SIGNAL CONNECTOR PIN ASSIGNMENT
RGB IN [1]/[2]
RGB OUT
D-sub 15-pin Shrink Mini Din 4-pin
S-VIDEO
Mini Din 4-pin
Pin No Signal
1
Color:
0.286Vp-p (NTSC, burst signal),
75Ωterminator
0.3Vp-p (PAL/SECAM, burst signal),
75Ωterminator
2Brightness:
1.0Vp-p, 75Ωterminator
3Ground
4Ground
signal Terminal Specification
RGB signal
input
RGB
Video: RGB separate, Analog, 0.7Vp-p, 75Ωterminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
BNC (RGB)
(R,G,B,H,V)
Video: RGB separate, Analog 0.7Vp-p, 75Ωterminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
BNC connector x 5
DVI
TMDS, DC 150-1200 mV/AC 1.56 Vp-p, TTL Level (Positive/Negative)
DVI connector
AUDIO IN 1 200mVrms, 57Ω(max. 3.0Vp-p)
Stereo mini jack
AUDIO IN 2
Video signal
input
VIDEO IN 1.0Vp-p, 75Ωterminator, RCA jack
S-VIDEO IN
Brightness signal: 1.0Vp-p, 75Ωterminator
Color signal: 0.286Vp-p (NTSC, burst signal),75Ωterminator
Color signal: 0.300Vp-p (PAL/SECAM, burst signal),75Ωterminator
Mini DIN 4-pin jack
COMPONENT VIDEO
(CR/PR, CB/PB, Y) Y signal: 1.0 Vp-p, 75 Ωterminator
CR/PRsignal: 0.7 Vp-p, 75 Ωterminator
CB/PBsignal: 0.7 Vp-p, 75 Ωterminator
RCA jack x 3 (BNC connector x 5)
BNC (COMPONENT)
(CR/PR, CB/PB, Y)
AUDIO IN R L 200mVrms, 50 kΩ(max. 3.0Vp-p)
RCA jack
Signal output
RGB OUT
Video: RGB separate, Analog 0.7Vp-p, 75Ω(positive)
Sync.: H,V separate, TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO OUT 200mV(rms), output impedance 1kΩ(max. 3.0Vp-p)
Stereo mini jack
Control
functions
CONTROL D-sub 15pin shrink plug
USB USB jack (B type)
Pin No Signal Pin No Signal
1Video input Red 9 -
2Video input Green 10 Ground
3Video input Blue 11 -
4 -
12
RGB IN [1]: SDA (DDC)
5Ground RGB IN [2]: -
6Ground Red RGB OUT : -
7Ground Green 13 H. sync./ Composite sync.
8Ground Blue 14 Vertical sync
15
RGB IN [1]: SCL (DDC)
RGB IN [2]: -
RGB OUT : -

2
Resolution
H ××VfH (kHz) fV (Hz) Rating Signal mode Display mode
CP-X880 CP-X885
720 ×400 37.9 85.0 VESA TEXT Zoom in Zoom in
640 ×480 31.5 59.9 VESA VGA (60Hz) Zoom in Zoom in
640 ×480 35.0 66.7 Mac13"mode Zoom in Zoom in
640 ×480 37.9 72.8 VESA VGA (72Hz) Zoom in Zoom in
640 ×480 37.5 75.0 VESA VGA (75Hz) Zoom in Zoom in
640 ×480 43.3 85.0 VESA VGA (85Hz) Zoom in Zoom in
800 ×600 35.2 56.3 VESA SVGA (56Hz) Zoom in
800 ×600 37.9 60.3 VESA SVGA (60Hz) Zoom in
800 ×600 48.1 72.2 VESA SVGA (72Hz) Zoom in
800 ×600 46.9 75.0 VESA SVGA (75Hz) Zoom in
800 ×600 53.7 85.1 VESA SVGA (85Hz) Zoom in
832 ×624 49.7 74.5 Mac16"mode Zoom out Zoom in
1024 ×768 48.4 60.0 VESA XGA (60Hz) Zoom out
1024 ×768 56.5 70.1 VESA XGA (70Hz) Zoom out
1024 ×768 60.0 75.0 VESA XGA (75Hz) Zoom out
1024 ×768 68.7 85.0 VESA XGA (85Hz) Zoom out
1152 ×864 67.5 75.0 VESA SXGA (75Hz) Zoom out Zoom out
1280 ×960 60.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 ×1024 64.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 ×1024 80.0 75.0 VESA SXGA (75Hz) Zoom out Zoom out
1280 ×1024 91.2 85.0 VESA SXGA (85Hz) Zoom out Zoom out
1600 ×1200 75.0 60.0 VESA UXGA (60Hz) Zoom out Zoom out
EXAMPLE OF COMPUTER SIGNAL
•Some computers may have multiple display screen modes. Use of some
of these modes will not be possible with this projector.
