Chapter 1
Hard Disk Installing
(Standard shipping products include neither HDD nor R/W)
Step 1: Remove the three screws in rear case, as the following figure at
circle marked.
Step 2: Remove a screw in the right case, as the following figure at circle
marked.
Step 3: Remove a screw in the left case, as the following figure at circle
marked.

5
Step 4: Open the chassis cover along the direction of the arrow
Step 5：Connect SATA & Power wire to Hard Disk and put it on right
position of the bottom case。

6
Step 5: Fix the Hard Disk with four screws on the bottom case as the
picture indicated
Step 6: Put the cover back and fix it with 5 screws as Step 1 indicated.
Note: After installation, please initialize Hard Disk before
starting to record. For more detailed information, please
check out User Manual System Tools for reference.

7
Chapter 2
Panel Appearance
2-1 Front panel controls
(1) USB 2.0 port
For USB
(2) Camera Bottom
CH1CH2CH3CH4
(3) IR Sensor
Remote Control Signal Receiver
(4) Auto -Sequence
Image will automatically transform to next image
according to the setting time.
(5) Play
Play/ Stop/ Playback/ Forward
(6) MENU
Menu setup/ Enter/ Leave
(7) Zoom Mode
Enter／Delete Use arrow keys or mouse to zoom
the specific area.
(8) Arrow Keys
Up, down, left and right arrow keys to select the
control button
(9) Split Key
Back to quad display
(10) LED- Power
DVR power On
(11)Manual Record
On／Off
(12) LED- REC
Recording
(13) LED-Alarm
Alarm on signal break and motion detection
(14) LED-LAN
Lan is working

8
2-2 Rear panel connectors
(1) DC 12V
DC 12V power jack
(2) AUDIO OUT
RCA output(For CH1)
(3) AUDIO IN
RCA input(For CH1)
(4) VIDEO IN
For camera BNC input，4 ports
(5) MAIN monitor
MAIN/SPOT monitor BNC video putout.
(6) RS485 Port
RS 485 for PTZ
(7) VGA
VGA port
(8) LAN
Network port
(9) USB 2.0 Port
USB port
(10)ALARMIN&RELAY
OUTPort
ALARMIN&RELAYOUTPort(DESCRIPTION
Table 3-2-7)

9
Chapter 3
Live, Playback Operations
(The IR remote control and mouse operate differently under each mode;
this chapter describes the functions of them under three different modes:
LIVE, PLAYBACK and PTZ).
3-1 In LIVE mode, the remote control instructions
ICON
DESCRIPTION
REC
Start/ Stop Recording
MUTE
Live Audio is On/Off
PLAY
Starting playing back the most recently recorder segment
1,2,3,4
Switch to full screen or quad display
FREEZE
Freeze is on, screen is frozen
MENU
Enable/ Disable Setup Menu
PTZ
PTZ mode
ZOOM
Enter／Delete Zoom mode
ESC
Return last menu
ENTER
Enter
FF
Fast forward. Each press increases the speed to the next level. There are six
speeds: 2x, 4X, 8X, 16X, 32X and 64X.
STOP
Stop playback.
RF
Rewind Fast. Each press increases the speed to the next level. There are six
speeds: 2x, 4X, 8X, 16X, 32X and 64X.
Pause
Turn on/off PAUSE
Split
Switch to split windows
Polling
Staring the Auto-Sequence
PIP
On／OFF picture in picture。Switch channel by mouse to click
LOCK
On／OFF Lock, activate the key lock
ZOOM IN
Zoom in ；use the arrow keys to change the Zoom in area
ZOOM OUT
Zoom out；use the arrow keys to change the Zoom out area
FOCUS IN
Focus in
FOCUS OUT
Focus out
CTRL1,2,3,4
On／Off 1~4Relay
DVR1,2,3,4
Switch DVR ID1~4

10
3-2 In LIVE mode, the operating instructions after right-clicking
mouse icon in a rapid functional
Table 3-2-1
ICON
DESCRIPTION
Main Menu，Resting the cursor on this icon will bring up the following nine menu
icons
Camera setup- show、Auto -Sequence、PTZ control 、Image control、
Audio control
Event Setup- OSD Motion Setup、Sensing Device Setup
Recording Setup- OSD Motion、Sound Record、Video Record
、Alarm Record、Schedule Record
Alarm Setup-Event、Time Setup、Image Broken Setup
HDD-Loop Record、Residual Rate Alarm、Capacity State
Networking setup - LAN、DHCP、PPPOE、HTTP、DDNS、EMAIL Setup
Data backup-Interface Option、System Event Clear、System Update Setup
System setup-Name、Language、VGA Resolution、Menu Lock、Display Option、
User、Relay Setup
Leave=「ESC」
System Disk Information-Version、IP、MAC、HDD capacity
Zoom In/Out =「Zoom」，AUX1~8〈Signal screen only〉
PTZ Control=「PTZ」，〈signal screen only〉
Sound Control
=「Polling」
=「PIP」

11
Table 3-2-2
Graphical icons that will display after right-clicking your mouse under LIVE mode
ICON
DESCRIPTION
~
CH1~CH16 Signal Screen
Record=「REC」， On/ Off record
Stop=「FREEZE」， Screen stop
Play=「PLAY」，playback
Freeze-screen is frozen
Lock=「LOCK」
Backup- information backup
Table 3-2-3
Graphical icons that will display after right-clicking your mouse under Remote mode
DESCRIPTION
Remote Snapshot- take picture on camera and store
〈Pre-archived folder-My Documents Folder/DVRData/Snapshot〉
Select Archive Folder-Select the folder to store the photo and video
Quad Display
9 Screen Display
16 Screen Display

