Hard disk drives
Product reference guide
Another stroke of genius from Hitachi
See inside to find out more about our colossal NEW 2TB hard drive!
2009 #14
For more information visit:
www.hitachigst.com

Deskstar™ 7K2000
Huge capacity, highest 7200 RPM reliability
for outstanding performance for desktop
computing
The Deskstar 7K2000 delivers a colossal 2TB
of storage capacity. Now in its fourth-
generation, the unique 5-platter design from
Hitachi utilizes relaxed bit density as well
as the industries most reliable proven
Perpendicular Magnetic Recording (PMR)
technology.
Deskstar 7K1000.C
Exceptional blend of power efficiency and
performance with up to 1TB capacity
Deskstar 7K1000.C is the 3rd generation of
1TB from Hitachi providing the right mix of
performance and power efficiency making it
ideal for power–friendly PCs.
Travelstar™ 7K500
7200RPM 2.5-inch hard drive with capacities
ranging from 120GB to 500GB
Designed to support the high-performance
needs of multi-tasking commercial users
and consumers on-the-go, Travelstar 7K500
offers speed without sacrificing battery life,
capacity or audio quality.
Travelstar 5K500.B
High-capacity EcoTrac storage for
Notebook PCs and mobile applications
Hitachi’s second-generation 500GB,
5400 RPM 2.5-inch hard drive for
entertainment power-house
notebooks. The 5K500.B has the lowest
power consumption in its class and is
halogen-free for an eco-friendly
footprint.
CinemaStar™ 7K1000.C
Power-efficient, high capacity storage
optimized for digital video applications
Hitachi delivers its third-generation 1TB
CinemaStar drive with best-in-class power
management and proven features like
silent-seek acoustics and streaming video
features set to improve handling of multiple,
simultaneous video streams, typical of
surveillance applications.
CinemaStar 5K1000
Cool, quiet, energy-efficient digital video
storage with 24x7 availability
CinemaStar 5K1000 hard drive provides
a generous 1TB of capacity and features
innovative CoolSpin technology to deliver
a new level of power efficiency and quiet
operation for digital video applications.
Ultrastar™ A7K2000
Huge 2TB capacity, reliable, power-efficient
hard drives for the enterprise
Delivers huge capacity to the enterprise,
with up to 2TB of capacity, 7200 RPM
performance and innovative technologies
like Rotational Vibration Safeguard (RVS).
Ultrastar C10K300
Cool, compact with SAS 6Gb/s performance
for 24x7 enterprise enviroments
The C10K300 drive delivers the performance
and reliability demanded in high
performance computing and mission-critical
environments. The ultra fast SAS interface
running at 6Gb/s improves data reliability,
availability and scalability.
Endurastar™ J4K100
Drives that are built to perform in the
harshest enviroments
With capacites up to 100GB and offering
a wider temperature range and improved
altitude range, the Endurastar J4K100 is
designed to operate in the most severe
conditions from -30˚C to +85˚C and
altitudes of -300 to +5500 meters.
Check out our on-line sales training tool
specifically designed for distribution sales
people (in the HDD Info Hub at):
www.hitachigst.com/partners
Use our Drive Quick Search tool to
quickly find information about any
Hitachi hard disk drive:
www.hitachigst.com/drivequicksearch
The Hitachi GST Partners First TM Program
is focused on building strong relationships
with our partners. For more information
and to begin accessing all the benefits
of the program, sign up today at:
www.hitachigst.com/partners
Products Highlights Online tools

The EcoTrac classification was created to assist customers in selecting products that minimize environmental impact
in the areas of product design, manufacturing, operation and disposal.
