Hobbytech CRX RTR SURVIVAL User manual

INSTRUCTION
MANUAL
• This is not a toy! Not suitable for children under 14 years old without adult supervision.
• Ceci n’est pas un jouet. Ne convient pas aux enfants de moins de 14 ans sans la surveillance d’un adulte.
• Kein Spielzeug. Nichte geeignet für Kinder unter 14 Jahren ohne Aufsicht Erwachsener.
•No es un juguete. No recomendado para niños menores de 14 años.
WARNING !
This vehicule deliveres a very powerfull velocity.
If the handling and the instructions is not followed with all attention needed, a lot of parts can be damaged easily.
It is better to start slowly to learn how to control this amazing power !
ATTENTION !
Ce véhicule possède une puissance extrêmement importante.
Le pilotage et les instructions doivent être eectués avec la plus grande attention.
De nombreuses pièces peuvent se détériorer ou casser très rapidement si vous n’apprenez pas d’abord à piloter et à contrôler la puissance
de ce véhicule !
ACHTUNG!
Dieses Fahrzeug ist extrem wichtig.
Die Lenkung und Anweisungen müssen mit größter Aufmerksamkeit durchgeführt werden.
Viele Teile beschädigt werden oder brechen können sehr schnell, wenn Sie nicht zuerst
lernen zu fahren und die Kraft dieses Fahrzeug zu steuern!
CUIDADO!
Este Vehiculo tiene una potensia muy importante.
El pilotaje y las instucciones tienen que ser dirigidas con la maxima atencion.
El utilisador tiene que aprender a conducir y a controlar la potenensia del
vehiculo sino muchas piezas puden estropearse o romperse immediatamente
OFF-ROAD SCALE TRAILER
SURVIVAL
RTR

2
HT 421900
Hex wrench complety set
(1,5-2-2,5-3mm)
Coret de tournevis allen
Multifonction pliers complety set
Gamme multifonction de pinces
TOOLS REQUIRED NOT INCLUDED IN THE KIT / OUTILLAGE REQUIS NON INCLUS DANS LE KIT
4xAA Alkaline batteries
4 piles Alkaline R6
PROVIDED WITH THE CAR / FOURNIS AVEC LE VÉHICULE
Moteur éléctrique brushed Konect 540
55T crawler
540 55T Brushed Motor
Batterie Konect li-ion 7.4V 1700 mA 15C
Li Ion Battery 7.4V 1700mA 15C
Servo Konect Digital 21kg-0.16s Etanche
pignons métal
Digital servo 21kg-0.16s Waterproof metal
gear
Variateur étanche charbon 40Amp spécial
Crawler et Bateaux
ESC waterproof 1/10 brushed Special Crawler
& Boat
Li-Po safety bag
Housse de charge LiPo
KN-LIPO.BAG
Ensemble radio KONECT 2.4GHZ KT3S+
2.4GHZ Radio KONECT KT3S+
KN-KT3S+/SET KN-M540-55T KN-2113LVWP
KN-BRUSH40-CRAWBTKN-LI0741700

3
KONECT KT3S+ TRANSMITTER
FCC ID: YDTHBT1000 FCC Statement: This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
(2) this device must accept any interference received, including interference that may cause undesired operation.
Notice: Modifications to this product will avoid the user’s authority to operate this equipment.
WARRANTY AND SERVICE INFORMATIONS
COMPONENT WARRANTY PERIOD
PLEASE READ THE FOLLOWING INFORMATION CAREFULLY !
Please note this is a high-quality hobby product and not a toy. Therefore, it is necessary that children under 14 years are
supervised by an adult. The guardians and / or parents have the responsibility to provide the appropriate guidance and
supervision of the minors .
This product has a 90 day warranty, which is only guaranteed to the original purchaser. The warranty valid only to products
that have been purchased from an authorized Hobbytech dealer. Warranty claims will be processed only with a valid proof of
purchase / receipts. If within the warranty period, a portion of the product fails due to manufacturing defects, then it is within
the discretion of Hobbytech to repair it or replace it. The decision to repair or replace the part will be taken by Hobbytech. After
use, we do not oer new for old warranty.
WARRANTY DISCLAIMER
This high performance model was made with highest attention and care and should be treated with respect. Excluded from
the warranty are components that have been damaged by wrong installation, mishandling, accident, operation, maintenance,
lack of maintenance and care, as well as abuse and / or repair attempts. Furthermore excluded from the guarantee are wearing
parts such as fuses and batteries, visual impairments, shipping -, transport costs.
WARRANTY CLAIM
Please contact your dealer with the warranty claim and / or repair. Your dealer and Hobbytech will make an proper decision
that will help you as soon as possible. For invalid warranty claims you may be charged for the processing costs before the parts
are returned. All repairs which are necessary by negligence or abuse are bill in advance. In case you decide that you not want
to repair your product then Hobbytech editing and reserves the right to charge shipping costs .
DECLARATION OF CONFORMITY IN ACCORDANCE WITH THE RADIO &
TELECOMMUNICATIONS TERMINAL EQUIPMENT (R&TTE) DIRECTIVE 1999/5EC.
