HMS Networks Anybus Wireless Bolt LTE User guide

Anybus®Wireless Bolt LTE™
STARTUP GUIDE
SP2868 1.1 en-US ENGLISH

Important User Information
Disclaimer
The information in this document is for informational purposes only. Please inform HMS Networks of any
inaccuracies or omissions found in this document. HMS Networks disclaims any responsibility or liability
for any errors that may appear in this document.
HMS Networks reserves the right to modify its products in line with its policy of continuous product
development. The information in this document shall therefore not be construed as a commitment on
the part of HMS Networks and is subject to change without notice. HMS Networks makes no
commitment to update or keep current the information in this document.
The data, examples and illustrations found in this document are included for illustrative purposes and are
only intended to help improve understanding of the functionality and handling of the product. In view of
the wide range of possible applications of the product, and because of the many variables and
requirements associated with any particular implementation, HMS Networks cannot assume
responsibility or liability for actual use based on the data, examples or illustrations included in this
document nor for any damages incurred during installation of the product. Those responsible for the use
of the product must acquire sufficient knowledge in order to ensure that the product is used correctly in
their specific application and that the application meets all performance and safety requirements
including any applicable laws, regulations, codes and standards. Further, HMS Networks will under no
circumstances assume liability or responsibility for any problems that may arise as a result from the use
of undocumented features or functional side effects found outside the documented scope of the product.
The effects caused by any direct or indirect use of such aspects of the product are undefined and may
include e.g. compatibility issues and stability issues.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Preface 3 (20)
1 Preface
1.1 About This Document
This manual describes how to install and configure Anybus Wireless Bolt LTE.
For additional documentation and software downloads, FAQs, troubleshooting
guides and technical support, please visit www.anybus.com/support.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Preface 4 (20)
1.2 Document Conventions
Numbered lists indicate tasks that should be carried out in sequence:
1. First do this
2. Then do this
Bulleted lists are used for:
• Tasks that can be carried out in any order
• Itemized information
►An action
→ and a result
User interaction elements (buttons etc.) are indicated with bold text.
Program code and script examples
Cross-reference within this document: Document Conventions, p. 4
External link (URL): www.hms-networks.com
WARNING
Instruction that must be followed to avoid a risk of death or serious injury.
Caution
Instruction that must be followed to avoid a risk of personal injury.
Instruction that must be followed to avoid a risk of reduced functionality
and/or damage to the equipment, or to avoid a network security risk.
Additional information which may facilitate installation and/or operation.
1.3 Trademarks
Anybus®is a registered trademark and Wireless Bolt LTE™is a trademark of HMS
Industrial Networks AB. All other trademarks mentioned in this document are
the property of their respective holders.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Safety 5 (20)
2 Safety
2.1 General Safety Instructions
Caution
This equipment emits RF energy in the ISM (Industrial, Scientific, Medical)
band. Make sure that all medical devices used in proximity to this
equipment meet appropriate susceptibility specifications for this type of
RF energy.
Caution
Minimum temperature rating of the cable to be connected to the field
wiring terminals, 90 °C.
Caution
Use copper wire only for field wiring terminals.
This equipment is recommended for use in both industrial and domestic
environments. For industrial environments it is mandatory to use the
functional earth connection to comply with immunity requirements. For
domestic environments the functional earth must be used if a shielded
Ethernet cable is used, in order to meet emission requirements.
This equipment contains parts that can be damaged by electrostatic
discharge (ESD). Use ESD prevention measures to avoid damage.
2.2 Intended Use
The intended use of this equipment is as a communication interface and router.
The equipment receives and transmits data over Ethernet and Cellular standard
networks.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 6 (20)
3 Installation
3.1 Installing SIM Card
Supported SIM card types are Nano SIM for IoT and M2M, for data
communication, as well as standard mobile phone Nano SIM.
Fig. 1
To connect Wireless Bolt LTE to a cellular data network, install a cellular SIM
card:
1. Insert a SIM card into the Wireless Bolt LTE SIM card holder.
Ensure that the SIM card contact surface is facing towards the Ethernet port.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 7 (20)
3.2 Mechanical Installation
Placement
• The device is intended to be mounted on top of a machine or cabinet
through an M50 (50.5 mm) hole using the included sealing ring and nut.