• Be sure to check jack type, signal level, timing and resolution before connecting this
projector to a computer.
• Depending on the input signal, full-size display may not be possible in some cases.
Refer to the number of display pixels above.
• Although the projector can display signals (except DVI input) with resolution up to
UXGA (1,600 x 1,200), the signal will be converted to the projector’s panel resolution
before being displayed. The best display performance will be achieved if the
resolutions of the input signal and projector panel are identical.
• The image may not be displayed correctly when the input sync. signal is “Composite
Sync.” or “Sync. on G”.
• UXGA (1,600 x 1,200) signals cannot be displayed with DVI input.
NOTE

3
The following signals are used for the initial settings.
The signal timing of some computer models may be different. In such case, refer to
adjust the V.POSIT and H.POSIT of the menu.
DATA
HSYNC
DATA
VSYNC
Display interval c
Back porch b
Sync a
Front porch d
Display interval c
Back porch b
Sync a
Front porch d
Computer /
Signal
Horizontal signal timing (µs)
a b c d
TEXT 2.0 3.0 20.3 1.0
VGA (60Hz) 3.8 1.9 25.4 0.6
Mac 13"mode 2.1 3.2 21.2 2.1
VGA (72Hz) 1.3 3.8 20.3 1.0
VGA (75Hz) 2.0 3.8 20.3 0.5
VGA (85Hz) 1.6 2.2 17.8 1.6
SVGA (56Hz) 2.0 3.6 22.2 0.7
SVGA (60Hz) 3.2 2.2 20.0 1.0
SVGA (72Hz) 2.4 1.3 16.0 1.1
SVGA (75Hz) 1.6 3.2 16.2 0.3
SVGA (85Hz) 1.1 2.7 14.2 0.6
Mac 16"mode 1.1 3.9 14.5 0.6
XGA (60Hz) 2.1 2.5 15.8 0.4
XGA (70Hz) 1.8 1.9 13.7 0.3
XGA (75Hz) 1.2 2.2 13.0 0.2
XGA (85Hz) 1.0 2.2 10.8 0.5
1152×864 (75Hz)
1.2 2.4 10.7 0.6
1280×960 (60Hz)
1.0 2.9 11.9 0.9
1280×1024 (60Hz)
1.0 2.3 11.9 0.4
1280×1024 (75Hz)
1.1 1.8 9.5 0.2
1280×1024 (85Hz)
1.0 1.4 8.1 0.4
1600×1200 (60Hz)
1.2 1.9 9.9 0.4
Computer /
Signal
Vertical signal timimg (lines)
a b c d
TEXT 342 400 1
VGA (60Hz) 233 480 10
Mac 13"mode 339 480 3
VGA (72Hz) 328 480 9
VGA (75Hz) 316 480 1
VGA (85Hz) 325 480 1
SVGA (56Hz) 222 600 1
SVGA (60Hz) 423 600 1
SVGA (72Hz) 623 600 37
SVGA (75Hz) 321 600 1
SVGA (85Hz) 327 600 1
Mac 16"mode 339 624 1
XGA (60Hz) 629 768 3
XGA (70Hz) 629 768 3
XGA (75Hz) 328 768 1
XGA (85Hz) 336 768 1
1152×864 (75Hz)
332 864 1
1280×960 (60Hz)
336 960 1
1280×1024 (60Hz)
338 1024 1
1280×1024 (75Hz)
337 1024 2
1280×1024 (85Hz)
344 1024 1
1600×1200 (60Hz)
346 1200 1
INITIAL SET SIGNALS

4
12345
6789
10
11 12 13 14 15
CONNECTION TO THE MOUSE CONTROL
1
2
3
4
1
2
3
4
+5V
—DATA
+DATA
GND
+5V
—DATA
+DATA
GND 1234
21
34
USB jack
(B type) USB jack
(A type)
Projector
USB cable
Computer
ADB Mouse
2
1
4
3
6
5
2
1
4
3
8
7
10
9
12
11
14
13
15
RTS
GND
+5V
ADB
GND
+5V
(POWER ON)
DATA
21
43
Mouse jack
Mini DIN 4-pin
Projector Computer
CONTROL Terminal
D-sub 15-pin shrink jack
Serial Mouse
2
1
4
3
6
5
2
1
4
3
6
5
8
7
10
9
8
7
9
12
11
14
13
15
RI
CD
RD
TD
DTR
GND
DSR
CTS
RTS
RTS
GND
SEL0
TD
21 4
3
6
5
89
7
Mouse jack
D-sub 9-pin
Projector Computer
12345
6789
10
11 12 13 14 15
CONTROL Terminal
D-sub 15-pin shrink jack
USB Mouse
PS/2 Mouse
2
1
4
3
6
5
2
1
4
3
6
5
8
7
10
9
12
11
14
13
15
CLK
DATA
SEL0
RTS
GND
+5V
DATA
GND
+5V
CLK
21
43
65
Mouse jack
Mini DIN 6-pin
Projector Computer
12345
6789
10
11 12 13 14 15
CONTROL Terminal
D-sub 15-pin shrink jack

5
(1) Turn off the projector and computer power supplies, and connect with the RS-232C