Sarl Imodel
5 place de Rome
13006 Marseille
France
Declares that he following product : 1.CRX.RTR
w/ KONECT KT3S+ Transmitter & Receiver
Item Number: KN-KT3S-PLUS/SET
Equipment class: 1
Complies with the essential requirements and other relevant provisions of the FTEG (Article
3 of the R&TTE directive)
• Protection of health and safety of the user and any other person, (article 3.1a of the
Directive)
Standards applied: EN 62311:2008
• The essential requirements of the Electromagnetic Compatibility Directive (article 3.1b)
Standards applied: EN 301 489-1 V1.9.2 (2011-09)
EN 301 489-3 V1.4.1 (2002-08)
• Eective use of the radio spectrum/orbital resource so as to avoid harmful interference
(article 3.2).
Standards applied: EN 300 440-1 V1.6.1 (2010-08)
EN 300 440-1 V1.4.1 (2010-08)
Manufacturer Address: Sarl Imodel
5 place de Rome
13006 Marseille
France
Date of issue: September 27, 2012
This product must not be disposed of with other
waste. Instead, it is the user’s responsibility to
dispose of their waste equipment by handing
it over to a designated collection point for the
recycling of waste electrical and electronic
equipment. The separate collection and
recycling of your waste equipment at the time of
disposal will help to conserve natural ressources
and ensure that it is recycled in a manner that
protects human health and the environment.
Help us to protect the environment and respect
our ressources !
i.A.

4
ENGLISHfraN
ç
aISDEUTSCH
4
IMPORTANT - READ ThIS BEFORE RuNNINg
PlEASE READ All INSTRuCTIONS AND FAMIlIARIzE YOuRSElF WITh ThE PRODuCTS AND CONTROl BEFORE
OPERATION.
This product is not a toy. It is a high performance model product. It is important to familiarize yourself with the model, its
manual, and its construction before assembly and operation. Adult supervision is necessary
CAUTION
To avoid serious personal injury and property damage, operate all remotely controlled models in a responsive manner as out-
lined below.
R/C car models can exceed speeds of 40km/h (25mph), and cannot be stopped quickly.
❶ Never run R/C models on the street or highways, as it could cause or contribute to serious trac accidents.
❷ Never run an R/C model near people or animals, nor use people or animals as obstacles when operation R/C vehicles.
❸ To avoid injury to persons or animals, and damage to property, never run a R/C model in a confined or crowed area.
❹ Running R/C models into furniture or other inanimate objects will cause damage to the objects and the R/C models.
CAUTION DURING OPERATIONS
When the R/C model is in operation, dot not touch any of its moving parts, such as drive shafts, wheels, as the rotating parts
can cause serious injury.
❶ The vehicle motor gets very hot during running and could cause burns if touched.
❷ Make sure that no one else is using the same frequency as yours in your running area. Using the same frequency at the same
time, whether is driving, flying or sailing, can cause loss of control of the R/C models, resulting in serious accidents.
❸ Properly connect plugs. To prevent electrical shock and/or damage to the product resulting from a short-circuit; insulate
connections with heat shrink tubing or electrical tape. Before running vehicle, check that battery wiring and plugs are not so
loose as to drag on the ground. Properly secure cables using electrical tape or nylon tie-wraps.
❹ Sti rotation of gears, shafts, joints and wheels can burn out the motor. It’s recommended to check proper joint and shaft
rotation by using one 1,5V dry cell during assembly of the model.
A worn motor will overheat and result in a short running time. Replace a worn out motor as soon as possible.
❺ R/C models will run out of control when either the receiver or transmitter battery voltage drops o. Stop the vehicle
immediately when the car starts to show down to prevent it from running out of control.
SAFETY PRECAUTIONS
Follow the outlined rules for safe radio control operation.
Avoid running the car in crowed area and near small children.
Make sure that no one else is using the same frequency in your running area. Using the same frequency at the same time can
cause serious accidents, whether it’s driving, flying or sailing.
Avoid running in standing water and rain. If R/C unit, motor, or battery get wet, clean and dry throughly in a dry shaded area.
R/C operating procedures
❶ Make sure the transmitter controls and trims are in neutral. Switch on transmitter.
❷ Switch on receiver.
❸ Inspect operation using transmitter before running.
❹ Adjust steering servo and trim so that the model runs straight with transmitter in neutral.
❺ Reverse sequence to shut down after running.
❻ Make sure to disconnect/remove all batteries.
❼ Completely remove sand, mud, dirt etc
❽ Store the car and batteries separately when not in use
SETTING UP THE MODEL
To greatly enhance the overall performance of your car, it’s necessary to tune the vehicle to the track (and its surface
conditions) on which you will be racing. Make adjustments referring to the instruction manual, keeping in mind that “balance” is
the key word.
❶ Tires
Tires have a great influence on the performance of your car, and are normally the first components tuned. Select the right tires
for the track you are racing on.
❷ Toe-in and Toe-out
Adjusting the car toe-in a little, by pointing the wheel inwards, provides the car with good straight running and moderate
steering characteristics. Toe-out, which point the wheels outwards, gives sharp and crisp steering. Take care not to overdo.
❸ Camber angle
While taking the corners, the car is forced to go outwards, causing instability. The area of contact on each tire is determined
by the camber angle, and therefore the traction of the tires can be made greater or lesser by adjustment of camber angle. To
increase traction during cornering, adjust camber angle negative, and reduce traction, adjust for positive camber.
❹ Ground clearance and suspension drop
Ground clearance and/or rebound stroke has a great eect on stability during cornering, acceleration, and braking. Ground
clearance can be adjusted by altering damper spring tension and stiness.
