Hitachi Virtual Storage Platform G400, G600

83-05-2x

Hardware Reference Guide

This document provides information about the system hardware components, mechanical, and

environmental specifications for the Hitachi Virtual Storage Platform G400 and VSP G600 storage

systems.

MK-94HM8022-15

March 2021

No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including copying and recording,

or stored in a database or retrieval system for commercial purposes without the express written permission of Hitachi, Ltd., or Hitachi Vantara LLC

(collectively “Hitachi”). Licensee may make copies of the Materials provided that any such copy is: (i) created as an essential step in utilization of the

Software as licensed and is used in no other manner; or (ii) used for archival purposes. Licensee may not make any other copies of the Materials.

“Materials” mean text, data, photographs, graphics, audio, video and documents.

Hitachi reserves the right to make changes to this Material at any time without notice and assumes no responsibility for its use. The Materials contain

the most current information available at the time of publication.

Some of the features described in the Materials might not be currently available. Refer to the most recent product announcement for information about

feature and product availability, or contact Hitachi Vantara LLC at https://support.hitachivantara.com/en_us/contact-us.html.

Notice: Hitachi products and services can be ordered only under the terms and conditions of the applicable Hitachi agreements. The use of Hitachi

products is governed by the terms of your agreements with Hitachi Vantara LLC.

By using this software, you agree that you are responsible for:

1. Acquiring the relevant consents as may be required under local privacy laws or otherwise from authorized employees and other individuals; and

2. Verifying that your data continues to be held, retrieved, deleted, or otherwise processed in accordance with relevant laws.

Notice on Export Controls. The technical data and technology inherent in this Document may be subject to U.S. export control laws, including the

U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries. Reader agrees to

comply strictly with all such regulations and acknowledges that Reader has the responsibility to obtain licenses to export, re-export, or import the

Document and any Compliant Products.

Hitachi and Lumada are trademarks or registered trademarks of Hitachi, Ltd., in the United States and other countries.

AIX, AS/400e, DB2, Domino, DS6000, DS8000, Enterprise Storage Server, eServer, FICON, FlashCopy, GDPS, HyperSwap, IBM, Lotus, MVS, OS/

390, PowerHA, PowerPC, RS/6000, S/390, System z9, System z10, Tivoli, z/OS, z9, z10, z13, z14, z/VM, and z/VSE are registered trademarks or

trademarks of International Business Machines Corporation.

Active Directory, ActiveX, Bing, Excel, Hyper-V, Internet Explorer, the Internet Explorer logo, Microsoft, the Microsoft Corporate Logo, MS-DOS,

Outlook, PowerPoint, SharePoint, Silverlight, SmartScreen, SQL Server, Visual Basic, Visual C++, Visual Studio, Windows, the Windows logo,

Windows Azure, Windows PowerShell, Windows Server, the Windows start button, and Windows Vista are registered trademarks or trademarks of

Microsoft Corporation. Microsoft product screen shots are reprinted with permission from Microsoft Corporation.

All other trademarks, service marks, and company names in this document or website are properties of their respective owners.

Copyright and license information for third-party and open source software used in Hitachi Vantara products can be found at https://

www.hitachivantara.com/en-us/company/legal.html.

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 2

Contents

Preface......................................................................................................6

Intended audience............................................................................................... 6

UEFI Development Kit 2010................................................................................ 6

Product version....................................................................................................7

Release notes......................................................................................................7

Changes in this revision.......................................................................................7

Document conventions........................................................................................ 7

Conventions for storage capacity values............................................................. 9

Accessing product documentation.....................................................................10

Getting help........................................................................................................10

Comments..........................................................................................................10

Chapter 1: Hitachi Virtual Storage Platform G400, G600 hardware

overview.................................................................................................. 11

Block configuration.............................................................................................11

Unified configuration.......................................................................................... 12

VSP G400 model............................................................................................... 12

VSP G600 model............................................................................................... 15

Features.............................................................................................................18

Scalability...........................................................................................................19

Examples of supported VSP G400 configurations....................................... 19

Examples of supported VSP G600 configurations....................................... 19