adapter via the RS-232C cable.
(2) Turn on the computer power supply and after the computer has started up, turn on the
projector power supply.
Control jack
D-sub 15-pin shrink jack
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RD
TD
GND
SELO
RTS
1
2
3
4
5
6
7
8
9
CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI
12345
6789
RS-232C jack
D-sub 9-pin
Projector Computer
Communications setting
19200bps, 8N1
1 Protocol
Consist of header (7 bytes) + command data (6 bytes).
2 Header
BE + EF + 03 + 06 + 00 + CRC_low + CRC_high
CRC_low : Lower byte of CRC flag for command data.
CRC_high : Upper byte of CRC flag for command data.
3 Command data
byte_0 byte_1 byte_2 byte_3 byte_4 byte_5
Action Type Setting code
low high low high low high
Command data chart
Action (byte_0 - 1)
Action Classification Content
1SET Change setting to desired value.
2GET Read projector internal setup value.
4INCREMENT Increment setup value by 1.
5DECREMENT Decrement setup value by 1.
6EXECUTE Run a command.
RS-232C COMMUNICATION
RS-232C adapter

6
Requesting projector status (Get command)
(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes)
+‘00H’+‘00H’) from the computer to the projector.
(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.
Changing the projector settings (Set command)
(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) +
setting code (2 bytes)) from the computer to the projector.
(2) The projector changes the setting based on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
Using the projector default settings (Reset Command)
(1) The computer sends the default setting code Header + Command data (‘06H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector changes the specified setting to the default value.
(3) The projector returns the response code ‘06H’ to the computer.
Increasing the projector setting value (Increment command)
(1) The computer sends the increment code Header + Command data (‘04H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector in creases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
Decreasing the projector setting value (Decrement command)
(1) The computer sends the decrement code Header + Command data (‘05H’+‘00H’+
type (2 bytes) +‘00H’ + ‘00H’) to the projector.
(2) The projector decreases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
When a command sent by the projector cannot be understood by the computer
When the command sent by the projector cannot be understood, the error command ‘15H’ is
returned by the computer. Some times, the projector ignores RS-232C commands during
other works. If the error command ‘15H’ is returned, please send the same command again.
When data sent by the projector cannot be practice
When the command sent by the projector cannot be practiced, the the error code ‘1cH’
+‘xxxxH’ is returned.
When the data length is greater than indicated by the data length code, the projector will
ignore the excess data code.
Conversely, when the data length is shorter than indicated by the data length code, an
error code will be returned to the projector.
RS-232C COMMUNICATION (continued)
•Operation cannot be guaranteed when the projector receives an
undefined command or data.
• Provide an interval of at least 40ms between the response code and any other code.