❺ Gear ratio
Proper gear ratio should be determined by the available output power of the motor; type of battery; track condition and layout
It should be also noted that running the car on a good grip surface suggests use of pinion gear 1 teeth smaller, in order to
eectively use all of the available battery power.
Notice 1/10ème-Multilingue.indd 4 08/11/13 15:19

5
ENGLISHfraN
ç
aISDEUTSCH
4
IMPORTANT - READ ThIS BEFORE RuNNINg
PlEASE READ All INSTRuCTIONS AND FAMIlIARIzE YOuRSElF WITh ThE PRODuCTS AND CONTROl BEFORE
OPERATION.
This product is not a toy. It is a high performance model product. It is important to familiarize yourself with the model, its
manual, and its construction before assembly and operation. Adult supervision is necessary
CAUTION
To avoid serious personal injury and property damage, operate all remotely controlled models in a responsive manner as out-
lined below.
R/C car models can exceed speeds of 40km/h (25mph), and cannot be stopped quickly.
❶ Never run R/C models on the street or highways, as it could cause or contribute to serious trac accidents.
❷ Never run an R/C model near people or animals, nor use people or animals as obstacles when operation R/C vehicles.
❸ To avoid injury to persons or animals, and damage to property, never run a R/C model in a confined or crowed area.
❹ Running R/C models into furniture or other inanimate objects will cause damage to the objects and the R/C models.
CAUTION DURING OPERATIONS
When the R/C model is in operation, dot not touch any of its moving parts, such as drive shafts, wheels, as the rotating parts
can cause serious injury.
❶ The vehicle motor gets very hot during running and could cause burns if touched.
❷ Make sure that no one else is using the same frequency as yours in your running area. Using the same frequency at the same
time, whether is driving, flying or sailing, can cause loss of control of the R/C models, resulting in serious accidents.
❸ Properly connect plugs. To prevent electrical shock and/or damage to the product resulting from a short-circuit; insulate
connections with heat shrink tubing or electrical tape. Before running vehicle, check that battery wiring and plugs are not so
loose as to drag on the ground. Properly secure cables using electrical tape or nylon tie-wraps.
❹ Sti rotation of gears, shafts, joints and wheels can burn out the motor. It’s recommended to check proper joint and shaft
rotation by using one 1,5V dry cell during assembly of the model.
A worn motor will overheat and result in a short running time. Replace a worn out motor as soon as possible.
❺ R/C models will run out of control when either the receiver or transmitter battery voltage drops o. Stop the vehicle
immediately when the car starts to show down to prevent it from running out of control.
SAFETY PRECAUTIONS
Follow the outlined rules for safe radio control operation.
Avoid running the car in crowed area and near small children.
Make sure that no one else is using the same frequency in your running area. Using the same frequency at the same time can
cause serious accidents, whether it’s driving, flying or sailing.
Avoid running in standing water and rain. If R/C unit, motor, or battery get wet, clean and dry throughly in a dry shaded area.
R/C operating procedures
❶ Make sure the transmitter controls and trims are in neutral. Switch on transmitter.
❷ Switch on receiver.
❸ Inspect operation using transmitter before running.
❹ Adjust steering servo and trim so that the model runs straight with transmitter in neutral.
❺ Reverse sequence to shut down after running.
❻ Make sure to disconnect/remove all batteries.
❼ Completely remove sand, mud, dirt etc
❽ Store the car and batteries separately when not in use
SETTING UP THE MODEL
To greatly enhance the overall performance of your car, it’s necessary to tune the vehicle to the track (and its surface
conditions) on which you will be racing. Make adjustments referring to the instruction manual, keeping in mind that “balance” is
the key word.
❶ Tires
Tires have a great influence on the performance of your car, and are normally the first components tuned. Select the right tires
for the track you are racing on.
❷ Toe-in and Toe-out
Adjusting the car toe-in a little, by pointing the wheel inwards, provides the car with good straight running and moderate
steering characteristics. Toe-out, which point the wheels outwards, gives sharp and crisp steering. Take care not to overdo.
❸ Camber angle
While taking the corners, the car is forced to go outwards, causing instability. The area of contact on each tire is determined
by the camber angle, and therefore the traction of the tires can be made greater or lesser by adjustment of camber angle. To
increase traction during cornering, adjust camber angle negative, and reduce traction, adjust for positive camber.
❹ Ground clearance and suspension drop
Ground clearance and/or rebound stroke has a great eect on stability during cornering, acceleration, and braking. Ground
clearance can be adjusted by altering damper spring tension and stiness.
❺ Gear ratio
Proper gear ratio should be determined by the available output power of the motor; type of battery; track condition and layout
It should be also noted that running the car on a good grip surface suggests use of pinion gear 1 teeth smaller, in order to
eectively use all of the available battery power.
Notice 1/10ème-Multilingue.indd 4 08/11/13 15:19
F
unctions
Battery LED Indicator
Battery Installa
tion
Warning:
Never disassemble batteries or put the batteries in fire, chemical
agents, otherwise they may cause personal injuries or property
damages.
Battery Disposal:
Observe corresponding regulations about wasted battery
treatment regulations.
1. After running out of power, dispose of wasted batteries in d
esignated
areas far away from water supply, household areas and planted a
reas.