The EcoTrac symbol identifies Hitachi products that deliver on the following principles:
•Lower operating costs through power-efficient design
•Smaller carbon footprint by reducing waste during manufacturing
•Safer product disposal through a reduction of toxic materials
•Creation of a more sustainable environment through conservation of natural resources in packaging and transportation
EcoTrac Products
Enterprise
Ultrastar 15K450
Ultrastar A7K2000
Ultrastar C10K300
Deskstar E7K1000
PC Storage
Deskstar 7K2000
Deskstar 7K1000.C
Deskstar 7K1000.B
Travelstar 7K320
Travelstar 7K200
Travelstar 7K500
Travelstar 5K500.B
Travelstar 5K320
Travelstar 5K250
Compact DVR
CinemaStar C5K500
CinemaStar C5K320
Full-size DVR
CinemaStar 7K1000.C
CinemaStar 7K1000.B
CinemaStar 5K1000
CinemaStar 5K500
CinemaStar 5K320
Surveillance
CinemaStar 7K1000.C
CinemaStar 7K1000.B
Deskstar E7K1000
CinemaStar 5K1000
CinemaStar C5K500
CinemaStar C5K320
Endurastar J4K100/N4K100

HiVERT™ technology
The first introduction of Hitachi Voltage
Efficiency Regulator (HiVERT) technology was
on a 2.5 inch product now Hitachi uses this
technology to achieve best-in-class power
efficiency on 3.5 inch products. In fact the
DeskstarP7K500 achieves power savings
of up to 40% over previous-generation
products. This reduction was accomplished
by using the same system-on-chip (SoC) that
is used in Hitachi’s Travelstar 2.5-inch mobile
product line, where low power has long been
a key design attribute to maximize battery
life in notebook PCs.
This SoC incorporates HiVERT technology
in which switching regulators are used
in place of less power-efficient linear
regulators in the voltage reduction
processes.
IrMnCr read sensor
To address the demand for increased
capacity and highly reliable operation of the
read sensor, Hitachi scientists developed a
material and process for the manufacture of
ultra-small read sensors. Use of a new read-
head alloy – iridium-manganese-chromium
(IrMnCr), incorporating an extremely thin
layer of ruthenium in the structure to create
a very high “pinning field”, resulted in the
storage industry’s most stable and reliable
read-sensor technology.
CoolSpin Technology
The CinemaStar 5K500, Hitachi’s first
CoolSpin drive, uses an enhanced motor
design to limit peak current during spin-up
and enable lower continuous running power.
With CoolSpin, Hitachi was able to achieve
just the right blend of performance, power
management and acoustics for digital video
applications. CoolSpin drives allow system
builders to develop set-top boxes and DVRs
that run cooler and require less power,
ultimately leading to improved product
reliability and lifespan.
Enhanced Adaptive Battery Life Extender
(ABLE)
Hitachi understands the challenges its
customers face in maximizing battery life
in their products, and engineered the ABLE
power management technology in response.
ABLE enables the host system to realize the
optimum power utilization from the drive,
and customize power consumption at drive
level to suit the specific application.
Hitachi load/unload technology
Load/unload technology helps keep the
read/write heads from coming into contact
with the media - even when the drive is not
rotating.
Some of the many benefits include increased
robustness, reliability and reduced power
consumption. Hitachi is the only company
to use load/unload technology across its
complete product line.
Bulk Data Encryption
Several Hitachi hard drives now offer
optional Bulk Data Encryption – a hard-
drive-level data security mechanism that
puts users’ data effectively ‘under lock
and key’, offering virtually impenetrable
protection. As an alternative to protecting
data through software-based encryption
or system-level passwords, hard-drive level
encryption provides better performance and
a much higher level of security.
Rotational Vibration Safeguard (RVS)
Enterprise class Hitachi hard drives have
advanced Rotational Vibration Safeguard
(RVS) that actually anticipates disturbances
and counteracts them— maximizing
performance in the most arduous conditions.
Vibration sensors at the edges of the disk
feed forward to the actuator, warning it of
oncoming disruption. In benchmark tests,
this technology improves performance in
business and high-end systems by as much
as 300%.
Technology Highlights

Hitachi GST Global Operations
Hitachi GST has a relentless focus on
leveraging its technology leadership to
delight customers around the globe.
Headquartered in San Jose, California,
the company manufactures components
and hard drives at six different locations
worldwide. These facilities are strategically
located near major customers, suppliers
and partners. Hitachi GST is committed
to customer satisfaction and provides
customer support and service operations
throughout the world. The company also
has world-class research and development
teams located in multiple geographies,
which are easily accessible to our factories
for pilot-line testing.