• The projector outputs test data when the power supply is switched ON, and when the
lamp is lit. Ignore this data.
• Commands are not accepted during warm-up.
NOTE

7
Command data chart
Names Operation type Header Command data
CRC Action Type Setting code
Blank Color Set
Blue BE EF 03 06 00 CB D3 01 00 00 30 03 00
White BE EF 03 06 00 6B D0 01 00 00 30 05 00
Black BE EF 03 06 00 9B D0 01 00 00 30 06 00
MyScreen BE EF 03 06 00 FB CA 01 00 00 30 20 00
ORIGNAL BE EF 03 06 00 FB E2 01 00 00 30 40 00
Get BE EF 03 06 00 08 D3 02 00 00 30 00 00
Mirror Set
Normal BE EF 03 06 00 C7 D2 01 00 01 30 00 00
H Inverse BE EF 03 06 00 57 D3 01 00 01 30 01 00
V lnverse BE EF 03 06 00 A7 D3 01 00 01 30 02 00
H&V Inverse BE EF 03 06 00 37 D2 01 00 01 30 03 00
Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00
Freeze Set Normal BE EF 03 06 00 83 D2 01 00 02 30 00 00 Freeze BE EF 03 06 00 13 D3 01 00 02 30 01 00
Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00
Startup Set
ORIGNAL BE EF 03 06 00 0B D2 01 00 04 30 00 00
OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00
MyScreen BE EF 03 06 00 CB CB 01 00 04 30 20 00
Get BE EF 03 06 00 38 D2 02 00 04 30 00 00
Language Set
English BE EF 03 06 00 F7 D3 01 00 05 30 00 00
Français BE EF 03 06 00 67 D2 01 00 05 30 01 00
Deutsch BE EF 03 06 00 97 D2 01 00 05 30 02 00
Español BE EF 03 06 00 07 D3 01 00 05 30 03 00
Italiano BE EF 03 06 00 37 D1 01 00 05 30 04 00
Norsk BE EF 03 06 00 A7 D0 01 00 05 30 05 00
Nederlands BE EF 03 06 00 57 D0 01 00 05 30 06 00
PortuguêsBE EF 03 06 00 C7 D1 01 00 05 30 07 00
BE EF 03 06 00 37 D4 01 00 05 30 08 00
BE EF 03 06 00 A7 D5 01 00 05 30 09 00
BE EF 03 06 00 57 D5 01 00 05 30 0A 00
Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00
Magnify
Get BE EF 03 06 00 7C D2 02 00 07 30 00 00
Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00
Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00
Auto off
Get BE EF 03 06 00 08 86 02 00 10 31 00 00
Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00
Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00
Brightness Reset
Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00
Contrast Reset Execute BE EF 03 06 00 A4 D2 06 00 01 70 00 00
V.Position Reset
Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00

8
Command data chart (continued)
Names Operation type Header Command data
CRC Action Type Setting code
H.Position Reset Execute BE EF 03 06 00 IC D3 06 00 03 70 00 00
H.Size Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00
Color Balance
R Reset
Execute BE EF 03 06 00 94 D3 06 00 05 70 00 00
Color Balance
B Reset
Execute BE EF 03 06 00 D0 D3 06 00 06 70 00 00
Sharpness Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00
Color Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00
Tint Reset Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00
Keystone_V Reset Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00
Keystone_H Reset Execute BE EF 03 06 00 98 D8 06 00 20 70 00 00
Auto Adjust Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00
Auto Keystone_V
Execute BE EF 03 06 00 E5 D1 06 00 0D 20 00 00
Lamp Time Reset Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00
Filter Time Reset Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00
Blank on/off Set off BE EF 03 06 00 FB D8 01 00 20 30 00 00 on BE EF 03 06 00 6B D9 01 00 20 30 01 00
Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00