Maximum number of mounted drive trays.................................................... 20

Chapter 2: Virtual Storage Platform G400, G600 controller...................23

CBLM controller................................................................................................. 23

CBLM with front panel bezel........................................................................ 23

CBLM front panel LEDs (without bezel)....................................................... 24

CBLM rear panel.......................................................................................... 26

CBLM power supply unit LEDs and connectors........................................... 28

Host, Network, and Drive Tray Ports and LEDs.................................................28

Front-end modules....................................................................................... 28

10-Gbps iSCSI board LEDs and connectors (optical).............................29

10-Gbps iSCSI board LEDs and connectors (copper)............................ 29

or 32-Gbps Fibre Channel (4-port) board LEDs and connectors............ 29

Contents

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 3

16-Gbps Fibre Channel (2-port) board LEDs and connectors................ 29

LAN blade LEDs and connectors................................................................. 31

Back-end modules........................................................................................31

Chapter 3: Drive trays............................................................................ 33

Small form-factor drive tray (DBS/DBSE).......................................................... 33

SFF with front panel bezel............................................................................33

SFF front panel without bezel.......................................................................34

SFF rear panel..............................................................................................35

SFF and LFF AC power supply unit LEDs and connectors..........................36

SFF power supply unit LEDs and connectors.............................................. 37

Large form-factor drive tray (DBL/DBLE)...........................................................37

LFF with front panel bezel............................................................................ 38

LFF front panel without bezel....................................................................... 38

LFF rear panel..............................................................................................39

SFF and LFF AC power supply unit LEDs and connectors..........................40

SFF power supply unit LEDs and connectors.............................................. 41

Flash module drive tray (DBF)...........................................................................41

FMD with front panel bezel...........................................................................42

FMD front panel without bezel......................................................................43

FMD rear panel.............................................................................................44

High-density intermix drive tray (DB60)............................................................. 45

Dense intermix drive tray with front panel bezel...........................................46

Dense intermix drive tray display LEDs........................................................47

Dense intermix drive tray rear panel.............................................................48

Chapter 4: Host port expansion chassis................................................. 50

Host port expansion chassis front panel bezel LEDs........................................ 50

PCIe switchboard...............................................................................................50

Host port expansion chassis fan........................................................................51

PCIe cable connector........................................................................................ 52

Host port expansion chassis power supply........................................................53

Chapter 5: NAS module.......................................................................... 55

NAS Module Ports and LEDs............................................................................ 55

Chapter 6: Maintaining the storage system............................................ 57

Storing the storage system................................................................................ 57

Powering off the storage system........................................................................57

Battery unit.........................................................................................................58

Removing cables............................................................................................... 58

Contents

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 4

Appendix A: Mechanical specifications for VSP G400, G600 ...............60

VSP G400 and VSP G600 mechanical specifications....................................... 60

Appendix B: Electrical specifications for VSP G400, G600.................... 69

Electrical specifications......................................................................................69

Appendix C: Environmental specifications for VSP G400, G600............71

Environmental specifications............................................................................. 71

Appendix D: iSCSI standards and specifications....................................77

iSCSI standards.................................................................................................77

iSCSI specifications........................................................................................... 77

Appendix E: Replacement parts............................................................. 82

Battery unit.........................................................................................................82

Appendix F: Data and power cables....................................................... 83

Required cables.................................................................................................83

Fibre Channel cables.........................................................................................85

iSCSI cables...................................................................................................... 88

iSCSI standards............................................................................................90

iSCSI specifications......................................................................................91

Managing cables................................................................................................94

AC power cables................................................................................................96

Power cable assemblies...............................................................................97

AC connections............................................................................................ 98

Power cable usage guidelines....................................................................100

Three-phase power considerations for racks............................................. 101

Cable management.................................................................................... 101

Appendix G: Port address mapping...................................................... 102

Port address mapping......................................................................................102

Appendix H: Non-Hitachi racks............................................................. 104

Non-Hitachi rack support ................................................................................ 104

Hitachi Universal V2 Rack rail kits................................................................... 104

Hitachi Universal V2 Rack accessories........................................................... 105

Third-party rack support for DB60 dense intermix drive trays......................... 105

Appendix I: Regulatory compliance...................................................... 107

Appendix J: Environmental notices.......................................................109

Contents

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 5

Preface

This guide describes the hardware features and specifications of the VSP G400, G600

models.