Shenzhen, China
Beijing, China
Havant, U.K.
Netherlands
Prachinburi, Thailand Laguna, Philippines
Odawara, Japan
Rochester, Minnesota
Fujisawa, Japan
Taiwan
Global Center
Singapore
U.S. Headquarters
San Jose, California
Sarawak, Malaysia
Research and Development
Manufacturing Locations
Customer System Integration Labs
China / Japan / Singapore / Taiwan / U.S.
Logistics Centers
Japan / Netherlands / Singapore / Taiwan / U.S.

Deskstar Reliable, power-efficient hard drives for value storage systems with Rotational Vibration Safeguard and 5-year warranty.
E7K1000:
Deskstar E7K1000 HDE721010SLA330 0A38028 1TB SATA 3Gb/s 3.5-inch 7200 32MB Targeted 1.2 million hours MTBF
HDE721075SLA330 0A38027 750GB SATA 3Gb/s 3.5-inch 7200 32MB Targeted 1.2 million hours MTBF
HDE721050SLA330 0A38025 500GB SATA 3Gb/s 3.5-inch 7200 32MB Targeted 1.2 million hours MTBF
Ultrastar: Proven reliability to help protect data in mission-critical applications. Stable design for fast and easy integration.
Rotational Vibration Safeguard technology for great performance in multi-drive designs.
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
Ultrastar A7K2000 HUA722020ALA330 0F10452 2TB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HUA722020ALA331 0F10937 2TB SATA 3Gb/s 3.5-inch 7200 32MB Bulk Data Encryption - New Q3 2009
HUA722010CLA330 0A39289 1TB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HUA722010CLA331 TBD 1TB SATA 3Gb/s 3.5-inch 7200 32MB Bulk Data Encryption - New Q3 2009
HUA722050CLA330 TBD 500GB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HUA722050CLA331 TBD 500GB SATA 3Gb/s 3.5-inch 7200 32MB Bulk Data Encryption - New Q3 2009
Ultrastar 15K300 HUS153030VL3800 0B22138 300GB Ultra320 (80 pin) 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153030VLF400 0B22144 300GB FC 4Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153030VLS300 0B22132 300GB SAS 3Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153014VL3800 0B22137 147GB Ultra320 (80 pin) 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153014VLF400 0B22143 147GB FC 4Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153014VLS300 0B22131 147GB SAS 3Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153073VL3800 0B22136 73GB Ultra320 (80 pin) 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153073VLF400 0B22142 73GB FC 4Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS153073VLS300 0B22130 73GB SAS 3Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
Ultrastar 15K450 HUS154545VLF400 0B22888 450GB FC 4Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS154545VLS300 0B22890 450GB SAS 3Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS154530VLF400 0B23316 300GB FC 4Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
HUS154530VLS300 0B23318 300GB SAS 3Gb/s 3.5-inch 15K 16MB Suitable for mission-critical 24x7 applications
Ultrastar C10K300 HUC103030CSS600 0B23695 300GB SAS 6Gb/s 2.5-inch 10K 64MB Targeted 1.6 million hours MTBF
HUC103014CSS600 0B23700 147GB SAS 6Gb/s 2.5-inch 10K 64MB Targeted 1.6 million hours MTBF
Ultrastar C10K147 HUC101414CSS300 0B21914 147GB SAS 3Gb/s 2.5-inch 10K 16MB Small form factor for the enterprise
HUC101473CSS300 0B21947 73GB SAS 3Gb/s 2.5-inch 10K 16MB Small form factor for the enterprise
Deskstar: The Deskstar 7K2000 has a colossal 2TB of capacity, while delivering exceptional blend of power efficiency and performance
making it an ideal solution for desktop storage.
Deskstar 7K2000 HDS722020ALA330 0F10311 2TB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
Deskstar 7K1000.C HDS721010CLA332 0F10383 1TB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HDS721075CLA332 0F10382 750GB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HDS721064CLA332 0A39267 640GB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HDS721050CLA362 0F10381 500GB SATA 3Gb/s 3.5-inch 7200 16MB New Q3 2009

Deskstar: The Deskstar 7K2000 has a colossal 2TB of capacity, while delivering exceptional blend of power efficiency and performance
making it an ideal solution for desktop storage.