2. Submit the wasted batteries to specific recycling stations.
KT3S+ Transmitter
Steering Wheel : Control direction (Left / Right) of the RC
model.
Throttle Trigger : Control speed and direction (Forwar-
d/Brake/Backward) of the driving model.
Battery Compartment Tray : Cover and hold the batteries powering the
transmitter.
Antenna : Transmit signal to the model
Power ON / OFF : Power ON / OFF the transmitter
SYNC & Battery Indicator : Top Green LED light indicates synchroni-
zation status
and/or adequate battery power supply.
ATV : Adjustable Steering Rate by ATV dial
ST. Trim Dial : Adjust the neutral position of steering
servo when model wheels are straight
ahead.
TH. Trim Dial : Make sure the model stays still when
releasing the throttle trigger.
EPA : End Point Adjustment
Channel 3 (CH3) : 3 positions (I - 0 - II)
WARNING
: accidental or intentional EPA function manipulation
may cause servos malfunction (reduced or inexistant travel).
Please reset maximum default values before contacting your
dealer (see «EPA», on page 7).
Works with 4 x 1.5V AA
Batteries (not provided),
KT3S+ can be operated a
few hours. Installation:
Remove the batte
ry
compartment cover as
shown belo
w.
Install the batteries
observing the polarity
marked on battery
compartment.
Then reicompart-
ment cover as the
picture shown
below.
- During normal operation, the LED should be solid green ON-
- When battery voltage is dropped below3.8V,the LEDwill becomered
color and flashing veryslowly, to indicate batteryis low, you should replace
new batteryas soon as possible
* Always turn on the transmitter first by sliding the switch on the left side
from bottom to top. The green lights above the switch should li
ght up. If not,
you need to check for low or incorrectly installed batteries.
1. Steering : Adjust the steering trim to
keep the front wheels in straight line
when steering wheel remains in
NEUTRAL position.
2. Throttle : Adjust the throttle trim to
ensure the wheels stop rotating when
throttle trigger remains in NEUTRAL
position (only for nitro).
For EP vehicles, this button must be
set to NEUTRAL.
Pre-Run Check
LED
indicatorIndicator
LED
Battery
Compartment Tray
Steering Trim Dial
Steering Wheel
Throttle Trigger
Throttle Trim Dial
BIND / EPA Key
Antenna
Power Indicator ATV
Channel 3
Power
ON / OFF
Throttle
Reverse Switch
Steering
Reverse Switch
TRANSMITTER
EVEN IF THIS CAR IS A READY TO RUN KIT, YOU STILL HAVE SOME LITTLE THINGS TO DO TO FAMILIARI ZE WITH YOUR
PRODUCT.
PLEASE FOLLOW THESE STEPS.

6
A
C
B
Pairing your receiver to your KT3S+
Place model on a block to prevent wheels from touching the
ground.
AConnect battery to ESC. Fix the wire correctly with the
provided connectors.
You must check the signal of transmitter and receiver before
you operating it at first.
Make sure TH Trim is on neutral
 TURN OFF THE TRANSMITTER AND RECEIVER 
BPress and Hold the BIND button on the receiver while
turning on the receiver C.
Release the BIND button when the LED flashes red.
While the red LED flashes, press the BIND button to select the
frame rate.
- Faster flashes= high frame rate (7ms), for digital servo
- Slower flashes= low frame rate (15ms), for analog servo
DPress and Hold the BIND/EPA key of the Transmitter (1),
and then turn on the transmitter (2), LED flahes green and the
Transmitter will communicate with the receiver. Release the
BIND/EPA button when the receiver LED is solid red, and the
transmitter is solid green, then your receiver is paired with your
transmitter.
BIND
D
(1)
(2)
HOW TO CONTROL YOUR MODEL
NEUTRAL POSITION
1. Pull up the trigger in order to brake or speed down
2. Pull the trigger in order to go forward or speed up
BRAKE / SPEED
DOWN POSITION
FORWARD / SPEED
UP POSITION
If the wheels operate in the opposite direction,
operate the servo reverse switch (ST in position NOR).
NEUTRAL
LEFT RIGHT

7
ABOUT THE RADIO SYSTEM
Reversing is used to change the response direction of steering
wheel and throttle trigger.
KT3S+ Transmitter features 2 reversing functions: Steering Reverse
and Throttle Reverse.
Steering Reverse: Reverse the response direction when operating
steering wheel.
Turning left steering wheel, the model turns right while turning
right the model turns left.
Throttle Reverse: Reverse the response direction when operating
throttle trigger.
Pushing forward throttle trigger the model moves backward while
pulling back, the model moves forward.
Adjustable Steering Rate enables to adjust the same maximum steering angle of servo on both sides (Left and Right) when
model makes steering. The Adjustable Steering Rate aects the sensitivity of servo. Reducing dual rate value can lower the
sensitivity of servo and reduce the same maximum steering angle on both sides. Remember to adjust the dual rate value within
the adjustment range: rotate clockwise = increase maximum steering angle; rotate counterclockwise = reduce maximum
steering angle.
The minimum adjustment of ATV (counterclockwise to the max) makes a zero steering angle.
KT3S+ features two trimming
functions:
Steering Trim and Throttle Trim.
Steering Trim Dial: Adjust the
neutral position of steering servo
when the wheels are straight
ahead.
Normally steering trim is adjusted
until the model can keep straight
tracks.
