ELECTRIC TOOL PARTS LIST
LIST NO. G819
CORDLESS IMPACT DRIVER
Model WH 9DMR
2005
•
4
•
1
(E1)
Hitachi Power Tools
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31 32
33
34
35
36
37
38
36
43
44
45
46
47
48
49
50
501 502
502
39
40
41
42

*ALTERNATIVE PARTS--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
4 -- 05
WH 9DMR
1315-984 RETAINING RING 1
2315-983 WASHER (D) 1
3322-716 GUIDE SPRING (B) 1
4322-717 GUIDE SLEEVE (D) 1
5322-727 FRONT CAP (B) 1
6322-728 PROTECTOR (C) 1
7319-917
TAPPING SCREW (W/SP. WASHER) D4X25 (BLACK) 4
8321-674 HAMMER CASE 1
9319-535 STEEL BALL D3.5 (10 PCS.) 2
*10 322-248 ANVIL (F) 1
*10 322-724 ANVIL (E) 1 FOR KOR, TPE, SIN
11 959-154 STEEL BALL D5.556 (10 PCS.) 2
12 322-730 HAMMER (F) 1
13 959-148 STEEL BALL D3.175 (10 PCS.) 28
14 315-978 WASHER (J) 1
15 320-407 HAMMER SPRING (A) 1
16 316-172 WASHER (S) 1
17 316-171 STOPPER 1
18 321-666 SPINDLE (D) 1
19 321-667 IDLE GEAR SET (2 PCS.) 2
20 319-914 NEEDLE ROLLER 2
21 320-877 RING GEAR (C) 1
22 319-911 WASHER (E) 1
23 690-1VV BALL BEARING 6901VVCMPS2L 1
24 319-909 DAMPER 2
25 321-664 INNER COVER (A) 1
26 360-702
ARMATURE ASS’Y (W/BALL BEARING) DC 9.6V 1
27 322-719 SIDE YOKE 1
28 322-723 MAGNET (E) 1
29 322-720 DUST GUARD FIN (B) 1
30 321-662 BRUSH BLOCK 1
31 999-054 CARBON BRUSH 5X6X11.5 (1 PAIR) 2
32 319-918 BRUSH CAP 2
33 302-086 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 7
34 NAME PLATE 1
35 324-287 HOUSING (A). (B) SET 1
36 994-532 MACHINE SCREW (W/SP. WASHER) M3X5 2
37 319-906 DC-SPEED CONTROL SWITCH 1
38 321-661 PUSHING BUTTON (A) 1
39 324-286 HITACHI PLATE 1
*40 CAUTION PLATE (A) 1 FOR USA, CAN
41 321-918 HOOK ASS’Y (W/LIGHT) 1 INCLUD. 42, 43
42 321-672 TAPPING SCREW D2X6 2
43 320-288 V-LOCK NUT M5 1
44 949-565 LOCK NUT M4 (10 PCS.) 1
45 306-952 STRAP (BLACK) 1
46 322-718 SLEEVE (A) 1
47 324-278
MACHINE SCREW (W/WASHERS) M4X25 (BLACK) 1
48 319-926 HOOK SPRING 1
49 319-927 SPECIAL SCREW M5 1
*50 310-377 BATTERY EB 9B (W/ENGLISH N.P.) 2

*ALTERNATIVE PARTS --- 3 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
4 -- 05
WH 9DMR
*50 310-451 BATTERY EB 9B (W/ENGLISH N.P.) 2 FOR USA, CAN
*50 324-288 BATTERY EB 9B (W/ENGLISH N.P.) 2 FOR TPE
*50 323-225 BATTERY EB 926H (W/ENGLISH N.P.) 2
*50 318-368 BATTERY EB 930H (W/ENGLISH N.P.) 2

*ALTERNATIVE PARTS
--- 4 --- 4 -- 05
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
WH 9DMR
Printed in Japan
(050401N)
*501 322-070 CASE 1 EXCEPT FOR THA
*502 CHARGER (MODEL UC 18YG) 1
*502 CHARGER (MODEL UC 14YFA) 1
601 992-671 + DRIVER BIT (B) NO. 2 50L 1
602 992-672 + DRIVER BIT (B) NO. 3 50L 1
603 996-177 NON-MAGNETIC HEX. SOCKET 8MM 65L 1
604 985-329 NON-MAGNETIC HEX. SOCKET 10MM 65L 1
605 996-178 NON-MAGNETIC HEX. SOCKET 12MM 65L 1
606 996-179 NON-MAGNETIC HEX. SOCKET 13MM 65L 1
607 996-180 NON-MAGNETIC HEX. SOCKET 14MM 65L 1
608 996-181 NON-MAGNETIC HEX. SOCKET 16MM 65L 1
609 996-182 NON-MAGNETIC HEX. SOCKET 17MM 65L 1
610 996-197 HEX. SOCKET (LONG) 21MMX166L 1
611 321-823 DRILL CHUCK AND ADAPTER SET 1 INCLUD. 612
612 307-543 CHUCK ADAPTER 1
613 309-922 GREASE FOR IMPACT DRIVER (500G) 1