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
Deskstar 7K1000.C HDS721050CLA382 0F10380 500GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
HDS721032CLA362 0A39264 320GB SATA 3Gb/s 3.5-inch 7200 16MB New Q3 2009
HDS721032CLA382 0A39263 320GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
HDS721025CLA382 0F10379 250GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
HDS721016CLA382 0A39261 160GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
Deskstar 7K1000.B HDT721010SLA360 0A38016 | 0A37993 | 0A38912 1TB SATA 3Gb/s 3.5-inch 7200 16MB Ideal for power friendly PCs
HDT721075SLA360 0A37992 | 0A38911 | 0A38015 750GB SATA 3Gb/s 3.5-inch 7200 16MB Ideal for power friendly PCs
HDT721064SLA360 0A38910 | 0A38014 | 0A37991 640GB SATA 3Gb/s 3.5-inch 7200 16MB Ideal for power friendly PCs
HDT721032SLA380 0A38007 | 0A37574 | 0A38903 320GB SATA 3Gb/s 3.5-inch 7200 8MB Ideal for power friendly PCs
HDT721032SLA360 0A38018 320GB SATA 3Gb/s 3.5-inch 7200 16MB Ideal for power friendly PCs
HDT721025SLA380 0A38902 | 0A38006 | 0A37572 250GB SATA 3Gb/s 3.5-inch 7200 8MB Ideal for power friendly PCs
HDT721016SLA380 0A37571 | 0A38901 | 0A38005 160GB SATA 3Gb/s 3.5-inch 7200 8MB Ideal for power friendly PCs
Deskstar 7K1000 HDS721010KLA330 0A33863 | 0A36414 | 0A35155 | 0A34915
0A34193
1TB SATA 3Gb/s 3.5-inch 7200 32MB
HDS721075KLA330 0Y30042 | 0A36413 | 0A35154 | 0A34914
0A34192
750GB SATA 3Gb/s 3.5-inch 7200 32MB
Deskstar P7K500 HDP725050GLAT80 0A35397 | 0A36512 500GB PATA 133MB/s 3.5-inch 7200 8MB
HDP725050GLA360 0A35415 | 0A36523 500GB SATA 3Gb/s 3.5-inch 7200 16MB
HDP725050GLA380 0A36519 500GB SATA 3Gb/s 3.5-inch 7200 8MB
HDP725032GLAT80 0A35393 | 0A36510 320GB PATA 133MB/s 3.5-inch 7200 8MB
HDP725032GLA380 0A36517 320GB SATA 3Gb/s 3.5-inch 7200 8MB
HDP725032GLA360 0A35411 | 0A36521 320GB SATA 3Gb/s 3.5-inch 7200 16MB
HDP725025GLAT80 0A35390 | 0A36508 250GB PATA 133MB/s 3.5-inch 7200 8MB
HDT725025VLAT80 0A33408 | 0A33697 250GB PATA 133MB/s 3.5-inch 7200 8MB
HDP725025GLA380 0A35399 | 0A36515 250GB SATA 3Gb/s 3.5-inch 7200 8MB
HDP725016GLAT80 0A35389 160GB PATA 133MB/s 3.5-inch 7200 8MB
HDP725016GLA380 0A35398 160GB SATA 3Gb/s 3.5-inch 7200 8MB
Deskstar T7K500 HDT725050VLAT80 0A33407 | 0A33700 500GB PATA 133MB/s 3.5-inch 7200 8MB
HDT725050VLA360 0A33437 | 0A34978 500GB SATA 3Gb/s 3.5-inch 7200 16MB
HDT725032VLA360 0A33435 320GB SATA 3Gb/s 3.5-inch 7200 16MB
HDT725032VLAT80 0A33405 | 0A33415 320GB SATA 3Gb/s 3.5-inch 7200 8MB
HDT725025VLA380 0A33423 | 0A33428 250GB SATA 3Gb/s 3.5-inch 7200 8MB
CinemaStar: Optimized for streaming video applications like surveillance systems and high-definition digital video recorders.