Throttle Trim Dial:
Adjust neutral position of throttle servo. Make sure the model
stays still when releasing the throttle trigger.
Reversing
Adjustable Steering Rate (ATV)
Trimming
PROGRAMMING THE END-POINTS
In order to avoid mechanical strain when steering to the maximum and/or accelerating and braking (nitro), an EPA function
(End Point Adjusment) can be digitally set. However ATV function can be used for steering end points, but on the left & right
together.
If you really want to use EPA function, please read the following instructions carefully:
1. Steering servo
a) Transmitter and receiver powered on (green LED on), turn the steering wheel to the maximum (on the side you want to set),
then hold down for 2 seconds the «BIND/EPA» button: LED turns solid red.
b) As long as LED is red, you can set the exact maximum turning angle of the wheels on the side you choose.
Once the angle is chosen, hold down again for 2 seconds the «BIND/EPA» button. LED flashes twice (light green/dark green)
then turns solid green.
IMPORTANT: Switch OFF and ON the transmitter to confirm the adjustment.
c) To reset the default value, follow a) step, then b) step, hold the steering wheel to the maximum and hold down for 2 seconds
the «BIND/EPA» button. LED flashes twice (light green/dark green) then turns solid green. IMPORTANT: Switch OFF and ON the
transmitter to confirm the adjustment.
To set the opposite side, follow a) and b) steps in the opposite side.
It is very important to perform these operations one by one.
2. Throttle servo (EPA is recommended only for nitro vehicles)
a) Transmitter and receiver powered on (green LED on), hold the throttle at forward-most position, then hold down for 2
seconds the «BIND/EPA» button: LED turns solid red.
b) As long as LED is red, you can set the exact your max throttle end-point.
Once the end-point is chosen, hold down again for 2 seconds the «BIND/EPA» button. LED flashes twice (light green/dark
green) then turns solid green.
IMPORTANT: Switch OFF and ON the transmitter to confirm the adjustment.
c) To reset the default value, follow a) step, then in b) step, hold the throttle at forward-most position, then hold down for 2
seconds the «BIND/EPA». LED flashes twice (light green/dark green) then turns solid green.
IMPORTANT: Switch OFF and ON the transmitter to confirm the adjustment.
To set the brake, follow a) step, then b) step braking to the maximum. You can now set your maximum brake end-point.
It is very important to perform these operations one by one.
3
24

8
Thank you for purchasing this product! We strongly recommend reading through this user manual before use. Because we have no control over
the use, installation, or maintenance of this product, no liability may be assumed for any damage or losses resulting from the use of the product.
We do not assume responsibility for any losses caused by unauthorized modifications to our product. Besides, we have the right to modify our
product design, appearance, features and usage requirements without notification. We are only responsible for our product cost and nothing
else as result of using our product.
WARNINGS
• To avoid short circuits, ensure that all wires & connections must be well insulated and there is no issue like poor contact, sold joint exists
before connecting the ESC to related devices.
• Read through the manuals of all power devices and chassis and ensure the power configuration is rational before using this unit.
• To avoid accidents, we strongly recommend holding the vehicle in the air during the connecting and adjusting process.
• Stop immediate usage once the casing of the ESC exceeds 90°C/194°F as this may cause damages to both the ESC and motor.
• Users must always disconnect the batteries after use as the current on the ESC is consuming continuously if it’s connected to the batteries
(even if the ESC is turned o). The battery will completely be discharged and may result in damage to the battery or ESC when it’s connected
for a long period of time. This WILL NOT be covered under warranty.
FEATURES
1. Fully waterproof and dustproof for all weather conditions. (Note: please clean and dry it after use for avoiding rusty connectors.)
2. New algorithm, specially programmed for cars & boats, guarantees excellent throttle linearity, brake linearity and control performance.
3. Features adjustable drag brake (0% and 100%), you can adjust it by yourself as per the terrains, personal preference and etc. 100% drag brake is
applicable to crawlers, the 0% drag brake is applicable to boats.
4. Built-in switch-mode BEC with cont. /peak current of 3A/6A for usage with most servos on the market.
5. Multiple protections: low-voltage cuto protection, thermal protection, throttle signal loss protection, and motor lock-up protection.
6. Simple and easy ESC programming via jumper caps.
SPECIFICATIONS
Model KN-BRUSH40 C&B
Cont. / Burst Current 40A / 180A
Input 2-3S LiPo, 5-9 Cells NiMH
Cars Applicable 1/10th Crawlers & Light-duty Boats
Motor
Limit
2S LiPo: 540/550 Size Brushed Motor ≥12T
or RPM < 30000 @7.2V 3S LiPo: 540/550
Size Brushed Motor ≥30T or RPM < 15000
@7.2V
BEC Output 6V@3A (Switch-mode)
Dimension & Weight 46.5mm*37.5mm*27.5mm / 67g
BEGIN TO USE
Step 1. Connect all the devices (as shown above) as per the motor you are using, and recheck all the connections before moving to the next step.
Notes: 1. swap the two wires from motor to ESC if you find the motor runs in reverse.
Step 2: Set the Throttle Range
This ESC can automatically recognize the neutral position of the transmitter, but you need to follow the following steps.
1) Turn on the transmitter and move the throttle stick/trigger to the neutral position.
2) With the ESC powered o, connect the motor, battery and other devices to it.