Error Status Get
BE EF 03 06 00 D9 D8 02 00 20 60 00 00
(Example of Return)
00 00 01 00 02 00 03 00
(Normal) (Cover-error) (Fan-error) (Lamp-error)
04 00 05 00 06 00 07 00 08 00
(Temp-error) (Air flow-error) (Lamp-Time-over) (Cool-error) (Filter-Error)
Power
Set OFF
BE EF 03 06 00 2A D3 01 00 00 60 00 00
ON
BE EF 03 06 00 BA D2 01 00 00 60 01 00
Get
BE EF 03 06 00 19 D3 02 00 00 60 00 00
Input Source Set
RGB BE EF 03 06 00 FE D2 01 00 00 20 00 00
RGB) BE EF 03 06 00 3E D0 01 00 00 20 04 00
Video BE EF 03 06 00 6E D3 01 00 00 20 01 00
S-Video BE EF 03 06 00 9E D3 01 00 00 20 02 00
Component BE EF 03 06 00 AE D1 01 00 00 20 05 00
DVI BE EF 03 06 00 0E D2 01 00 00 20 03 00
BNC (Component) BE EF 03 06 00 5E D1 01 00 00 20 06 00
Get BE EF 03 06 00 CD D2 02 00 00 20 00 00
Volume
Get BE EF 03 06 00 31 D3 02 00 01 20 00 00
Increment BE EF 03 06 00 57 D3 04 00 01 20 00 00
Decrement BE EF 03 06 00 86 D2 05 00 01 20 00 00
Mute Set Normal BE EF 03 06 00 46 D3 01 00 02 20 00 00 Mute BE EF 03 06 00 D6 D2 01 00 02 20 01 00
Get BE EF 03 06 00 75 D3 02 00 02 20 00 00
Brightness
Get BE EF 03 06 00 89 D2 02 00 03 20 00 00
Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00
Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00
Contrast
Get BE EF 03 06 00 FD D3 02 00 04 20 00 00
Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00
Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00
Color Balance R
Get BE EF 03 06 00 01 D2 02 00 05 20 00 00
Increment BE EF 03 06 00 67 D2 04 00 05 20 00 00
Decrement BE EF 03 06 00 B6 D3 05 00 05 20 00 00

9
Names Operation type Header Command data
CRC Action Type Setting code
Color Balance B
Get BE EF 03 06 00 45 D2 02 00 06 20 00 00
Increment BE EF 03 06 00 23 D2 04 00 06 20 00 00
Decrement BE EF 03 06 00 F2 D3 05 00 06 20 00 00
Keystone_V
Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00
Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00
Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00
Keystone_H
Get BE EF 03 06 00 E9 D0 02 00 0B 20 00 00
Increment BE EF 03 06 00 8F D0 04 00 0B 20 00 00
Decrement BE EF 03 06 00 5E D1 05 00 0B 20 00 00
Aspect Set
4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00
16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00
Small BE EF 03 06 00 FE D1 01 00 08 20 02 00
Get BE EF 03 06 00 AD D0 02 00 08 20 00 00
Position at
16 : 9 or Small
Set
Default BE EF 03 06 00 62 D1 01 00 09 20 00 00
Bottom BE EF 03 06 00 F2 D0 01 00 09 20 01 00
Top BE EF 03 06 00 02 D0 01 00 09 20 02 00
Get BE EF 03 06 00 51 D1 02 00 09 20 00 00
V.Position
Get BE EF 03 06 00 0D 83 02 00 00 21 00 00
Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00
Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00
H.Position
Get BE EF 03 06 00 F1 82 02 00 01 21 00 00
Increment BE EF 03 06 00 97 82 04 00 01 21 00 00
Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00
H.Size
Get BE EF 03 06 00 B5 82 02 00 02 21 00 00
Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00
Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00
H.Phase
Get BE EF 03 06 00 49 83 02 00 03 21 00 00
Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00
Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00
Sharpness
Get BE EF 03 06 00 F1 72 02 00 01 22 00 00
Increment BE EF 03 06 00 97 72 04 00 01 22 00 00
Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00
Color
