WARNING
○
Be careful of electrical shock.
○
When not in use or during inspection and
maintenance, be sure to turn the switch OFF
on the unit, and remove the battery from it.
○
Do not cover the work light with cloth,
cardboards or other materials when the light
is on. Doing so may result in fire.
CAUTION
○
Do not use any other than the specified
batteries.
○
Do not look at the LED light directly.
○
The LED cover will remain at a high
temperature when alight and immediately
after use, so do not touch it.
○
Be sure to turn the switch OFF when not using.
○
Do not expose the work light to rain.
○
Do not shock or disassemble the work light.
○
Do not allow the work light to contact gasoline, thinner etc.
○
Do not leave the work light in a car or the like that tends to be exposed to be searching
heat of the sun (above 60 °C). Otherwise, troubles can result.
SYMBOL
WARNING
The following show symbols used for the machine. Be sure that you understand their
meaning before use.
Read all safety warnings and all instructions.
SPECIFICATIONS
LED 18 W (0.5 W × 36 Pcs.)
Dimensions (without battery) 256 mm (width) × 198 mm (length) × 252 mm (height)
Weight (without battery) 0.74 kg
Operating time (Approx.): Using full charged Battery
Battery BSL1840 BSL1830 BSL1820 BSL1815 BSL1440 BSL1430 BSL1420 BSL1415
[High/Low]
mode (h) 5.0 / 11.5 3.5 / 8.5 2.5 / 6.0 2.0 / 4.0 3.5 / 7.5 2.5 / 5.5 2.0 / 4.0 1.5 / 3.0
LED light
(built-in)
Switch
Top handle
Bottom handle
Pipe hook
Strap hole
1/4-inch
screw hole
Fig. 1
Cordless Work Light UB 18DGL
Handling instructions
Keep for future reference
HOW TO USE
1. Battery insert/removal
Insert the battery in direction A until it
clicks. To remove, extract it in direction B
while holding down the latch. (Fig. 2)
2. Turning on the light
Press the switch to turn on the light.
The light setting will alternate between
[Strong], [Weak] and [Off] whenever the
switch is pressed.
3. Light angle adjustment
The angle of the light can be adjusted within a range
of approximately 120 degrees both upward and
downward. (Fig. 3)
4. Installation
In addition to placing it directly onto the floor or other
flat surface, the unit can also be installed as follows.
⦁
Attached to a tripod with the use of a 1/4-inch screw. (Fig. 4)
⦁
Suspended from a pipe with the use of the pipe hook. (Fig. 5)
⦁
Hung on the wall with the use of the wall-hanging hook. (Fig. 6)
CAUTION
○
There are cases in which it will not be possible to turn
on the light owing to a function to prevent the batteries
from over-discharging. IN this event, either replace the
batteries or recharge them.
○
Use cord or a similar article to fix the unit in place to
prevent it from falling.
NOTE
Make sure the instruction manuals supplied with the
separately-purchased rechargers and batteries are read
thoroughly prior to use.
Battery (sold separately)
AB
Latch
Fig. 2
120°
120°
Fig. 3
1/4-inch screw hole
Fig. 4
Item
No. Part Name Q’TY
1 HEXGON HEAD TAPPING SCREW D4×12 4
2FRONTCABINET 1
3LENS 1
4PCB 1
5 TAPPING SCREW D3×8 6
6 MAIN BODY 1
1
2
3
4
5
6
Fig. 5
Wall-hanging hook Bottom handle
Fig. 6
Code No. C99210821 NA