Intended audience

This document is intended for Hitachi Vantara representatives, system administrators,

authorized service providers, or customers who install, configure, and operate the storage

system.

Readers of this document should be familiar with the following:

■Data processing and RAID storage systems and their basic functions

■RAID storage system hardware components and operational specifications

UEFI Development Kit 2010

This product includes UEFI Development Kit 2010 written by the UEFI Open Source

Community. For more information, see the UEFI Development Kit website:

http://sourceforge.net/apps/mediawiki/tianocore/index.php?title=UDK2010

Redistribution and use in source and binary forms, with or without modification, are permitted

provided that the following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions

and the following disclaimer.

Redistributions in binary form must reproduce the above copyright notice, this list of

conditions and the following disclaimer in the documentation and/or other materials provided

with the distribution.

Neither the name of the Intel Corporation nor the names of its contributors might be used to

endorse or promote products derived from this software without specific prior written

permission.

Preface

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 6

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS

“AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED

TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT

OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,

SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT

LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,

DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY

THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT

(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE

OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Product version

This document revision applies to the following product versions:

■VSP G400, G600 firmware 83-05-2x or later

■Hitachi Storage Virtualization Operating System (SVOS) 7.4.0 or later

■Hitachi NAS firmware version 13.1 or later

Release notes

Read the release notes before installing and using this product. They may contain

requirements or restrictions that are not fully described in this document or updates or

corrections to this document. Release notes are available on Hitachi Vantara Support

Connect: https://knowledge.hitachivantara.com/Documents.

Changes in this revision

■Added support for DW-F800-NASR (RoHS Compliant)

Document conventions

This document uses the following typographic conventions:

Convention Description

Bold ■Indicates text in a window, including window titles, menus, menu

options, buttons, fields, and labels. Example:

Click OK.

■Indicates emphasized words in list items.

Product version

Preface

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 7

Convention Description

Italic ■Indicates a document title or emphasized words in text.

■Indicates a variable, which is a placeholder for actual text provided

by the user or for output by the system. Example:

pairdisplay -g group

(For exceptions to this convention for variables, see the entry for

angle brackets.)

Monospace Indicates text that is displayed on screen or entered by the user.

Example: pairdisplay -g oradb

< > angle

brackets

Indicates variables in the following scenarios:

■Variables are not clearly separated from the surrounding text or

from other variables. Example:

Status-<report-name><file-version>.csv

■Variables in headings.

[ ] square

brackets

Indicates optional values. Example: [ a | b ] indicates that you can

choose a, b, or nothing.

{ } braces Indicates required or expected values. Example: { a | b } indicates that

you must choose either a or b.

| vertical bar Indicates that you have a choice between two or more options or

arguments. Examples:

[ a | b ] indicates that you can choose a, b, or nothing.

{ a | b } indicates that you must choose either a or b.

This document uses the following icons to draw attention to information:

Icon Label Description

Note Calls attention to important or additional information.

Tip Provides helpful information, guidelines, or suggestions for

performing tasks more effectively.

Caution Warns the user of adverse conditions and/or consequences (for

example, disruptive operations, data loss, or a system crash).

Document conventions

Preface

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 8

Icon Label Description

WARNING Warns the user of a hazardous situation which, if not avoided,

could result in death or serious injury.