Super quiet operation and low-power requirements deliver customer satisfaction and superb field reliability.
CinemaStar 7K1000.C HCS721010CLA332 0F10776 1TB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HCS721075CLA332 0F10775 750GB SATA 3Gb/s 3.5-inch 7200 32MB New Q3 2009
HCS721050CLA382 0F10774 500GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
HCS721032CLA382 0F10773 320GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
HCS721025CLA382 0F10772 250GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009

CinemaStar: Optimized for streaming video applications like surveillance systems and high-definition digital video recorders.
Super quiet operation and low-power requirements deliver customer satisfaction and superb field reliability.
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
CinemaStar 7K1000.C HCS721016CLA382 0F10771 160GB SATA 3Gb/s 3.5-inch 7200 8MB New Q3 2009
CinemaStar 5K1000 HCS5C1010CLA382 0A39420 1TB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
HCS5C1075CLA382 0A39419 750GB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
HCS5C1050CLA382 0A39418 500GB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
HCS5C1032CLA382 0A39417 320GB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
HCS5C1025CLA382 0A39416 250GB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
HCS5C1016CLA382 0A39415 160GB SATA 3Gb/s 3.5-inch - 8MB Coolspin Technology - New Q3 2009
CinemaStar 7K1000.B HCT721010SLA360 0A37594 1TB SATA 3Gb/s 3.5-inch 7200 16MB Targeted 1.2 million hours MTBF
HCT721075SLA380 0A37592 750GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
HCT721064SLA380 0A37590 640GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
HCT721050SLA380 0A37589 500GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
HCT721032SLA380 0A37587 320GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
HCT721025SLA380 0A37586 250GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
HCT721016SLA380 0A37585 160GB SATA 3Gb/s 3.5-inch 7200 8MB Targeted 1.2 million hours MTBF
CinemaStar 7K1000 HCS721010KLA330 0A35274 1TB SATA 3Gb/s 3.5-inch 7200 32MB
HCS721075KLA330 0A35273 750GB SATA 3Gb/s 3.5-inch 7200 32MB
CinemaStar 7K500 HCS725050VLAT80 0A33512 500GB PATA 133MB/s 3.5-inch 7200 8MB
HCS725050VLA380 0A33516 500GB SATA 3Gb/s 3.5-inch 7200 8MB
HCS725032VLAT80 0A33511 320GB PATA 133MB/s 3.5-inch 7200 8MB
HCS725032VLA380 0A33515 320GB SATA 3Gb/s 3.5-inch 7200 8MB
HCS725025VLAT80 0A33513 250GB PATA 133MB/s 3.5-inch 7200 8MB
HCS725025VLA380 0A33517 250GB SATA 3Gb/s 3.5-inch 7200 8MB
CinemaStar P7K500 HCP725050GLAT80 0A37041 500GB PATA 133MB/s 3.5-inch 7200 8MB
HCP725050GLA380 0A37045 500GB SATA 3Gb/s 3.5-inch 7200 8MB
HCP725032GLAT80 0A37040 320GB PATA 133MB/s 3.5-inch 7200 8MB
HCP725032GLA380 0A37044 320GB SATA 3Gb/s 3.5-inch 7200 8MB
HCP725025GLAT80 0A37039 250GB PATA 133MB/s 3.5-inch 7200 8MB
HCP725025GLA380 0A37043 250GB SATA 3Gb/s 3.5-inch 7200 8MB
HCP725016GLAT80 0A37038 160GB PATA 133MB/s 3.5-inch 7200 8MB
HCP725016GLA380 0A37042 160GB SATA 3Gb/s 3.5-inch 7200 8MB
CinemaStar 7K160 HCS721616PLAT80 0A33482 | 0A33492 160GB PATA 133MB/s 3.5-inch 7200 8MB
HCS721616PLA380 0A33484 | 0A33494 160GB SATA 3Gb/s 3.5-inch 7200 8MB
HCS721680PLA380 0A33493 80GB SATA 3Gb/s 3.5-inch 7200 8MB
HCS721680PLAT80 0A33481 | 0A33491 80GB PATA 133MB/s 3.5-inch 7200 8MB
CinemaStar 5K500 HCS545050GLA380 0A37965 500GB SATA 3Gb/s 3.5-inch - 8MB New CoolSpin technology
HCS545040GLA380 0A37964 400GB SATA 3Gb/s 3.5-inch - 8MB New CoolSpin technology