3) Turn on the ESC, when setting the “Battery Type” to “ LiPo”, the motor will beep two short beeps if you are using a 2S LiPo, three short beeps if
you are using a 3S LiPo. If setting the “Battery Type” to “NiMH”, the motor will beep one short beep, and a long beep 1 second later to indicate the
self detection is over and it’s ready to function.
Attention!
1. After turning on the ESC, you must wait (about 3 seconds) till the self detection completes. Otherwise, it may not function normally.
2. After turning on the ESC, if there is no power output and the Red LED flashes rapidly, then it means the actual throttle of the transmitter is not
at the neutral position. In that case, please check if the “Throttle Trim” of the transmitter is at the “0” position, fine tune the throttle neutral position
till the Red LED stops flashing.
3. To avoid any possible trouble, please always turn on the transmitter first and the ESC last; turn o the ESC first and the transmitter last.
Step 3: The motor can function normally after the wiring & setting completes. The Red LED flashes in the following ways during the running.
1. The Red LED dies out when the throttle trigger is in throttle neutral zone.
2. The Red LED flashes rapidly when your vehicle runs forward and it turns solid Red when you pull the throttle trigger to the full throttle endpoint.
3. The Red LED flashes rapidly when your vehicle runs backward and it turns solid Red when you push the throttle trigger to the full brake endpoint.
40amp BRUSHED C&B WATERPROOF SPEED CONTROLLER - USER MANUAL
# KN-BRUSH40-CRAWBT

9
ESC PROGRAMMING
The ESC has two programmable items, you can easily program them via jumper caps (as explained and shown below).
The first row is “Drag Brake”, connecting one jumper cap
to the two pins on the left will allow you to have 100% drag
brake; connecting it to the two pins on the right will allow
you to have 0% drag bake. The drag brake is 100% by default.
Note: 100% drag brake are applicable to crawlers, 0% drag
brake is applicable to boats, you can adjust it as per the
actual condition. When setting the “Drag Brake” to 100%, the
“Maximum Reverse Force” will be 100%, when setting to “0%”,
the “Maximum Reverse Force” will be 25%.
The second row is “Battery Type”, connect the other jumper
cap to the two pins on the left when you’re using a LiPo pack,
and connect it to the two pins on the right when you’re using
a NiMH pack. The “Battery Type” is “LiPo” by default, you can adjust it as per the actual condition.
PROTECTION FUNCTIONS
1. Low-voltage Cuto Protection
When the “Battery Type” is set to “LiPo”, the cuto voltage for one cell is 3.2V. That means when you’re using a 2S LiPo, the cuto voltage for the
pack will be 6.4V; the cuto voltage for the pack will be 9.6V when you’re using a 3S LiPo. When the “Battery Type” is set to “NiMH”, the cuto
voltage (for the pack) is 4.5V.
The ESC will have the output when it detects the battery voltage has reached the threshold for 2 seconds, and cut o the output 2 seconds later. It
will resume the 50% output when the throttle trigger is released to the neutral position, cut o the output 2 seconds later, resume the 50% output
(when the throttle trigger is released to the neutral position), and then cut o the output 2 seconds later, ......this will continue (unless the battery is
removed or changed). The Red LED flashes a single flash that repeats when the LVC protection is activated. Please try to charge the pack or change
another one when the protection is activated, as long-time usage will cause the pack to over-discharge and be damaged.
Note: please check if you’ve set the “Battery Type” properly when the low-voltage cuto protection can easily get activated. If you’ve set the
“Battery Type” correctly, then the issue is probably caused by the poor discharge capability of the battery. In that case, please try with a battery with
better discharge capacity to see if the problem can be solved.
2. Thermal Protection
The ESC will directly cut o the output and the Red LED will flash a double flash that repeats when its internal temperature reaches the value
(105°C/221°F) preset by the factory. You can use it again when the ESC temperature gets below 60°C/140°F.
Note: if the thermal protection can easily be activated, then the issue in general is caused by improper configuration. That’s the ESC cannot meet
the demand of the vehicle. In that case, please reduce the vehicle’s load or change another ESC with higher continuous current.
3. Throttle Signal Loss Protection
The ESC will immediately cut o the output and the Red LED flashes rapidly when it detects that the throttle signals have been lost for 0.1 second.
Note: because the ESC works based on the throttle signals received from the transmitter, so its performance (after losing throttle signals) is closely
related to the setting of your transmitter.
TROUBLESHOOTING
PROBLÈME RAISON POSSIBLE SOLUTION
The ESC was unable to start the status LED
and the motor after it was powered on
No power was supplied to the ESC. Check if all ESC & battery joints or connections have
been well soldered or firmly connected
The ESC switch was damaged. Replace the switch
The ESC was unable to start the motor but
the Red LED flashed rapidly after it was
powered on.
The neutral position on the transmitter was moved or
changed.
Re-calibrate the throttle range or fine tune the throttle
trim to make the neutral position on the transmitter match
the existing neutral position of the ESC.
The throttle control cable was reversely plugged in. Check if the throttle cable has been reversely plugged in.
The vehicle ran backward when you pulled
the throttle trigger towards you. The motor-to-ESC wiring order was incorrect. Swap the two wires from motor to ESC.
The motor suddenly stopped spinning in
operation.
The throttle signals were lost. Check the transmitter and the receiver.
The LVC protection or the thermal protection was
activated.
