Hitachi CM-N8100 User manual

XYZ2(KW)EDCBA
62004401
CM-N8100
Ion cleansing with moisturizing support device

AC/RECHARGEABLE
100-240V AC FREE VOLTAGE
INSTRUCTIONS
Փ⫼䇈ᯢк


⾏ᄤ⏙⋕఼䜡ᏺ䕙ࡽֱ⑓ࡳ㛑
Made in Japan
᮹ᴀࠊ䗴



For household use only
াկᆊ⫼




㪚㪤㪄㪥㪏㪈㪇㪇
English Page
14~26
27~40

41~53


trang
1~13

-1- -2-
Safety precautions
Precautions described here are intended for safe and correct use of this product and are
to prevent injury and damage to you and others before they occur.
Precautions are classified as follows.
Make sure to observe the precautions because they are all important in relation to safety.
●
●
<Examples of pictorial indication>
The symbol indicates "Compulsory" (Make sure to do this).
"Disassembly prohibited""Use prohibited in wet areas"
"Use with wet hands prohibited"
"General action" "Unplug"
English
Indicates a dangerous situation in which improper handling
could result in death or serious injury to a user.
Indicates a dangerous situation in which improper handling
could result in slight injury to a user or damage to property
(house, household effects, etc.).
Indicates an imminently dangerous situation in which improper
handling may result in death or serious injury to a user.
The symbol indicates "Prohibited" (Do not do this).
Persons who use the following medical electronic devices should not use this
product. (This product may cause the medical electronic devices to malfunction.)
- Self-contained medical electronic devices such as a pacemaker
- Wearable medical electronic devices such as an electrocardiograph
Prohibited
Never use this product by other methods which are not described in this
instruction manual. (Cause of an accident, trouble, or failure)
Prohibited
Use this product only for face and neck. (Cause of an accident or trouble)
Prohibited
Prohibited
Do not use this product on the following regions.
(Cause of an accident or trouble)
- Regions where orthopedic treatment was given - Eyeballs and upper eyelids
- Wound sites - Facial melanoderma - Mucosal regions, such as inside the mouth
- Regions irritated due to pimples or skin rash
- Regions which suffer from sensation of pain or perception disorder
- Regions where metal, plastic or silicone etc., is embedded under skin
- Regions where there is itching, sensation of warmth, or liver spots due to physical stimulus etc.
- Regions where skin irritation is caused by cosmetics
Children should be supervised to ensure that they do not play with
the appliance.
When feeling pain or disorder during use of this product, or sensing anything
wrong with your skin after use, stop using this product and consult a
dermatologist. (Cause of skin trouble etc.)
Unplug
Make sure
If any abnormality occurs during charge or use, immediately pull out
the power plug of the charger from the outlet. (Cause of an accident or fire)
Use only 100-240V AC for power supply. (Cause of a fire or electric shock)
Never use if the power cord or the power plug is damaged or its insertion to
the outlet is loose. ( If the power cord breaks, a fire or electric shock may occur.)
Never damage the power cord, unnecessarily bend, pull, twist, bind, place a
heavy object on it, pinch, process, or wind around the charger, etc.
(If the power cord breaks, a fire or electric shock may occur.)
Make sure
If any unusual sound or abnormality occurs in the main body, immediately
stop using this product and contact the distributor for repair together with the
charger. (Cause of an accident or trouble)
Persons who use this product for the first time should use it while observing
the condition of their skin. (Cause of skin trouble or poor physical condition)
The following persons should avoid use of this product.
(Cause of an accident or trouble)
- Persons with heart disease - Persons with an acute (pain) illness
- Persons with a fever - Persons with a blood pressure disorder
- Persons with an infectious disease - Persons with a tubercular disease
- Persons with a malignant tumor - Persons with facial neuralgia
- Persons who are pregnant - Persons who are menstruating
- Persons with atopic dermatitis - Persons with an allergic predisposition
- Persons with particularly sensitive skin - Persons with hemophilia
- Persons under dental care
- Persons whose blood vessels have expanded due to long time use of steroid
hormones or liver function disorder
- Persons who are under the influence of alcohol or medication, or who are very tired
Never insert or remove the power plug in/from the outlet with wet hands.
(Cause of a failure or short circuit)
Never wash this product with water. And, never soak in water or splash
water on this product. (Cause of a failure or short circuit)
Use with wet
hands prohibited
Never use, charge or leave this product in places splashed with water or in
damp places, such as in a bathroom. (Cause of a failure or short circuit)
Disassembly
prohibited
Never modify this product. Only a qualified technician may make repairs.
(Cause of a fire, electric shock, injury, or failure)
Use prohibited
in wet areas
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