CinemaStar 5K320 HCS5C3232SLA380 0A38963 320GB SATA 3Gb/s 3.5-inch - 8MB New CoolSpin technology
HCS5C3225SLA380 0A38962 250GB SATA 3Gb/s 3.5-inch - 8MB New CoolSpin technology
CinemaStar C5K500 HCC545050B9A300 0A70535 500GB SATA 3Gb/s 2.5-inch 5400 8MB Fourth generation CE design
HCC545032B9A300 0A70533 320GB SATA 3Gb/s 2.5-inch 5400 8MB Fourth generation CE design
HCC545025B9A300 0A70532 250GB SATA 3Gb/s 2.5-inch 5400 8MB Fourth generation CE design
CinemaStar C5K500 HCC545016B9A300 0A70531 160GB SATA 3Gb/s 2.5-inch 5400 8MB Fourth generation CE design

Travelstar: All Hitachi mobile drives feature industry-leading power management for low power and longer battery life.
The optional disk-level Bulk Data Encryption technology available on most models helps guard against data loss and piracy.
Travelstar 7K500 HTS725050A9A364 0A72335 500GB SATA 3Gb/s 2.5-inch 7200 16MB New Q3 2009
HTS725050A9A361 0A72345 500GB SATA 3Gb/s 2.5-inch 7200 16MB Bulk Data Encryption - New Q3 2009
HTS725032A9A364 0A72333 320GB SATA 3Gb/s 2.5-inch 7200 16MB New Q3 2009
HTS725032A9A361 0A72343 320GB SATA 3Gb/s 2.5-inch 7200 16MB Bulk Data Encryption - New Q3 2009
HTS725025A9A364 0A72332 250GB SATA 3Gb/s 2.5-inch 7200 16MB New Q3 2009
HTS725025A9A361 0A72342 250GB SATA 3Gb/s 2.5-inch 7200 16MB Bulk Data Encryption - New Q3 2009
HTS725016A9A364 0A72331 160GB SATA 3Gb/s 2.5-inch 7200 16MB New Q3 2009
HTS725016A9A361 0A72341 160GB SATA 3Gb/s 2.5-inch 7200 16MB Bulk Data Encryption - New Q3 2009
HTS725012A9A364 0A72330 120GB SATA 3Gb/s 2.5-inch 7200 16MB New Q3 2009
HTS725012A9A361 0A72340 120GB SATA 3Gb/s 2.5-inch 7200 16MB Bulk Data Encryption - New Q3 2009
Travelstar 7K320 HTS723232L9A360 0A57547 320GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS723232L9SA61 0A57527 320GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
Travelstar 7K320 HTS723225L9A360 0A57546 250GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS723225L9SA61 0A57526 250GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS723216L9A360 0A57543 160GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS723216L9SA61 0A57523 160GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS723212L9A360 0A57542 120GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS723212L9SA61 0A57522 120GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS723280L9A360 0A57541 80GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS723280L9SA61 0A57521 80GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
Travelstar 7K200 HTS722020K9A300 0A53065 200GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS722020K9SA00 0A50940 200GB SATA 1.5Gb/s 2.5-inch 7200 8MB
HTS722080K9SA00 0A53070 200GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS722020K9SA00 0A55575 200GB SATA 1.5Gb/s 2.5-inch 7200 8MB
HTS722016K9A300 0A53064 160GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS722016K9SA00 0A53069 160GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS722016K9SA00 0A50939 160GB SATA 1.5Gb/s 2.5-inch 7200 8MB
HTS722012K9A300 0A53063 120GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS722012K9SA00 0A53068 120GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS722012K9SA00 0A50938 120GB SATA 1.5Gb/s 2.5-inch 7200 8MB
HTS722010K9A300 0A53062 100GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS722010K9SA00 0A53067 100GB SATA 1.5Gb/s 2.5-inch 7200 16MB Bulk Data Encryption
HTS722010K9SA00 0A50937 100GB SATA 1.5Gb/s 2.5-inch 7200 8MB
CinemaStar: Optimized for streaming video applications like surveillance systems and high-definition digital video recorders.