12
Full Screen-Switch to full screen
HQ/LQ image quality switch
Remote Recording- record and store.
〈Pre-archived folder-My Documents Folder/DVRData/Snapshot〉
Remote shortcut bar narrow
NOTE！Before IE browser into the "remote control model" will be required to
change the ActiveX controls to prompt under Tools / Internet Options /
Security / Custom Level / Download theActiveX controls unsigned
Table 3-2-4
Switch to the PLAYBACK Mode by pressing “PLAY” button under the LIVE mode.
The control panel will appear on down right of screen, the control panel can be moved be
mouse.
ICON
DESCRIPTION
Snapshot- turn the current screen into the “Image “and store in USB
device.；the Image will be stored in computer on Remote mode
Rewind Fast. Each press increases the speed to the next level. There are
six speeds: 2x, 4X, 8X, 16X, 32X and 64X.
Pause/Signal Screen playback
Normal speed playback
Stop
Normal speed play
Pause/Signal screen play
Fast forward. Each press increases the speed to the next level. There are
six speeds: 2x, 4X, 8X, 16X, 32X and 64X

13
Table 3-2-5
Graphical icons that will display under Remote mode
ICON
DESCRIPTION
USB device detected
HDD not detected
Lock is on—need code to unlock
Network connecting
Recoding- in full screen the icon appears when the one of the cameras is recording
Event occur-appear on alarm、lost channel、motion detected
Recording-in signal screen the icon appears when the camera is recording
Live Audio is on in signal screen
Live Audio is off in signal screen
OSD< motion detection> is on in signal screen
Relay off
Relay on
Shows the current hard disk space has been used.

14
Table 3-2-6
Switch to the PTZ mode by pressing “PTZ” button under the LIVE mode. The
PTZ icon will appear on upper left side of screen and the control panel will
appear on the down right side of screen.
Remote controller operation under the PTZ mode
ICON
DESCRIPTION
Arrow keys
Up, down, left, right
ENTER KEY
Executive function
PTZ arrow keys
Move PTZ camera
ZOOM IN
Let PTZ camera closer
ZOOM OUT
Let PTZ camera further
Mouse operation under the PTZ mode
ICON
DESCRIPTION
Pr- set point- set location through arrow keys and press Enter, and
then camera starts to patrol.
Pre-set number N(1~255)
Move to Pre-set number N
Delete Pre-set number
Automatically patrol

15
ZOOM IN
ZOOM OUT
IRIS IN
IRIS OUT
FOCUS OUT
FOCUS IN
Table 3-2-7
DVR-4P-8P Relay-control wiring diagram
1
Sensor 1
14
Sensor 2
2
Sensor 3
15
Sensor 4
3
GND
16
GND
4
Sensor 5 *
17
Sensor 6 *
5
Sensor 7 *
18
Sensor 8 *
6
ALARM_N.O
19
ALARM_COM
7
ALARM_N.C
20
RELAY1_N.O
8
RELAY1_COM
21
RELAY1_N.C
9
RELAY2_N.O
22
RELAY2_COM
10
RELAY2_N.C
23
RELAY3_N.O
11
RELAY3_COM
24
RELAY3_N.C
12
RELAY4_N.O
25
RELAY4_COM
13
RELAY4_N.C

16
Table 3-2-8
DVR-16p Relay-control wiring diagram
1
Sensor 1
20
Sensor 9
2
Sensor 2
21
Sensor 10
3
Sensor 3
22
Sensor 11
4
Sensor 4
23
Sensor 12
5
Sensor 5
24
Sensor 13
6
Sensor 6
25
Sensor 14
7
Sensor 7
26
Sensor 15
8
Sensor 8
27
Sensor 16
9
GND
28
RELAY1_N.O
10
RELAY1_N.C
29
RELAY1_COM
11
RELAY2_N.O
30
RELAY2_N.C
12
RELAY2_COM
31
RELAY3_ N.O
13
RELAY3_N.C
32
RELAY3_COM
14
RELAY4_N.O
33
RELAY4_N.C
15
RELAY4_COM
34
ALARM_N.O
16
ALARM_N.C
35
ALARM_COM
17
GND
36
RS485 TX+
18
RS485 RX+
37
RS485 TX-
19
RS485 RX-

17
Chapter 4 The Main Menu Setup
Enter the setup menu first time, please choose the login account, and then enter
the password. Administrator default password is "123456."
Verify password, if correct will enter the setup menu

18
4-1 Camera Setup
ICON
DESCRIPTION
1 –4
Each channel can be set dependently
Camera screen Display
On /Off
Polling mode
On /Off
Polling mode time
On/ 0~100 seconds (the time that screen stays.)
Camera Title Setup
Customize the camera channel name
PTZ Enable
On/Off
No.of PTZ
PTZ Number( 0~255)
Baud Rate
Select the PTZ camera transmission speed(2400、4800、
9600、19200)
PTZ Protocol
Support ：PELCO-D、PELCO-P、HME PDZ ,UNITED-D
Brightness
Brightness Adjustment(From value１~２５５)
Contrast
Contrast Adjustment(From value１~２５５)
Hue
Color Adjustment(From value１~２５５)
Saturation
Chroma Adjustment(From value１~２５５)
Volume
Channel 1 can adjust the volume and record volume

19
4-2 Event Setup
ICON
DESCRIPTION
Motion Setup
Enter Motion Detection Setup
Sensor Setup
Enter Sensing Device Setup

20
4-2.1 Motion Setup
ICON
DESCRIPTION
1 - 4
Each channel can be set dependently
Enable
Switch on or off the motion detection function
Buzzer Alarm
On／Off
Sensitivity
Set up Sensitivity from value 1 to 10 for each channel. The
lower value you set the higher sensitivity it will be
Motion Area Setup
Enter to Motion Area Setup
Apply All
On／Off
Motion Popup
On／Off
