HMS Networks Ewon Cosy 131 User manual

Download and install eCatcher.
Create your account by clicking on “Create a Free+ Account”.
To complete the process, you will need to activate your
account by clicking on the URL sent by email.
Log into eCatcher and add your Ewon Cosy by clicking on the
“Add” button. Follow the dialog boxes to personalize & identify
easily your Ewon Cosy
Insert a USB stick/SD card and click “Launch Setup Wizard”.
Once files are on your USB stick/SD card,
close the eCatcher application.
Step 1: Create & configure your Talk2M account
Step 2: Configure your Ewon Cosy
Power ON your Ewon Cosy
Plug the Internet cable into the WAN port.
By default, the WAN port is the No. 4, on the bottom left.
You can check it with the red led (instead of green) beneath
the Ethernet port.
When the PWR LED is green & the USR LED is blinking green,
insert your configured USB stick/SD card into your Ewon Cosy
USR LED will start a quick orange pattern to indicate that a valid
file has been detected.
Quick Start Guide
for Ewon COSY 131
USR LED :

USR LED starts a slow orange pattern to indicate that the
files are being processed
USR LED becomes fixed green (success) or red (error)
to indicate the result of the configuration
The USB stick/SD card can now be removed.
Your Ewon Cosy will reboot to apply the new settings.
The Talk2M connection configuration takes several minutes (up to 5 min.)
Step 3: Connect to your remote device
Consult the COSY 131 Installation Guide for mounting, safety & security requirements on
http://support.ewon.biz/cosy-131
Check our warranty policy on http://www.ewon.biz/warranty
Warning !
USR LED :
USR LED :
The status of your Ewon Cosy should be “Online”.
Simply select your Ewon Cosy and click on the “Connect” button.
At the end of the configuration process,
the Talk2M LED should light up.
eCatcher will establish the remote connection with your Ewon
Cosy.