Conventions for storage capacity values

Physical storage capacity values (for example, disk drive capacity) are calculated based on

the following values:

Physical capacity unit Value

1 kilobyte (KB) 1,000 (103) bytes

1 megabyte (MB) 1,000 KB or 1,0002 bytes

1 gigabyte (GB) 1,000 MB or 1,0003 bytes

1 terabyte (TB) 1,000 GB or 1,0004 bytes

1 petabyte (PB) 1,000 TB or 1,0005 bytes

1 exabyte (EB) 1,000 PB or 1,0006 bytes

Logical capacity values (for example, logical device capacity, cache memory capacity) are

calculated based on the following values:

Logical capacity unit Value

1 block 512 bytes

1 cylinder Mainframe: 870 KB

Open-systems:

■OPEN-V: 960 KB

■Others: 720 KB

1 KB 1,024 (210) bytes

1 MB 1,024 KB or 1,0242 bytes

1 GB 1,024 MB or 1,0243 bytes

1 TB 1,024 GB or 1,0244 bytes

1 PB 1,024 TB or 1,0245 bytes

Conventions for storage capacity values

Preface

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 9

Logical capacity unit Value

1 EB 1,024 PB or 1,0246 bytes

Accessing product documentation

Product user documentation is available on the Hitachi Vantara Support Website: https://

knowledge.hitachivantara.com/Documents. Check this site for the most current

documentation, including important updates that may have been made after the release of

the product.

Getting help

The Hitachi Vantara Support Website is the destination for technical support of products and

solutions sold by Hitachi Vantara. To contact technical support, log on to the Hitachi Vantara

Support Website for contact information: https://support.hitachivantara.com/en_us/contact-

us.html.

Hitachi Vantara Community is a global online community for Hitachi Vantara customers,

partners, independent software vendors, employees, and prospects. It is the destination to

get answers, discover insights, and make connections. Join the conversation today! Go to

community.hitachivantara.com, register, and complete your profile.

Comments

Please send us your comments on this document to [email protected].

Include the document title and number, including the revision level (for example, -07), and

refer to specific sections and paragraphs whenever possible. All comments become the

property of Hitachi Vantara LLC.

Thank you!

Accessing product documentation

Preface

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 10

Chapter 1: Hitachi Virtual Storage Platform

G400, G600 hardware overview

Hitachi Virtual Storage Platform G400, G600 are modular, rack-mountable, all-flash arrays

that deliver high performance, high reliability, and flash-accelerated scalability.

The storage system contain dual controllers, each controller contains its own processor, dual

in-line cache memory modules (DIMMs), cache flash memory (CFM), battery, fans and iSCSI

and Fibre Channel I/O modules. Each controller also has an Ethernet connection for out-of-

band management. If the data path through one controller fails, all data drives remain

available to data hosts using a redundant data path through the other controller.

The storage system can be equipped with embedded network-attached storage (NAS)

modules. The NAS modules provide file access through CIFS and NFS protocols and block

access by using iSCSI protocols.

All storage system models allow defective drives to be replaced without the interruption of

data availability to hosts. A hot spare drive can be configured to replace a failed drive

automatically, securing the fault-tolerant integrity of the logical drives. Self-contained,

hardware-based RAID logical drives provide maximum performance in compact external

enclosures.

Essential hardware components are implemented with a redundant configuration so that the

storage system can remain operational if a component fails. Adding and replacing

components, along with firmware upgrades, can be conducted while the storage system is

active.

Block configuration

A storage system configured for block-level storage provides the ability to access and

provision raw storage volumes using protocols such as Fibre Channel and iSCSI.

A block configuration consists of the following:

■Two controllers

■One or more drive trays

■Optional service processor (SVP)

Chapter 1: Hitachi Virtual Storage Platform G400, G600 hardware overview

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 11

Unified configuration

A unified configuration includes embedded NAS modules that support file system protocols

such as CIFS and NFS and operate across a block-level setup using iSCSI or FC

connections.

■Two controllers

■Two NAS modules for file operations and storage

■One or more drive trays for block-level storage

■One 1U block service processor server (SVP)

VSP G400 model

The VSP G400 is a highly reliable storage system that offers high storage capacity with full

redundancy to better protect data and manage storage operations.

The storage system consists of a 4U enclosure that includes two controllers and two NAS

modules to support file operations. Drives are supported using drive trays connected to the

controllers. The maximum number of drives supported is 384 (480 with dense intermix drive

tray).

The storage system supports 128 GB of high-speed cache memory. The DIMMs are arranged

as 64 GB per controller.