-3- -4-
Body socket
"LEVEL" indicator lamps
"HIGH" (red) : "LOW" (green)
When the power switch is turned "ON,"
"LOW" or "HIGH" lights.
High/low selector button
Every time this button is pressed, the
potential power level is switched between
"HIGH" and "LOW." The vibration power
does not change.
Side plate
Touch this part and apply the head to
the skin, and the device will start to
operate.
"CHARGE" lamp
The lamp lights in red during charge,
and changes to green after completion
of charge.
Buzzer (selecting sound/warning
sound/ending sound)
Every time the switch/button is pressed,
a selecting sound can be heard.
If a warning sound can be heard during
use, it is a signal to indicate recharging.
When each mode exits, an ending
sound can be heard.
Body
Accessories
Charger Model: KH-182B
Rings (two)
Rings for fixing a cotton puff.
Power plug
Insert in an outlet to the roots.
Device plug
Stand
Cord
Batteries (built-in)
Nickel-hydrogen batteries
About the skin sensing function
●The electric circuit operates with the skin in contact with the side plate and head.
Unplug
Check the head for any damage or deformation before use.
(Cause of skin damage)
Never use this product together with other beauty treatment devices at the
same time. (Cause of a failure or trouble)
Prohibited
Use only the attached charger. And, do not charge any other product
with the attached charger. (Possibility of an electric shock or ignition)
Never use this product if there is some injury or wound to your skin.
(Cause of skin trouble or pain)
Do not drop this product, or give it a strong impact.
(Cause of injury or a failure)
Do not wipe with benzene, thinner or alcohol, and do not spray insecticide.
(Cause of cracking, an electric shock, or ignition)
Make sure
Remove accessories such as earrings and necklaces, and contact lenses for
use. (Cause of an accident or trouble)
If there is any severe skin disorder or irregularity on your skin surface, or due
to downy hair, you may feel strong irritation in rare instances. In this case,
avoid using this product on that region. (Cause of an accident or trouble)
Do not keep the cotton puff on one part of your skin but always keep it in
motion. (Cause of skin trouble or poor physical condition)
Pull out the power plug and device plug without holding the cord.
(Cause of disconnection, an electric shock, short circuit, or ignition)
Make sure to pull out the power plug from the outlet unless used.
(Cause of an electric shock or fire by deterioration)
About the memory function
This device is equipped with a memory function for storing the potential power level
("HIGH" or "LOW") in memory.
In each mode (step 1 to 4), the power level ("HIGH" or "LOW") is stored in the memory
before an automatic stop or turning off the power switch.
The potential power level can be switched between "HIGH" and "LOW" by pressing
the "LEVEL" selector button during use.
Preparation before use
●
●
Since this product is not fully charged, charge before the first use.
Make sure to use 100-240V AC and use the attached charger.
How to charge
Names of parts and their functions (Fig. 1)
Head (titanium material)
Set a cotton puff and apply it to the skin.
This section vibrates during use.
Mode indicator lamp (orange)
When the power switch is turned "ON,"
"CLEANSING LAMP" flashes.
This lamp lights during use.
"MODE" selector button
Every time this button is pressed,
the mode is switched.
Side plate
Power switch (" ")
When this switch is pressed, it turns
"ON", and when this switch is pressed
again, it turns "OFF". Equipped with an
auto-off function, it will automatically turn
"OFF" if the device is not used for about
30 seconds in an "ON" state.
The standard charging time is 5 hours.
On a single charge, this device can be used approximately 10 times [when used at
the "HIGH" level in basic mode (three steps) in combination with " REFRESH " ].
* Depending on the operating conditions, such as the ambient temperature,
the number of operating times may decrease.
During charge, the main body and the charger may become slightly hot, but
not an abnormality.
2. After the standard charging time (5 hours) has elapsed, pull out the charger from
the electric outlet and the main body. (Fig. 3)
1. Turn off the power, and connect the charger to the main body and outlet. (Fig. 2)
●
●
●
The charge lamp: lights in red during charge, and
lights in green after completion of charge.
Never use this product in places splashed with water or in damp places,
such as in a bathroom. (Cause of an electric shock or short circuit)
Do not insert or remove the power plug in/from an electric outlet
with wet hands. (Cause of an electric shock or short circuit)
It will not operate unless the side plate is touched and the head is applied to the skin.

