HOBBY ENGINE 0708 User manual

rffier
HOBBY ENGINE
Hobbyengine Model Limited
Address: Rm 619,6/F., Peninsula Centre,67 l\ilody Road, Tsim Sha Tsui East, Kowloon, Hong Kong.
Website: www.hobbyengine.com.hk

On scale MINING TRUCK modelwilh 2.4G Radio controlsystem.
Hidden antenna on MINING TRUCK & remote controller.
Aged decoration{races of oil,rusted,mudded.
Full digital proportional control
Climb up to 20 degrees.
lndependent loader control.

1. Turn sclew anti-clockwise on battery door under MINING TRUCK to open.
2- Plug with tully charged battery pack on socket in ballery compadment.
3. Coverthe battery door and lighten lhe screw clockwise.
4. Activate MINING TRUCK by sliding swilch to'ON"
REMARKS: Chaqe lhe batlery pack6 hourc for the fißl lime, 4 hoursf.om 2nd time.
1. Slide rcmote conlroller power switch lo'ON". LED luminaled to Red.
2. Slide N4lNlNG TRUCK power switch lo "ON".
3. Press "I/ATCHING' butlon on top deck olMlNlNG TRLJCK. The LED on side willbe flashed for5 seconds.
4. LED stop nashinq, the MINING TRUCK is already malched wilh controller and rcadv to wo.k.

R3
R2
R1
LEFT
JOYSTICK RIGHT
INDICATOR
FoMard by pushing left joystick to lhe fiont. gackward by pushing lefl ioystick to the back.

Left turn by pushing ghl joystick Io left. Right tum by pushing ghtjoystick to right.
Tllt up dumper by pressing (11) button. Till down dumpff by prcssjng (Rl) button.