Super quiet operation and low-power requirements deliver customer satisfaction and superb field reliability.
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
CinemaStar C5K320 HCC543232L9SA00 0A58617 320GB SATA 1.5Gb/s 2.5-inch 5400 8MB
HCC543225L9SA00 0A58615 250GB SATA 1.5Gb/s 2.5-inch 5400 8MB
HCC543216L9SA00 0A58613 160GB SATA 1.5Gb/s 2.5-inch 5400 8MB
HCC543212L9SA00 0A58612 120GB SATA 1.5Gb/s 2.5-inch 5400 8MB

TravelStar These drives include design enhancements for data intensive applications requiring round-the-clock operation
Enhanced Availability: such as industrial systems, network routers/telephony, point-of-sale terminals, web hosting, and video surveillance.
Travelstar: All Hitachi mobile drives feature industry-leading power management for low power and longer battery life.
The optional disk-level Bulk Data Encryption technology available on most models helps guard against data loss and piracy.
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
Travelstar 7K200 HTS722080K9A300 0A53061 80GB SATA 3Gb/s 2.5-inch 7200 16MB
HTS722080K9SA00 0A50936 80GB SATA 1.5Gb/s 2.5-inch 7200 8MB
Travelstar 5K500.B HTS545050B9A300 0A57915 500GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545050B9A301 0A59505 500GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS545040B9A300 0A57914 400GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545040B9A301 0A59504 400GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS545032B9A300 0A57913 320GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545032B9A301 0A59503 320GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS545025B9A300 0A57912 250GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545025B9A301 0A59502 250GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS545016B9A300 0A57911 160GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545016B9A301 0A59501 160GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS545012B9A300 0A57910 120GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS545012B9A301 0A59500 120GB SATA 3Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
Travelstar 5K320 HTS543232L9A300 0A56417 320GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543232L9SA01 0A56407 320GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS543225L9A300 0A56415 250GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543225L9SA01 0A56405 250GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS543216L9A300 0A56413 160GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543216L9SA01 0A56403 160GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS543212L9A300 0A56412 120GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543212L9SA01 0A56402 120GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS543280L9A300 0A56411 80GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543280L9SA01 0A56401 80GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
Travelstar 5K250 HTS542525K9A300 0A53329 | 0A53409 | 0A54966 250GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS542525K9SA00 0A53399 250GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS542520K9A300 0A52123 200GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS542516K9A300 0A52124 | 0A53404 160GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS542516K9SA00 0A53394 160GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS542512K9A300 0A52126 | 0A53406 120GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS542512K9SA00 0A53396 120GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
HTS542580K9A300 0A52127 | 0A53407 80GB SATA 3Gb/s 2.5-inch 5400 8MB
HTS543280L9SA00 0A53397 80GB SATA 1.5Gb/s 2.5-inch 5400 8MB Bulk Data Encryption
Travelstar These drives include design enhancements for data intensive applications requiring round-the-clock operation
Enhanced Availability: such as industrial systems, network routers/telephony, point-of-sale terminals, web hosting, and video surveillance.
Travelstar 7K320 HTE723232L9A300 0A59577 320GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
HTE723225L9A300 0A59576 250GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
HTE723216L9A300 0A59573 160GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications

Travelstar These drives include design enhancements for data intensive applications requiring round-the-clock operation
Enhanced Availability: such as industrial systems, network routers/telephony, point-of-sale terminals, web hosting, and video surveillance.
Endurastar: Designed specifically to perform in extreme temperature environments. Ideal for automotive entertainment, surveillance
and navigation applications. Now offering a much wider temperature range and industry-leading altitude specifications.