Get BE EF 03 06 00 B5 72 02 00 02 22 00 00
Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00
Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00
Tint
Get BE EF 03 06 00 49 73 02 00 03 22 00 00
Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00
Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00
BNC Set RGB BE EF 03 06 00 C2 D7 01 00 11 20 00 00
Component BE EF 03 06 00 52 D6 01 00 11 20 01 00
Get BE EF 03 06 00 F1 D7 02 00 11 20 00 00
Video Format Set
Auto BE EF 03 06 00 9E 75 01 00 00 22 0A 00
NTSC BE EF 03 06 00 FE 71 01 00 00 22 04 00
PAL BE EF 03 06 00 6E 70 01 00 00 22 05 00
SECAM BE EF 03 06 00 6E 75 01 00 00 22 09 00
NTSC 4.43 BE EF 03 06 00 5E 72 01 00 00 22 02 00
M-PAL BE EF 03 06 00 FE 74 01 00 00 22 08 00
N-PAL BE EF 03 06 00 0E 71 01 00 00 22 07 00
Get BE EF 03 06 00 0D 73 02 00 00 22 00 00
HDTV Set 1080i BE EF 03 06 00 F2 73 01 00 05 22 00 00
1035i BE EF 03 06 00 62 72 01 00 05 22 01 00
Get BE EF 03 06 00 C1 73 02 00 05 22 00 00

10
Command data chart (continued)
Names Operation type Header Command data
CRC Action Type Setting code
Sync on G Set off BE EF 03 06 00 CB D0 01 00 08 30 01 00
on BE EF 03 06 00 5B D1 01 00 08 30 00 00
Get BE EF 03 06 00 68 D1 02 00 08 30 00 00
PinP Size Set
off BE EF 03 06 00 FE 22 01 00 00 23 00 00
Large BE EF 03 06 00 6E 23 01 00 00 23 01 00
Small BE EF 03 06 00 9E 23 01 00 00 23 02 00
Get BE EF 03 06 00 CD 22 02 00 00 23 00 00
PinP Position Set
Upper left BE EF 03 06 00 02 23 01 00 01 23 00 00
Upper right BE EF 03 06 00 92 22 01 00 01 23 01 00
Bottom left BE EF 03 06 00 62 22 01 00 01 23 02 00
Bottom right BE EF 03 06 00 F2 23 01 00 01 23 03 00
Get BE EF 03 06 00 31 23 02 00 01 23 00 00
PinP Audio ch Set RGB BE EF 03 06 00 BA 22 01 00 03 23 00 00 Video BE EF 03 06 00 2A 23 01 00 03 23 01 00
Get BE EF 03 06 00 89 22 02 00 03 23 00 00
PinP Input Set Video BE EF 03 06 00 D6 22 01 00 02 23 01 00 S-Video BE EF 03 06 00 26 22 01 00 02 23 02 00
Get BE EF 03 06 00 75 23 02 00 02 23 00 00
WHISPER Set NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00 WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00
Get BE EF 03 06 00 08 23 02 00 00 33 00 00
GAMMA Set
NORMAL BE EF 03 06 00 C7 F0 01 00 A1 30 00 00
CINEMA BE EF 03 06 00 57 F1 01 00 A1 30 01 00
DYNAMIC BE EF 03 06 00 A7 F1 01 00 A1 30 02 00
Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00
Over Scan Set
Large BE EF 03 06 00 C2 71 01 00 09 22 02 00
Middle BE EF 03 06 00 32 71 01 00 09 22 01 00
Small BE EF 03 06 00 A2 70 01 00 09 22 00 00
Get BE EF 03 06 00 91 70 02 00 09 22 00 00
MyScreen Size Set Full BE EF 03 06 00 43 D6 01 00 12 30 00 00 X1 BE EF 03 06 00 D3 D7 01 00 12 30 01 00
Get BE EF 03 06 00 70 D6 02 00 12 30 00 00
MyScreen Lock Set off BE EF 03 06 00 3B EF 01 00 C0 30 00 00 on BE EF 03 06 00 AB EE 01 00 C0 30 01 00
Get BE EF 03 06 00 08 EF 02 00 C0 30 00 00
Lamp Time Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00
Filter Time Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00
IR Remote Front Set off BE EF 03 06 00 FF 32 01 00 00 26 00 00
on BE EF 03 06 00 6F 33 01 00 00 26 01 00
Get BE EF 03 06 00 CC 32 02 00 00 26 00 00
IR Remote Rear Set off BE EF 03 06 00 03 33 01 00 01 26 00 00
on BE EF 03 06 00 93 32 01 00 01 26 01 00
Get BE EF 03 06 00 30 33 02 00 01 26 00 00
IR Remote Top Set off BE EF 03 06 00 47 33 01 00 02 26 00 00
on BE EF 03 06 00 D7 32 01 00 02 26 01 00
Get BE EF 03 06 00 74 33 02 00 02 26 00 00