The Red LED would flash a single flash repeatedly. Please
check the battery voltage and the ESC temperature.
The motor accelerated suddenly, stuttered or
stopped during the starting-up process.
The discharge capacity of the pack was insucient. Change another pack with better discharge capability.
The RPM was too high, the gear ratio or FDR was
improper.
Change another motor with lower RPM or increase the
gear ratio or FDR.

10
NOTES

11
GUIDE DE RÉFÉRENCE / REFERENCE GUIDE
RÉF. / ITEM DÉSIGNATION / DESIGNATION
CRX-001 Couronne de differentiel 39 dents CRX (1 pièce)
CRX 39T Differential Crown Gear (1 pc)
CRX-002 Bloque differentiel avant/arrière CRX 1 pièce
CRX Differential Locker (1 pc)
CRX-003 Corps de différentiel av/ar CRX
CRX Differential Case set
CRX-004 Kit de roulements CRX
CRX Ball bearing set
CRX-005 Essieu avant/arrière CRX (1 pièce)
CRX F&R Axle Casing (1pc)
CRX-006
Pignon d'attaque 16 dents + axe pour CRX (1 set)
CRX 16T Differential Input Pinion Gear + axle
(1 set)
CRX-007 Etriers avants CRX
CRX Front Steering C Hub
CRX-008 Cardans avants CVD complet CRX (1pièce)
CRX Front complety CVD driveshaft (1 pc)
CRX-009
Vis de fusée avants CRX
CRX Front Steering Knuckle screws
CRX-010 Fusées avants droite/gauche CRX
CRX L&R Front Steering Knuckle
CRX-011 Fusées arrières CRX
CRX Rear Axle Lockout
CRX-012 Cardans arrières CRX ( 1 pièce)
CRX Rear Axle Drive Shaft (1 pc)
CRX-013 Supports d'amortisseurs et de pare-chocs CRX
CRX F&R Bumper Holder + F&R Shocks Hoop
CRX-014 Support boite de vitesse CRX
CRX 4-link Skid Plate for gear box
CRX-015 Renfort arrière de support d'amortisseurs
CRX Rear Shock & Chassis Brace
CRX-016 Bielettes complètes inferieures CRX
CRX lower link complety set
CRX-017 Bielettes complètes supérieures CRX
CRX upper link complety set
CRX-018 Fixations marche-pieds CRX
CRX Rock Sliders Holder
CRX-019 Amortisseurs complet 95 mm aluminium CRX (4 pcs)
CRX 95mm aluminium shocks CRX complety set
CRX-020 Entretoise et rondelle xation Sup d'amortisseur
CRX Shock cap bushing + washer
CRX-021 Pignonerie boite 2 vitesses CRX
CRX Speed box pinions complety set
CRX-022 Axe sortie complet boite de vitesse CRX
CRX complety Speed box main axle
CRX-023 Axe intermediare complet boite de vitesse CRX
CRX Speed box second axle
CRX-024 Slipper complet CRX
CRX slipper complety set
RÉF. / ITEM DÉSIGNATION / DESIGNATION
CRX-049 Ecrous de roue (x4) pour CRX
CRX M4 wheel nuts (not anged)
CRX-050 Set de support de carrosserie CRX
CRX body mount set
CRX-051 Clavette de roue 2x10mm (x4) pour CRX
CRX Wheel hexagon pin 2x10mm (x4)
CRX-052 Kit complet de tirant suspension CRX
CRX Suspension linkage complety set
CRX-053
Kit de boule et chappe complet CRX
CRX ball end + ball complety set
CRX-055 Kit de visserie complet pour CRX
CRX screws complety set
CRX-056 Mini servo pour boite de vitesse CRX
CRX Mini servo for 2 speed box
CRX-058 Kit complet de manille (avec vis)
shackles complety set (with screws)
CRX-059 Kit plastique amortisseur CRX
CRX shocks plastic set
CRX-060 Ressort amortisseurs (x4) pour CRX
CRX shocks spring (x4)
CRX-061 Entretoise plastique amortisseur (x4) pour CRX
CRX schocks cap bushing (x4)
CRX-062 Boules d'amortisseur (x4) pour CRX
CRX balls shocks (x4)
CRX-063 Membranes d'amortisseurs (x4) pour CRX
CRX shocks bladders (x4)
HT-
SU1802002
Roues complètes en acier chromé Crawler
«CLIMBER» 121/45 (1 paire)
«CLIMBER» 121/45 Crawler tyres and chromium
plated rims assembled (not glued, 1 pair)
HT-
SU1803020
Carrosserie complete Crawler Survival avec
accessoires
Crawler Survival clear Body fully complety set
HT-
SU1803030
Pare choc avant et arrière noir pour carrosserie
Survival
Crawler Survival Front and rear bumpers
KN-
2113LVWP
Servo Konect Digital 21kg-0.16s Etanche pignons métal
Digital servo 21kg-0.16s Waterproof metal gear
KN-
BRUSH40-
CRAWBT
Variateur étanche charbon 40Amp spécial Crawler
et Bateaux
ESC waterproof 1/10 brushed Special Crawler & Boat
KN-KT3S+/
SET
Ensemble radio KONECT 2.4GHZ KT3S+
2.4GHZ Radio KONECT KT3S+
KN-
LI0741700
Batterie Konect li-ion 7.4V 1700 mA 15C
Li Ion Battery 7.4V 1700mA 15C
KN-M540-
55T
Moteur éléctrique brushed Konect 540 55T
crawler
540 55T Brushed Motor
REV-158 Boite etanche 1/10eme
Waterproof receiver box
STICK-CRX.