Endurastar J4K100 HEJ421010G9AT00 0A60166 | 0A60167 100GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -30° to +85° C
HEJ421010G9SA00 0A60173 | 0A60174 100GB SATA 1.5Gb/s 2.5-inch 4200 8MB Op temp -30° to +85° C
HEJ421080G9AT00 0A60164 | 0A60165 80GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -30° to +85° C
HEJ421080G9SA00 0A60171 | 0A60172 80GB SATA 1.5Gb/s 2.5-inch 4200 8MB Op temp -30° to +85° C
HEJ421040G9AT00 0A60162 | 0A60163 40GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -30° to +85° C
Endurastar N4K100 HEN421010G9AT00 0A60170 100GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -20° to +75° C
HEN421080G9AT00 0A60169 80GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -20° to +75° C
HEN421040G9T00 0A60168 40GB PATA 100MB/s 2.5-inch 4200 8MB Op temp -20° to +75° C
Endurastar J4K50 HEJ425050F9AT00 0A60006 | 0A60008 50GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -30° to +85° C
HEJ425040F9AT00 0A60003 | 0A60005 40GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -30° to +85° C
HEJ425030F9AT00 0A60000 | 0A60002 30GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -30° to +85° C
Endurastar N4K50 HEN425050F9AT00 0A60011 50GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -16° to +70° C
HEN425040F9AT00 0A60010 40GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -16° to +70° C
HEN425030F9AT00 0A60009 30GB PATA 100MB/s 2.5-inch 4260 8MB Op temp -16° to +70° C
Product name Model number Part number/Alternate part numbers Capacity Interface Form
factor
RPM Buffer Other information
Travelstar 7K320 HTE723212L9A300 0A59572 120GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
Travelstar E7K200 HTE722020K9A300 0A55005 200GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
Travelstar 7K500 HTE725050A9A364 0A73255 500GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 application
HTE725032A9A364 0A73253 320GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 application
HTE725025A9A364 0A73252 250GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 application
HTE725016A9A364 0A73251 160GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 application
Travelstar E7K200 HTE722016K9A300 0A55004 160GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
HTE722016K9A300 0A55004 120GB SATA 3Gb/s 2.5-inch 7200 16MB Suitable for mission-critical 24x7 applications
Travelstar 5K500.B HTE545050B9A300 0A70395 500GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE545032B9A300 0A70393 320GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE545025B9A300 0A70392 250GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE545016B9A300 0A70391 160GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
Travelstar E5K500 HTE545050KTA300 0A57319 500GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
Travelstar 5K320 HTE543232L9A300 0A58607 320GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE543225L9A300 0A58605 250GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE543216L9A300 0A58603 160GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE543212L9A300 0A58602 120GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
Travelstar E5K250 HTE542525K9A300 0A55266 250GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE542516K9A300 0A55264 160GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE542512K9A300 0A55263 120GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications
HTE542580K9A300 0A55261 80GB SATA 3Gb/s 2.5-inch 5400 8MB Suitable for mission-critical 24x7 applications

Hitachi advanced disk drive technologies deliver performance, reliability and
security across a wide portfolio. Whether for desktops, video recorders,
closed circuit TV applications, online transaction processing, PC gaming
machines, ATA servers or disk-to-disk backup and recovery, our technology
ensures that Hitachi drives meet and exceed the highest expectations.
©2009 Hitachi Global Storage Technologies.
All rights reserved.
Endurastar, Travelstar, Ultrastar, Deskstar, CinemaStar, CoolSpin, EcoTrac, Partners First and HiVERT are trademarks of
Hitachi Global Storage Technologies.
Hitachi GST trademarks are authorized for use in countries and jurisdictions in which Hitachi GST has the right to
use, market and advertise the brands. The Travelstar trademark is authorized for use in the Americas, EMEA, and
the following Asia-Pacific countries and jurisdictions: Australia, Hong Kong, Japan, New Zealand, South Korea
and Taiwan. Contact Hitachi GST for further information. Hitachi GST shall not be liable to third parties for
unauthorized use of Hitachi GST trademarks.
One GB is equal to one billion bytes and one TB equals 1,000GB (one trillion bytes) when referring to hard
drive capacity. Accessible capacity may be less.
www.hitachigst.com
