CP-WX8255A LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, one standard ML703 lens, lens
cover, user's manual, security label,
application CD, adapter cover
Optional
Accessories
USBWL11N USB wireless adapter,
MS-1 wired multifunction switcher,
MS-1WL wireless multifunction switcher
Optional Lenses 4 optional lenses are available: FL701,
SL702, LL704, UL705
Replacement Parts
Lamp DT01291
Remote Control HL02801
Filter UX38241
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution WXGA 1280 x 800
White Light Output 5,500 ANSI lumens
Color Light Output 5,500 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 16:10 and 4:3 / 16:9 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 3.0:1
(with standard lens)
Lens & Operation
Lens F = 1.6 - 2.9, f = 24 - 48 mm
x 2.0 motorized zoom, focus & lens shift
Lamp Wattage 330W
Expected Lamp Life* Approximately 2,500 hours (standard mode)
3,000 hours (Eco mode)
Expected Filter Life** Approximately 20,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 37 dB (31 dB in Eco mode)
Keystone H and V: +/- 35º (with standard lens)
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+/SXGA/WSXGA+/UXGA
(compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 BNC x 5
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video RCA jack x 3, 15-pin mini D-sub x 1 (shared with computer In 1)
BNC x 3 (shared with computer In 2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 480W
Operating Temperature 32ºF - 113ºF (0ºC - 45ºC)
Dimensions (W x D x H) 19.6" x 15.6" x 5.3" (without lens)
Weight Approximately 19.3 lbs
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class A
Warranty 3 year limited parts and labor.
Extended Service Contract available (additional cost)
Installation
Series
Projection Throw Chart
Screen Size 16:10 Throw Distance
Diagonal Width Min Max
30 25 39 78
60 51 78 154
80 68 104 206
100 85 129 257
150 127 194 385
200 170 259 513
250
212 323 641
300 254 388 769
Throw Ratio: 1.5 - 3.0 : 1 (distance : width)
Screen size and throw distance are measured in inches
with standard lens ML703.
Projection Lens Chart
Lens Inches Meters
ML703 129 - 257 3.3 - 6.5
FL701 71
1.8
SL702 102 - 154 2.6 - 3.9
LL704 244 - 415 6.2 - 10.5
UL705
415 - 705 10.5 - 17.9
Projection distances measured in inches and meters with standard lens
and optional lenses when projecting onto a 100" diagonal screen.
CP-WX8255A
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI •Email: [email protected]
Web: hitachi-america.us/projectors
HI0150-Rev.1-07/13
All specifications subject to change without notice.