• The top mounting surface, in contact with the sealing, must be flat with a
finish equivalent to Ra 3.2 or finer and cleaned and free from oils and
greases.
• For optimal reception, cellular devices require a zone around them clear of
objects that could obstruct or reflect the signal. To avoid interference, a
minimum distance of 50 cm between Wireless Bolt LTE and other cellular
devices should be observed.
Make sure that the sealing ring is correctly placed in the circular groove
in the top part of the housing before tightening the nut.
Always hold the BOTTOM part of the unit when untightening the nut, not
the top part (the cap).
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 8 (20)
Tightening torque: 5 Nm ±10 %
Fig. 2 Installation drawing
All measurements are in mm.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 9 (20)
3.3 Connecting to Power Over Ethernet (PoE)
Before You Begin
Connecting the Wireless Bolt LTE to PoE and DC power simultaneously
may result in a current loop that could damage both the power sources
and the Wireless Bolt LTE. Ensure to use only one of the power
connections at a time.
Shielded or unshielded Ethernet cables may be used.
Wireless Bolt LTE is designed to comply with PoE, IEEE 802.3at Type 1 (Class 0,
37-57 VDC, max 12.95 W).
Procedure
Fig. 3
1. Connect the Wireless Bolt LTE Ethernet port to Ethernet/PoE.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 10 (20)
Ethernet Connector, RJ45 PoE
Pin Data PoE
1 TD+ A+ Positive power from alt. A PSE
2 TD-
3 RD+ A- Negative power from alt. A PSE (with pin 6)
4B+ Positive power from alt. B PSE
5
6 RD- A- Negative power from alt. A PSE (with pin 3)
7B- Negative power from alt. B PSE
8
Housing Shield Functional Earth (FE), via 1 nF capacitor and 1 MΩ bleeder
resistor
3.4 Connecting to Power and Ethernet
Before You Begin
Connecting power with reverse polarity or using the wrong type of power
supply may damage the equipment. Make sure that the power supply is
connected correctly and of the recommended type.
Connecting the Wireless Bolt LTE to PoE and DC power simultaneously
may result in a current loop that could damage both the power sources
and the Wireless Bolt LTE. Ensure to use only one of the power
connections at a time.
When Wireless Bolt LTE is powered via the power connector, Functional
Earth (FE) must be connected.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 11 (20)
When Wireless Bolt LTE is installed in an environment with a high level of
electrical noise, use a power/Functional Earth (FE) cable with a maximum
length of 3 meters.
See also Technical Data, p. 18 regarding power supply requirements.
Functional earth wire screw placement
Fig. 4
When Wireless Bolt LTE is mounted on a sheet metal plate, connect Functional
Earth (FE) to the plate near Wireless Bolt LTE.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 12 (20)
Procedure
Connecting to power
Fig. 5
1. Connect Wireless Bolt LTE Power connector to a power supply.
2. Connect Wireless Bolt LTE Power connector to Functional Earth (FE).
Power connector, 3-pin terminal block
Pin Function
1 + 11–33 VDC
2 -
3Functional Earth (FE)
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Installation 13 (20)
Connecting to Ethernet
3. Connect the Wireless Bolt LTE to Ethernet.
Fig. 6
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Configuration 14 (20)
4 Configuration
Wireless Bolt LTE Built-In Web Interface
Fig. 7 Example, Wireless Bolt LTE built-in web interface
The Wireless Bolt LTE built-in web interface is used to configure the
Wireless Bolt LTE system settings.
The System Overview page shows the current settings and network connection
status.
Before You Begin
The Wireless Bolt LTE comes with a default username and password.
The default username is admin. Written in lowercase letters.
You find the default password on the Wireless Bolt LTE product housing.
Wireless Bolt LTE default IP address is 192.168.0.98.
To access the Wireless Bolt LTE built-in web interface, ensure that the
Wireless Bolt LTE IP address and your PC IP address are within the same IP
address range.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Configuration 15 (20)
Procedure
Fig. 8
Connecting Wireless Bolt LTE to internet:
1. Insert a cellular SIM card in the Wireless Bolt LTE SIM card holder.
Ensure that the SIM card contact surface is facing towards the Ethernet port.
