HOBBY ENGINE 0703 User manual

On scale EXCAVATOR model with 2.4G Radio control system.
Hidden antenna on EXCAVATOR & remote controller.
Aged decoration-traces of oil,rusted,mudded.
Full digital proportional control
Working platform turn left & right 360 degrees freely.
Body spin 360 degrees freely.
Climb up to 20 degrees.
lndividual track control.
Scooping light

1. Turn screw anti-clockwise on baftery door under EXCAVATOR to open.
2. Plug with fully charged battery pack on socket in battery compartment-
3. Cover the battery door and tighten the screw clockwise.
4. Activate EXCAVATOR by sliding switch to 'ON"
REMARKS: Charge the battery pack 6 hours for the tirst time, 4 hours from 2'time.
1. Slide remote controller power switch to "ON". LED luminated to Red.
2. Slide EXCAVATOR power switch to "ON'.
3. Press "[4ATCHING" button on top deck of EXCAVATOR. The LED on side will be flashed for 5 seconds.
4. LED stop flashing, lhe EXCAVATOR is already matched with controller and ready to work.

R3
R2
R1 POWER
INDICATOR
ry
Forward by pushing both joystick to the front. Backward by pushing both joystick to the back.
Left turn by pushing leftjoystick to front. Right turn by pushing rightjoystick to front.

Left spin by pushing leftjoystick to front and
rightjoystick to back. Right spin by pushing rightjoystick to ftont and
left joystick to back.
\
/
Working plattorm left turn by pressing (L1)
button. Working platform right turn by pressing (R1)
button.
N4ain arm tilt up by pressing (L2) button. Main arm tilt down by pressing (R2) butlon.

Dipper arm move up by pressing (L3) button. { image attached} Dipper arm move down by pressing (R3) button. { image altached}
Bucket move up by pressing (L4) button. { image attached} Bucker move down by pressing (R4) button. { image atttached}
@
1. Check the battery connection on remote controller or replace with new battery.
2. check the battery connection inside EXCAVATOR batlery compartment or
recharge battery.
3. Repeat matching procedure by switching remote and EXCAVATOR on again.
Press the matching button.
4. Contact us at our Email: [email protected]
1. Operation temperature 5oc-38'c
2. Recharge battery ONLY with charger
included in packing.
* The products can be used on the sand or mud, but do not put sand from the top of the products