RTR
Planche de stickers CRX RTR
CRX RTR Stickers sheet
RÉF. / ITEM DÉSIGNATION / DESIGNATION
CRX-025 garnitures de slipper CRX (x2)
CRX slipper pads (x2)
CRX-026 Couronne centrale CRX 80 dents
CRX Spur Gear 80T
CRX-027 plaque support moteur CRX en aluminium
CRX aluminium motor holder
CRX-028 Kit support moteur et slipper CRX
CRX Plastic motor mount
CRX-029 Axe primaire complet boite de vitesse CRX
CRX complety Speed box rst axle
CRX-030 Goupille cardan central 2x8,75mm (x2) pour CRX
CRX center driveshaft pin 2x8,75mm (x2)
CRX-031 Vis xation cardans centraux CRX (x4)
CRX center driveshaft screw (x4)
CRX-032
Cardan central arrière CVD telelescopique CRX
(x1)
CRX rear center complety driveshaft (x1)
CRX-033 Marche pieds CRX gauche et droite
CRX Rock Sliders R&L
CRX-034 Support batterie CRX
CRX Battery holder
CRX-035 Kit xation de servo CRX
CRX servo mount parts
CRX-036 Kit bielette de direction CRX
CRX steering tie-rods
CRX-037 Kit de sangle de xation accus CRX
CRX battery strap kit
CRX-038 Support plaque moteur CRX
CRX motor plate holder
CRX-039 Carter plastique boite de vitesse CRX
CRX 2 speed box plastic case
CRX-040
Arbre transmission central plastique + entretoise
CRX
CRX plastic center driveshaft + Bushing
CRX-041 Palonnier servo selection et capot boite CRX
CRX Speed box cover+servo horn
CRX-042 Support esc/Rx CRX
CRX ESC/RX holder
CRX-043 Longerons CRX
CRX Ladder chassis
CRX-044 Passage de ls CRX
CRX wires holder
CRX-045 boite de vitesse complet CRX
CRX 2 speed box assembled
CRX-046 Cardan central avant CVD telelescopique CRX
CRX Front center complety driveshaft
CRX-047 Entretoise aluminium 3x7,5x2 mm pour CRX
CRX Aluminium spacer 3x7,5x2 mm (x4)
CRX-048 Hexagone de roue en plastique CRX (x4)
CRX Plastic Wheel hexagon (x4)

12
CRX-050
CRX-028
CRX-013
HT-SU1803030
CRX-024
CRX-004
CRX-026
CRX-025
CRX-034
CRX-027
CRX-038
CRX-040
CRX-001
CRX-003
CRX-002
CRX-013
CRX-011
CRX-041
CRX-039
CRX-022
CRX-041
CRX-021
CRX-021
CRX-029
CRX-021 CRX-023
CRX-039
CRX-046
CRX-043
CRX-033
CRX-048
CRX-010
CRX-007
CRX-006
CRX-005
CRX-047
CRX-036
CRX-009
CRX-020
CRX-036
CRX-035
CRX-062
CRX-019
CRX-013
CRX-061
CRX-063
CRX-060
CRX-058
CRX-059
CRX-008
CRX-014
CRX-051
CRX-049
CRX-012
CRX-016
CRX-017
CRX-016
HT-SU1802002
STICK-CRX.RTR
CRX-018
CRX-044
CRX-032
CRX-031
CRX-045
CRX-042
CRX-004
CRX-040
CRX-030
REV-158
CRX-015
CRX-004
CRX-030
KN-M540-55T
KN-LI0741700
CRX-055
CRX-037
CRX-052
CRX-053
CRX-056
KN-KT3S+/SET
HT-SU1803020
KN-BRUSH40-CRAWBT
KN-2113LVWP

13
CRX-050
CRX-028
CRX-013
HT-SU1803030
CRX-024
CRX-004
CRX-026
CRX-025
CRX-034
CRX-027
CRX-038
CRX-040
CRX-001
CRX-003
CRX-002
CRX-013
CRX-011
CRX-041
CRX-039
CRX-022
CRX-041
CRX-021
CRX-021
CRX-029
CRX-021 CRX-023
CRX-039
CRX-046
CRX-043
CRX-033
CRX-048
CRX-010
CRX-007
CRX-006
CRX-005
CRX-047
CRX-036
CRX-009
CRX-020
CRX-036
CRX-035
CRX-062
CRX-019
CRX-013
CRX-061
CRX-063
CRX-060
CRX-058
CRX-059
CRX-008
CRX-014
CRX-051
CRX-049
CRX-012
CRX-016
CRX-017
CRX-016
HT-SU1802002
STICK-CRX.RTR
CRX-018
CRX-044
CRX-032
CRX-031
CRX-045
CRX-042
CRX-004
CRX-040
CRX-030
REV-158
CRX-015
CRX-004
CRX-030
KN-M540-55T
KN-LI0741700
CRX-055
CRX-037
CRX-052
CRX-053
CRX-056
KN-KT3S+/SET
HT-SU1803020
KN-BRUSH40-CRAWBT
KN-2113LVWP
