CP-D32WN LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord,
computer cable, user's manual,
network manual
Optional
Accessories
USBWL11N USB wireless adapter,
MS-1 switcher, MS-1WL wireless switcher
(switchers have limited function with this
projector model)
Replacement Parts
Lamp DT01381
Remote Control HL02881
Filter UX37191
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA - 1024 x 768
White Light Output 3,200 ANSI lumens
Color Light Output 3,200 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 / 16:9 and 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
0.4 : 1
Focus Distance 20" - 36"
Display Size 60" - 100"
Lens & Operation
Lens F = 2.0, f = 6.1 mm
Lamp Wattage 215W
Expected Lamp Life* Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Expected Filter Life** Approximately 4,000 hours
Speaker Output 10W
Acoustic Noise Level 34 dB (28 dB in Eco mode)
Keystone +/- 5º (vertical only)
Compatibility
Computer VGA, SVGA, XGA
WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2, (shared with computer in 1/2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin mini D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 320W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 13.6" x 11.9" x 3.4" (excl. protruding parts)
Weight Approximately 8.2 lbs
Approvals UL 60950-1 / cUL FCC Part 15 subpart B Class B
Warranty 3 year limited parts and labor.
Extended Service Contract available (additional cost)
Short Throw
Series
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Width
60 48 20.1
70
56 24.0
80
64 28.0
90
72 32.0
100
80 35.9
Throw Ratio: (distance : width) 0.4 : 1
CP-D32WN
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0217-06/13
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
iPad and iPhone are registered trademarks of Apple Inc., registered in the U.S. and other countries.
©2013 Hitachi America, Ltd. All Rights Reserved .
