CinemaStar™5K1000
3.5-INCH CE HARD DISK DRIVES
A different spin for digital video
The CinemaStar™ 5K1000 hard drive provides a generous 1TB capacity and features innovative
CoolSpin technology to deliver a new level of power efciency and quiet operation for digital video
applications. Key to CoolSpin technology is an optimization of motor speed to provide an ideal
balance of performance, power utilization and acoustics. With customized features, capacity
and cool operation, the 3.5-inch CinemaStar 5K1000 enables a new generation of digital video
recorders and set-top boxes that store more hours of video, run more quietly and use less power.
Designed to support on-demand digital video solutions
An exceptional blend of audio/visual (AV) features ne tunes the CinemaStar 5K1000 for digital
video storage needs. Hitachi SmoothStream technology supports the ATA-7 streaming command
set, and SCT provides time-limited error recovery and thermal monitoring capabilities. Because
IT data and video streams have different throughput demands, AV-Zoning allows the denition
of various error recovery procedures for predened ranges of data blocks, or zones. To enable
the system to effectively deliver critical data and time-sensitive video content from a single
drive. Other features that tailor this drive for streaming video applications include Read Con-
tinuous mode, which helps manage error recovery for video streams, and Media Maintenance
enhancements, to help prevent track wear-out from around-the-clock operation.
Innovation for a more sustainable environment
The CinemaStar 5K1000 demonstrates Hitachi’s ecological leadership with its halogen-free
design and power-efficient operation. Both these features helped qualify the drive for the
Hitachi EcoTrac classification, which identifies products that minimize environmental impact in
the areas of product design, manufacturing, operation and disposal.

Model(s) HCS5C1010CLA382
HCS5C1075CLA382
HCS5C1050CLA382
HCS5C1032CLA382
HCS5C1025CLA382
HCS5C1016CLA382
Conguration
Interface SATA 3Gb/s
Capacity (GB)11TB / 750 / 500 / 320 / 250 / 160
Max. areal density (Gbits/sq. in) 352
Performance
Data buffer (MB)48
Media transfer rate (Mbits/sec, max.) 1265
Interface transfer rate (MB/sec, max.) 300
Reliability
Error rate (non-recoverable, bits read) 1 in 1014
Load/unload cycles 300,000
Availability2 (hrs/day x days/wk) 24x7
Targeted MTBF3(hours) 1,200,000
Power
Requirement +5 VDC (+/-5%)
+12 VDC (+/-10%)
Startup (max. A) 1.1 (+5V) & 1.7 (+12V)
Performance idle (W, avg.) 1TB / 750GB
500GB / 320GB / 250GB / 160GB
3.3
2.9
Physical size
z-height (mm, max.) 26.1
Dimensions (width x depth, mm, typical) 101.6 x 147
Weight (g, max.) 1TB / 750GB
500GB / 320GB / 250GB / 160GB
680
400
Environmental (operating)
Device temperature50oto 70o C
Relative humidity (non-condensing) 8% to 90%
Shock (half-sine wave (G 2ms)) 70
Vibration, random (G RMS) 0.67 (XY)
Environmental (non-operating)
Ambient temperature -40oto 70o C
Relative humidity (non-condensing) 5% to 95%
Shock (half-sine wave (G 2ms)) 350
Vibration, random (G RMS) 1.04 (XYZ)
Acoustics (A-weighted sound power)
Operating (Bels, typical) 2.4
1 One GB is equal to one billion bytes when referring to hard drive capacity. Accessible capacity may be less.
2 Based on typical AV multi-stream recording environments accumulating up to 2000 hours of HD content per month or equivalent workload.
3This MTBF target is based on a sample population in typical CE/surveillance product environment and is estimated by statistical measurements
and acceleration algorithms under normal operating conditions. MTBF ratings do not predict reliability of an individual drive.
4 Portion of buffer capacity used for drive rmware
5Temperature tested at top cover surface
Specifications
How to read the CinemaStar model number
HCS5C1010CLA382 = 1TB/8MB buffer
H = Hitachi
C = CinemaStar
S = Standard
5C = CoolSpin technology
10 = Full capacity — 1TB
10 = Capacity this model, 10 = 1TB
(75 = 750GB, 50 = 500GB, 32 = 320GB,
25 = 250GB, 16 = 160GB)
C = Generation code
L = 26.1mm z-height
A3 = SATA 3Gb/s
8 = 8MB buffer
2 = Reserved