Storage system interfaces consist of:

■10-Gbps iSCSI: 28 ports per system (or 32 ports per systems for systems without drives

or 12 ports per systems when NAS Modules are installed)

■10-Gbps iSCSI (Copper): 28 ports per system (or 32 ports per systems for systems

without drives or 12 ports per systems when NAS Modules are installed)

■8-Gbps Fibre Channel: 56 ports per system (or 64 ports per systems for systems without

drives or 24 ports per systems when NAS Modules are installed)

■16-Gbps Fibre Channel (2-port): 28 ports per system (or 32 ports per systems for systems

without drives or 12 ports per systems when NAS Modules are installed)

■16-Gbps Fibre Channel (4-port): 56 ports per system (or 64 ports per systems for systems

without drives or 24 ports per systems when NAS Modules are installed)

■32-Gbps Fibre Channel (4-port): 56 ports per system (or 64 ports per systems for systems

without drives or 24 ports per systems when NAS Modules are installed)

Controller Controller chassis Controller model Height

CBLM DW800-CBL DW-F800-CTLM 4U (174.3 mm)

Unified configuration

Chapter 1: Hitachi Virtual Storage Platform G400, G600 hardware overview

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 12

Controller Model number Description

NAS ■DW-F800-NAS

■DW-F800-NASR

NAS modules provide file

support.

Drive tray

model name

Supported

drive type

Number of

drives

supported Height

SFF drive tray ■DW-F800-

DBS (power

supply,

contains

BNST)

■DW-F800-

DBSC

(Silver-rated

power

supply)

■DW-F800-

DBSE

(Platinum-

rated power

supply)

2.5-inch SFF 24 2U (86.2 mm)

LFF drive tray ■DW-F800-

DBL (power

supply,

contains

BNST)

■DW-F800-

DBLC

(Silver-rated

power

supply)

■DW-F800-

DBLE

(Platinum-

rated power

supply)

3.5-inch LFF 12 2U (86.2 mm)

FMD tray ■DW-F800-

DBF

5.25-inch FMD 12 2U (86.2 mm)

VSP G400 model

Chapter 1: Hitachi Virtual Storage Platform G400, G600 hardware overview

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 13

Drive tray

model name

Supported

drive type

Number of

drives

supported Height

Dense intermix

drive tray

■DW-F800-

DB60 (power

supply,

contains

BNST)

■DW-F800-

DB60C

3.5-inch LFF 60 4U (174.3 mm)

Disk drives

The VSP G400 storage system supports the listed disk drive capacities.

Model number Drive type Drive capacity

DKC-F810I-600JCM SFF disk drive 600 GB

DKC-F810I-1R2JCM SFF disk drive 1.2 TB

DKC-F810I-1R2J5M LFF disk drive 1.2 TB

DKC-F810I-2R4JGM SFF disk drive 2.4 TB

DKC-F810I-2R4J8M LFF disk drive 2.4 TB

DKC-F810I-6R0H9M LFF disk drive 6 TB

DKC-F810I-10RH9M LFF disk drive 10 TB

Flash module drives

The VSP G400 storage system supports the listed flash module drive capacities.

Model number Drive type Drive capacity

DKC-F810I-7R0FP FMD 7 TB

DKC-F810I-14RFP FMD 14 TB

Solid-state drives

The VSP G400 storage system supports the listed SSD capacities.

Model number Drive type Drive capacity

VSP G400 model

Chapter 1: Hitachi Virtual Storage Platform G400, G600 hardware overview

Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide 14

Model number Drive type Drive capacity

DKC-F810I-1R9MGM SSD 1.9 TB

DKC-F810I-3R8MGM SSD 3.8 TB

DKC-F810I-7R6MGM SSD 7.6 TB

VSP G600 model

The VSP G600 is a highly reliable storage system that offers high storage capacity with full

redundancy to better protect data and manage storage operations.

The storage system consists of a 4U enclosure that includes two controllers and two NAS

modules to support file operations. Drives are supported using drive trays connected to the

controllers. The maximum number of drives supported is 576 (720 with dense intermix drive

tray).

The storage system supports 256 GB of high-speed cache memory. The DIMMs are arranged

as 128 GB per controller.
