Hitachi CP-X443 series User manual

CP-X443 series
Model name CP-X443 series
Liquid crystal panel structure 0.8” polysilicon active-matrix TFT x 3
Number of pixels 786, 432 pixels (H 1,024 x V 768)
Resolution Video 540 TV lines
RGB 1024 dots x 768 lines
Colors 16.7 million colors
Aspect ratio Native 4:3/16:9 compatible
Lens Manual zoom 1:1.3 (F1.7 - 2.1)
Throw ratio (distance:width) 2.3 ~ 3.0 : 1
Lamp 230W UHB
Expected lamp life Approx. 2,000 hours
Brightness 2,700 ANSI lumens
Contrast ratio 400 : 1
Speakers 3.0W x 4
Power supply AC100-120V/AC220-240V 50/60Hz
Power consumption 370W
Operating temperature 5°~ 35°C (41° ~ 95° F)
Input signals RGB VGA, SVGA, XGA, SXGA, UXGA, MAC16”
Composite video/ NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, PAL60,
S-video
Component video 480i, 576i, 480p, 720p, 1,080i
Acoustic noise level 38dB (33dB in whisper mode)
H sync 15kHz ~ 91kHz
Vsync 50Hz ~ 120Hz
Vertical keystone correction Digital keystone +/- 15°
Horizontal keystone correction Digital keystone +/- 5°
Approvals UL60950/C-UL, FCC Class B, CE, TUV EN60950
RGB input Digital RGB DVI x 1
Analog RGB 15-pin D-sub connector x 2
Audio Stereo mini jack x 1
Audio output Stereo mini jack x 1
Video input S-video Mini DIN 4-pin connector x 1
Composite video RCA jack x 1
Component video RCA jack x 3
Audio RCA jack x 2 (L/R)
Control terminals 9-pin D-sub for RS-232C
USB connector (USB mouse) x 1
Wired remote control
Ethernet RJ-45 Port / 10BASE-T
Dimensions 13.2” x 3.7” x 10.4” (W x H x D)
Weight 8.3 lbs.
Supplied accessories Remote Control, Batteries (AA), Power Cord, RGB Cable,
Video/Audio Cable, Filter Cover for Bottom-up Use, Multiple
Language Operator/ Safety Manual, Soft Case, Rivet, Strap
Lamp CPX445LAMP (DT00691)
Remote control (Part #: HL01883)
Filter NJ20642
Input/Output terminalsChassis
• Component/composite/S-video
•V ertical & horizontal keystone correction
• Auto vertical keystone correction
• Reverse image function for ceiling mount
• “My screen” (user programmable start-up screen)
• 33dB (Whisper Mode)
• 16:9 mode
• Digital zoom/freeze function
• Switchable IR receiver for
remote controller
• Digital gamma correction
• Supplied with soft case
• Kensington security slot
•( 4) 3.0W speakers
• Remote control with laser pointer
SPECIFICATIONS
• 2,700 ANSI lumens
• Native XGA resolution
• 8.3 lbs
• 2RGB inputs and RGB
output/DVI inputs
• Manual zoom/manual focus
• Contrast ratio 400:1
• HDTV theater ready
• FCC class B
Replace-ment
parts

CP-X443 series
For sales information, call 1.800.225.1741.
Printed 05.05
Specifications are subject to change without notification.
www.hitachi.us/digitalmedia
Screen Size 4.3 Throw distance
Diagonal* Width* Min* Max*
40 32 71 94
60 48 108 142
80 64 145 190
100 80 182 238
120 96 219 286
150 120 274 359
200 160 366 479
250 200 458 599
300 240 551 719
Throw ratio: 2.3 ~ 3.0 : 1 (distance:width)
*Measured in inches
13 1/4”(*)
10 7/16”(*)3 3/4”(*)
(*) Excluding Lens and Leg