-5- -6-
When the power is ON, if a warning sound can be heard, it is a signal to indicate recharging.
Charge as soon as possible.
In order to make full use of battery performance, observe the following.
(1) If you have not used this device for three months or longer, or charge it for every
use, the number of operating times may decrease even if you fully charge at
the next time. [This is due to deactivation of the batteries (slowdown in charge
reaction) and memory effect.]
How to activate the batteries
Use the batteries until a recharge sound can be heard.
After pulling out the charger from the outlet, plug it in
again and charge for 5 hours.
Repeat 1) through 3) a few times, and the batteries are activated.
(2) In the first use:
If the number of operating times is less even after the batteries are charged for
5 hours, charge in accordance with the above method to activate the batteries.
They will return to normal.
(3) Charge the batteries at an ambient temperature in the range of 5℃to 35℃.
▼
Charge for 5 hours as is standard in accordance with
"How to charge."
▲
▼
●
●
●
Avoid use exceeding 20 minutes per day including " REFRESH ".
" CLEANSING "
" MICRO-PAT "
"
MOISTURIZE "
" REFRESH "
<Automatic stop>
<Automatic stop>
<Automatic stop>
(5 minutes)
(5 minutes)
(5 minutes)
(5 minutes)
●
It is recommended that you use " REFRESH " once every one or two weeks.
●
<Automatic stop>
Time to charge
Before use
When sensing anything unusual with your skin or body during
use, immediately stop using this product and consult a
dermatologist. (Cause of an accident or poor physical condition)
Remove accessories and contact lenses.
(Cause of skin trouble or poor physical condition)
2. Wash your face to remove dirt and make skin clean.
3. Attach a cotton puff to the main body. (Fig. 4)
(1) Remove the protection seal from the head.
The device will not operate unless the protection seal is removed.
(2) Place a cotton puff, and fix it with the included ring.
Use a commercially available cotton puff. However, if the cotton puff is too small or
thick may not be attachable.
The ring is directional. Attach it from straight above with the wider side of the inner
circumference placed toward the head.
Face the thinner side upward
Cotton puff Protection seal
Do not attach the ring in the reverse direction. Be aware that the ring, if pushed with
force, will not be able to be removed.
(3) Remove the ring by pressing the thinner parts on both sides. (Fig.5)
Thinner part
4. Please observe the following so as not to damage your skin when you use the device.
(1) The maximum amount of time allowed for skin care with this device is 15 minutes
once a day in basic mode. (Avoid use exceeding 5 minutes per day in each step.)
Basic mode
Step 1
Step 2
Step 3
Step 4 This function makes your skin healthy
by using it in combination with your
regular milky lotion or sheet mask.
3
4
1
2
1. About mode selection
Step Mode
" CLEANSING " (Pulls out fine dirt
remaining in pores.)
" MICRO-PAT " (Optimize skin
condition for moisturizing
ingredient to penetrate easily.)
" MOISTURIZE "
(Allow the toner lotion to penetrate
into cornfield layer of skin.)
" REFRESH " (Refresh the skin to
relieve stress on the skin.)
Cotton puff and cosmetics
Apply your regular toner onto a new cotton
and use.
Apply your regular toner onto the skin and
use. No cotton required.
Apply your regular toner onto a new cotton
and use.
Apply your regular milky lotion or sheet mask
to your skin for use. No cotton puff required.
You can choose "HIGH" or "LOW" as you like, but if your skin tingles, use the
device at the "LOW" level.
If you feel something unusual with your skin, stop using this device and consult a
dermatologist.
●
●
(2) Use this device on bare skin after removing makeup.
(3) Do not use this device on the same part of your skin for more than 10 seconds.
(4) Switch the potential power level between high and low by pressing the
" LEVEL "
selector button according to your skin condition.
This device is equipped with a memory function for storing in memory the potential
power level ( "HIGH" or "LOW" ) you usually use. For details, see "About the memory
function."
●
