refer to the user manual of the Bluetooth
device to learn how to set the device to pairing mode.
You can connect audio devices or remote controllers
via Bluetooth to your TV. For audio devices you should
use the Audio Link option in the System>Sound
menu, for remote controllers the Smart Remote
option in the System>Settings>More menu. Select
the menu option and press the OK button to open
the related menu. Using this menu you can discover
and connect the devices that use Bluetooth wireless
technology and start to use them. Follow the on-
screen instructions. Start the device discovery. A
list of available bluetooth devices will be displayed.
Select the device you want to connect from the list
and press the OK button to connect. If “Device
connected” message is displayed, the connection
is successfully established. If the connection fails try
it again.
Connectivity Troubleshooting
Wireless Network Not Available
• Ensure that any rewalls of your network allow the
TV wireless connection.
• Try searching for wireless networks again, using the
Network Settings menu screen.
If the wireless network does not function properly,
try using the wired network in your home. Refer to
the Wired Connection section for more information
on the process.
If the TV does not function using the wired connection,
check the modem (router). If the router does not
have a problem, check the internet connection of
your modem.
Connection is Slow
See the instruction book of your wireless modem to
get information on the internal service area, connection
speed, signal quality and other settings. You need to
have a high speed connection for your modem.
Distruption during playback or slow
reactions
You could try the following.
Keep at least three meters distance from microwave
ovens, mobile telephones, bluetooth devices or any
other Wi-Fi compatible devices. Try changing the active
channel on the WLAN router.
Using DLNA Network Service
DLNA (Digital Living Network Alliance) is a standard
that eases the viewing process of digital electronics and
makes them more convenient to use on a home network.
For further information, visit www.dlna.org.
The DLNA standard allows you to view and play photos,
music and videos stored in the DLNA media server
connected to your home network.
1. Media Home Installation
The DLNA function cannot be used if the server
program is not installed onto your PC. Please prepare
your PC with the provided Media Home programme.
For more information about the installation, please
refer to the Windows Media Server.
2. Connect to a Wired or Wireless Network
See the chapter Network Settings for detailed conguration
information.
3. Play Shared Files via Media Browser
Select Media Browser by using the Left or Right
buttons from the main menu and press OK. The Media
browser will then be displayed.
