FT-01 Finger Touch Unit - Quick Start Guide
INSTALLATION:
• Use one of three ways to attach/secure the
finger touch unit:
— Use four strips of double sided tape (A) on
flat, smooth surfaces
— Using magnetic sheet (B), affix three strips.
Secure on a fixed location i.e. metal
— Using two screws (C)
*Always use screws when installing at heights
of more than 6.5’ or 2m
• Use a Phillips-head screwdriver to remove the
cover
• Use the USB cable to connect the Finger
Touch to the Projector option port
CONFIGURATION:
1. Press the IWB button on the remote control to change to
WITH PC mode.
The unit must be mounted 2"- 4" above the
projected image, also allow 2" between the
projected image and the screen frame. You may
need to shrink your image. The image needs to be
between 60"- 80" diagonal.
The adjustment procedure using a Windows PC
is shown. If using a Mac PC, perform the same
procedure by referring to the U-Pointer manual
loaded in the DVD drive.
Models CP-TW2503 and CP-TW3003
Getting Started: Installation and Configuration
Please read pages 12-16 in the FT-01 User’s Manual for complete installation instructions
U-Pointer software should be installed on computer before Finger Touch Unit is used
This device can only be used with Hitachi LCD projectors. It cannot be used with
other projectors or for floor-mounted installation.
Double-sided tape (A)
3M
Pull out so that
3M is visible.
Red side
Magnetic sheet (B) Fixing screws (C)
or or
Projector's Ports
USB cable
Option port
2 Click the U-Pointer icon in the task tray of the
computer and select configuration

U-POINTER CONFIGURATION:
1. Set U-Pointer configuration as shown below
2. Once the confirmation screen is displayed,
click [Finish]
Getting Started: Installation and Configuration (continued)
3. Click [Next] [Alignment View] to open the
Alignment View.
4. Secure the supplied adjusting bars to the right
and left edges of the projector display screen.
Align the white print surface of the adjusting bar
toward the direction of the finger touch unit and
use the double sided tape to secure
Adjusting bar
approx. 8mm
1
2
3
5. Turn the adjusting knob 2until the reflection line
appears on the screen.
6. Turn the adjusting knob 3clockwise until the
reflection line is horizontal.
7. Turn the adjusting knob 1clockwise so the
reflection line moves near the vertical center.
8. If the reflection line is not horizontal, use the
adjusting knobs 2or 3to make the reflection
line horizontal
9. Turn the adjusting knob 1counterclockwise
until two adjusting bars each appear at the
bottom right and left of the screen. You are
looking for two white dots on either side.
Touch your finger on the projector display and check that your fingertip is lit up within
the display
2
3
1
2
3
1
Configuration continued on next page

• Attach the cover so that it does not touch the adjusting knobs
• Remove adjusting knobs
• Click [OK] to exit the alignment view
• Click [Next] [Auto Calibration] to run Auto Calibration
• Click [Finish] to exit U-Pointer Configuration
• Click the U-Pointer icon on the task tray, select [Finger Touch Mode]
This completes the adjustment
GLOSSARY:
IWB - Interactive white board. Use with I-PEN or finger touch unit to make drawings on your own or
projected images.
I-PEN - The interactive pen that is provided with the projector.
Stand Alone Mode – With this mode, you can use the projector as an interactive whiteboard by itself.
With PC - With this mode, you can connect the projector and PC and use advanced drawing, annotation,
media features and organize files.
Calibration (Calibrate) - Process needed so that the projector can recognize the I-PEN or Finger
Touch Unit.
U-Pointer - U-Pointer is the “interactive projector driver” for PC or MAC®. It also has an auto
calibration feature.
i-PRO - Advanced annotation, drawing & multi-media interactive software. For use WITH PC mode.
StarBoard Software - Advanced Interactive software that comes complimentary with your Hitachi
projector. There is no yearly subscription fee associated with the use of this software.
BASIC FINGER TOUCH OPERATIONS:
Left Click - Touching the screen with your finger performs a clicking operation
Double Click - Two quick clicks results in a double click operation
Right Click - Touch and hold for 2 seconds to perform a right click command
Drag - Moving your finger while touching the screen performs a dragging operation
There is no yearly subscription fee for the StarBoard Interactive Software,
it comes complimentary with Hitachi Interactive Projectors
If you have been using other interactive software and want to transfer files to use with StarBoard, you can!
1. Open your current file
2. Go to the File tab and select Save As
3. Save your files as .IWB
4. Load back into StarBoard as .IWB file
To begin, click the U-Pointer icon on the task tray
of your computer and select Finger Touch Mode
You can now use your finger to control operations
in the same way as if using the I-PEN or mouse.
You can switch between using the I-PEN
and finger touch, but they can not be used
simultaneously.
How to transfer files to StarBoard
Using the Finger Touch Unit
Getting Started: Installation and Configuration (continued)

For complete information and installation instructions refer to the
FT-01 User’s Manual or go to www.hitachiserviceusa.com
We are here to help! 800-HITACHI was established to give our U.S.
customers easier access to Hitachi products and service information.
Hitachi’s Call Center is empowered to provide you with expedited service
& solutions. Our goal is to ensure you have smooth performance from
any of our Hitachi Business Products. Some examples of our service
include:
• Out of the box missing accessories
• In-warranty lamp replacement
• Hook-up and operational assistance
• Wireless, networking and support of RS-232 codes
• Coordinating a service solution for any service related issue
Call: 800-HITACHI (800-448-2244)
Email: [e-mail]
Hours of operation: Monday through Friday, 9:00 AM—6:00 PM EST
Trouble Shooting
HI0392-04/15
Q. Where do I get the U-Pointer Software?
A. U-Pointer software comes complimentary with your Hitachi interactive
projector. It is also available for download under the interactive projectors
resources tab on the Hitachi Projectors website:
http://dmd.hitachi-america.us/products/consumer/digitalmedia/lcd_
projectors/lineup/details/CP-TW2503.php
Q. Can I mount the finger touch unit above my white board?
A. No. The finger touch unit MUST be mounted on the same surface as the
display.
Q. Can I use the finger touch unit on an uneven surface?
A. No. The surface must be flat, there is only a 2mm tolerance.
Q. Can I use this in “stand alone mode”?
A. No. A PC is required in order for you to interact with this unit. Also make
sure the projector’s IWB mode is set to “with PC mode” in the OSD menu of
projector, and set to “Finger touch mode” at the U-pointer’s menu on the PC.
Q. When using the finger touch unit, the cursor and drawing
functions are inaccurate (i.e. The line I am drawing is 2 inches away
from tip of the interactive pen.)
A. This may caused by some factors. It may be out of calibration, run auto
or manual calibration and retry. Or an uneven surface, surface with curve
will cause inaccuracy. Also inaccurate alignment of FT-01 will also cause the
inaccuracy. Please refer to the manual for appropriate settings.
Q. Will the chalk shelf on my whiteboard interfere with my finger
touch interaction?
A. Sometimes Yes. The reflection from the chalk shelf sometimes interferes.
There are “Antireflection bars” included with the finger unit for this reason.
Q. How do I get a full image and full screen interaction on my white
board when using the finger touch unit?
A. You cannot. The finger touch unit MUST be mounted 2-4 inches above the
image, and it also requires 2 inches between the frame, if there is frame. This
means you have to shrink the image to provide this requirement.