2. Connect the Wireless Bolt LTE Ethernet port to your PC.
3. Connect the Wireless Bolt LTE Power connector to a power supply.
4. To access the built-in web interface, enter the Wireless Bolt LTE IP address
in your web browser and click Enter.
5. Login to the Wireless Bolt LTE built-in web interface.
6. Configure the Ethernet Settings, IP address and internal DHCP server
settings.
7. Verify that the APN Settings are correct. You can adjust the settings
manually.
8. In the left sidebar menu, click Save and Reboot.
→ Wireless Bolt LTE automatically reboots for the settings to take effect.
9. On the System Overview page, verify that the cellular Data Connection has
status Yes.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Configuration 16 (20)
Result
Wireless Bolt LTE should now be connected to internet.
Depending on the mobile network operator and network type, it can take up to
10 minutes the first time Wireless Bolt LTE is connecting to internet.
Verify that Wireless Bolt LTE is connected to internet, by sending a ping to
Google Public DNS.
1. On the Diagnostics page, select the Ping method.
2. In the Target field, enter the IP address 8.8.8.8.
3. To Perform Action, click Start.
→ The ping request is sent.
→ When the ping response returns, a message appears.
Fig. 9 Example, Ping response message from target 8.8.8.8
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Configuration 17 (20)
Connecting Devices
Fig. 10
Connecting a device to internet:
1. Connect an Ethernet cable between Wireless Bolt LTE and the device.
2. Verify that the device is connected to internet.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Technical Data 18 (20)
5 Technical Data
5.1 Technical Specifications
Order code EMEA: AWB1500
Americas: AWB1502
EMEA: AWB1501
Americas: AWB1503
Color Black White top and black base
Operating temperature Shadow: -40 to +65 °C
Direct sunlight: -40 to +45
°C
Shadow: -40 to +65 °C
Direct sunlight: -40 to +65
°C
Host interface RJ45 Ethernet 10/100 Mbit/s, PoE
Storage temperature -40 to +85 °C
Humidity compability EN 600068-2-78: Damp heat, +40 °C, 90% (non-
condensing).
Vibration Refer to datasheet at www.anybus.com/support.
Dimensions Diameter: 68 mm.
Height: 75 mm without Power connector, 84 mm incl.
Power connector.
Height above mounting surface: 41 mm.
Weight 100 g
Housing material Plastic (see datasheet for details)
Protection class Top (outside of host): IP66 and IP67 / UL Type 4X
Base (inside of host): IP21
Mounting M50 screw and nut (50.5 mm hole needed)
Power 3-pin screw connector and PoE (Power over Ethernet)
11-33 VDC through Power connector, PoE, IEEE 802.3at
Type 1 (Class 0, 37-57 VDC, max 12.95 W)
Redundant or separate operation of PoE and DC
connectors.
Power Consumption:
Sleep Mode: Power connector 0.1 W. PoE 0.3 W
Idle Mode: Power connector 0.6 W. PoE 0.8 W
Worst Case average power: Power connector 3.2 W.
PoE 3.6 W.
Worst case peak current: 1.2A@11VDC
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

Technical Data 19 (20)
Order code EMEA: AWB1500
Americas: AWB1502
EMEA: AWB1501
Americas: AWB1503
Cellular standards EMEA: LTE B1, B3, B7, B8, B20, B28. Fallback 3G and
2G
Americas: LTE B2, B4, B5, B12, B13, B14, B25, B26, B66.
Fallback 3G.
Maximum Data speeds Max download speed: 100 Mbit/s
Max upload speed: 50 Mbit/s
Ethernet protocols Transparent transfer of any TCP/UDP based protocol,
Built-in firewall, NAT and DHCP server.
Certifications Refer to datasheet at www.anybus.com/support.
Anybus®Wireless Bolt LTE™Startup Guide SP2868 1.1 en-US

last page
© 2021 HMS Industrial Networks
Box 4126
300 04 Halmstad, Sweden
[email protected] SP2868 1.1 en-US / 2021-09-01 / 23260
